YASKAWA YRC1000micro User manual

MANUAL NO.
HW1485152
2
YRC1000micro OPTIONS
PROFINET COMMUNICATION FUNCTION
INSTRUCTIONS
FOR SST-PN-2-PE MADE BY Molex, Inc.
Upon receipt of the product and prior to initial operation, read these instructions thoroughly, and
retain for future reference.
MOTOMAN INSTRUCTIONS
MOTOMAN- INSTRUCTIONS
YRC1000micro INSTRUCTIONS
YRC1000micro OPERATOR’S MANUAL
YRC1000micro MAINTENANCE MANUAL
YRC1000micro ALARM CODES (MAJOR ALARMS) (MINOR ALARMS)
1/47
186580-1CD
2

ii
HW1485152
HW1485152
DANGER
• This manual explains the SST-PN-2-PE board (manufactured by
Molex, Inc.) of the YRC1000micro system. Read this manual
carefully and be sure to understand its contents before handling the
YRC1000micro. Any matter not described in this manual must be
regarded as “prohibited” or “improper”.
• General information related to safety are described in “Chapter 1.
Safety” of the YRC1000micro INSTRUCTIONS. To ensure correct
and safe operation, carefully read “Chapter 1. Safety” of the
YRC1000micro INSTRUCTIONS.
CAUTION
• In some drawings in this manual, protective covers or shields are
removed to show details. Make sure that all the covers or shields
are installed in place before operating this product.
• YASKAWA is not responsible for incidents arising from unauthorized
modification of its products. Unauthorized modification voids the
product warranty.
NOTICE
• The drawings and photos in this manual are representative
examples and differences may exist between them and the
delivered product.
• YASKAWA may modify this model without notice when necessary
due to product improvements, modifications, or changes in
specifications. If such modification is made, the manual number will
also be revised.
• If your copy of the manual is damaged or lost, contact a YASKAWA
representative to order a new copy. The representatives are listed
on the back cover. Be sure to tell the representative the manual
number listed on the front cover.
2/47

iii
HW1485152
HW1485152
Notes for Safe Operation
Read this manual carefully before installation, operation, maintenance, or
inspection of the YRC1000micro.
In this manual, the Notes for Safe Operation are classified as “DANGER”,
“WARNING”, “CAUTION”, or “NOTICE”.
Even items described as “CAUTION” may result in a serious accident in
some situations.
At any rate, be sure to follow these important items.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in death or serious injury.
Safety Signs identified by the signal
word DANGER should be used
sparingly and only for those
situations presenting the most
serious hazards.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, will
result in death or serious injury.
Hazards identified by the signal
word WARNING present a lesser
degree of risk of injury or death than
those identified by the signal word
DANGER.
CAUTION
Indicates a hazardous situation,
which if not avoided, could result in
minor or moderate injury. It may
also be used without the safety alert
symbol as an alternative to
“NOTICE”.
NOTICE
NOTICE is the preferred signal word
to address practices not related to
personal injury. The safety alert
symbol should not be used with this
signal word. As an alternative to
“NOTICE”, the word “CAUTION”
without the safety alert symbol may
be used to indicate a message not
related to personal injury.
NOTE
To ensure safe and efficient operation at all times, be sure
to follow all instructions, even if not designated as “DAN-
GER”, “WARNING” and “CAUTION”.
3/47

iv
HW1485152
HW1485152
NOTICE
• Do not use or keep the board in the following environmental
conditions.
– Where exposed to direct sunshine
– Where vibration or impact occurs
– Where high humidity exists
– Where a strong magnetic field exists
– Where much dust exists
– Where a sudden change in the temperature occurs
– Where corrosive gases occur
– Where condensation occurs
• Improper usage of the board may damage the board.
4/47

v
HW1485152
HW1485152
DANGER
• Before operating the manipulator, make sure the servo power is
turned OFF by performing the following operations. When the servo
power is turned OFF, the SERVO ON LED on the programming
pendant is turned OFF.
– Press the emergency stop button on the programming pendant or
on the external control device, etc.
– Disconnect the safety plug of the safety fence.
(when in the play mode or in the remote mode)
If operation of the manipulator cannot be stopped in an emergency,
personal injury and/or equipment damage may result.
Fig. : Emergency Stop Button
• Before releasing the emergency stop, make sure to remove the
obstacle or error caused the emergency stop, if any, and then turn
the servo power ON.
Failure to observe this instruction may cause unintended movement of
the manipulator, which may result in personal injury.
Fig. : Release of Emergency Stop
TURN
• Observe the following precautions when performing a teaching
operation within the manipulator's operating range:
– Be sure to perform lockout by putting a lockout device on the
safety fence when going into the area enclosed by the safety
fence. In addition, the operator of the teaching operation must
display the sign that the operation is being performed so that no
other person closes the safety fence.
– View the manipulator from the front whenever possible.
– Always follow the predetermined operating procedure.
– Always keep in mind emergency response measures against the
manipulator’s unexpected movement toward a person.
– Ensure a safe place to retreat in case of emergency.
Failure to observe this instruction may cause improper or unintended
movement of the manipulator, which may result in personal injury.
• Confirm that no person is present in the manipulator's operating
range and that the operator is in a safe location before:
– Turning ON the YRC1000micro power
– Moving the manipulator by using the programming pendant
– Running the system in the check mode
– Performing automatic operations
Personal injury may result if a person enters the manipulator's
operating range during operation. Immediately press an emergency
stop button whenever there is a problem. The emergency stop button
is located on the right of the programming pendant.
• Read and understand the Explanation of the Warning Labels before
operating the manipulator.
5/47

