Yakima LockNLoad Platform User manual

Instruction #1035998F - Page 1 of 14
Platform
LockNLoad
Pour le français, aller à la page 8. Para español ir a la página 8.
10
6
19
16
17
14
11
7
8
2
53
13
1
12 18
9
15
4
TOOLS REQUIRED
AVAILIABLE ACCESSORIES
4 mm hex or torque wrench
10 mm socket wrench or spanner
13 mm socket wrench or spanner
LockNLoad Jerry Can Holder #8005038
LockNLoad Spare Wheel Holder #8005032
LockNLoad Corner Bracket Kit #8005036
High Lift Jack Holder #8005033
CONTENTS • CONTENU • CONTENIDO
ITEM COMPONENT Platform K
#8005044 Platform B #8005045 Platform J #8005046 Platform E #8005047 Platform N #8005048 Platform H #8005049
1. Platform Side Left & Right x2 x2 x2 x2 x2 x2
2. Platform Corner x4 x4 x4 x4 x4 x4
3. Slat x6 x7 x9 x10 x10 x10
4.M6T-Nut x8x8x8x8 x8 x8
5. M6 Capscrew 25 mm with Washer x10 x10 x10 x10 x10 x10
6. M6 Capscrew 16 mm with Washer x32 x36 x48 x52 x52 x52
7. Platform Support Front and Rear x2 x2 x2 x2 x2 x2
8. Slat Clamp x14 x14 x18 x18 x18 x18
9. Mounting Block x4 x4 x6 x6 x6 x6
10. M8 T, Self Aligning x8 x8 x12 x12 x12 x12
11. M6 Plastite Capscrew 20 mm x8 x8 x8 x8 x8 x8
12. M8 Nyloc Nut x14 x14 x18 x18 x18 x18
13. M8 Washer x14 x14 x18 x18 x18 x18
14. Spare Fasteners Pack x1 x1 x1 x1 x1 x1
15. Platform Corner Brace x4 x4 x4 x4 x4 x4
16. Platform Rear x1 x1 x1 x1 x1 x1
17. Platform Front x1 x1 x1 x1 x1 x1
18. Leg Mounting Bracket x4 x4 x6 x6 x6 x6
19. M8 T-Bolt 25 mm x6 x6 x6 x6 x6 x6
Go to yakimatech.com for your speciic vehicle's load capacity.

Instruction #1035998F - Page 2 of 14
LOCKNLOAD CROSSBAR CLAMPS
(ROOF RACK)
LOCKNLOAD CROSSBAR CLAMPS (HD TRUCK) CUSTOM APPLICATION
PLATFORM FIT GUIDE • GUIDE D’ADAPTATION • GUÍA DE COMPATIBILIDAD DE LA PLATAFORMA
• Minimum crossbar spread of 27.5” (700 mm).
• Mounting blocks must be secured to at least the second slat from the ends.
NOTE: Follow this guideline when installing a platform that includes 3 pairs of
mounting blocks onto a two bar roof rack. The middle pair of mounting blocks
will go unused in this scenario.
• Do not install the platform with the lange of the rail overlapping the mounting
blocks as shown at right.
• Center platform when possible.
• Platform can be slid forward on the mounting blocks for better hatch clearance.
• For a 3+ crossbar system, evenly space the middle crossbars to ensure balanced
weight distribution.
• Ensure Clamps are as widely
spaced as possible, but INBOARD
of towers.
SPECIFIC APPLICATION GUIDELINES
Platform BPlatform K Platform J Platform E Platform N Platform H
GENERAL
TIMBERLINE TOWERS OR
SKYLINE TOWERS (SIDE RAILS OR
ADJUSTABLE TRACK)
• Set front towers as far forward as
possible.
• Refer to TimberLine or Landing Pad
instructions for adjustment.
SKYLINE TOWERS (FIXED POINTS)
• Lay a towel on the roof before
installing the mounting block
assemblies.
• Ensure LockNLoad Crossbar Clamps are spaced as wide on the
crossbars as possible. Outboard of the towers is preferred. • Refer to platform measurements above for custom placement.
WIDTH
X
Y
Platform Width Length XY
K49”
1245 mm 55” 1397 mm 26” - 37.25” 660 mm - 946 mm 27” - 33” 686 mm - 838 mm
B54”
1372 mm 60” 1524 mm 31.5” - 42.5” 800 mm - 1080 mm 27” - 39” 686 mm - 991 mm
J65”
1651 mm 76” 1930 mm 42.5” - 53.5” 1080 mm - 1959 mm 28” - 54.5” 711 mm - 1384 mm
E49”
1245 mm 84” 2134 mm 26” - 37.25” 600 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
N54”
1372 mm 84” 2134 mm 31.5” - 42.5” 800 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
H62”
1575 mm 84” 2134 mm 39” - 50.5” 991 mm - 1283 mm 35” - 62.5” 889 mm - 1588 mm
Min. - Max.Min. - Max.

