YOKOGAWA UP350 User manual

Instruction
Manual
IM 05E01D02-41E
Model UP350
Program Controller
User’s Manual
IM 05E01D02-41E
1st Edition

Blank Page

<Toc> <Rev> i
IM 05E01D02-41E
Introduction
Thank you for purchasing the UP350 program controller.
■How to Use the Manuals
Purpose Title Description
Setup Describes the tasks (installation, wiring, and others) required
to make the controller ready for operations.
Basic operation
Describes examples of setting PV input types, and control output
types. Making settings described herein and program creation in
“3. Programming” allow you to carry out basic control.
Operating
procedures
and troubleshooting
Describes key operation sequences.
For operation control through external contact inputs, see
“1.5 Terminal Wiring Diagrams.”
Brief operation
and setpoint recording
Contains the parameter map used as a guideline for setting
parameters and lists of parameters for recording User Settings.
Program creation Describes examples of creating basic programs. See “3.8
Program Pattern Setup Charts,” and program functions.
1. Installation
2. Initial Settings
3. Programming
4. Operations
5.1 Troubleshooting
6. Parameters
■Regarding This User’s Manual
(1) This manual should be provided to the end user. Keep an extra copy or copies of the
manual in a safe place.
(2) Read this manual carefully to gain a thorough understanding of how to operate this
product before starting operation.
(3) This manual describes the functions of this product. Yokogawa M&C Corporation
(hereinafter simply referred to as Yokogawa) does not guarantee the application of
these functions for any particular purpose.
(4) Under absolutely no circumstances may the contents of this manual, in part or in
whole, be transcribed or copied without permission.
(5) The contents of this manual are subject to change without prior notice.
(6) Every effort has been made to ensure that the details of this manual are accurate.
However, should any errors be found or important information be omitted, please
contact your nearest Yokogawa representative or our sales office.
1st Edition : May 31,2000-00Media No. IM 05E01D02-41E (CD) 1st Edition : May 2000 (YK)
All Rights Reserved Copyright © 2000, Yokogawa M&C Corporation

ii
<Toc> <Rev>
IM 05E01D02-41E 1st Edition : May 31,2000-00
■Safety Precautions
The following symbol is indicated on the controller to ensure safe use.
CAUTION
This symbol on the controller indicates that the operator must refer to an explanation in the
user’s manual in order to avoid the risk of injury or death of personnel or damage to the
instrument. The manual describes how the operator should exercise special care to avoid
electric shock or other dangers that may result in injury or loss of life.
The following symbols are used in the hardcopy user’s manuals and in the user’s manual
supplied on the CD-ROM.
NOTE
Indicates that operating the hardware or software in a particular manner may damage it or
result in a system failure.
IMPORTANT
Draws attention to information that is essential for understanding the operation and/or
features of the controller.
■Regarding Force Majeure
Yokogawa M&C Corporation assumes no liability for any loss or damage, direct or indirect,
caused by the use of or unpredictable defects of the product.

Toc-1
<Int> <Rev>
IM 05E01D02-41E
CONTENTS
1. Installation .............................................................................................. 1-1
1.1 Model and Suffix Codes.................................................................................. 1-1
1.2 How to Install................................................................................................... 1-2
1.3 How to Connect Wires .................................................................................... 1-5
1.4 Hardware Specifications ................................................................................ 1-7
1.5 Terminal Wiring Diagrams .............................................................................1-11
2. Initial Settings ......................................................................................... 2-1
2.1 Names and Functions of Front Panel Parts ................................................... 2-2
2.2 Setting PV Input Type (Setting First at Power-on) ......................................... 2-3
2.3 Changing PV Input Type ................................................................................. 2-7
2.4 Setting Control Output Type........................................................................... 2-9
3. Programming .......................................................................................... 3-1
3.1 Overview of Program Patterns ....................................................................... 3-1
3.2 Example of Program Pattern Setup Charts ................................................... 3-2
3.3 Creating Program Patterns............................................................................. 3-3
3.4 Changing Program Patterns........................................................................... 3-8
3.5 Program Parameter Map ............................................................................... 3-10
3.6 Lists of Program Parameters ........................................................................3-11
3.7 Explanation of Program Functions .............................................................. 3-16
3.8 Program Pattern Setup Charts ..................................................................... 3-22
4. Operations .............................................................................................. 4-1
4.1 Monitoring-purpose Operating Displays Available during Operation ......... 4-1
4.2 Performing/Canceling Auto-tuning ................................................................ 4-2
4.3 Setting PID Manually....................................................................................... 4-3
4.4 Starting (PRG)/Stopping (RESET) the Controller .......................................... 4-5
4.5 Enabling/Disabling Hold Mode of Program Operation ................................. 4-7
4.6 Changing Program Setpoints when in Hold Mode ........................................ 4-8
4.7 Executing “Advance” Function ..................................................................... 4-9
1st Edition : May 31,2000-00
Model UP350
Program Controller
User’s Manual
IM 05E01D02-41E 1st Edition