vi
HW1485152
HW1485152
DANGER
• In the case of not using the programming pendant, be sure to
supply the emergency stop button on the equipment. Then before
operating the manipulator, check to be sure that the servo power is
turned OFF by pressing the emergency stop button.
Connect the external emergency stop button to the 2-12 pin and 3-
13 pin of the Safety connector (Safety).
• Upon shipment of the YRC1000micro, this signal is connected by a
jumper cable in the dummy connector. To use the signal, make sure
to supply a new connector, and then input it.
If the signal is input with the jumper cable connected, it does not
function, which may result in personal injury or equipment damage.
WARNING
• Do not touch the inside of the controller cabinet for at least 5
minutes after turning the power off.
Failure to observe this warning may result in electric shock or personal
injury because of the residual voltage of the condenser.
• During power ON, do not touch the board.
Failure to observe this warning may result in fire or electric shock.
• Perform the following inspection procedures prior to conducting
manipulator teaching. If there is any problem, immediately take
necessary steps to solve it, such as maintenance and repair.
– Check for a problem in manipulator movement.
– Check for damage to insulation and sheathing of external wires.
• Return the programming pendant to a safe place after use.
If the programming pendant is left unattended on the manipulator, on a
fixture, or on the floor, etc., the Enable Switch may be activated due to
surface irregularities of where it is left, and the servo power may be
turned ON. In addition, in case the operation of the manipulator starts,
the manipulator or the tool may hit the programming pendant left
unattended, which may result in personal injury and/or equipment
damage.
• Wiring and installation must be performed by authorized or certified
personnel.
Failure to observe this caution may result in fire or electric shock.
6/47

vii
HW1485152
HW1485152
CAUTION
• Check to be sure that there is no foreign matter (metal piece, etc.)
on the board.
Failure to observe this caution may result in personal injury or
equipment damage because of malfunction.
• Check to be sure that there is no problem (damage, bend, etc.) with
the components of the board.
Failure to observe this caution may result in personal injury or
equipment damage because of malfunction.
• Connect the cables and connectors properly.
Failure to observe this caution may result in fire or equipment failure.
• Make sure to properly perform the setting of the switches, etc.
Failure to observe this caution may result in personal injury or
equipment damage because of malfunction.
• Do not touch the solder surface of the board directly with a finger.
Failure to observe this caution may result in personal injury because of
solder projection, etc.
NOTICE
• Do not touch the component-mounting surface of the board directly
with a finger.
Failure to observe this caution may result in the failure of IC, etc.
because of static electricity.
• Avoid shock on the board.
Failure to observe this caution may result in the failure of the board.
7/47

viii
HW1485152
HW1485152
Definition of Terms Used Often in This Manual
The MOTOMAN is the YASKAWA industrial robot product.
The MOTOMAN usually consists of the manipulator, the YRC1000micro
controller, manipulator cables, the YRC1000micro programming pendant
(optional), and the YRC1000micro programming pendant safety signal
short circuit connector (optional).
In this manual, the equipment is designated as follows:
Equipment Manual Designation
YRC1000micro controller YRC1000micro
YRC1000micro programming pendant Programming pendant (optional)
Cable between the manipulator
and the controller
Manipulator cable
YRC1000micro programming pendant
safety signal short circuit connector
Programming pendant
safety signal short circuit connector
(optional)
8/47

ix
HW1485152
HW1485152
Descriptions of the programming pendant keys, buttons, and displays are
shown as follows:
Equipment Manual Designation
Programming
Pendant
Character Keys
/Symbol Keys
The keys which have characters or symbols
printed on them are denoted with [ ].
e.g. [ENTER]
Axis Keys
/Numeric Keys
[Axis Key] and [Numeric Key] are generic
names for the keys for axis operation and
number input.
Keys pressed
simultaneously
When two keys are to be pressed
simultaneously, the keys are shown with a “+”
sign between them, e.g. [SHIFT]+[COORD].
Mode Switch Mode Switch can select three kinds of modes
that are denoted as follows: REMOTE, PLAY or
TEACH.
(The switch names are denoted as symbols)
Button The three buttons on the upper side of the
programming pendant are denoted as follows:
START, HOLD, or EMERGENCY STOP.
(The button names are denoted as symbols)
Displays The menu displayed in the programming
pendant is denoted with { }.
e.g. {JOB}
E
M
E
R
G
E
N
C
Y
S
T
O
P
Numeric keys
Axis keys
Enter key
Mode switch*
Start button* Hold button*
Emergency stop button
Shift key
Page key
Coordinate key
PLAY
REMOTE
TEACH
START
*The button/switch names
are denoted as symbols.
HOLD
9/47

x
HW1485152
HW1485152
Description of the Operation Procedure
In the explanation of the operation procedure, the expression “Select • • •”
means that the cursor is moved to the object item and [SELECT] is
pressed, or that the item is directly selected by touching the screen.
Registered Trademark
In this manual, names of companies, corporations, or products are
trademarks, registered trademarks, or brand names for each company or
corporation. The indications of (R) and
TM
are omitted.
10/47
