York R-410A Quick start guide

036-21548-001-D-0405
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
TECHNICAL GUIDE
CHAMPION®R-410A
SINGLE PACKAGE GAS/ELECTRIC
AIR COOLED AIR CONDITIONERS
2 THRU 5 NOMINAL TON
DNZ024, 030, 036 and 042
13 SEER
DNZ048 and 060
12 SEER
®
ISO 9001
Certified Quality
Management System
FLEXIBLE LIGHT COMMERCIAL UNIT
GENERAL
YORK’s Champion®package units are designed to handle
applications ranging from residential to light commercial and
any in between. The Champion®is a unit that gives you the
flexibility and choices you need in today’s market.
FEATURING
• R-410A REFRIGERANT
• COOLING/GAS HEATING UNITS (NATURAL GAS OR
PROPANE)
• LOW PROFILE
• QUIET OPERATION
• COMMON FOOTPRINT
• OPTIONAL SLIDE IN MOTORIZED DAMPERS
• OPTIONAL SLIDE IN ECONOMIZERS
• OPTIONAL PROPANE CONVERSION KIT
• OPTIONAL HIGH ALTITUDE CONVERSION KIT
(NATURAL GAS/PROPANE)
• OPTIONAL LOW NOx KIT
• FULL PERIMETER BASE RAILS
• BOTTOM AND SIDE UTILITY CONNECTIONS
• 1” OR 2” CLEANABLE FILTERS STANDARD ON ALL
3 PHASE MODELS. OPTIONAL ON 1 PHASE MODELS
• WARRANTY - 1 PHASE
• 10 year compressor
• 20 year heat exchanger
• 5 year other parts
• WARRANTY - 3 PHASE
• 5 year compressor
• 10 year heat exchanger
• 1 year other parts

036-21548-001-D-0405
2Unitary Products Group
TABLE OF CONTENTS
NOMENCLATURE. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
STANDARD FEATURES/BENEFITS . . . . . . . . . . . . 3
FIELD-INSTALLED ACCESSORIES. . . . . . . . . . . . . 5
TYPICAL WIRING DIAGRAM NOTES . . . . . . . . . . 26
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . 26
LIST OF FIGURES
Fig. # Pg. #
1 UNIT COMPONENT LOCATION. . . . . . . . . . . . . . . . . . 6
2 FIELD WIRING DIAGRAM CONTROL WIRING . . . . .16
3 POWER WIRING FIELD DIAGRAM . . . . . . . . . . . . . .17
4 UNIT DIMENSIONS - FRONT. . . . . . . . . . . . . . . . . . .18
5 UNIT DIMENSIONS - FRONT & BOTTOM. . . . . . . . .19
6 UNIT DIMENSIONS - BACK & BOTTOM . . . . . . . . . .19
7 TYPICAL SLAB ON GROUND INSTALLATION . . . . .20
8 TYPICAL ROOF CURB INSTALLATION. . . . . . . . . . .20
9 TYPICAL DUCT APPLICATIONS . . . . . . . . . . . . . . . .21
10 UNIT CENTER OF GRAVITY . . . . . . . . . . . . . . . . . . .21
11 ROOF CURB DIMENSIONS . . . . . . . . . . . . . . . . . . . .22
12 ROOF CURB CROSS SECTION. . . . . . . . . . . . . . . . .22
13 TYPICAL WIRING DIAGRAM DNZ 024-060
(208/230-1-60 POWER SUPPLY) . . . . . . . . . . . . . . . .23
14 TYPICAL WIRING DIAGRAM DNZ 030-060
(208/230-3-60 POWER SUPPLY). . . . . . . . . . . . . . . . 24
15 TYPICAL WIRING DIAGRAM DNZ 030-060
(460-3-60 POWER SUPPLY) . . . . . . . . . . . . . . . . . . . 25
LIST OF TABLES
Tbl. # Pg. #
1 PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 RATINGS COOLING/GAS HEATING. . . . . . . . . . . . . . 7
3 DNZ024 COOLING CAPACITIES - 2 TON. . . . . . . . . . 8
4 DNZ030 COOLING CAPACITIES - 2-1/2 TON. . . . . . . 9
5 DNZ036 COOLING CAPACITIES - 3 TON. . . . . . . . . 10
6 DNZ042 COOLING CAPACITIES - 3-1/2 TON. . . . . . 11
7 DNZ048 COOLING CAPACITIES - 4 TON. . . . . . . . . 12
8 DNZ060 COOLING CAPACITIES - 5 TON. . . . . . . . . 13
9 SIDE SUPPLY AIR BLOWER PERFORMANCE -
208/230 VOLTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 BOTTOM SUPPLY AIR BLOWER PERFORMANCE -
208/230 VOLTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
11 ADDITIONAL STATIC PRESSURE RESISTANCE -
2, 2-1/2 AND 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 16
12 ADDITIONAL STATIC PRESSURE RESISTANCE -
3-1/2, 4 AND 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . 16
13 ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . 17
14 UNIT DIMENSIONS FRONT. . . . . . . . . . . . . . . . . . . . 18
15 UNIT MINIMUM CLEARANCES . . . . . . . . . . . . . . . . . 18

036-21548-001-D-0405
Unitary Products Group 3
NOMENCLATURE
DESCRIPTION
These packaged cooling/heating air conditioners are
designed for outdoor installation. Only utility and duct con-
nections are required at the point of installation.
The gas-fired heaters have aluminized steel tubular heat
exchangers and hot surface to pilot ignition. They are avail-
able in natural gas with field conversion to propane.
STANDARD FEATURES/BENEFITS
OPERATING EFFICIENCY - All units provide high operating
efficiencies and have a minimum AFUE of 80% and SEERS of
12.0 and 13.0. All efficiencies exceed legislated minimum levels.
ON SITE FLEXIBILITY - All model sizes share a common,
compact design cabinet in a single footprint. The installer has
the flexibility of setting one curb and placing the proper ton-
nage unit on that curb after the internal load has been deter-
mined. Field convertible duct connections from side shot to
down shot allows the installer to have greater flexibility with
less inventory.
LOWER INSTALLATION COST - Installation time and costs
are reduced by easy power and control wiring connections.
The small base dimension means less space is required on
the ground or roof, plus, the installer can fit this unit between
the wheel wells of full size pick-up truck. All models are well
under 500 pounds.
All units are completely wired, charged with R-410A and
tested prior to shipment. Unique test stations using a new
state of the art computerized process system are used to
insure product quality. Refrigerant charge and component
part numbers are verified via computers at assembly. Vital
run test statistics such as system pressure, motor currents,
air velocity and temperature, unit vibration, and gas system
safeties are monitored and recorded by the system to insure
unit performance.
Equal size, side supply and return duct connections allows
easy hook-up of ducts to match low crawl spaces without
transition pieces.
UTILITY CONNECTIONS MADE EASY - Gas and electric
utility knockouts are provided through the bottom as well as
the side of the unit. Utility connections can be made quickly
and with a minimum amount of field labor. A field supplied
and field installed electrical disconnect switch must be
installed.
CONVERTIBLE AIRFLOW DESIGN - The bottom duct open-
ings are covered when they leave the factory ready to be
used for a side supply / side return application. If a bottom
supply / bottom return application is desired, you simply
remove the two panels from the bottom of the unit and place
them in the side supply / side return duct openings. No panel
cutting is required and no accessory panel is necessary.
Convertible airflow design allows maximum field flexibility and
minimum inventory.
CONDENSATE PAN - A non-corrosive, long-lasting, water-
tight pan is positioned below the evaporator coil to collect and
drain all condensate. Less collection of stagnate condensate
will build-up. The condensate pan conforms to ASHRAE 62-
89 standards (Ventilation for Acceptable Indoor Air Quality).
CONDENSATE DRAIN - The heavy duty, 3/4 inch NPTI cop-
per connection is more durable over time. The connection is
rigidly mounted to assure proper fit and leak tight seal.
      