Instruction #1035998F - Page 3 of 14
21
3
4
4X
Remove the corner braces.
Insert two M6 square nuts into
each corner piece as shown.
INSERT NUTS INTO
PLATFORM CORNERS.
2X
4X
Clear a work area that will be large
enough for the Platform when fully
assembled and place Platform ends
and sides upside down in this work
space (use logos as reference).
TIP: To prevent scratching, place a blanket (or the
Platform’s carton, lattened out) over the work area.
ASSEMBLE PLATFORM ENDS AND SIDES.
Install the Platform end assemblies
created in Step 2 to the Platform sides.
Push irmly until fully inserted.
INSTALL CORNER BRACES.
Install the corner braces to the corner pieces using two M6 x 25 mm capscrews with washers
and two M6 x 20 mm Capscrews as shown. Tighten all screws to 4 Nm with a 4 mm hex or
torque wrench. TIP: Press irmly and angle the M6 x 20 mm screws towards the hole opening.
ASSEMBLE PLATFORM ENDS.
2X
Insert Platform
corners into Platform
ends. Push irmly
until fully inserted.
NOTE: Having the Platform ends
upside down prevents the corner’s
square nuts from falling out.
ASSEMBLY • ASSEMBLAGE • ENSAMBLAJE

Instruction #1035998F - Page 4 of 14
A. Slide each slat into position
underneath the perimeter’s inside lip.
B. Swing the other end into place and
align the holes.
5
6 7
POSITION THE SLATS.
SECURE THE SLATS. POSITION PLATFORM SUPPORTS.
Be sure the slats are
turned upside down to
match the ends and sides.
Starting from the middle slat
and working outwards, secure
each slat end using two
M6x16mm capscrews with
washers as shown. Tighten all
screws to 4Nm with a4mm
hex wrench or torque wrench.
4 Nm
A
B
Carefully lip the Platform over and position the platform supports
underneath the center of the front and rear platform ends. Note that the
notched end of the support sits under the lip. The platform supports ideally
should be ixed using the center of the three holes. However, they can be
offset left or right depending on the vehicle’s roof or usage requirements.
2X

Instruction #1035998F - Page 5 of 14
8SECURE THE PLATFORM SUPPORTS.
2X
MOUNTING • MISE EN PLACE • MONTAJE
B
A
C
7 Nm 7 Nm
A. Thread three M8x25T-bolts up
through the Platform support and
through three slat clamps. Install
three M8 washers and lock nuts
on the M8 tee bolts and install a
M6x25mm capscrew with washer
as shown. Do not fully tighten.
B. Slide each slat clamps so that
it engages in the side channels
of the slats as shown.
C. Being sure the M8 T-bolt is captured
in the slot beneath the platform
support use a 13mm wrench to fully
tighten the nuts to 7 Nm. Then use a
hex or torque wrench to tighten the
capscrew to 7 Nm.
D. Repeat for the platform support at the other end of the platform.
A. NEXT Install the mounting blocks to your vehicle. Follow the instructions from either SL Adapters
or Crossbar Clamps, and reference the Platform Fit Guide on page 2.
B. THEN place the platform on the roof after the mounting block assemblies are installed to your
vehicle according to the guidelines. Follow platform installation on page 6.
A
A
B

