Yowza NAVARRE PILOT User manual

NAVARRE PILOT Elliptical
※TABLE OF CONTENTS
1. PRECAUTIONS．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P1
2. POWER REQUIRMENTS．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P2
3. BEFORE YOU BEGIN．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P3
4. SUPPLIED COMPONENTS / SUPPLIED HARDWARE．．．．．．．．．．．．．． P4~P5
5. PARTS LIST．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P6~P10
6. ASSEMBLY INSTRUCTIONS．．．．．．．．．．．．．．．．．．．．．．．． P11~P19
7. EXPLODED DIAGRAM．．．．．．．．．．．．．．．．．．．．．．．．．．． P20~P23
8. WIRE DIAGRAM．．．．．．．．．．．．．．．．．．．．．．．． ．．．．．．．P24~25
9. STABILIZER ADJUSTMENT．．．．．．．．．．．．．．．．．．．．．．．．．． ．P26
10. TRANSPORT INSTRUCTIONS ．．．．．．．．．．．．．．．．．．．．．．．．．．P27
11. IMPORTANT STEPS．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P28
12. MUSCLE CHART．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P29
13. STRETCHING ROUTINE．．．．．．．．．．．．．．．．．．．．．．．．．．．． P30
14. WARRANTY．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．． P31~P32
15. COMPUTER OPERATION．．．．．．．．．．．．．．．．．．．．．．．．． P33~P38
Yowza Technical Support: 877-969-9240
Serial Number: ________________________
Original Sales Order # ________________________
Purchase Date: ______________

1
http://www.yowzafitness.com/
PRECAUTIONS
Open the boxes:
You are now ready to open the boxes of your new equipment. Make sure to inventory all of the parts that are included in the boxes.
Check the Parts List for a full count of the number of parts included for this product to be assembled properly. If you are missing
any parts or have any assembly questions call your local dealer or contact us directly.
Gather your tools:
Before starting the assembly of your unit, make sure that you have gathered all the necessary tools you may require to assemble
the unit properly. Having all of the necessary equipment at hand will save time and make the assembly quick and hassle-free.
Clear your work area:
Make sure that you have cleared away a large enough space to properly assemble the unit. Make sure the space is free from
anything that may cause injury during assembly. After the unit is fully assembled, make sure there is a comfortable amount of free
area around the unit for unobstructed operation.
Invite a friend:
Some of the assembly steps may require heavy lifting. It is recommended that you obtain the assistance of another person when
assembling this product.
User Weight Limitation:
Please note that there is a weight limitation for this product. If you weigh more than 400lbs. it is not recommended that you use this
product. Serious injury may occur if the user’s weight exceeds the limit shown here. This product is not intended to support users
whose weight exceeds this limit.
Attention:
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.

2
YOWZA NAVARRE PILOT ELLIPTICAL
POWER REQUIREMENTS
IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN THE RISK OF AN ELECTRIC
SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE
PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT, IF IT WILL NOT FIT
THE OUTLET; HAVE A PROPER OUTLET INSTALLED BY A QUALIFIED ELECTRICIAN.
This cross trainer can be seriously damaged by sudden voltage changes in your home’s electrical power. Voltage spikes, surges
and noise interference can result from weather conditions or from other appliances being turned on or off. To reduce the possibility
of cross trainer damage, always use a surge protector (not included) with your cross trainer.
Surge protectors can be purchased at most hardware stores. The manufacturer recommends a single outlet surge protector with a
UL 1449 rating as a Transient Voltage Surge Suppressor (TVSS) with a UL suppressed voltage rating of 400V or less and an
electrical rating 110VAC, 20 amps.
This cross trainer must be grounded to reduce the risk of electrical shock. Grounding provides a path of least resistance for electric
current, should the cross trainer malfunction. This cross trainer is equipped with an electrical cord that has an equipment-
grounding conductor and a grounding plug. Always plug the power cord into a surge protector, and plug the surge protector into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
This product is for use on a nominal 110-volt circuit, and has a grounding plug that looks like the plug illustrated in the drawing
below.