 
   
 
    ! 
"
 #
  $% &' 
() 
  &*'&$$
&+  &*'&$$
%  %$$
,) )
 -,./0
&%  &%1 ./
  1 ./
  1 ./
%&  %&1 ./
%*  %*1 ./
  1 ./
#
))  /
 
,)  /
 
  1 ./
+  +1 ./
2&  2&1 ./
+  +1 ./
3  31 ./
  1 ./
  4  / "
 /' 

036-21548-001-D-0405
4Unitary Products Group
DURABLE FINISH - With a heavy duty cabinet made of pow-
der-painted, galvanized steel the neutral color blends into
surrounding areas. The powdered paint provides a better
paint to steel bond, which resists corrosion and rust creep.
The special primer formulas and glossy finish insures less
fading when exposed to sunlight and offers a more attractive
on site appearance. This paint finish meets ASTM-B117 stan-
dards for 1000 hours salt spray rating. The highest in the
industry.
FULL PERIMETER BASE RAILS - The easily removable
base rails provide a solid foundation for the entire unit and
protects the unit during shipment. The rails provide fork lift
access from all sides, and rigging holes are also provided so
that an overhead crane can be used to place the units on a
roof. On applications where the unit is placed on a pad, the
base will keep the unit off the pad to deter corrosion. On
applications where height is limited, the inch high base rails
may be removed on location.
MORE ATTRACTIVE APPEARANCE - A single piece Water
Shed top cover containing a top discharge condenser fan
arrangement requires less square footage on installation and
provides a wider variety of installations. The one piece design
adds greater water integrity. Rounded corners with water drip
edges add to the attractive appearance. The cabinet panels
have a non-fibrous insulation that will not release insulation
fibers into conditioned area.
TOP DISCHARGE - The top discharge condenser fan does
not disrupt neighboring areas or dry-out vegetation surround-
ing the unit. The warm air from the top mounted fan is blown
up away from the structure and any landscaping. This allows
compact location on multi-unit applications.
CONDENSER COIL GRILLE - A multi-piece totally enclosed,
rigidly mounted condenser coil grille provides protection from
objects after installation and provides protection during transit.
LOW OPERATING SOUND LEVEL - The upward air flow
carries the normal operating noise up and away from the liv-
ing area. The rigid top panel effectively isolates any motor
sound. Isolator mounted compressor and the rippled fins of
the condenser coil muffle the normal fan motor and compres-
sor operating sounds. The unique formed base pan also aids
in sound alterations with it's Super-Structure design. This
design strategically places embossments in the pan for opti-
mum strength and rigidity.
FAN SYSTEM - All models operate over a wide range of
design conditions with a constant CFM, electrically commu-
tated (ECM) fan motor. These units easily match all types of
applications and provide greater on site flexibility to match
comfort requirement. These models have 2 cooling speeds
and a single heating speed. The cooling speed is factory set
and can be field adjusted to a second speed. The heating
speed is factory set to maintain mid point rise at the units
heating input. It cannot be field adjusted. This allows maxi-
mum comfort conditions.
SIMPLE CONTROL CIRCUIT - A low voltage printed circuit
board contains a diagnostic indicator light and a low voltage
terminal strip. An additional set of pin connectors is also pro-
vided to simplify the field interface of external controls. Mate-
n-lock plug connectors are used. The electrical control box is
not located in the compressor compartment. The controls are
mounted on a Control-Tilt control panel to allow the access
cover to be removed for trouble shooting and maintenance
without affecting the normal system operating pressures. All
wiring internal to the unit is color/number coded.
PROTECTED COMPRESSOR - The compressor is internally
protected against high pressure and temperature. This is
accomplished by the simultaneous operation of high pressure
relief valve and a temperature sensor which protect the com-
pressor if undesirable operating conditions occur.
PRESSURE SWITCHES- High pressure and low pressure/
loss of charge switches standard in all units. When abnormal
conditions are sensed through the pressure switches, the unit
will lock out preventing any further operation until reset or
problem is corrected.
EXCLUSIVE COIL DESIGN - Grooved copper tubes and
enhanced aluminum fin construction improves heat transfer
for maximum efficiency and durability.
HEAT EXCHANGERS - Are corrosion-resistant, aluminized-
steel tubular construction to provide long-life, trouble-free
operation. The unique blow-through design also assures that
condensate does not collect in humid areas when in the cool-
ing cycle. This adds to longer heat exchanger life and higher
long term efficiencies.
POST PURGE INDUCED DRAFT COMBUSTION - Exhausts
combustion products from the heat exchanger upon comple-
tion of the heating cycle to prolong the heat exchanger life.
SELF DIAGNOSTIC FAN CONTROL MODULE - Due to this
self diagnostic control, less on site time is required to trouble
shoot these units.
HOT SURFACE TO PILOT IGNITION - Provides faster heat
delivery. This ignition is highly reliable, durable and elimi-
nates nuisance lockouts. Also assures starts in damp condi-
tions.
MULTI PORT IN-SHOT BURNERS - No field adjustment is
required to mix the air and gas. These burners are con-
structed of high-grade corrosion-resistant, aluminized-steel.
LOW MAINTENANCE - Long life, permanently lubricated
condenser and evaporator fan motor bearings need no
annual maintenance adding greater reliability to the unit.
Blower assembly can be easily cleaned by the unique Slip-
Track slide-out blower assembly.
SECURED SERVICE ACCESS PORTS - Protected, exter-
nally mounted, re-usable service access ports are provided
on both the high and low lines for ease of evacuating and
charging the system. No final field mounting required.

036-21548-001-D-0405
Unitary Products Group 5
EASY SERVICE ACCESS - A large, single panel covers the
electrical and gas controls makes servicing easy. The blower
compartment has an additional large panel with a built-in
handle tab. Removing this panel will allow the blower assem-
bly to slide-out for easy removal for maintenance and ease of
trouble shooting.
REPLACEMENT PARTS - The installer requires no special
training to replace any of the components of these units and
does not need to maintain an inventory of unique parts.
SYSTEM INTEGRATION - Each unit has the internal ability
to integrate an electronic air cleaner or humidifier to work in
conjunction with the base unit.
FIELD-INSTALLED ACCESSORIES
LOW NOx KIT - Kit includes all the necessary hardware and
instructions to field convert units to reduce emissions to less
than 40 nanogram per Joule. California requirement on single
phase models only.
PROPANE CONVERSION KIT - Kit includes burner orifices,
gas valve conversion and installation instructions necessary
to field convert unit from natural gas to propane.
HIGH ALTITUDE CONVERSION KIT (Natural Gas/Propane)
- Kit includes all necessary labels and instructions to field
alter units with natural gas/propane for installations above
2000 feet. Burner orifices must be obtained from Source 1
Parts. Propane Conversion Kit must be obtained separately.
ECONOMIZER DOWN DISCHARGE / SUPPLY KIT - Modu-
lating integrated economizer provides simultaneous opera-
tion between the mechanical cooling and economizer
operation. Independent blade design insures proper control
and less than 1% leak rate. Includes hood and mesh bird
screen filter integrated into the hood, dry bulb sensor and
relief damper. Separate field accessories of single enthalpy
and dual enthalpy are also available. A built-in barometric
relief of 25% is provided.
SINGLE ENTHALPY SENSOR - Sensor replaces dry bulb
sensor standard in economizer kit. Provides improved econo-
mizer operation by sensing the dry bulb temperature from
outdoors plus the enthalpy content of the outdoor air.
DUAL ENTHALPY SENSOR - Additional sensor to single
enthalpy sensor. Sensor senses both the return air tempera-
ture dry bulb and humidity in conjunction with the single
enthalpy to determine the most economical mix. Single
Enthalpy sensor also required.
HAIL GUARD KIT - Kit contains protective grilles made of
expanded aluminum with full perimeter frame. Sloped hoods
are also included to assure maximum protection.
ANTI SHORT CYCLE TIMER - Automatically prevents the
compressor from restarting for 5 minutes after cycled off.Not
required if Thermostat 2ET07700224 and 2ET04700224 are
used.
FILTER / FRAME KIT (Single Phase only) - Kit contains the
necessary hardware to field install return air filters into the
base unit. Pre-cut filter racks and appropriate cleanable stan-
dard size filters are shipped in one kit. The filter rack is suit-
able for either 1" or 2" filters. (1" filter is supplied) This kit is
available for single phase horizontal or vertical duct applica-
tion only. Standard in all 3 Phase models.
MOTORIZED FRESH AIR DAMPER - Designed for duct
mounted side supply/return and unit mounted down supply/
return applications. Damper capable of providing 0% through
50% of outdoor air (field supplied). Closes on power loss,
includes hood and screen assembly.
RECTANGLE TO ROUND ADAPTERS - Kit includes one
supply and one return air rectangle to round duct adapter.
Adapters are preformed and designed to fit over current duct
openings on the base unit. Transition is from side square duct
opening to 14" round duct opening.
ROOF CURBS - NRCA approved curbs provide proper fit to
base unit for rooftop installations. Curbs are designed to be
assembled through hinge pins in each corner. Kit also pro-
vides seal strip to assure a water tight seal. 8 and 14 inch
high roof curbs are available.
MANUAL OUTDOOR DAMPER - Provides 0% through 50%
outdoor air capability (field adjustable). Designed for duct
mounted side supply/return applications. Includes hood and
screen assembly.
WALL THERMOSTAT - The units are designed to operate
with 24-volt electronic and electro-mechanical thermostats.
All units can operate with single stage heat / single stage cool
thermostats - with or without the economizer.
LOW AMBIENT KIT - Kit provides necessary hardware to
convert unit to operate in cooling cycle down to 0º F. Stan-
dard unit operation 45º F.
TRANSFORMER KIT - Kit provides necessary hardware to
provide single phase models from factory furnished 40 VA
transformer capability to 75 VA transformer capability.
(Required on installations with economizer or motorized
damper.)