<Int> <Rev>
IM 05E01D02-41E
Toc-2
1st Edition : May 31,2000-00
5. Troubleshooting and Maintenance ........................................................ 5-1
5.1 Troubleshooting .............................................................................................. 5-1
5.2 Maintenance .................................................................................................... 5-4
5.2.1 Cleaning ........................................................................................... 5-4
5.2.2 Replacing Brackets ........................................................................... 5-4
5.2.3 Attaching Terminal Cover .................................................................. 5-4
5.2.4 Replacing Parts with a Limited Service Life ....................................... 5-6
5.2.5 Replacing Control Output Relays ...................................................... 5-7
6. Parameters .............................................................................................. 6-1
6.1 Parameter Map ................................................................................................ 6-1
6.2 Lists of Parameters ......................................................................................... 6-4
7. Function Block Diagram and Descriptions............................................ 7-1

<Toc> <1. Installation> 1-1
IM 05E01D02-41E
1. Installation
This chapter describes installation, wiring, and other tasks required to make the
controller ready for operation.
1.1 Model and Suffix Codes
Before using the controller, check that the model and suffix codes match your order.
Model Suffix Code Description
UP350 Program controller (provided with retransmission output and
15 V DC loop power supply as standard)
Type -0 Standard type
0 None
1 With communication
Optional functions
Check that the following items are provided:
• Program controller (of ordered model).................................. 1
• Brackets (mounting hardware) ............................................. 1 pair
• Unit label.............................................................................. 1
• User’s Manuals .................................................................... 4 (A2 size)
• User’s Manual (Reference) (CD-ROM version) .................... 1
1st Edition : May 31,2000-00

1-2
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
1.2 How to Install
NOTE
To install the controller, select a location where:
1. no one may accidentally touch the terminals,
150mm150mm
150mm
150mm
2. mechanical vibrations are minimal,
3. corrosive gas is minimal,
4. temperature can be maintained at about 23C and
the fluctuation is minimal,
5. no direct radiant heat is present,
6. no magnetic disturbances are caused,
7. no wind blows against the terminal board (reference junction compensation element),
8. no water is splashed,
9. no flammable materials are around,
Never place the controller directly on flammable items or equipment.
If the controller has to be installed close to flammable items or equipment, be sure to
provide shielding panels all around the controller, at least 150 mm away from every side;
the panels should be made of either 1.43 mm-thick metal-plated steel plates or 1.6 mm-
thick uncoated steel plates.
NOTE
Never touch the opening at the bottom of the case. It is to be used in the factory at ship-
ping.
●Installation Position
Install the controller at an angle within 30from horizontal with the front panel facing up-
ward. Do not install it facing downward. The position of right and left sides should be hori-
zontal.
Front panel
of controller Must not
exceed 30
30Rear of
controller

<Toc> <1. Installation> 1-3
IM 05E01D02-41E 1st Edition : May 31,2000-00
■External Dimensions and Panel Cutout Dimensions
(25)
(53)
[(N-1)96+92]117 min.
145 min.
+0.8
0
+0.8
0
92
+0.8
0
92
+0.8
0
92
"N" stands for the number of controllers to be
installed.
However, the measured value applies if N  5.
100
11
UP350
General installation Side-by-side close installation
1 to 10 mm (Panel thickness)
Small bracket
Large bracket
91.8
112
Unit: mm
96
96

