Yakima K1011 User manual

1/1137-13-011-Rev1
K1011 Fitting Kit
MAXIMUM kg (lb) • MAXIMAL kg • MASSIMO kg • MÁXIMO kg • 最大 kg • МАКСИМУМ kg
++ =
kg (lb)
Use with these roof racks:
kg (lb)
kg (lb)
>
kg (lb)
kg (lb)
<
Suzuki Baleno 5dr Hatch 16+ AU, NZ, EU 50 kg (110 lb) 50 kg (110 lb)
F T P HD
REQUIRED • OBLIGATOIRE • REQUERIDOS • ERFORDERLICH • RICHIESTO • 需要 • ОБЯЗАТЕЛЬНО
!
kg (lb)
kg (lb)

2/1137-13-011-Rev1
B
B
A
B
A
B
A
A
P
HD
FT
FLUSH BAR (F) THROUGH BAR (T) HEAVY DUTY BAR (HD) P BAR (P)
T
FPHD
CONTENTS • CONTENU • CONTENIDO • INHALT • CONTENUTO • CONTEÚDO • 内容 • СОДЕРЖАНИЕ
ATTENTION • ATENCIÓN • AUFMERKSAMKEIT • ATTENZIONE • ATENÇÃO • 注意 • ВНИМАНИЕ
Use with these roof racks:
≈ 1 kg (2.20 lb)
EN
FittingInstructions for Basic Carrier
D
Montageanleitungfür Basisträgersystem
ES
Instruccionesde montaje para el sistema
detransporte
F
Instructionsde montage pour Basic Carrier
NO
Monteringsanvisningfor takstativ
PT
Instruçõesde Montagem para sistema de
transporte.
RU
Установочные Инструкции для
Поперечных Балок
x1 x1 x4 x2
RevisionNo: XX 1
XX BAR
EN Fitting Instructions for Basic Carrier
DMontageanleitung für Basisträgersystem
ES Instrucciones de montaje para el sistema
de transporte
FInstructions de montage pour Basic Carrier
NO Monteringsanvisning for takstativ
PT Instruções de Montagem para sistema de
transporte.
RU Установочные Инструкции для
Поперечных Балок
x 1 x 1 x 4 x 2
Revision No: XX 1
XX BAR
= kg (lb)
T
FT
TT
HD T
P
T
FPHD

3/1137-13-011-Rev1
Use with these roof racks:
A
3
4
x4
P
HD
T
F
x4
1
2
11-04-xxx-x
= 11-04-250-AA
= 11-04-251-AB
= 11-04-293-AC
= 11-04-294-AD
PLACEMENT • MONTAGE • COLOCACIÓN • PLATZIERUNG • COLLOCAMENTO • COLOCAÇÃO • 位置 • РАЗМЕЩЕНИЕ
x10
FRONT REAR
REARFRONT
C B
D A
GENERAL USE
ROPPOF BARS
5

4/1137-13-011-Rev1
a
A
A
A
A
a
A
a
A
A
A
A
a
A
x2
6
B
A
A
A
T
FT
TT
HD T
P
AAA
A
7
HD
P
T
F
CB
A
D

5/1137-13-011-Rev1
A mm (X”) B mm (X”)
8
mm / inches
A B
Suzuki Baleno 5dr Hatch 16+ AU, NZ, EU 200 mm (7 7/8”) 400 mm (15 3/4”)
B
Use with these roof racks:
x4
9
REAR
PLACEMENT • MONTAGE • COLOCACIÓN • PLATZIERUNG • COLLOCAMENTO • COLOCAÇÃO • 位置 • РАЗМЕЩЕНИЕ

6/1137-13-011-Rev1
10
12 13
x4
PLACEMENT • MONTAGE • COLOCACIÓN • PLATZIERUNG • COLLOCAMENTO • COLOCAÇÃO • 位置 • РАЗМЕЩЕНИЕ
x4
11
= A861A
= A860B
= A863C
= A862D
A616
!!
D
B
AC

7/1137-13-011-Rev1
a
A
A
A
A
a
A
a
A
A
A
A
a
A
HD
P
T
F
B
A
A
A
T
FT
TT
HD T
P
AAA
A
15
x3
B
14
x4

8/1137-13-011-Rev1
x4
18
17
10
x4
ATTENTION • ATENCIÓN • AUFMERKSAMKEIT • ATTENZIONE • ATENÇÃO • 注意 • ВНИМАНИЕ
x4
CLOSE • FERMER • CERRAR • GESCHLOSSEN • VICINO • FECHAR • 关紧 • ЗАКРЫТЬ
T
FT
T
T
HD T
P
xx
xx
==
==
==
==
18
16