036-21548-001-D-0405
6Unitary Products Group
FIGURE 1 - UNIT COMPONENT LOCATION
DIRECT DRIVE
CONDENSER
FAN MOTOR
HIGHLY EFFICIENT ENHANCE
COPPER TUBE/ALUMINUM FIN
EVAPORATOR COIL
HIGHLY EFFICIENT
ENHANCED COPPER
TUBE/ALUMINUM FIN
CONDENSER COIL
DECORATIVE
PROTECTIVE
COIL GAURD
HIGH EFFICIENCY
COMPRESSOR
RIGIDLY
MOUNTED
HOT SURFACE PILOT
ASSEMBLY
HIGH GRADE ALUMINIZED
IN-SHOT BURNERS
LOW VOLTAGE
TERMINAL BLOCK
SELF-DIAGNOSTIC CONTROLS WITH
"COMFORT-MATCH" SPEED CONTROL
AUTOMATIC GAS VALVE (1/2" - 14 NPTI)
HIGH VOLTAGE
TERMINAL BLOCK
POWER VENTER MOTOR
DIRECT DRIVE
BLOWER MOTOR WITH
SLIDE-OUT BLOWER ASSEMBLY
HEAVY GAUGE
REMOVABLE
BASE RAILS
REAR AND BOTTOM
RET RUNAIR
AND SUPPLY AIR
DUCT OPENINGS
LONG LASTING
POWDER PAINT
FINISH
BLOW-THROUGH DESIGN
WITH RELIABLE ALUMINIZED
STEEL TUBULAR HEAT EX HANGERS
C
D
TABLE 1: PHYSICAL DATA
MODEL DNZ
024 030 036 042 048 060
EVAPORATOR
BLOWER CENTRIFUGAL BLOWER (Dia. x W. in.) 10 x 8 10 x 8 11 x 10 12 x 11 12 x 11 12 x 11
FAN MOTOR HP 1/2 3/4 3/4 1 1 1
EVAPORATOR
COIL
ROWS DEEP 2 3 3 3 3 3
FINS PER INCH 15 13 13 16 16 16
FACE AREA (Sq. Ft.) 3.5 3.5 3.5 4.5 4.5 4.5
CONDENSER
FAN
PROPELLER DIA. (in.) 22 22 22 22 22 22
FAN MOTOR HP 1/4 1/4 1/4 1/3 1/3 1/3
NOM. CFM TOTAL 2,200 2,400 2,400 3,000 3,000 3,000
CONDENSER
COIL
ROWS DEEP 1 2 2 2 2 2
FINS PER INCH 20 16 16 20 20 20
FACE AREA (Sq. Ft.) 11.7 11.7 11.7 14.7 14.7 14.7
CHARGE REFRIGERANT R-410A (lbs./oz.) 4 / 8 7 / 5 7 / 0 9 / 0 8 / 6 9 / 0
FILTER FACE AREA (Sq. Ft.) Size (Nominal) 2.6 / 20 x 20 2.6 / 20 x 20 2.6/20x20 3.3 / 20 x 12
(2 Reqd.) 3.3/20x12 (2 Reqd.) 3.3/20x12 (2 Reqd.)
FURNACE
SECTION
NATURAL GAS BURNER ORIFICE NO.
(Drill Size) 43 43 43 40 40 40
PROPANE BURNER ORIFICE NO.
(Drill Size) 55 55 55 53 53 53
GAS CONNECTION SIZE 1/2 NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI
COMPRESSOR HERMETIC TYPE, (Qty. = 1) Scroll Scroll Scroll Scroll Scroll Scroll

036-21548-001-D-0405
Unitary Products Group 7
TABLE 2: RATINGS COOLING/GAS HEATING
MODEL
DNZ
NET COOLING CAPACITY1SOUND
RATING
(dbels)2
GAS HEAT CAPACITY / EFFICIENCIES
MBH SEER3INPUT
(MBH) OUTPUT (MBH) AFUE4
(%) NUMBER OF
BURNERS
TEMP.
RISE
(°F) RANGE
024N03606 22.8 13.2 76 45 36 80.2 2 25 - 55
024N05606 22.8 13.2 76 70 56 80.2 3 30 - 60
030N03606 29.8 13.2 73 45 36 80.2 2 25 - 55
030N03625 29.8 13.2 73 45 36 80.2 2 25 - 55
030N03646 29.8 13.2 73 45 36 80.2 2 25 - 55
030N05606 29.8 13.2 73 70 56 80.2 3 30 - 60
030N05625 29.8 13.2 73 70 56 80.2 3 30 - 60
030N05646 29.8 13.2 73 70 56 80.2 3 30 - 60
036N03606 35.6 13.0 75 45 36 80.4 2 25 - 55
036N03625 35.6 13.0 75 45 36 80.4 2 25 - 55
036N03646 35.6 13.0 75 45 36 80.4 2 25 - 55
036N05606 35.6 13.0 75 70 56 80.2 3 25 - 55
036N05625 35.6 13.0 75 70 56 80.2 3 25 - 55
036N05646 35.6 13.0 75 70 56 80.2 3 25 - 55
036N07206 35.6 13.0 75 90 72 80.1 4 30 - 60
036N07225 35.6 13.0 75 90 72 80.1 4 30 - 60
036N07246 35.6 13.0 75 90 72 80.1 4 30 - 60
042N06506 41.5 13.25 79 80 64 80.6 3 25 - 55
042N06525 41.5 13.25 79 80 64 80.6 3 25 - 55
042N06546 41.5 13.25 79 80 64 80.6 3 25 - 55
042N09006 41.5 13.25 79 108 87 80.8 4 45 - 75
042N09025 41.5 13.25 79 108 87 80.8 4 45 - 75
042N09046 41.5 13.25 79 108 87 80.8 4 45 - 75
048N06506 45.5 12.45 79 80 64 80.8 3 25 - 55
048N06525 45.5 12.45 79 80 64 80.8 3 25 - 55
048N06546 45.5 12.45 79 80 64 80.8 3 25 - 55
048N09006 45.5 12.45 79 108 86 80.6 4 35 - 65
048N09025 45.5 12.45 79 108 86 80.6 4 35 - 65
048N09046 45.5 12.45 79 108 86 80.6 4 35 - 65
048N11006 45.5 12.45 79 135 107 80.5 5 45 - 75
048N11025 45.5 12.45 79 135 107 80.5 5 45 - 75
048N11046 45.5 12.45 79 135 107 80.5 5 45 - 75
060N06506 58.0 12.0 78 80 64 80.7 3 25 - 55
060N06525 58.0 12.0 78 80 64 80.7 3 25 - 55
060N06546 58.0 12.0 78 80 64 80.7 3 25 - 55
060N09006 58.0 12.0 78 108 87 80.9 4 35 - 65
060N09025 58.0 12.0 78 108 87 80.9 4 35 - 65
060N09046 58.0 12.0 78 108 87 80.9 4 35 - 65
060N11006 58.0 12.0 78 135 107 80.2 5 45 - 75
060N11025 58.0 12.0 78 135 107 80.2 5 45 - 75
060N11046 58.0 12.0 78 135 107 80.2 5 45 - 75
1. Net Cooling Capacity = ARI 210 standard rating conditions.
2. (dbels) = ARI 270-95
3. Seasonal Energy Efficiency Ration - the total cooling output in BTU’s during a normal annual usage period for cooling divided by
the total electric power input in watt-hours during the same period.
4. AFUE = Annual Fuel Utilization Efficiency.