Instruction #1035998F - Page 6 of 14
1PLACE PLATFORM ONTO MOUNTING BLOCKS.
NOTE: For vehicles with a rear
hatch be sure to position the
Platform so that there is adequate
hatch clearance when fully opened.
With the help of a friend, carefully lift the
assembled Platform onto the mounting
blocks on your vehicle. Position the platform
evenly so there is an equal overhang on the
sides and ideally on the front and rear as well.
NOTE: Wind
Delector is to be
at the front of
the vehicle.
A. Insert one M8 T-bolt into
each channel of the mounting
blocks on either side of the
slats. Twist the T-bolts so
that they are captured by the
channels.
B. Lower the slat clamp onto
the T-bolt and install an M8
washer and lock nut. Do not
fully tighten. Then slide the
slat clamp so that it engages
in the side channel of the slat.
C. Use a 13mm wrench to fully
tighten the hardware to 7Nm.
2INSTALL
MOUNTING
CLAMPS.
A
B
C
It may be necessary to move
the mounting blocks. If you
you need to move them
refer to your mounting kit
instructions (e.g., LockNLoad
SL Adapters or LockNLoad
Crossbar Clamps).
IMPORTANT:
The slat
clamps must
be installed
on two
separate
slats for each
mounting
block.
7 Nm 7 Nm

Instruction #1035998F - Page 7 of 14
4
3
TEST THE INSTALLATION.
Test the installation by pushing and pulling
in all directions. The Platform should not
slide or move on crossbars or mounting
blocks. Retighten the mounting clamps or
mounting kit hardware if necessary.
NOTE: The Wind Delector can be removed
to suit certain anchors/accessories to be
used with the front extrusion. This is done
by simply peeling the part from the slot,
starting at one end and working across
the length of the delector.
Installation is the reverse and should be
conirmed by hearing an audible ‘CLICK’
when the delector is fully installed.
OPTIONAL: WIND
DEFLECTOR
REMOVAL
TIMBERLINE
TOWERS:
LOCK YOUR TOWERS.
FINAL TIGHTENING • SERRAGE FINAL • AJUSTE FINAL
Now, fully tighten each Crossbar Clamp or TimberLine tower
(SkyLine towers are ixed so no tightening is required).
If you have
purchased and
installed lock
cores for your
towers use your
SKS Key to lock
the towers.
Install the
covers onto your
TimberLine towers.
CROSSBAR CLAMPS
PINCES CROSSBAR CLAMP PIEDS TIMBERLINE
ABRAZADERAS PARA BARRA TRANSVERSAL TORRES TIMBERLINE
TIMBERLINE TOWERS
3.5 Nm
2.5 Nm