1-4
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
■How to Install
CAUTION
Turn off the power to the controller before installing it on the panel because there is a
possibility of electric shock.
After opening the mounting hole on the panel, follow the procedures below to install the
controller:
1. Insert the controller into the opening from the front of the panel so that the terminal
board on the rear is at the far side.
2. Set the brackets in place on the top and bottom of the controller as shown in the figure
below, then tighten the screws of the brackets. Take care not to overtighten them.
Large bracket
(top mounting hardware)
Terminal board
Small bracket
(bottom mounting hardware)
Panel
Insert a screwdriver into the
brackets to tighten the screws.
Direction to insert the
controller
Insert the controller
into the opening at
the front of the panel.

<Toc> <1. Installation> 1-5
IM 05E01D02-41E 1st Edition : May 31,2000-00
1.3 How to Connect Wires
CAUTION
1) Before carrying out wiring, turn off the power to the controller and check that the
cables to be connected are not alive with a tester or the like because there is a possi-
bility of electric shock.
2) Wiring must be carried out by personnel who have basic electrical knowledge and
practical experience.
NOTE
1) Provide power from a single-phase instrument power supply. If there is a lot of noise in
the power line, insert an insulating transformer into the primary side of the line and use
a line filter (recommended part: ZAC2205-00U from TDK) on the secondary side.
As a countermeasures against noise, do not place the primary and secondary power
cables close to each other.
2) For thermocouple input, use shielded compensating lead wires for wiring. For RTD
input, use shielded wires that have low conductor resistance and cause no significant
differences in resistance between the three wires.
The cables to be used for wiring, terminal specifications, and recommended parts are
as shown below.
3) Control output relays may be replaced. However, because they have a life of 100,000
times that of the resistance load, use auxiliary relays to turn on/off a load.
4) The use of inductance (L) loads such as auxiliary relays, motors and solenoid valves
causes malfunction or relay failure; always insert a CR filter for use with alternating
current or a diode for use with direct current, as a spark-removal surge suppression
circuit, into the line in parallel with the load.
■For DC Relay Wiring ■For AC Relay Wiring
R
UP350
Diode
(Mount it directly
to the relay coil
terminal (socket).)
External DC power supply
Relay
UP’s contact Relay
(Use one with a relay coil
rating less than the UP’s
contact rating.)
R
UP350
CR filter
(Mount it directly
to the relay coil
terminal (socket).)
External AC power supply
Relay
(Use one with a relay coil
rating less than the UP’s
contact rating.)
UP’s contact

1-6
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
●Cable Specifications and Recommended Cables
Purpose Name and Manufacturer
Power supply, grounding, relay contact outputs
600 V PVC insulated wires, JIS C 3307, 0.9 to 2.0 mm
2
Thermocouple Shielded compensating lead wires, JIS C 1610, X- - -
(See Yokogawa Electric's GS 6B1U1-E.)
RTD Shielded wires (three conductors), UL2482 (Hitachi Cable)
Other signals Shielded wires
●Recommended Terminal Lugs
3.7mm
7 mm or less
3.7mm
7 mm or less
or
0.3 to 1.65 mm
2
0.8 N·m or less
Applicable wire size Tightening torque
●Terminal Covers
Target Model Part Number Sales Unit
UP350
T9115YD 1