036-21548-001-D-0405
8Unitary Products Group
TABLE 3: DNZ024 COOLING CAPACITIES - 2 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
800 CFM 1,000 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 28.7 26.7 24.6 24.2 29.7 27.7 25.5 25.1
TOTAL POWER kW 1.99 1.98 1.98 1.96 2.15 2.13 2.14 2.11
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 18.8 22.7 24.6 24.2 22.3 26.8 25.5 25.1
83 16.4 20.4 24.6 24.2 19.3 23.8 25.5 25.1
80 14.1 18.0 22.3 24.2 16.3 20.8 25.5 25.1
77 11.8 15.7 20.0 21.9 13.3 17.8 22.5 22.1
74 9.4 13.4 17.7 19.6 10.3 14.9 19.5 19.2
71 -- 11.0 15.3 17.2 -- 11.9 16.5 16.2
68 -- 8.7 13.0 14.9 -- 8.9 13.5 13.2
95 °F
NET CAP. MBH 27.4 25.5 23.2 22.7 28.1 26.2 23.8 23.3
TOTAL POWER kW 2.23 2.23 2.21 2.16 2.31 2.31 2.29 2.24
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 18.7 22.9 23.2 22.7 21.5 26.2 23.8 23.3
83 16.3 20.6 23.2 22.7 18.5 23.2 23.8 23.3
80 14.0 18.2 22.2 22.7 15.5 20.2 23.8 23.3
77 11.7 15.9 19.9 20.4 12.6 17.3 20.8 20.4
74 9.3 13.6 17.6 18.1 9.6 14.3 17.8 17.4
71 -- 11.2 15.2 15.7 -- 11.3 14.9 14.4
68 -- 8.9 12.9 13.4 -- 8.3 11.9 11.4
105 °F
NET CAP. MBH 25.5 23.1 20.9 21.1 26.3 23.9 21.6 21.8
TOTAL POWER kW 2.51 2.50 2.47 2.44 2.61 2.61 2.58 2.54
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 17.8 21.8 20.9 21.1 20.9 23.9 21.6 21.8
83 15.5 19.5 20.9 21.1 18.0 22.4 21.6 21.8
80 13.1 17.1 20.4 21.1 15.0 19.6 21.6 21.8
77 10.8 14.8 18.1 18.8 12.0 16.6 18.6 18.8
74 8.5 12.5 15.8 16.5 9.0 13.6 15.6 15.9
71 -- 10.1 13.4 14.1 -- 10.6 12.6 12.9
68 -- 7.8 11.1 11.8 -- 7.6 9.7 9.9
115 °F
NET CAP. MBH 23.5 20.7 18.6 19.5 24.5 21.6 19.4 20.3
TOTAL POWER kW 2.79 2.78 2.74 2.72 2.91 2.90 2.86 2.85
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 16.9 20.7 18.6 19.5 20.4 21.6 19.4 20.3
83 14.6 18.4 18.6 19.5 17.4 21.6 19.4 20.3
80 12.3 16.1 18.6 19.5 14.4 18.9 19.4 20.3
77 9.9 13.7 16.3 17.2 11.4 15.9 16.4 17.3
74 7.6 11.4 13.9 14.8 8.4 12.9 13.4 14.3
71 -- 9.1 11.6 12.5 -- 9.9 10.4 11.4
68 -- 6.7 9.3 10.2 -- 6.9 7.4 8.4
125 °F
NET CAP. MBH 21.6 18.3 16.3 17.9 22.7 19.2 17.2 18.8
TOTAL POWER kW 3.06 3.05 3.00 3.00 3.21 3.20 3.14 3.15
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 16.0 19.6 16.3 17.9 19.8 19.2 17.2 18.8
83 13.7 17.3 16.3 17.9 16.8 20.7 17.2 18.8
80 11.4 15.0 16.8 17.9 13.8 18.2 17.2 18.8
77 9.1 12.6 14.5 15.5 10.9 15.2 14.2 15.8
74 6.7 10.3 12.1 13.2 7.9 12.2 11.2 12.8
71 -- 8.0 9.8 10.9 -- 9.2 8.2 9.8
68 -- 5.6 7.5 8.5 -- 6.3 5.2 6.8
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
Unitary Products Group 9
TABLE 4: DNZ030 COOLING CAPACITIES - 2-1/2 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,000 CFM 1,250 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 32.7 31.0 28.7 28.7 33.3 31.6 29.2 29.2
TOTAL POWER kW 2.10 2.10 2.10 2.09 2.28 2.29 2.29 2.27
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 22.2 27.8 28.7 28.7 25.7 31.6 29.2 29.2
83 19.3 24.9 28.7 28.7 21.9 28.2 29.2 29.2
80 16.4 22.0 27.2 28.7 18.2 24.4 29.2 29.2
77 13.5 19.0 24.3 25.8 14.5 20.7 25.4 25.5
74 10.5 16.1 21.4 22.9 10.8 17.0 21.7 21.8
71 -- 13.2 18.5 20.0 -- 13.2 18.0 18.0
68 -- 10.3 15.6 17.1 -- 9.5 14.2 14.3
95 °F
NET CAP. MBH 31.2 29.2 26.6 26.8 31.8 29.7 27.2 27.4
TOTAL POWER kW 2.36 2.36 2.35 2.33 2.55 2.54 2.53 2.51
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 21.8 27.3 26.6 26.8 25.2 29.7 27.2 27.4
83 18.9 24.4 26.6 26.8 21.5 27.7 27.2 27.4
80 15.9 21.5 26.3 26.8 17.8 24.0 27.2 27.4
77 13.0 18.6 23.4 23.9 14.1 20.3 23.4 23.7
74 10.1 15.7 20.5 21.0 10.3 16.5 19.7 19.9
71 -- 12.8 17.5 18.1 -- 12.8 16.0 16.2
68 -- 9.9 14.6 15.2 -- 9.1 12.3 12.5
105 °F
NET CAP. MBH 28.9 26.6 24.7 24.9 29.5 27.2 25.1 25.4
TOTAL POWER kW 2.67 2.66 2.65 2.64 2.85 2.85 2.83 2.82
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 21.0 25.7 24.7 24.9 24.6 27.2 25.1 25.4
83 18.1 23.4 24.7 24.9 20.9 26.1 25.1 25.4
80 15.2 20.5 24.5 24.9 17.2 23.2 25.1 25.4
77 12.3 17.6 21.6 22.0 13.4 19.5 21.4 21.7
74 9.3 14.7 18.7 19.1 9.7 15.8 17.7 18.0
71 -- 11.8 15.8 16.2 -- 12.1 14.0 14.2
68 -- 8.9 12.8 13.3 -- 8.3 10.2 10.5
115 °F
NET CAP. MBH 26.7 24.1 22.7 23.0 27.2 24.6 23.1 23.4
TOTAL POWER kW 2.97 2.97 2.94 2.94 3.16 3.16 3.13 3.13
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 20.2 24.1 22.7 23.0 24.0 24.6 23.1 23.4
83 17.3 22.5 22.7 23.0 20.3 24.6 23.1 23.4
80 14.4 19.5 22.7 23.0 16.6 22.5 23.1 23.4
77 11.5 16.6 19.8 20.1 12.8 18.7 19.4 19.7
74 8.6 13.7 16.9 17.2 9.1 15.0 15.6 16.0
71 -- 10.8 14.0 14.3 -- 11.3 11.9 12.3
68 -- 7.9 11.0 11.4 -- 7.6 8.2 8.5
125 °F
NET CAP. MBH 24.5 21.6 20.8 21.2 24.9 22.0 21.1 21.5
TOTAL POWER kW 3.28 3.28 3.24 3.25 3.47 3.47 3.43 3.44
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 19.5 22.5 20.8 21.2 23.4 22.0 21.1 21.5
83 16.5 21.5 20.8 21.2 19.7 23.0 21.1 21.5
80 13.6 18.6 20.9 21.2 15.9 21.7 21.1 21.5
77 10.7 15.6 18.0 18.2 12.2 18.0 17.3 17.8
74 7.8 12.7 15.1 15.3 8.5 14.3 13.6 14.0
71 -- 9.8 12.2 12.4 -- 10.5 9.9 10.3
68 -- 6.9 9.3 9.5 -- 6.8 6.2 6.6
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
10 Unitary Products Group
TABLE 5: DNZ036 COOLING CAPACITIES - 3 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,200 CFM 1,350 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 40.9 38.4 35.2 35.9 41.2 38.7 35.4 36.1
TOTAL POWER kW 2.93 2.94 2.90 2.85 3.05 3.06 3.02 2.97
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 27.6 34.7 35.2 35.9 29.3 36.6 35.4 36.1
83 24.2 31.2 35.2 35.9 25.3 32.6 35.4 36.1
80 20.7 27.7 33.4 35.9 21.3 28.6 34.4 36.1
77 17.2 24.2 29.9 32.4 17.3 24.6 30.4 32.1
74 13.7 20.7 26.4 28.9 13.2 20.5 26.3 28.1
71 -- 17.2 22.9 25.4 -- 16.5 22.3 24.0
68 -- 13.7 19.4 21.9 -- 12.5 18.3 20.0
95 °F
NET CAP. MBH 39.0 36.1 33.2 33.6 39.3 36.4 33.5 33.9
TOTAL POWER kW 3.24 3.23 3.18 3.19 3.48 3.48 3.42 3.43
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 27.1 33.7 33.2 33.6 28.5 35.2 33.5 33.9
83 23.6 30.2 33.2 33.6 24.4 31.2 33.5 33.9
80 20.1 26.7 32.2 33.6 20.4 27.2 32.8 33.9
77 16.6 23.2 28.7 30.1 16.4 23.2 28.7 29.8
74 13.1 19.7 25.2 26.6 12.4 19.1 24.7 25.8
71 -- 16.2 21.7 23.1 -- 15.1 20.7 21.8
68 -- 12.7 18.2 19.6 -- 11.1 16.7 17.8
105 °F
NET CAP. MBH 36.7 33.0 31.0 31.4 37.1 33.3 31.4 31.7
TOTAL POWER kW 3.39 3.58 3.54 3.54 3.58 3.78 3.73 3.74
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 26.7 31.8 31.0 31.4 28.3 32.8 31.4 31.7
83 23.2 29.0 31.0 31.4 24.2 30.2 31.4 31.7
80 19.7 25.5 30.4 31.4 20.2 26.2 31.0 31.7
77 16.2 22.0 26.9 27.9 16.2 22.2 27.0 27.7
74 12.7 18.5 23.4 24.4 12.2 18.1 23.0 23.7
71 -- 15.0 19.9 20.9 -- 14.1 18.9 19.7
68 -- 11.5 16.4 17.4 -- 10.1 14.9 15.6
115 °F
NET CAP. MBH 34.4 29.8 28.8 29.2 35.0 30.3 29.3 29.6
TOTAL POWER kW 3.55 3.94 3.89 3.89 3.69 4.09 4.04 4.04
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 26.3 29.8 28.8 29.2 28.1 30.3 29.3 29.6
83 22.8 27.7 28.8 29.2 24.0 29.2 29.3 29.6
80 19.3 24.2 28.5 29.2 20.0 25.2 29.3 29.6
77 15.8 20.7 25.0 25.7 16.0 21.1 25.3 25.6
74 12.3 17.2 21.5 22.2 12.0 17.1 21.2 21.6
71 -- 13.7 18.0 18.7 -- 13.1 17.2 17.6
68 -- 10.2 14.5 15.2 -- 9.1 13.2 13.5
125 °F
NET CAP. MBH 32.1 26.7 26.6 27.0 32.8 27.3 27.2 27.5
TOTAL POWER kW 3.71 4.29 4.24 4.24 3.79 4.39 4.35 4.35
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 25.9 27.9 26.6 27.0 27.9 27.8 27.2 27.5
83 22.4 26.5 26.6 27.0 23.8 28.2 27.2 27.5
80 18.9 23.0 26.7 27.0 19.8 24.1 27.5 27.5
77 15.4 19.5 23.2 23.5 15.8 20.1 23.5 23.5
74 11.9 16.0 19.7 20.0 11.8 16.1 19.5 19.5
71 -- 12.5 16.2 16.5 -- 12.1 15.5 15.4
68 -- 9.0 12.7 13.0 -- 8.0 11.4 11.4
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
Unitary Products Group 11
TABLE 6: DNZ042 COOLING CAPACITIES - 3-1/2 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,150 CFM 1,400 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 45.4 42.9 39.9 39.7 45.6 43.2 40.1 39.9
TOTAL POWER kW 3.26 3.23 3.22 3.17 3.47 3.45 3.43 3.38
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 27.2 35.3 39.9 39.7 30.9 39.8 40.1 39.9
83 24.0 32.1 39.3 39.7 26.8 35.7 40.1 39.9
80 20.7 28.8 36.1 36.9 22.7 31.6 39.6 40.6
77 17.4 25.5 32.8 33.7 18.6 27.5 35.5 36.5
74 14.1 22.2 29.5 30.4 14.5 23.5 31.4 32.4
71 -- 19.0 26.2 27.1 -- 19.4 27.4 28.3
68 -- 15.7 23.0 23.8 -- 15.3 23.3 24.2
95 °F
NET CAP. MBH 43.1 40.2 37.2 37.5 43.6 40.7 37.7 38.0
TOTAL POWER kW 3.59 3.55 3.51 3.49 3.80 3.76 3.72 3.70
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 26.3 34.3 37.2 37.5 30.3 39.2 37.7 38.0
83 23.1 31.1 37.2 37.5 26.2 35.1 37.7 38.0
80 19.8 27.8 34.3 34.5 22.1 31.0 38.3 38.6
77 16.5 24.5 31.0 31.3 18.0 27.0 34.3 34.5
74 13.2 21.2 27.8 28.0 13.9 22.9 30.2 30.4
71 -- 17.9 24.5 24.7 -- 18.8 26.1 26.3
68 -- 14.7 21.2 21.4 -- 14.7 22.0 22.3
105 °F
NET CAP. MBH 39.9 36.7 34.5 34.7 40.6 37.3 35.1 35.3
TOTAL POWER kW 3.99 3.95 3.84 3.88 4.20 4.16 4.05 4.09
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 25.5 33.0 34.5 34.7 29.4 36.5 35.1 35.3
83 22.2 29.7 34.5 34.7 25.3 33.7 35.1 35.3
80 19.0 26.5 32.0 32.1 21.3 29.7 35.9 35.9
77 15.7 23.2 28.8 28.8 17.2 25.6 31.8 31.8
74 12.4 19.9 25.5 25.5 13.1 21.5 27.7 27.8
71 -- 16.6 22.2 22.2 -- 17.4 23.7 23.7
68 -- 13.3 18.9 18.9 -- 13.3 19.6 19.6
115 °F
NET CAP. MBH 36.7 33.1 31.7 32.0 37.6 33.9 32.5 32.7
TOTAL POWER kW 4.39 4.34 4.18 4.28 4.60 4.55 4.38 4.48
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 24.7 31.7 31.7 32.0 28.6 33.9 32.5 32.7
83 21.4 28.4 31.7 32.0 24.5 32.4 32.5 32.7
80 18.1 25.1 29.7 29.6 20.4 28.3 33.5 33.3
77 14.9 21.9 26.5 26.3 16.3 24.2 29.4 29.2
74 11.6 18.6 23.2 23.0 12.2 20.1 25.3 25.1
71 -- 15.3 19.9 19.7 -- 16.0 21.2 21.0
68 -- 12.0 16.6 16.4 -- 12.0 17.1 16.9
125 °F
NET CAP. MBH 33.5 29.6 29.0 29.3 34.5 30.5 29.8 30.1
TOTAL POWER kW 4.79 4.74 4.51 4.67 5.00 4.95 4.71 4.88
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 23.9 30.4 29.0 29.3 27.7 31.2 29.8 30.1
83 20.6 27.1 29.0 29.3 23.6 31.0 29.8 30.1
80 17.3 23.8 27.5 27.1 19.6 26.9 31.0 30.6
77 14.0 20.5 24.2 23.8 15.5 22.8 26.9 26.5
74 10.8 17.3 20.9 20.5 11.4 18.8 22.9 22.4
71 -- 14.0 17.6 17.2 -- 14.7 18.8 18.3
68 -- 10.7 14.3 14.0 -- 10.6 14.7 14.3
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
12 Unitary Products Group
TABLE 7: DNZ048 COOLING CAPACITIES - 4 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,400 CFM 1,600 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 37.9 48.6 45.6 45.8 38.3 49.1 46.1 46.3
TOTAL POWER kW 4.61 3.34 3.22 3.19 4.80 3.47 3.35 3.32
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 37.9 43.1 45.6 45.8 38.3 46.7 46.1 46.3
83 34.6 39.1 45.6 45.8 37.2 42.0 46.1 46.3
80 30.6 35.1 42.6 43.5 32.5 37.3 45.3 46.3
77 26.6 31.2 38.6 39.6 27.9 32.7 40.6 41.6
74 22.6 27.2 34.6 35.6 23.2 28.0 36.0 36.9
71 -- 23.2 30.6 31.6 -- 23.4 31.3 32.3
68 -- 19.2 26.7 27.6 -- 18.7 26.6 27.6
95 °F
NET CAP. MBH 49.2 45.7 43.2 44.0 49.1 45.5 43.1 43.9
TOTAL POWER kW 3.75 3.72 3.54 3.52 3.94 3.91 3.72 3.70
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 32.7 42.0 43.2 44.0 35.5 45.4 43.1 43.9
83 28.7 38.0 43.2 44.0 30.9 40.7 43.1 43.9
80 24.7 34.0 40.6 41.0 26.2 36.1 43.1 43.5
77 20.7 30.0 36.6 37.1 21.6 31.4 38.4 38.9
74 16.7 26.0 32.7 33.1 16.9 26.7 33.8 34.2
71 -- 22.0 28.7 29.1 -- 22.1 29.1 29.5
68 -- 18.0 24.7 25.1 -- 17.4 24.4 24.9
105 °F
NET CAP. MBH 45.1 41.7 39.6 40.3 45.4 41.9 39.8 40.5
TOTAL POWER kW 4.22 4.18 4.00 3.98 4.40 4.35 4.17 4.15
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 31.7 39.9 39.6 40.3 34.3 41.9 39.8 40.5
83 27.7 36.5 39.6 40.3 29.7 39.0 39.8 40.5
80 23.7 32.5 37.7 38.2 25.0 34.3 39.8 40.2
77 19.7 28.5 33.7 34.2 20.3 29.6 35.1 35.6
74 15.7 24.5 29.8 30.2 15.7 25.0 30.5 30.9
71 -- 20.5 25.8 26.2 -- 20.3 25.8 26.2
68 -- 16.6 21.8 22.2 -- 15.6 21.1 21.6
115 °F
NET CAP. MBH 41.0 37.8 36.0 36.7 41.6 38.3 36.5 37.2
TOTAL POWER kW 4.69 4.64 4.46 4.45 4.85 4.80 4.62 4.60
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 30.7 37.8 36.0 36.7 33.1 38.3 36.5 37.2
83 26.7 35.0 36.0 36.7 28.5 37.2 36.5 37.2
80 22.7 31.0 34.8 35.3 23.8 32.5 36.5 37.0
77 18.7 27.0 30.8 31.3 19.1 27.9 31.8 32.3
74 14.7 23.1 26.8 27.3 14.5 23.2 27.2 27.6
71 -- 19.1 22.9 23.3 -- 18.5 22.5 23.0
68 -- 15.1 18.9 19.3 -- 13.9 17.8 18.3
125 °F
NET CAP. MBH 36.9 33.9 32.4 33.0 37.9 34.7 33.2 33.8
TOTAL POWER kW 5.17 5.11 4.92 4.91 5.31 5.25 5.06 5.05
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 29.7 35.7 32.4 33.0 31.9 34.8 33.2 33.8
83 25.7 33.5 32.4 33.0 27.3 35.4 33.2 33.8
80 21.7 29.6 31.9 32.4 22.6 30.8 33.2 33.7
77 17.7 25.6 27.9 28.4 17.9 26.1 28.5 29.0
74 13.7 21.6 23.9 24.4 13.3 21.4 23.9 24.3
71 -- 17.6 19.9 20.4 -- 16.8 19.2 19.7
68 -- 13.6 16.0 16.4 -- 12.1 14.5 15.0
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
Unitary Products Group 13
TABLE 8: DNZ060 COOLING CAPACITIES - 5 TON
TEMPERATURE
OF AIR ON
CONDENSER COIL
AIR ON EVAPORATOR COIL
1,800 CFM 2,000 CFM
WB °F WB °F
72 67 62 57 72 67 62 57
85 °F
NET CAP. MBH 63.2 58.9 54.7 54.9 63.5 59.2 55.0 55.2
TOTAL POWER kW 5.64 5.63 5.53 5.39 5.84 5.82 5.72 5.57
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 44.9 56.1 54.7 54.9 47.7 59.2 55.0 55.2
83 39.4 50.5 54.7 54.9 41.4 53.0 55.0 55.2
80 33.9 45.0 54.7 58.2 35.2 46.7 55.0 55.2
77 28.3 39.5 49.2 52.6 28.9 40.5 48.7 48.9
74 22.8 33.9 43.6 47.1 22.7 34.2 42.4 42.6
71 -- 28.4 38.1 41.6 -- 28.0 36.2 36.4
68 -- 22.8 32.6 36.0 -- 21.7 29.9 30.1
95 °F
NET CAP. MBH 59.9 55.9 52.3 52.0 59.5 55.6 52.0 51.7
TOTAL POWER kW 6.26 6.17 6.03 5.95 6.53 6.43 6.29 6.21
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 43.9 54.9 52.3 52.0 46.6 55.6 52.0 51.7
83 38.3 49.4 52.3 52.0 40.4 51.9 52.0 51.7
80 32.8 43.9 53.1 55.1 34.1 45.6 52.0 51.7
77 27.3 38.3 47.5 49.6 27.9 39.4 45.8 45.4
74 21.7 32.8 42.0 44.0 21.6 33.1 39.5 39.2
71 -- 27.2 36.4 38.5 -- 26.8 33.2 32.9
68 -- 21.7 30.9 33.0 -- 20.6 27.0 26.7
105 °F
NET CAP. MBH 55.6 51.5 48.2 51.0 55.5 51.4 48.2 50.9
TOTAL POWER kW 6.86 6.78 6.78 6.55 7.10 7.02 7.01 6.78
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 42.2 51.0 48.2 51.0 44.9 51.4 48.2 50.9
83 36.7 47.4 48.2 51.0 38.6 49.6 48.2 50.9
80 31.1 41.8 49.9 54.0 32.4 43.5 48.2 50.9
77 25.6 36.3 44.4 48.5 26.1 37.3 41.9 44.7
74 20.0 30.7 38.8 42.9 19.9 31.0 35.7 38.4
71 -- 25.2 33.3 37.4 -- 24.7 29.4 32.2
68 -- 19.7 27.7 31.9 -- 18.5 23.1 25.9
115 °F
NET CAP. MBH 51.3 47.0 44.1 49.9 51.5 47.2 44.3 50.2
TOTAL POWER kW 7.46 7.39 7.52 7.14 7.67 7.61 7.74 7.34
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 40.5 47.0 44.1 49.9 43.2 47.2 44.3 50.2
83 35.0 45.3 44.1 49.9 36.9 47.2 44.3 50.2
80 29.4 39.8 46.8 52.9 30.7 41.4 44.3 50.2
77 23.9 34.2 41.2 47.4 24.4 35.2 38.1 43.9
74 18.4 28.7 35.7 41.8 18.1 28.9 31.8 37.7
71 -- 23.2 30.1 36.3 -- 22.7 25.6 31.4
68 -- 17.6 24.6 30.8 -- 16.4 19.3 25.1
125 °F
NET CAP. MBH 46.9 42.5 40.0 48.9 47.5 43.1 40.5 49.4
TOTAL POWER kW 8.05 8.00 8.26 7.73 8.25 8.19 8.46 7.91
Sensible Capacity
MBH1
Entering Dry
Bulb °F
86 38.8 43.0 40.0 48.9 41.5 43.1 40.5 49.4
83 33.3 43.3 40.0 48.9 35.2 44.9 40.5 49.4
80 27.8 37.8 43.6 51.8 28.9 39.4 40.5 49.4
77 22.2 32.2 38.1 46.3 22.7 33.1 34.2 43.2
74 16.7 26.7 32.5 40.7 16.4 26.8 28.0 36.9
71 -- 21.1 27.0 35.2 -- 20.6 21.7 30.6
68 -- 15.6 21.4 29.6 -- 14.3 15.5 24.4
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity.
ALL SENSIBLE CAPACITY

