YOODA CAMELEO_1RwT Configuration guide

CAMELEO_1RwT | CAMELEO_5RwT
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.
Illustrations (from the top):
Fig. 1. 5-channel CAMELEO wall-mounted remote control with timer, white
Fig. 2. Single-channel CAMELEO wall-mounted remote control with timer, white
General information
Detailed description
www.sukcesgroup.pl
1. Control:
can control single motor,
or a group of up to 20 motors on each channel
2. Range:
200 meters outdoor,
35 meters indoor
3. Battery:
2 x CR2430
4. Power supply:
3 V
5. Dimensions:
80 x 80 x 14 mm
6. Transmitting power:
10 mW
7. Operating temperature:
from 0°C to 50°C
8. Protection degree:
IP 30
Radio receiver range is a variable value and can differ from declared values depending on conditions in which device
operates. Possible sources of changes in range are building construction, interference caused by other radio transmitters
etc.
Single or 5-channel transmitter
(front)
LCD display
DOWN buttonUP button
STOP button
PREVIOUS CHANNEL
button
NEXT CHANNEL button
P2 programming button
FR
MAN
currently
chosen channel
(only in 5RwT model)
current
work mode
FR
MAN
AUTO
TH SAWETUMOSU
current
time
low battery warning
(only when battery is low)
roller shutter
direction
week days with active
in automatic mode
number
of currently active
automatic mode

1. For channel to work correctly when remote is set to automatic mode, it has to be activated. If automatic mode is
chosen for the channel and the channel number is flashing, that means device does not work in this mode.
2. Difference between automatic time of roller shutter opening and closing cannot be shorter than 32 minutes. In case of
smaller than minimal time difference fault message will appear and none of the changes will be saved.
3. Pressing UP or DOWN button in automatic mode will show currently set opening / closing time and symbol of current
process.
4. Estimated battery lifespan is one year if the device runs 4 commends a day in average.
5. Batteries should be changed when LED diode stops flashing when channel is being changed or receiving device stops
reacting to commands.
6. When placing the battery ensure that polarity is correct.
7. When on display all channels are selected remote controls all programmed devices on all channels at the same time.
No programming functions can be performed on group channel. All devices programmed to any other channel can be
controlled on group channel without additional programming.
8. For all devices, that are programmed on all the channels, to work at programmed time, group channel and automatic
mode should be chosen.
Batteries contain substances that may be hazardous to health and may pollute the environment. Used batteries should
be disposed of properly.
CAMELEO_1RwT | CAMELEO_5RwT
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.
Detailed description
Changing work mode
www.sukcesgroup.pl
1. Manual work mode: standard mode without using time programming function.
2. Automatic mode: standard mode with activated automatic work time.
3. Random work mode: automatic mode with random time of work (15 minutes difference from programmed time).
4. Work mode changes for all channels.
5. Automatic work mode has three different options. Active option is indicated by the number on the display.
'0' - manual mode.
‘1’ – automatic or random mode,
allows to program time of automatic work for each day individually.
‘2’ – automatic or random mode,
allows to program single time of automatic work for every day of the week (Mon-Sun).
‘3’ – automatic or random mode,
allows to program three different times of automatic work – Mon-Fri, Sat, Sun.
By pressing
P2 programming button
for about 3 seconds work mode
will change to manual mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to first
of automatic mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to second
of automatic mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to third
of automatic mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to first
random mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to second
random mode.
By pressing
P2 programming button
for about 3 seconds work mode
will change to third
random mode.
Pressing
P2 programming button
will cause for work mode
to change again.