<Toc> <1. Installation> 1-7
IM 05E01D02-41E 1st Edition : May 31,2000-00
1.4 Hardware Specifications
PV Input Signals
•Number of inputs: 1 (terminals
11
-
12
-
13
)
•Input type: Universal input system. The input type can be selected with the software.
•Sampling period: 250 ms
•Burnout detection: Functions at TC, RTD, standard signal (0.4 to 2 V or 1 to 5 V)
Upscale, downscale, and off can be specified.
For standard signal, burnout is determined to have occurred if it is 0.1 V or less.
•Input bias current: 0.05 A (for TC or RTD b-terminal)
•Measurement current (RTD): About 0.13 mA
•Input resistance: 1 Mor more for thermocouple or mV input
About 1 Mfor DC voltage input
•Allowable signal source resistance: 250 or less for thermocouple or mV input
Effects of signal source resistance: 0.1 V/or less
2 kor less for DC voltage input
Effects of signal source resistance: About 0.01%/100 
•Allowable wiring resistance: for RTD input
Maximum 150 /wire: Conductor resistance between three wires should be equal
However, 10 /wire for a maximum range of -150.0 to 150.0C.
Wire resistance effect: 0.1C /10 
•Allowable input voltage: 10 V DC for thermocouple, mV, or RTD input
20 V DC for DC voltage input
•Noise rejection ratio: 40 dB (50/60 Hz) or more in normal mode
120 dB (50/60 Hz) or more in common mode
•Reference junction compensation error: 1.0C (15 to 35C)
1.5C (0 to 15C, 35 to 50C)
•Applicable standards: JIS, IEC, DIN (ITS-90) for thermocouples and RTD
Loop Power Supply
Power is supplied to a two-wire transmitter.
(15 V DC: terminals
14
-
15
)
A resistor (10 to 250 ) connected between the controller and transmitter converts a
current signal into a voltage signal, which is then read via the PV input terminal.
Supply voltage: 14.5 to 18.0 V DC, max. 21 mA (provided with a protection circuit
against a field short-circuit)
Retransmission Output
Either PV, program setpoint, or control output is output.
Either the retransmission output or the loop power supply can be used with terminals
14
-
15
.
•Number of outputs: 1 (terminals
14
-
15
)
•Output signal: 4-20 mA DC
•Load resistance: 600 or less
•Output accuracy: 0.3% of span under standard operating conditions (232C,
5510% RH, power frequency of 50/60 Hz)

1-8
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
Control Output
Universal output system, The output type can be selected with the software.
•Current output
(Standard type: terminals
16
-
17
)
Number of outputs
Output signal 4-20 mA DC
Load resistance 600  or less
Output accuracy 0.3% of span under standard operating
conditions (232C, 5510% RH,
power frequency of 50/60 Hz)
1 (switched between a voltage pulse output
and current output)
•Voltage pulse output
(Standard type: terminals
16
-
17
)
Number of outputs 1 (switched between a voltage pulse output
and current output)
Output signal On-voltage = 12 V or more
(load resistance: 600 Ωor more)
Off-voltage = 0.1 V DC or less
Resolution 10 ms
•Relay contact output
(Standard type: terminals
1
-
2
-
3
)
Number of outputs 1
Output signal Three terminals (NC, NO, and common)
Contact rating 250 V AC or 30 V DC, 3 A (resistance load)
Resolution 10 ms
Contact Inputs
•Purpose: Run/Reset switching
•Number of inputs: 2 points
•Input type: Non-voltage contact or transistor open collector input
•Input contact rating: 12 V DC, 10 mA or more
•On/off determination: For non-voltage contact input, contact resistance of 1 kor less
is determined as “on”and contact resistance of 20 kor more as “off.”
For transistor open collector input, input voltage of 2 V or less is determined as “on”
and leakage current must not exceed 100 A when “off.”
•Minimum status detection hold time: About 1 sec.
Contact Outputs
•Purpose: PV event outputs (2) and time event output (1)
•Number of outputs: 3 points
•Relay contact rating: 240 V AC, 1 A, or 30 V DC, 1 A
Display Specifications
•PV display: 4-digit, 7-segment red LED display, character height of 20 mm
•Setpoint display: 4-digit, 7-segment red LED display character height of 9.3 mm
•Status indicating lamps: LEDs