036-21548-001-D-0405
14 Unitary Products Group
TABLE 9: SIDE SUPPLY AIR BLOWER PERFORMANCE - 208/230 VOLTS1
MODEL #
DNZ MODE (COOLING / HEATING) CFM
EXTERNAL STATIC PRESSURE - IWG
.20 .30 .40 .50 .60 .70 .80 .90 1.0
WATTS WATTS WATTS WATTS WATTS WATTS WATTS WATTS WATTS
024 HEATING (2 TUBE)
(FACTORY SETTING) 1000 277 292 316 357 399 430 454 ~ ~
024 HEATING (3 TUBE)
(FACTORY SETTING) 1150 362 400 435 473 511 544 578 ~ ~
024 COOLING
(FACTORY SETTING) 800 161 190 218 243 268 297 326 ~ ~
024 COOLING
(FIELD SETTING) 1000 277 292 316 357 399 430 454 ~ ~
030 COOLING
(FACTORY SETTING) 1000 248 298 325 365 385 411 470 498 500
030 COOLING
(FIELD SETTING) 1250 342 385 431 474 510 562 614 657 694
030 HEATING (2 TUBE)
(FACTORY SETTING) 850 169 217 237 278 302 334 374 401 431
030 HEATING (3 TUBE)
(FACTORY SETTING) 1100 300 338 378 416 447 493 539 576 609
036 COOLING
(FACTORY SETTING) 1200 354 396 436 511 548 599 641 677 721
036 COOLING
(FIELD SETTING) 1350 442 503 563 606 648 685 721 774 826
036 HEATING (2 TUBE)
(FACTORY SETTING) 700 207 231 254 298 320 349 ~ ~ ~
036 HEATING (3 TUBE)
(FACTORY SETTING) 1250 383 432 478 543 581 628 ~ ~ ~
036 HEATING (4 TUBE)
(FACTORY SETTING) 1350 442 503 563 606 648 685 ~ ~ ~
042 COOLING
(FACTORY SETTING) 1150 348 388 428 489 549 584 620 663 705
042 COOLING
(FIELD SETTING) 1400 418 465 514 596 678 742 772 811 873
042 HEATING (3 TUBE)
(FACTORY SETTING) 1500 450 500 553 641 729 798 830 872 939
042 HEATING (4 TUBE)
(FACTORY SETTING) 1275 388 433 478 545 612 652 691 739 787
048 COOLING
(FACTORY SETTING) 1400 427 476 525 599 673 716 759 812 865
048 COOLING
(FIELD SETTING) 1600 476 532 587 687 786 872 958 994 1030
048 HEATING (3 TUBE)
(FACTORY SETTING) 1525 458 511 564 654 744 814 ~ ~ ~
048 HEATING (4 TUBE)
(FACTORY SETTING) 1600 476 532 587 687 786 872 ~ ~ ~
048 HEATING (5 TUBE)
(FACTORY SETTING) 1600 476 532 587 687 786 872 ~ ~ ~
060 HEATING (3 TUBE)
(FACTORY SETTING) 1500 297 348 400 470 540 610 680 750 820
060 HEATING (4 & 5 TUBE)
(FACTORY SETTING) 1700 443 497 550 620 690 760 830 900 ~
060 COOLING
(FACTORY SETTING) 1800 515 570 625 690 755 820 962 ~ ~
060 COOLING
(FIELD SETTING) 2000 700 760 820 928 ~ ~ ~ ~ ~
1. Above data includes allowances for a dry coil, gas heat exchanger and no filters. For additional pressure drops, refer to Tables 11
and 12.