GFCI outlets and GFCI Circuit Breakers are NOT recommended for use on this product. GFCI outlets and GFCI Circuit Breakers
may cause this equipment to function improperly.

3
http://www.yowzafitness.com/
BEFORE YOU BEGIN
Before assembling or using the exercise cycle, please read the following instructions carefully. They contain important information for
use and maintenance of the equipment as well as for your personal safety. Keep these instructions in a safe place for maintenance
purposes or for ordering spare parts.
This product has moving parts and users must be careful not to accidentally pinch fingers or other appendages in the
openings especially while in use. Please keep small children and pets away from this product. Interference with the moving
parts can cause serious injury or death.
Product-Scope: This product is made for home use only and tested up to a maximum body weight of 400lbs.
Product-Performance: This ergo meter is speed independent, i.e. the performance is independent from pedal frequency.
Product-Feature: The resistance can be changed by the computer.
Use-Scope: The exerciser may not be used by persons with a weight of over 400lbs.
Use-Scope: This product is designed for the physical exercise by adults. Please ensure that children only use it under the
supervision of an adult.
Use-Environment: Ensure that those present are aware of possible hazards, e.g. movable parts during training.
Use-Environment: Ensure that sufficient space is available to use the home exerciser.
Use-Environment: Place the home exerciser on an even, non-slippery surface.
Use-Environment: Please ensure that liquids or perspiration never enter the machine or electronics.
Use-Environment: Keep the equipment indoors, away from moisture and dust. Do not put the equipment in a garage or covered
patio, or near water.
Use-Environment: The product is made for home use only. Warranty and manufacturer's liability do not extend to any product or
damage to the product caused by commercial purposes.
User-Health: Consult your physician before starting with any exercise programs to receive advice on the optimal training.
User-Health: Incorrect/excessive training can cause health complications and/or injuries.
User-Health: If you feel any sickness, chest pain, fits of dizziness or breathlessness during your training, immediately stop the
training and consult your physician.
Product-Preparation: Ensure that training only starts after correct assembly, adjustment and inspection of the home exerciser.
Product-Preparation: Follow the instructions for assembly carefully.
Product-Preparation: Only use suitable tools for assembly and ask for assistance if necessary.
Product-Preparation: Only use original Yowza parts as delivered (see checklist).
Use-Preparation: Tighten all adjustable parts to prevent sudden movement while training.
Use-Instruction: Please follow the advice to correct training as detailed in the training instructions.
Use-Instruction: Do not use the home exerciser without shoes or loose shoes.
Use-Safety: Be aware of non-fixed or moving parts whilst mounting or dismounting the home exerciser.
Use-Safety: Use the height adjustment caps on the rear tube to ensure stable position of the home exerciser
Use-Safety: Make sure the front wheels are placed in the correct position: see assembly instructions.
Product-Power-Safety: The unit requires a power supply of 100V –125V / 50-60Hz. It should be connected to a safety socket
with a single 20A fuse. Before commissioning the appliance pay attention to the fact that the correct plug-in power supply unit
(observe marking) has been connected properly
Product-Maintenance: If the equipment is in regular use, check all its components thoroughly every 1 –2 month. Pay particular
attention to the tightness of bolts and nuts. This applies especially to the securing bolts for saddle and handlebars.
Product-Maintenance: Incorrect repairs and structural modifications (e.g. removal or replacement of original parts) may endanger
the safety of the user.
Product-Maintenance: Damaged components may endanger your safety or reduce the lifetime of the equipment. For this reason,
worn or damaged parts should be replaced immediately and the equipment taken out of use until this has been done.
Product-Maintenance: Only use original Yowza spare parts.
Product-Maintenance: Do not under any circumstances carry out electrical repairs or alterations yourself. Always ensure that
such work is done by a properly qualified electrician.
Product-Maintenance: Disconnect the power from the unit before doing repair, maintenance or cleaning work.