9/1137-13-011-Rev1
Xmm (X”) Xmm (X”) 2
1
19
mm / inches
T
F
T
T
T
HD
T
P
A mm (X”) B mm (X”)
1 2
Suzuki Baleno 5dr Hatch 16+ AU, NZ, EU X = 806 mm (31 3/4”) X = 794 mm (31 2/8”)
20 21
B
A mm (X”) B mm (X”)
9
mm / inches
A B
Make Model, Variant, xdrs Vehicle Type xx-+ AU, NZ, CN, US, EU, ZA xxxx mm (xxx xx/xx”) xxxx mm (xxx xx/xx”)
Make Model, Variant, xdrs Vehicle Type xx-+ AU, NZ, CN, US, EU, ZA xxxx mm (xxx xx/xx”) xxxx mm (xxx xx/xx”)
Make Model, Variant, xdrs Vehicle Type xx-+ AU, NZ, CN, US, EU, ZA xxxx mm (xxx xx/xx”) xxxx mm (xxx xx/xx”)
Use with these roof racks:
x4
11
= AXXXA
= AXXXB
= AXXXC
= AXXXD
A325
10
!

10/1137-13-011-Rev1
2 Nm
(18 in-lb)
A
22
x4
2.5 Nm
(22 in-lb)
B
23
x4
ATTENTION • ATENCIÓN • AUFMERKSAMKEIT • ATTENZIONE • ATENÇÃO • 注意 • ВНИМАНИЕ
X X
X X
P
HD
T
F
x4
24

11/1137-13-011-Rev1
SXX
FLUSH BAR
EN Fitting Instructions for Basic Carrier
DMontageanleitung für Basisträgersystem
ES Instrucciones de montaje para el sistema
de transporte
FInstructions de montage pour Basic Carrier
NO Monteringsanvisning for takstativ
PT Instruções de Montagem para sistema de
transporte.
RUУстановочные Инструкции для
Поперечных Балок
x 1 x 4 x 2 x 1
Revision No: 2C 1
Kxxxx Fitting Kit
REQUIRED • OBLIGATOIRE• REQUERIDOS • ERFORDERLICH • RICHIESTO • 需要 • ОБЯЗАТЕЛЬНЫЙ
Make Model,Variant,xdrs Vehicle Type xx-+ AU,NZ, CN,US, EU,ZA xxkg (xx lb) xxxkg (xxx lb)
Make Model,Variant,xdrs Vehicle Type xx-+ AU,NZ, CN,US, EU,ZA xxkg (xx lb) xxxkg (xxx lb)
Make Model,Variant,xdrs Vehicle Type xx-+ AU,NZ, CN,US, EU,ZA xxkg (xx lb) xxxkg (xxx lb)
F T P HD
MAXIMUM kg (lb) • MÁXIMO kg • MAXIMAL kg • MASSIMO kg • MÁXIMO kg • 最大 kg • МАКСИМАЛЬНАЯ kg
++ =
kg (lb)
Use with these roof racks:
kg(lb)
kg(lb)
kg(lb)
kg (lb)
>
kg(lb)
kg (lb)
<
!
Please read safety and warranty booklet included with this product prior to use. For more
information visit your local dealer.
Veuillez lire attentivement le manuel de sécurité et de garantie avant utilisation. Pour plus
d’informations, visitez votre concessionnaire local.
Por favor, lea folleto de seguridad y garantía que se incluye con este producto antes de su uso .
Para obtener más información, visite a su distribuidor local.
Bitte lesen und beachten Sie die beiliegende Montageanleitung, Sicherheitshinweise und
Garantiebedingungen bevor Sie das Produkt montieren/benutzen. Für weitere Informationen
kontaktieren Sie bitte Ihnen Händler.
Si prega di leggere il libretto di sicurezza e garanzia incluso nel prodotto prima dell’uso. Per
maggiori informazioni visita il rivenditore locale.
Por favor leia o manual de segurança e garantia incluído, antes de utilizar o produto. Para mais
informações visite o seu revendedor local.
使用前，请仔细阅读产品内安全和保修细则。欲了解更多信息，请咨询当地经销商。
Пожалуйста, ознакомьтесь с инструкцией перед тем, как использовать товар. Для
получения более подробной информации обратитесь к местному дилеру.
ATTENTION • ATENCIÓN • AUFMERKSAMKEIT • ATTENZIONE • ATENÇÃO • 注意 • ВНИМАНИЕ
20 km
50 km
R8A9N1D
4X
4X
4X
20 km
50 km
R8A9N1D
4X
4X
XX kg
MAX.
XX kg
MAX.
EN
FR
ES
DE
IT
PT
CN
RU
27
20 km
50 km
R8A9N1D
4X
4X
4X
20 km
50 km
R8A9N1D
4X
4X
XX kg
MAX.
XX kg
MAX.
Use with these roof racks:
+ +
Use with these roof racks:
10
25
x3
25
x4