036-21548-001-D-0405
Unitary Products Group 15
TABLE 10: BOTTOM SUPPLY AIR BLOWER PERFORMANCE - 208/230 VOLTS1
MODEL #
DNZ MODE (COOLING / HEATING) CFM
EXTERNAL STATIC PRESSURE - IWG
.20 .30 .40 .50 .60 .70 .80 .90 1.0
WATTS WATTS WATTS WATTS WATTS WATTS WATTS WATTS WATTS
024 HEATING (2 TUBE)
(FACTORY SETTING) 1000 277 292 316 357 399 430 454 ~ ~
024 HEATING (3 TUBE)
(FACTORY SETTING) 1150 362 400 435 473 511 544 578 ~ ~
024 COOLING
(FACTORY SETTING) 800 161 190 218 243 268 297 326 ~ ~
024 COOLING
(FIELD SETTING) 1000 277 292 316 357 399 430 454 ~ ~
030 COOLING
(FACTORY SETTING) 1000 248 298 325 365 385 411 470 498 500
030 COOLING
(FIELD SETTING) 1250 342 385 431 474 510 562 614 657 694
030 HEATING (2 TUBE)
(FACTORY SETTING) 850 169 217 237 278 302 334 374 401 431
030 HEATING (3 TUBE)
(FACTORY SETTING) 1100 300 338 378 416 447 493 539 576 609
036 COOLING
(FACTORY SETTING) 1200 354 396 436 511 548 599 641 677 721
036 COOLING
(FIELD SETTING) 1350 442 503 563 606 648 685 721 774 826
036 HEATING (2 TUBE)
(FACTORY SETTING) 700 207 231 254 298 320 349 ~ ~ ~
036 HEATING (3 TUBE)
(FACTORY SETTING) 1250 383 432 478 543 581 628 ~ ~ ~
036 HEATING (4 TUBE)
(FACTORY SETTING) 1350 442 503 563 606 648 685 ~ ~ ~
042 COOLING
(FACTORY SETTING) 1150 348 388 428 489 549 584 620 663 705
042 COOLING
(FIELD SETTING) 1400 418 465 514 596 678 742 772 811 873
042 HEATING (3 TUBE)
(FACTORY SETTING) 1500 450 500 553 641 729 798 830 872 939
042 HEATING (4 TUBE)
(FACTORY SETTING) 1275 388 433 478 545 612 652 691 739 787
048 COOLING
(FACTORY SETTING) 1400 427 476 525 599 673 716 759 812 865
048 COOLING
(FIELD SETTING) 1600 476 532 587 687 786 872 958 994 1030
048 HEATING (3 TUBE)
(FACTORY SETTING) 1525 458 511 564 654 744 814 ~ ~ ~
048 HEATING (4 TUBE)
(FACTORY SETTING) 1600 476 532 587 687 786 872 ~ ~ ~
048 HEATING (5 TUBE)
(FACTORY SETTING) 1600 476 532 587 687 786 872 ~ ~ ~
060 HEATING (3 TUBE)
(FACTORY SETTING) 1500 297 348 400 470 540 610 680 750 820
060 HEATING (4 & 5 TUBE)
(FACTORY SETTING) 1700 443 497 550 620 690 760 830 900 ~
060 COOLING
(FACTORY SETTING) 1800 515 570 625 690 755 820 962 ~ ~
060 COOLING
(FIELD SETTING) 2000 700 760 820 928 ~ ~ ~ ~ ~
1. Above data includes allowances for a dry coil, gas heat exchanger and no filters. For additional pressure drops, refer to Tables 11
and 12.