4
YOWZA NAVARRE PILOT ELLIPTICAL
SUPPLIED COMPONENTS
This list identifies the major components you will use to assemble this product.
No.
Description
Qty.
102
Moving Handlebar –Left
1
103
Moving Handlebar –Right
1
341
Incline Frame Lower Cover –Rear
2
342
Incline Frame Lower Cover –Front
2
701
Action Arm Lower Cover
4
702
Pedal Arm Front Pivot Cover
2
703
Incline Frame Front Cover
1
704
Undercarriage Cover –Left
1
705
Undercarriage Cover –Right
1
706
Nylon Bushing
2
707
Handle Moving Arm Cove
2
708
Incline Frame Holder –Front
2
709
Water Bottle Holder
1
A1
Button Control Panel Assembly
1
A2
Console Upright Assembly
1
A3
Incline Frame Assembly
1
A4
Main Frame Assembly
1
A
2.5mm Allen Key
1
B
5mm T-Type Allen Key
1
C
8mm Allen Key
1
D
6mm Allen Key
1
E
Screwdriver
1
F
13&17 Wrench
1
G
13 &17 Combination Wrench
1
I
Power Cord
1
J
MP3 Audio Wire
1
341 342103102 701
704 705703702 706
709 A1708707 A2
A4A3
A B C D E F G I J

5
http://www.yowzafitness.com/
SUPPLIED HARDWARE
This list identifies the hardware you will use to assemble the product. To help distinguish between the various types of
screws and bolts, use the scale below to measure them and compare them to the sizes listed.
No.
Description
Qty.
405
8x14xT2.0mm Spring Washer
2
408
4x15mm Screw –Cone point
4
411
4x12mm Screw –Cone Point
4
461
M6 Nylon Nut
4
470
Plastic Washer 8x27x1
2
494
20x30x0.5mm Washer
2
501
4x12mm Screw –Cone Point
4
502
15x22–M8x10mm Bolt
2
503
15x26–M8x15mm Bolt
2
504
M8x20mm Allen Head CAP Bolt
4
505
20x79.9-M14x25mm Bolt
2
507
M10x56mm Allen Head Bolt
1
508
M10 Nylon Nut
1
509
4x19mm Screw
4
510
4.5x12mm Screw
4
511
M10x40mm Allen Head CAP Bolt
4
513
8x27x2 Washer
2
515
M8x20mm Allen Head Bolt
2
517
10x16x2mm Spring Washer
4
518
4x12x1mm Washer
1
520
4.5x15mm Screw
2
521
20.7x29.1x0.3mm Wave Washer
2
522
M4X12X12mm Screw
1
MILLIMETERS
405 408 411 461
470 494 501 502
503 504 505
507 508 509 510
511 513 515 517
518 520 521 522

6
YOWZA NAVARRE PILOT ELLIPTICAL
PARTS LIST
Item No.
Description
Qty.
Part No.