CAMELEO_1RwT | CAMELEO_5RwT
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.
Activating channels in automatic mode
Setting current time
Changing automatic opening and closing time
www.sukcesgroup.pl
1. Each channel can be activated or deactivated in automatic mode.
2. If channel is deactivated transmitter will not control programmed radio receiver at preset time.
3. Channel is deactivated if its number is flashing.
4. In default mode all channels are active in automatic mode.
Time can be set only when device is in manual working mode.
Longer than 60 seconds pause between series of button clicks during programming will cause device to switch off from
time setting mode without saving any changes.
1. Difference between automatic time of roller shutter opening and closing cannot be shorter than 32 minutes. In case of
smaller than minimal time difference fault message will appear.
2. Changes to opening and closing time can be done only in automatic mode.
3. Longer than 60 seconds pause between series of button clicks during programming will cause device to switch off from
time setting mode without saving any changes.
4. Group channel needs to chosen for transmitter to control all devices at the same time. That applies to all working modes.
5. If while setting time of automatic opening or closing ‘--:--‘ symbol appears, it means that this time is not active in automatic
mode.
5. To leave time programming mode without saving any changes press STOP button.
By pressing
P2 programming button
for about 3 seconds
change work mode
to automatic or random.
By pressing ‘L1’ or ‘P1’
choose a channel.
By pressing
‘P1’ button for about 3 seconds
automatic mode is deactivated
on chosen channel.
Channel number is flashing.
Another pressing ‘P1’ button
for about 3 seconds
will activate automatic mode
on chosen channel.
Channel displays constantly.
By pressing ‘L1’ button
switch to day setting.
Using UP and DOWN buttons
set day of the week.
By pressing ‘P1’ button
for about 3 seconds
confirm new setting.
Pressing ‘L1’ button
will start the clock.
By pressing
P2 programming button
for about 3 seconds
change work mode to manual.
By pressing ‘L1’ button
for approximately 5 seconds
(hour starts to flash).
Using UP and DOWN
buttons set hour.
By pressing ‘L1’ button
switch to minute setting.
Using UP and DOWN buttons
set minute.

Instructions described below need to be repeated for all five channels during the same programming.
CAMELEO_1RwT | CAMELEO_5RwT
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.
Setting automatic opening and closing time
www.sukcesgroup.pl
ACTION
PROGRAMMING OPENING AND CLOSING TIME
DISPLAYED MESSAGE
By pressing
P2 programming button
for about 3 seconds
change work mode to automatic.
Press L1 button
single time.
Using UP and DOWN buttons
select the hour.
Using UP and DOWN buttons
select the minutes.
By pressing
P2 programming button
single time switch
to setting closing time.
Press L1 button
single time.
Transmitter switched to minute setting.
Minute starts to flash.
Press L1 button
single time.
Transmitter switched to minute setting.
Minute starts to flash.
Newly set hour
will be displayed.
Using UP and DOWN buttons
select the hour.
Newly set hour
will be displayed.
Newly set minute
will be displayed.
Using UP and DOWN buttons
select the minutes.
Using P1 button
change day of the week in 1st and 3rd mode.
Repeat actions described above to set time.
Days of the week are switched. For each day
opening and closing times are being set.
After setting all the times
press P1 button for about 3 seconds
to confirm all changes.
Newly set time
will start to flash.
Newly set minute
will be displayed.
Closing time will be shown.
Hour will start to flash.
Opening time will be shown.
Hour will start to flash.
AUTO symbol
will be displayed.
Press L1 button
for 3 seconds.
Current opening time is being displayed.
To check programmed opening times
for each day of the week
press UP or DOWN.
AUTO
SA
AUTO
SU
AUTO
SU
AUTO
SA
AUTO
SU
AUTO
SU
AUTO
SU
AUTO
SU
AUTO
SU
AUTO
SU
AUTO
MO
AUTO
SU

CAMELEO_1RwT | CAMELEO_5RwT
In order to fully explore available functions of CAMELEO series please take a moment and read this manual before using the device.
CAMELEO transmitters are compatible with all YOODA brand devices.
www.sukcesgroup.pl
Programming first remote to R-type motors
1. Way of programming first transmitter depends on type of radio receiver. When programming first transmitter please
follow instruction of the device that is going to be controlled by the transmitter.
2. Longer than 5 seconds pause between series of button clicks during programming will cause device to switch off from
programming mode without saving any changes.
3. Programming first transmitter will result in deleting all previously programmed transmitter.
Turn on power supply
or press microswitch
(for 2 sec.) when power is on.
Motor will make a sound.
Roller shutter will make
an up/down move.
Motor will
make a sound.
Press
programming button
(P2) on the remote.
or
Roller shutter will
make an up / down
move as the motor will
make few sounds.
Motor will
make a sound.
Press
programming button
(P2) on the remote.
Press UP button
on the remote.