<Toc> <1. Installation> 1-9
IM 05E01D02-41E 1st Edition : May 31,2000-00
Safety and EMC Standards
•Safety: Compliant with IEC1010-1: 1990 and EN61010-1: 1992
Approved by CSA1010
CSA1010 installation category (overvoltage category): CATII (IEC1010-1)
Approved by UL508
•EMC standards: This instrument complies with the following EMC standards (the
instrument continues to operate at a measuring accuracy of within 20% of the range
during tests):
- EMI (emission), EN61326-1: 1997+Am1: 1998
- EMS (immunity), EN61326-1: 1997+Am1: 1998
Construction, Installation, and Wiring
•Construction: Only the front panel is dust-proof and drip-proof (protection class IP55)
For side-by-side close installation the controller loses its dust-proof and drip-proof
protection.
•Material: ABS resin and polycarbonate
•Case color: Black
•Weight: About 1 kg or less
•Dimensions: 96 (W) 96 (H) 100 (depth from panel face) mm
•Installation: Panel-mounting type. With top and bottom mounting hardware (1 each)
•Panel cutout dimensions: 920
+0.8 (W) 920 +0.8 (H) mm
•Installation position: Up to 30upward facing (not designed for facing downward)
•Wiring: M3.5 screw terminals (for signal wiring and power/ground wiring as well)
Power Supply Specifications
•Power supply: Rated voltage of 100 to 240 V AC (10%), 50/60 Hz
•Power consumption: Max. 20 VA (8.0 W max.)
•Data backup: Non-volatile memory (can be written to up to 100,000 times)
•Withstanding voltage
- Between primary terminals* and secondary terminals**:
At least 1500 V AC for 1 minute (Note)
- Between primary terminals* and grounding terminal:
At least 1500 V AC for 1 minute (Note)
- Between grounding terminal and secondary terminals**:
At least 1500 V AC for 1 minute
- Between secondary terminals**:
At least 500 V AC for 1 minute
* Primary terminals indicate power terminals and relay output terminals
** Secondary terminals indicate analog I/O signal, voltage pulse output, and contact
input terminals
Note: The withstanding voltage is specified as 2300 V AC per minute to provide a margin of safety.
•Insulation resistance: 20 Mor more at 500 V DC between power terminals and
grounding terminal
•Grounding: Class 3 grounding (grounding resistance of 100 or less)

1-10
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
Signal Isolations
•PV input terminals: Isolated from other input/output terminals. Not isolated from the
internal circuit.
•15 V DC loop power supply terminals: Not isolated from 4-20 mA analog output and
voltage pulse control output. Isolated from other input/output terminals and internal
circuit.
•4-20 mA analog output terminals (for control output and retransmission): Not isolated
between 4-20 mA outputs and from 15 V DC loop power supply and voltage pulse
control output. Isolated from other input/output terminals and internal circuit.
•Voltage pulse control output terminals: Not isolated from 4-20 mA outputs and 15 V
DC loop power supply. Isolated from other input/output terminals and internal circuit.
•Relay contact control output terminals: Isolated between contact output terminals and
from other input/output terminals and internal circuit.
•Contact input terminals: Not isolated between contact input terminals and from com-
munication terminals. Isolated from other input/output terminals and internal circuit.
•Relay contact event output terminal: Not isolated from each other; isolated from other
input/output terminals and the internal circuit.
•RS-485 communication terminals: Not isolated from contact input terminals. Isolated
from other input/output terminals and internal circuit.
•Power terminals: Isolated from other input/output terminals and internal circuit.
•Grounding terminals: Isolated from other input/output terminals and internal circuit.
Environmental Conditions
•Normal operating conditions:
Ambient temperature: 0 to 50C (40C or less for side-by-side close installation)
Temperature change rate: 10C/h or less
Ambient humidity: 20 to 90% RH (no condensation allowed)
Magnetic field: 400 A/m or less
Continuous vibration at 5 to 14 Hz: Full amplitude of 1.2 mm or less
Continuous vibration at 14 to 150 Hz: 4.9 m/s2or less
Short-period vibration: 14.7 m/s2, 15 seconds or less
Shock: 14.7 m/s2or less, 11 ms
Installation height: Height above sea level of 2000 m or less
Warm-up time: 30 minutes or more after power on
•Transportation and storage conditions:
Temperature: -25 to 70C
Temperature change rate: 20C/h or less
Humidity: 5 to 95% RH (no condensation allowed)
•Effects of changes in operating conditions
- Effects from changes in ambient temperature:
- On voltage or thermocouple input, 1 V/C or 0.01% of F.S./C,
whichever is larger
- On RTD input, 0.05C/C (ambient temperature) or less
- On analog output, 0.05% of F.S./C or less
- Effects from power supply fluctuation (within rated voltage range)
- On analog input, 1 V/10 V or 0.01% of F.S./10 V, whichever is
larger
- On analog output, 0.05% of F.S./10 V or less

<Toc> <1. Installation> 1-11
IM 05E01D02-41E 1st Edition : May 31,2000-00
1.5 Terminal Wiring Diagrams
NOTE
Do not use unassigned terminals as relay terminals.
Terminal wiring diagrams are shown on and after the next page.