Instruction #1035998F - Page 8 of 14
FRANÇAIS
ESPAÑOL
N° Pièce Plateforme K
n° 8005044 Plateforme B n° 8005045 Plateforme J n° 8005046 Plateforme E n° 8005047 Plateforme N n° 8005048 Plateforme H n° 8005049
1. Proilé de côté de plateforme (gauche et droit) x2 x2 x2 x2 x2 x2
2. Coin de plateforme x4 x4 x4 x4 x4 x4
3. Latte x6 x7 x9 x10 x10 x10
4. Plaquette iletée M6 x8 x8 x8 x8 x8 x8
5. Vis à tête bombée M6 x 25 mm avec rondelle x10 x10 x10 x10 x10 x10
6. Vis à tête bombée M6 x 16 mm avec rondelle x32 x36 x48 x52 x52 x52
7. Renforts de plateforme (avant et arrière) x2 x2 x2 x2 x2 x2
8. Griffe de latte x14 x14 x18 x18 x18 x18
9. Balancier x4 x4 x6 x6 x6 x6
10. Boulon en T M8 x8 x8 x12 x12 x12 x12
11. Vis Plastite à tête bombée M6 x 20 mm x8 x8 x8 x8 x8 x8
12. Écrou autofreiné M8 x14 x14 x18 x18 x18 x18
13. Rondelle M8 x14 x14 x18 x18 x18 x18
14. Quincaillerie de rechange x1 x1 x1 x1 x1 x1
15. Renfort de coin x4 x4 x4 x4 x4 x4
16. Proilé de plateforme arrière x1 x1 x1 x1 x1 x1
17. Proilé de plateforme avant x1 x1 x1 x1 x1 x1
18. Support de montage des pieds x4 x4 x6 x6 x6 x6
19. Vis en T M8 x 25 mm x6 x6 x6 x6 x6 x6
ARTÍCULO COMPONENTE Plataforma K
#8005044 Plataforma B #8005045 Plataforma J #8005046 Plataforma E #8005047 Plataforma N #8005048 Plataforma H #8005049
1. Proilé de côté de plateforme (gauche et droit) x2 x2 x2 x2 x2 x2
2. Coin de plateforme x4 x4 x4 x4 x4 x4
3. Latte x6 x7 x9 x10 x10 x10
4. Plaquette iletée M6 x8 x8 x8 x8 x8 x8
5. Vis à tête bombée M6 x 25 mm avec rondelle x10 x10 x10 x10 x10 x10
6. Vis à tête bombée M6 x 16 mm avec rondelle x32 x36 x48 x52 x52 x52
7. Renforts de plateforme (avant et arrière) x2 x2 x2 x2 x2 x2
8. Griffe de latte x14 x14 x18 x18 x18 x18
9. Balancier x4 x4 x6 x6 x6 x6
10. Boulon en T M8 x8 x8 x12 x12 x12 x12
11. Vis Plastite à tête bombée M6 x 20 mm x8 x8 x8 x8 x8 x8
12. Écrou autofreiné M8 x14 x14 x18 x18 x18 x18
13. Rondelle M8 x14 x14 x18 x18 x18 x18
14. Quincaillerie de rechange x1 x1 x1 x1 x1 x1
15. Renfort de coin x4 x4 x4 x4 x4 x4
16. Proilé de plateforme arrière x1 x1 x1 x1 x1 x1
17. Proilé de plateforme avant x1 x1 x1 x1 x1 x1
18. Support de montage des pieds x4 x4 x6 x6 x6 x6
19. Vis en T M8 x 25 mm x6 x6 x6 x6 x6 x6
• CONTENU •
• CONTENIDO •
OUTILS NÉCESSAIRES AVAILIABLE ACCESSORIES
clé hexagonale ou dynamométrique de 4 mm
clé plate ou douille de 10 mm
clé plate ou douille de 13 mm
LockNLoad Jerry Can Holder #8005038
LockNLoad Spare Wheel Holder #8005032
LockNLoad Corner Bracket Kit #8005036
High Lift Jack Holder #8005033
Consulter le site yakimatech.com pour connaître la capacité de chargement du véhicule en question.
HERRAMIENTAS NECESARIAS ACCESORIOS DISPONIBLES
llave hexagonal o de torsión de 4 mm
tubo o llave de boca y anillo de 10 mm
tubo o llave de boca y anillo de 13 mm
LockNLoad Jerry Can Holder #8005038
LockNLoad Spare Wheel Holder #8005032
LockNLoad Corner Bracket Kit #8005036
High Lift Jack Holder #8005033
Visite yakimatech.com para informarse sobre la capacidad de carga de un vehículo especíico.

Instruction #1035998F - Page 9 of 14
MÂCHOIRES DE BARRES TRANSVERSALES
LOCKNLOAD (PORTE-BAGAGE DE TOIT)
MÂCHOIRES DE BARRES TRANSVERSALES LOCKNLOAD (CAMIONNETTE HD) APPLICATIONS SPÉCIALES
• GUIDE D’ADAPTATION •
• La distance minimale entre les barres transversales est de 700 mm
(27,5 po).
• Les balanciers doivent être ixés au moins à la deuxième latte depuis
les bouts. REMARQUE : respecter cette règle pour l’installation d’une
plateforme munie de trois paires de balanciers sur un porte-bagage à
deux barres transversales. Dans ce cas, la paire centrale de balanciers
ne servira pas.
• Ne pas installer la plateforme de manière que les balanciers ne
supportent que le rebord d’un proilé de bout, tel qu’illustré à droite.
• Centrer la plateforme dans la mesure du possible.
• On peut faire glisser la plateforme vers l’avant sur les balanciers pour
faciliter l’ouverture du hayon.
• Si le montage se fait sur trois barres transversales ou plus, espacer les
barres centrales également pour bien répartir le poids de la charge.
• Faire en sorte que les mâchoires soient
le plus espacées possible, mais À
L’INTÉRIEUR des pieds.
CONSIGNES SPÉCIFIQUES
Plateforme H
Plateforme B Plateforme EPlateforme JPlateforme K Plateforme N
GÉNÉRALITÉS
PIEDS TIMBERLINE OU SKYLINE
(LONGERONS LATÉRAUX OU
GLISSIÈRE RÉGLABLE)
• Poser les pieds avant le plus en avant possible.
• Consulter les instructions accompagnant les
pieds TimberLine ou les patins Landing Pad
pour les réglages.
PIEDS SKYLINE (POSITION FIXE)
• Étendre une serviette sur le toit avant
d’installer les ensembles balanciers.
• Faire en sorte que les mâchoires de barres transversales LockNLoad soient le
plus espacées possible sur les barres, de préférence à l’extérieur des pieds. • Consulter les dimensions des plateformes ci- dessus pour les applications spéciales.
LARGEUR
X
Y
FRANÇAIS
Plateforme Largeur Longueur XY
K49”
1245 mm 55” 1397 mm 26” - 37.25” 660 mm - 946 mm 27” - 33” 686 mm - 838 mm
B54”
1372 mm 60” 1524 mm 31.5” - 42.5” 800 mm - 1080 mm 27” - 39” 686 mm - 991 mm
J65”
1651 mm 76” 1930 mm 42.5” - 53.5” 1080 mm - 1959 mm 28” - 54.5” 711 mm - 1384 mm
E49”
1245 mm 84” 2134 mm 26” - 37.25” 600 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
N54”
1372 mm 84” 2134 mm 31.5” - 42.5” 800 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
H62”
1575 mm 84” 2134 mm 39” - 50.5” 991 mm - 1283 mm 35” - 62.5” 889 mm - 1588 mm
Min. - Max.Min. - Max.