036-21548-001-D-0405
16 Unitary Products Group
FIGURE 2 - FIELD WIRING DIAGRAM CONTROL WIRING
TABLE 11: ADDITIONAL STATIC PRESSURE RESISTANCE - 2, 2-1/2 AND 3 TON
DESCRIPTION
RESISTANCE, IWG
CFM
500 600 700 800 900 1,000 1,100 1,200 1,300 1,400 1,500 1,600
WET EVAPORATOR COIL .01 .01 .01 .02 .03 .04 .05 .06 .07 .08 .09 .09
ECONOMIZER1.00 .00 .00 .01 .01 .01 .01 .02 .03 .04 .05 .06
FILTER FRAME KIT .01 .02 .04 .06 .08 .10 .13 .16 .17 .18 .19 .20
1. The pressure through the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air
duct system is less than 0.25 IWG, the unit will deliver less CFM during full economizer operation.
TABLE 12: ADDITIONAL STATIC PRESSURE RESISTANCE - 3-1/2, 4 AND 5 TON
DESCRIPTION
RESISTANCE, IWG
CFM
1,100 1,200 1,300 1,400 1,500 1,600 1,700 1,800 1,900 2,000
WET EVAPORATOR COIL .02 .03 .04 .05 .06 .07 .07 .08 .09 .09
ECONOMIZER1.02 .02 .02 .03 .03 .04 .04 .04 .05 .05
FILTER FRAME KIT .04 .04 .05 .05 .06 .07 .08 .09 .10 .11
1. The pressure through the economizer is greater for 100% outdoor air than for 100% return air. If the resistance of the return air
duct system is less than 0.25 IWG, the unit will deliver less CFM during full economizer operation.
R
G
W
R
G
C
YY
W
C
PROGRAMMABLE
THERMOSTAT ONLY
**
*
*=Minimumwiresizeof18AWG
wire should be used for all
field installed 24 volt wire.
THERMOSTAT UNIT TERMINAL STRIP
NOTE:
HEAT ANTICIPATOR
SHOULD BE SET AT 0.35
AMPS FOR ALL MODELS.
24 VOLT
TRANSFORMER

