Hatch Clearance
TIPS AND TRICKS TO ENSURE PROPER TRUNK DOOR CLEARANCE
ADJUSTMENT CHECK LIST:
CARGO BOXES
✓Loosen the clamps on the inside of the box.
✓Once they’re free shift them all the way forward or backward.
You will be able to adjust the box this way.
✓Open the hatch and adjust the box accordingly so there is
space between the door and the box. Figure 2
✓Make sure the box is strait and the clamps are around the bars.
✓Once they’re all situated tighten the clamps. Done!
OTHER ROOF MOUNTS
✓If your crossbars are adjustable*, move the front bar forward as
far as it can go, then adjust to the correct crossbar spread for
the product. *Do not adjust your crossbars if you have Yakima®
BaseLine towers or Q towers.
ADJUSTABLE ROOF RACK SYSTEMS:
TimberLine Towers, SkyLine Towers*with Tracks, RidgeLine Towers*, OverHaul HD, OutPost HD, BedRock HD, BedRock, Outdoorsman,
and most Factory Roof Racks. *Some vehicles have a ixed crossbar spread, check yakimatech.com for your vehicle’s crossbar capabilities
in the measurements section.
Figure 2
HATCH MEASUREMENT
To ind the best it for your cargo box or ishing rod carrier,
use the measurement in Figure 1 to ind the minimum
distance for your product.
Measure Distance Figure 1
✓Measure from the center of the front crossbar to the
edge of the open trunk door.
✓TIP - make sure you are measuring across the top of the
crossbars, not the side.
Figure 1
PRODUCTS MEASUREMENTS
STANDARD METRIC
CBX 18 52.25” 132.72 cm
CBX Solar (16) 45" 114.30 cm
CBX 16 45" 114.30 cm
GrandTour 18 50.75" 128.91 cm
GrandTour 16 48" 121.92 cm
GrandTour Lo 50.75" 128.91cm
SkyBox NX 16 47" 119.38 cm
SkyBox NX 18 50" 127 cm
SkyBox 16* 52" / 47" 132.08 / 119.38 cm
SkyBox 12, 18, and 21 57" 144.78 cm
SkyBox Lo 57" 144.78 cm
RocketBox 12 40" 101.60 cm
RocketBox 11 and 14 45" 114.30 cm
TopWater 54" 137.16 cm
DoubleHaul 57" 144.78 cm * SkyBox 16 models produced before 5/2020: 52" (132.08cm)
* SkyBox 16 models produced after 5/2020: 47" (119.38cm)

8 ft
7 ft
6 ft
5 ft
4 ft
3 ft
2 ft
Yakima® Fishing Rod Carriers
DoubleHaul
DoubleHaul
Half length
TopWater
6 ft 7 ft 8 ft 9 ft 10 ft 11 ft
PRODUCTS DIMENSIONS AND WEIGHT
STANDARD LBS METRIC KGS
CBX 18 91" X 38" X 16" 58 lbs 231 x 96.5 x 40.6cm 26.3 kg
CBX Solar (16) 83" x 38" x 15" 51 lbs 211 x 96.5 x 38cm 23.1 kg
CBX 16 83" x 38" x 15" 51 lbs 211 x 96.5 x 38cm 23.1 kg
GrandTour 18 90.5" x 37" x 16" 60 lbs 230 x 94 x 40.5cm 27 kg
GrandTour 16 79" x 35" x 17" 56 lbs 201 x 89 x 43cm 21 kg
GrandTour Lo 91" x 37" x 10" 60 lbs 231 x 94 x 26cm 27.2 kg
SkyBox NX 16 75.5” x 35” x 16” 48 lbs 192 x 89 x 40.6cm 21.8 kg
SkyBox NX 18 84” x 36” x 16.5” 53 lbs 213 x 91 x 42cm 24 kg
SkyBox 21 92" x 36" x 18” 62 lbs 234 x 61 x 41cm 19 kg
SkyBox 18 92" x 36" x 16" 52 lbs 234 x 91 x 41cm 24 kg
SkyBox Lo 92" x 36" x 11.5" 52 lbs 234 x 91 x 30cm 24 kg
SkyBox 16 81" x 36" x 15" 47 lbs 206 x 91 x 38cm 22 kg
SkyBox 12 92" x 24" x 16" 41 lbs 234 x 61 x 41cm 19 kg
RocketBox 14 74" x 33" x 16" 38 lbs 188 x 84 x 40cm 18 kg
RocketBox 12 58" x 36" x 16" 30 lbs 147 x 91 x 40cm 14 kg
RocketBox 11 89" x 24" x 16" 38 lbs 226 x 61 x 40cm 18 kg
DoubleHaul 130" x 15" x 9.5" 47 lbs 330 x 38 x 24cm 21 kg
DoubleHaul Half Length 72" x 15" x 9.5" 37 lbs 183 x 38 x 24cm 17 kg
TopWater 102" x 18" x 9" 31 lbs 259 x 45.72 x 23cm 14 kg
Yakima® Cargo Boxes
RocketBox 14 SkyBox 12
SkyBox 16 SkyBox NX 16 CBX Solar, 16
CBX 18
GrandTour 16
GrandTour 18,
GrandTour Lo
SkyBox 18,
21, Lo
SkyBox NX 18
MAX SKI LENGTH
Yakima is a registered trademark of Yakima Products, Inc.
185 CM
175 CM
170 CM
215 CM
185 CM
215 CM 215 CM
185 CM195 CM
210 CM