Instruction #1035998F - Page 10 of 14
ABRAZADERAS PARA BARRAS
LOCKNLOAD (RACK DE TECHO)
ABRAZADERAS PARA BARRAS LOCKNLOAD (HD PARA CAMIONETAS) OTROS USOS
• GUÍA DE COMPATIBILIDAD DE LA PLATAFORMA •
• Separación mínima entre barras transversales: 27.5” (700 mm).
• Los bloques de montaje se deben asegurar al segundo travesaño al
menos, a partir de los extremos. NOTA: Respete esta recomendación
cuando instale una plataforma que incluya 3 pares de bloques de
montaje en un portaequipaje para techo de dos barras. En ese caso,
el par de bloques de montaje centrales no se debe utilizar.
• No instale la plataforma con el reborde del riel encima de los bloques
de montaje, como se ilustra a la derecha.
• Centre la plataforma cuando sea posible.
• La plataforma se puede deslizar hacia adelante sobre los bloques de
montaje con el in de ganar más espacio para la portezuela trasera.
• Para un sistema de 3 o más barras transversales, separe las del
centro de manera que la distribución del peso resulte uniforme.
• Asegúrese de que las abrazaderas se
encuentren lo más espaciadas posible, pero
DENTRO del espacio entre las torres.
RECOMENDACIONES PARA USOS ESPECÍFICOS
Plataforma H
Plataforma B Plataforma EPlataforma JPlataforma K Plataforma N
RECOMENDACIONES PARA USOS GENERAL
TORRES TIMBERLINE O SKYLINE
(RIELES LATERALES O GUÍAS
AJUSTABLES)
• Ajuste las torres delanteras para que
queden lo más alejadas posible.
• Consulte las instrucciones de las torres
TimberLine o patines Landing Pad para
realizar el ajuste.
TORRES SKYLINE (POSICIÓN FIJA)
• Coloque una toalla sobre el
techo antes de instalar los
bloques de montaje armados.
• Asegúrese de que las abrazaderas para las barras transversales LockNLoad queden lo más
separadas posible sobre dichas barras. Es preferible que queden al exterior de las torres. • Consulte las medidas de más arriba para el caso de otros usos.
ANCHO
X
Y
ESPAÑOL
Plataforma Ancho Largo XY
K49”
1245 mm 55” 1397 mm 26” - 37.25” 660 mm - 946 mm 27” - 33” 686 mm - 838 mm
B54”
1372 mm 60” 1524 mm 31.5” - 42.5” 800 mm - 1080 mm 27” - 39” 686 mm - 991 mm
J65”
1651 mm 76” 1930 mm 42.5” - 53.5” 1080 mm - 1959 mm 28” - 54.5” 711 mm - 1384 mm
E49”
1245 mm 84” 2134 mm 26” - 37.25” 600 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
N54”
1372 mm 84” 2134 mm 31.5” - 42.5” 800 mm - 946 mm 35” - 62.5” 889 mm - 1588 mm
H62”
1575 mm 84” 2134 mm 39” - 50.5” 991 mm - 1283 mm 35” - 62.5” 889 mm - 1588 mm
Min. - Max.Min. - Max.