1-12
<Toc> <1. Installation>
IM 05E01D02-41E 1st Edition : May 31,2000-00
■UP350 Standard Type
1
2
3
4
5
6
7
8
9
10
21
22
23
24
25
26
27
28
29
30
11
12
13
14
15
16
17
18
19
20
12
13
14
15
100 
Two-wire transmitter
PV input
0.4 to 2.0 V DC signal
Loop power
supply
14.5 to
18.0 V DC
External
resistor
(Note)
Note: Connecting a 100 resistor to the terminals is optional.
Model: X010-100-2 (resistor with M3.5 crimp-on terminal lugs)
15 V DC Power Supply Wiring to Two-wire Sensor
4-20mADC
OT=0 (factory-set default)
Time proportional control
Relay output (terminals , and )
OT=1
Correspondence between parameter OT and control output types
Time proportional control
Voltage pulse output (terminals and )
OT=2
Current output
(terminals and )
OT=3
On-off control
Relay output (terminals , and )
* OT is a setup parameter.
You can change the settings of the parameter OT to change the control output types. See “2. Initial Settings,”for more information.
123
16 17 16 17
123
Contact rating: 12 V DC, 10 mA or more
19
18
Correspondence between parameter DIS and external contact input functions
20
When DIS=3
DI1
DI2
COM
Common
Start program 1 when DI1 = ON
Reset program 1 when DI1 = OFF
Hold program when DI2 = ON
Cancel hold when DI2 = OFF
When DIS=2
Hide setup parameter lock when DI1 = ON
Show setup parameter lock when DI1 = OFF
Common
When DIS=OFF (Factory-set default)
No function
No function
Common
When DIS=1
Start program 1 when DI1 = ON
Reset program 1 when DI1 = OFF
Start program 2 when DI2 = ON
Reset program 2 when DI2 = OFF
Common
19
18
20
DI1
DI2
COM
+5V
+5V
Contact
Transistor contact
* DIS is a setup parameter.
Changing DIS setpoint allows you to change the function of external contact input.
No function
6
5
Event output
4
7
PVE1
PVE2
TME
COM
Relay contact rating: 240 V AC, 1 A
30 V DC, 1 A (resistance load)
Relay
PV event-1 output
PV event-2 output
Time event output
Common
UP
UP
8
9
Power supply
10
L
N
Allowable range: 100 to 240 V AC (10%)
(free voltage)
50/60 Hz shared
Power supply CAUTION
Before carrying out wiring, turn off the power
to the controller and check that cables to be
connected are not alive with a tester or the like
because there is a possibility of electric shock.
16
17
Current/voltage
pulse output
4-20 mA DC,
voltage pulse
(12 V)
Control output
+
-
Note:Select the control output
type from the OT
parameter.
14
15
Retransmission output
4-20 mA DC
14
15
15 V DC loop power supply
14.5-18.0VDC
(21 mA DC max.)
* PV retransmission is configured at factory
before shipment.
Load resistance: 600 Ω or less
* If 15 V DC loop power supply is used,
retransmission output cannot be used.
-
+
-
+
12
13
TC input
11
12
RTD input
13
12
13
mV/V input
Installation category (overvoltage category): II (IEC1010-1)
A
b
B
NOTE
-
+
-
+12
13
Note: Connecting a 250 Ωresistor to the terminals is
optional.
Model: X010-250-2 (resistor with M3.5 crimp-on terminal
lugs)
* When receiving 4-20 mA DC current signals,
set the PV input type to 1-5 V DC (setpoint “41”).
䊏 Receiving 4-20 mA DC Current
Signals with the Controller
250 Ω4-20mA
PV input
* Not configured at factory before shipment
See “2. Initial Settings,”for more information.
-
+
23
24
RS-485 communication
* Wiring can only be carried out
for controllers with communication
functions.
Maximum baud rate: 9600 bps
25
26
27
SDB(+)
SDA(-)
RDB(+)
RDA(-)
SG
1
2
Relay contact output
3
Control output
NC
NO
COM
Contact rating: 250 V AC, 3 A
30 V DC, 3 A (resistance load)
Note: Select the control output type
from the OT parameter.
* Time proportional PID relay contact
output is configured at factory
before shipment.