Navarre Pilot-100
101
Console Support Tube
1
Navarre Pilot-101
104
Moving Linkage –Left
1
Navarre Pilot-104
105
Moving Linkage –Right
1
Navarre Pilot-105
106
Pedal Arm –Left
1
Navarre Pilot-106
107
Pedal Arm –Right
1
Navarre Pilot-107
108
Pedal Swing Arm
2
Navarre Pilot-108
109
Incline Frame
1
Navarre Pilot-109
110
Incline Transmission Tube-Front
1
Navarre Pilot-110
111
Incline Transmission Tube-Rear
1
Navarre Pilot-111
112
Main Frame
1
Navarre Pilot-112
115
Tension Wheel Bracket
1
Navarre Pilot-115
116
Pedal Support Base
2
Navarre Pilot-116
118
Action Arm –Left
1
Navarre Pilot-118
119
Action Arm –Right
1
Navarre Pilot-119
120
Cover Support Tube - Rear
1
Navarre Pilot-120
121
Cover Support Tube - Front
1
Navarre Pilot-121
Navarre Pilot-200
204
Console Cover Support Rear Plate - Left
1
Navarre Pilot -204
205
Console Cover Support Rear Plate - Right
1
Navarre Pilot -205
206
Incline Frame Holder –Rear
2
Navarre Pilot -206
210
Bearing 6004 TPI
4
Navarre Pilot -210
211
Bearing 2201
2
Navarre Pilot -211
212
Bearing 6000
4
Navarre Pilot -212
213
Moving Linkage Bushing
4
Navarre Pilot -213
215
Bearing 2203
2
Navarre Pilot -215
216
Pedal Connection Plate
2
Navarre Pilot -216
217
Bearing 6205
4
Navarre Pilot -217
219
Bushing 16x22.2x10.7mm
4
Navarre Pilot -219
220
12X20X9 Bushing
4
Navarre Pilot -220
221
Flywheel Pivot
1
Navarre Pilot -221
222
Bearing 6003
2
Navarre Pilot -222
223
Aluminum Disk
1
Navarre Pilot -223
224
Flywheel
1
Navarre Pilot -224
225
Bearing 6300
2
Navarre Pilot -225
226
Crank
2
Navarre Pilot -226
227
Crank Disk
1
Navarre Pilot -227
228
Crank Disk Oval Cap
1
Navarre Pilot -228
229
Crank Pivot Bushing
1
Navarre Pilot -229
230
Bearing 6005
2
Navarre Pilot -230
231
Crank Disk Pivot
1
Navarre Pilot -231
233
Belt
1
Navarre Pilot -233
234
Level Adjuster
3
Navarre Pilot -234
235
Magnet
2
Navarre Pilot -235
236
Speed Sensor Supporting Plate
1
Navarre Pilot -236
237
Compression Spring
1
Navarre Pilot -237
238
Console Overlay
1
Navarre Pilot -238
239
Motor Mounts
1
Navarre Pilot -239

7
http://www.yowzafitness.com/
PARTS LIST
Item No.
Description
Qty.
Part No.
240
Motor Link
1
Navarre Pilot -240
245
Bearing 6904
4
Navarre Pilot -245
Navarre Pilot-300
301
Rear Shroud –Up Cover
1
Navarre Pilot -301
302
Handle Moving Arm End Cap
2
Navarre Pilot -302
303
Hand Pulse Sensor Cover
2
Navarre Pilot -303
304
Button Cover –Top
1
Navarre Pilot -304
305
Button Cover –Bottom
1
Navarre Pilot -305
306
Console Bottom Cover –Left
1
Navarre Pilot -306
307
Console Bottom Cover –Right
1
Navarre Pilot -307
309
Volume Membrane Button Overlay
1
Navarre Pilot -309
311
Pivot Cap
2
Navarre Pilot -311
314
Action Arm Drive Gear
2
Navarre Pilot -314
315
Action Arm Cover –Left/Left
1
Navarre Pilot -315
316
Action Arm Cover –Left/Right
1
Navarre Pilot -316
317
Action Arm Cover –Right/Left
1
Navarre Pilot -317
318
Action Arm Cover –Right/Right
1
Navarre Pilot -318
319
Switch Plate
1
Navarre Pilot -319
320
Pedal Soft Cushion
2
Navarre Pilot -320
321
Left Pedal
1
Navarre Pilot -321
324
Pedal Buffer Cover
4
Navarre Pilot -324
325
Vent Cover –Rear
1
Navarre Pilot -325
326
Rear Shroud Inlet –Left
1
Navarre Pilot -326
327
Rear Shroud Inlet –Right
1
Navarre Pilot -327
328
Lift Handlebar End Cap
2
Navarre Pilot -328
329
Pedal Swing Arm Cap