036-21548-001-D-0405
Unitary Products Group 17
FIGURE 3 - POWER WIRING FIELD DIAGRAM
G R O U N D
L U G
R E F E R T O E L E C T R I C A L
D A T A T A B L E S T O S I Z E
T H E D I S C O N N E C T
F I E L D - S U P P L I E D
D I S C O N N E C T
C O N T A C T O R
F I E L D - S U P P L I E D
D I S C O N N E C T
C O N T A C T O R
G R O U N D
L U G R E F E R T O E L E C T R I C A L
D A T A T A B L E S T O S I Z E
T H E D I S C O N N E C T
S I N G L E
PH A S E
P O W E R
S U P P L Y
T H R E E
PHASE
P O W E R
S U P P L Y
TABLE 13:ELECTRICAL DATA
MODEL
DNZ POWER SUPPLY
VOLTAGE
LIMITATIONS1COMPRESSOR COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
024 208/230-1-60 187 253 12.8 60 1.0 2.5 19.5 30 30 0.96 40
030 208/230-1-60 187 253 14.7 72.5 1.0 5.0 24.4 35 35 0.96 40
030 208/230-3-60 187 253 10.4 60 1.0 5.0 19.0 25 25 0.96 75
030 460-3-60 414 504 4.5 31 0.5 2.5 8.6 15 15 0.96 75
036 208/230-1-60 187 253 15.4 83 1.0 4.4 24.7 40 40 0.96 40
036 208/230-3-60 187 253 11.5 77 1.0 4.4 19.8 30 30 0.96 75
036 460-3-60 414 504 5.1 35 0.5 2.2 9.1 15 15 0.96 75
042 208/230-1-60 187 253 18.6 105 1.2 3.5 28.0 45 45 0.96 40
042 208/230-3-60 187 253 13.4 88 1.2 3.5 21.5 30 30 0.96 75
042 460-3-60 414 504 6.4 39 0.6 1.8 10.4 15 15 0.96 75
048 208/230-1-60 187 253 20.5 109 1.6 5.1 32.3 50 50 0.96 40
048 208/230-3-60 187 253 14.5 91 1.6 5.1 24.8 35 35 0.96 75
048 460-3-60 414 504 7.0 46 0.8 2.6 12.2 15 15 0.96 75
060 208/230-1-60 187 253 27.5 158 1.6 8.9 44.9 70 70 0.96 40
060 208/230-3-60 187 253 18.1 137 1.6 8.9 33.1 50 50 0.96 75
060 460-3-60 414 504 9.0 62 0.8 4.5 16.6 25 25 0.96 75
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element, time delay type.

036-21548-001-D-0405
18 Unitary Products Group
FIGURE 4 - UNIT DIMENSIONS - FRONT
3-3/4
2-1/2
47-1/4
1-1/2
2-5/8
3-1/3
5-3/8 11 12-3/4 49-1/8
A
2-3/8
VENT AIR OUTLET HOOD
BLOWER SERVICE
ACCESS COMPARTMENT
PANEL
GAS SUPPLY 1-1/4" DIA.
HOLE (1/2" NPTI
CONNECTION)
UNIT CONDENSATE
CONNECTION 3/4" NPTI
(TRAP RECOMMENDED)
B
HIGH VOLTAGE
CONN. 1-3/8" DIA.
KNOCKOUT
HIGH VOLTAGE
CONN. 7/8" DIA.
KNOCKOUT
GAS SUPPLY 1-1/4" DIA.
KNOCKOUT (1/2" NPTI
CONNECTION)
LOW VOLTAGE CONN.
1-3/8" DIA. KNOCKOUT
X 7/8" HOLE
CONDENSER COIL
REFRIGERANT
CONNECTIONS
COMBUSTION AIR
INLET LOUVERS
FRONT
GAS/ELECTRIC CONTROL
SERVICE ACCESS
COMPARTMENT PANEL
(OVERALL) (OVERALL)
All dimensions are in inches.
They are subject to change with-
out notice. Certified dimensions
will be provided upon request.
TABLE 14: UNIT DIMENSIONS FRONT
UNIT SIZE DIMENSION
“A” “B”
024, 030, 036 33-1/2 18-1/4
042, 048, 060 41-1/2 23-1/8
TABLE 15: UNIT MINIMUM CLEARANCES12
1. A 1” clearance must be provided between any combus-
tible material and the supply air ductwork.
2. The products of combustion must not be allowed to
accumulate within a confined space and recirculate.
CLEARANCES
FRONT 36”
BACK 0”
LEFT SIDE (Filter-Access) 24”
RIGHT SIDE 12”
BELOW UNIT3
3. Units may be installed on combustible floors made from
wood or class A, B, or C roof covering material.
0”
ABOVE UNIT 4
4. Units must be installed outdoors. Overhanging struc-
tures or shrubs should not obstruct condenser air dis-
charge outlet.
36” (For Condenser Air Discharge)

036-21548-001-D-0405
Unitary Products Group 19
FIGURE 5 - UNIT DIMENSIONS - FRONT & BOTTOM
FIGURE 6 - UNIT DIMENSIONS - BACK & BOTTOM
26-3/4
6
4-5/8
8-7/8 11-7/8 19-1/4
HIGH VOLTAGE
CONN. 1-3/32" DIA.
KNOCKOUT FRONT
CONDENSATE
DRAIN 3/4"' NPTI
GAS SUPPLY 1-5/8" DIA.
KNOCKOUT (1/2" NPTI
CONNECTION)
LOW VOLTAGE CONN.
" DIA. KNOCKOUT
/87
1 - 3 / 4
1 5
2 9 - 9 / 1 6
1 5
3 - 1 / 2
1 - 3 / 4
1 - 3 / 4
1 5
4
1 4 - 1 / 2
3 - 1 / 2
3 - 3 / 8
1 4 - 1 / 2
2 8 - 3 / 8
1 4 - 1 / 2
C O N D E N S E R
C O I L
B O T T O M S U P P L Y
A I R O P E N I N G
B O T T O M R E T U R N
A I R O P E N I N G
S I D E R E T U R N
A I R O P E N I N G
S I D E S U P P L Y
A I R O P E N I N G
B A C K

036-21548-001-D-0405
20 Unitary Products Group
FIGURE 7 - TYPICAL SLAB ON GROUND INSTALLATION
FIGURE 8 - TYPICAL ROOF CURB INSTALLATION
F I E L D S U P P L I E D
D I S C O N N E C T S I T C H
L O C A T E D T O R E A R O F U N I T
T O G A S
S
U P P L Y L I N E
M A N U A L G A S
S H U T - O F F V A L V E
R E T U R N A I R
D U C T
SUPPLY AI
R
D U C T
C O N T R O L I R I N G
T O I N D O O R
T H E R M O S T A T
T O P O E R S U P P Y
M A N U A L G A S
S H U T - O F F V A L V E
F I E L D
S U P P L I E D
D I S C O N N E C T
S I T C H
M O U N T E D
O N U N I T
T O P O E R
S U P P L Y
T O G A S
S U P P L Y L I N E
C O N T R O L I R I N G
T O I N D O O R T H E R M O S T A T
R E T U R N A I R
D U C T
S U P P L Y A I R
D U C T