<Toc> <2. Initial Settings> 2-1
IM 05E01D02-41E
2. Initial Settings
This chapter describes examples of setting PV input types, and control output types.
Carrying out settings described herein allows you to perform basic control. Refer to
examples of various settings to understand how to set parameters required. Refer to
“6.1 Parameter Map” for an easy to understand explanation of setting various
parameters. If you cannot remember how to carry out an operation during setting,
press the
SET/ENT
key for more than 3 seconds. This brings you to the display (operating
display) that appears at power-on. When you have finished configuring the initial
settings discussed in this manual, create operation programs as explained in “3.
Programming.”
Power-on
Set the alarm
type and other setup
parameters.
See “2.2 Setting PV Input Type (Setting First at Power-on),”
or “2.3 Changing PV Input Type.”
Set the control
output.
Set Program
parameters.
(Factory-set to “Time Proportional Relay Output.”)
Denotes a step that must always be followed.
(Factory-set to “Unspecified.”)
Denotes a step that should be followed as necessary.
Setup Procedure
Set operating
parameters.
Controller operation
See “2.4 Setting Control Output Type.”
See “3. Programming.”
Set PV input.
1st Edition : May 31,2000-00

2-2
<Toc> <2. Initial Settings>
IM 05E01D02-41E
2.1 Names and Functions of Front Panel Parts
3. Status indicator
lamps
6. PRG 1 and
PRG 2 keys
7. RESET key
4. Event indicator
lamps
1. Process
variable (PV)
display
2. Setpoint
display
5. Light-loader
interface
8. SET/ENT key 9. and keys
1.
Name of Part Function
Process variable (PV) display
2. Setpoint display
•Displays PV during operation.
•Displays a parameter symbol when you set a parameter.
•Displays an error code in red if the controller fails.
•Displays such data items as the program setpoint and control output value (OUT), as
shown below, during operation.
Program setpoint
Segment number for which operation is in progress
Remaining segment time
Program setpoint at the time of hold (shown when program operation is at a pause)
Control output value
•Displays the setpoint of a parameter when it is configured.
5. Light-loader interface A communication interface for connection with an adapter cable when setting and storing
parameters from a PC. Use of this interface requires an optional parameter setting tool.
3. Status indicator lamps
Remain lit during operation.
PRG1: Program-1 operation
PRG2: Program-2 operation
HLD: Hold operation (lit when program operation is paused)
6. PRG1 and
PRG2 keys
Used to start program operation or set a program.
Operation with program pattern 1: With the operating display shown, hold down the
PRG1 key for more than 2 seconds.
Operation with program pattern 2: With the operating display shown, hold down the
PRG2 key for more than 2 seconds.
Setting of program pattern 1: With the operating parameter setting display shown,
press the PRG1 key to show the relevant program
setting parameter.
Setting of program pattern 2: With the operating parameter setting display shown,
press the PRG2 key to show the relevant program
setting parameter.
7. RESET key
Press this key for more than 2 seconds during normal operation or hold operation to
stop the operation. When stopped, the controller outputs a fixed value (preset output
value). The output is factory-set to 0.0% or OFF.
8. SET/ENT key
SET/ENT
Used to switch or register parameters. Press this key for more than 3 seconds to
alternate between the operating display and the menu for operating parameter setting
display.
Used to change numerical values. On setting displays for various parameters, you can
change the program setpoints, and parameters values. Pressing the key decreases
a numerical value, while pressing the key causes it to increase.
You can hold down either key to gradually increase the speed of change.
4. Event indicator lamps
Come on when PV event 1 or 2, or a time event occurs.
PVE1: PV event 1
PVE2: PV event 2
TME: Time event
1
PRG
2
PRG
RESET
9. and keys
IMPORTANT
The controller automatically returns to the display at the time of power-on (i.e., operating
display) if no key is operated for at least one minute.
1st Edition : May 31,2000-00