2
Navarre Pilot -329
330
Incline Frame Positioner
1
Navarre Pilot -330
331
Wheel Cap 112x41.5mm
2
Navarre Pilot -331
332
Wheel Cap 46x12mm
2
Navarre Pilot -332
333
Wheel 140x51.86mm
2
Navarre Pilot -333
334
Bearing Bracket
2
Navarre Pilot -334
335
Motor Link
1
Navarre Pilot -335
336
Oval Tube Cap
2
Navarre Pilot -336
337
Vent Cover –Left
1
Navarre Pilot -337
338
Rear Shroud –Left
1
Navarre Pilot -338
339
Rear Shroud –Right
1
Navarre Pilot -339
340
Vent Cover –Right
1
Navarre Pilot -340
341
Incline Frame Lower Cover –Rear
2
Navarre Pilot -341
342
Incline Frame Lower Cover –Front
2
Navarre Pilot -342
343
Incline Frame Top Cover –Rear
2
Navarre Pilot -343
344
Incline Frame Top Cover –Front
2
Navarre Pilot -344
349
Right Pedal
1
Navarre Pilot -349
359
Pedal Rear Cushion
4
Navarre Pilot -359
Navarre Pilot-400
401
4x12mm Screw –Cone Point
4
Navarre Pilot -401
402
M12 Nylon Nut
1
Navarre Pilot -402
403
Taper Fixing Insert
48
Navarre Pilot -403
404
M8x15mm Allen Head CAP Bolt
4
Navarre Pilot -404

8
YOWZA NAVARRE PILOT ELLIPTICAL
PARTS LIST
Item No.
Description
Qty.
Part No.
405
8x14xT2.0mm Spring Washer
12
Navarre Pilot -405
406
M10x20mm Allen Head Cap Bolt
4
Navarre Pilot -406
407
4x15mm Screw –Flat Point
8
Navarre Pilot -407
408
4x15mm Screw –Cone Point
8
Navarre Pilot -408
410
M8x20mm Screw
6
Navarre Pilot -410
411
4x12mm Screw –Cone Point
17
Navarre Pilot -411
412
M32 C Clip
2
Navarre Pilot -412
413
12x20x2mm PU Washer
2
Navarre Pilot -413
414
M6x12mm Allen Head Bolt
8
Navarre Pilot -414
416
M8x15mm Allen Head Bolt
12
Navarre Pilot -416
417
M8 Nylon Nut
2
Navarre Pilot -417
418
M25 C Clip
4
Navarre Pilot -418
419
M6 C Clip
1
Navarre Pilot -419
420
Pivot M10 x 56.6mm
2
Navarre Pilot -420
421
M12 C Clip
2
Navarre Pilot -421
424
M6x12mm Allen Head CAP Bolt
3
Navarre Pilot -424
425
6x10x1mm Spring Washer
11
Navarre Pilot -425
426
20x6x1.5mm Washer
3
Navarre Pilot -426
427
M40 C Clip
2
Navarre Pilot -427
429
M10x20mm Allen Head Bolt
2
Navarre Pilot -429
430
CSpring Fixed Block
4
Navarre Pilot -430
431
10x30x3mm Washer
1
Navarre Pilot -431
432
M4 Nylon Nut
2
Navarre Pilot -432
433
5X16XT1mm Washer
4
Navarre Pilot -433
435
16x25xT3.0 Washer
4
Navarre Pilot -435
436
M10x55mm Allen Head Bolt
1
Navarre Pilot -436
437
M6X12mm Screw
6
Navarre Pilot -437
438
17x22x1mm Washer
9
Navarre Pilot -438
439
M8x50mm Allen Head CAP Bolt
2
Navarre Pilot -439
440
6x32x2mm Washer
1
Navarre Pilot -440
442
M10x45mm Bolt
1
Navarre Pilot -442
443
5X8X1mm Spring Washer
4
Navarre Pilot -443
445
Pedal Arm Pivot
2
Navarre Pilot -445
446
3/4” Nut
6
Navarre Pilot -446
447
M10x30mm Allen Head CAP Bolt
2
Navarre Pilot -447
448
M4x15mm Screw
2
Navarre Pilot -448
449
4x12mm Screw –Flat Point
11
Navarre Pilot -449
451
M14x45mm Allen Head CAP Bolt
1
Navarre Pilot -451
452
M5x8mm Allen Head Bolt
4
Navarre Pilot -452
453
M4x6mm Screw
4
Navarre Pilot -453
454
Pin Nut
4
Navarre Pilot -454
455
10X18X3 mm Washer
1
Navarre Pilot -455
456
M3x8mm Screw
4
Navarre Pilot -456
457
Iron Plate Nut
8
Navarre Pilot -457
458
M5x12mm Screw
2
Navarre Pilot -458
459
M8x45mm Bolt
3
Navarre Pilot -459
460
8x16x1mm Washer
3
Navarre Pilot -460
461
M6 Nylon Nut
6
Navarre Pilot -461
463
M6x15mm Screw
2
Navarre Pilot -463

9
http://www.yowzafitness.com/
PARTS LIST
tem No.
Description
Qty.
Part No.
466
4x8mm Screw –Flat Point
4
Navarre Pilot -466
467
M5x15mm Screw
5
Navarre Pilot -467
468
M5 Nut
9
Navarre Pilot -468
469
5mm Lock Washer
2
Navarre Pilot -469
470
Plastic Washer 8x27x1
2
Navarre Pilot -470
471
M4X0.7mm Flanged nuts
1
Navarre Pilot -471
472
4x15mm Screw –Flat Point
8
Navarre Pilot -472
473
M4x30mm Screw
2
Navarre Pilot -473
474
M6X45mm Allen Head Bolt
2
Navarre Pilot -474
476
M5 Nylon Nut
4
Navarre Pilot -476
478
Washer 10X20 T-5
2
Navarre Pilot -478
480
12X20X0.5mm Plastic Washer
4
Navarre Pilot -480
482
M6x20mm Screw
4
Navarre Pilot -482
483
6x13x1.5mm Washer
14
Navarre Pilot -483
484
8x18x2mm Washer
2
Navarre Pilot -484
485
10x30x1mm Plastic Washer
1
Navarre Pilot -485
487
U - Iron Screw Hole Plate –5x11x16.5mm
6
Navarre Pilot -487
490
M10X62 Screw
2
Navarre Pilot -490
493
Elevation Motor Plastic Bushing
1
Navarre Pilot -493
494
20X30X0.5mm Washer
2
Navarre Pilot -494
496
M5X6.5mm Screw
2
Navarre Pilot -496
497
M5X50mm Screw
3
Navarre Pilot -497
498
M5X5mm Hex Socket Cap Screw
3
Navarre Pilot -498
499
M5x10mm Allen Head Bolt
4
Navarre Pilot -499
Navarre Pilot-500
501
4x12mm Screw –Cone Point
37
Navarre Pilot -501
502
15x22–M8x10mm Bolt
2
Navarre Pilot -502
503
15x26–M8x15mm Bolt
2
Navarre Pilot -503
504
M8x20mm Allen Head CAP Bolt
4
Navarre Pilot -504
505
20x79.9-M14x25mm Bolt
2
Navarre Pilot -505
507
M10x56mm Allen Head Bolt
1
Navarre Pilot -507
508
M10 Nylon Nut
4
Navarre Pilot -508
509
4x19mm Screw
4
Navarre Pilot -509
510
4.5x12mm Screw
4
Navarre Pilot -510
511
M10x40mm Allen Head CAP Bolt
4
Navarre Pilot -511
513
8x27x2 Washer
2
Navarre Pilot -513
515
M8x20mm Allen Head Bolt
2
Navarre Pilot -515
516
M5x6mm Screw
2
Navarre Pilot -516
517
10x16x2mm Spring Washer
10
Navarre Pilot -517
518
4x12x1mm Washer
1
Navarre Pilot -518
520
4.5x15mm Screw
4
Navarre Pilot -520
521
20.7x29.1x0.3mm Wave Washer
2
Navarre Pilot -521
522
M4X12X12mm Screw
1
Navarre Pilot -522
525
M10 Nut
1
Navarre Pilot -525
559
5x10x1 Washer
4
Navarre Pilot -559
564
M5X12mm Allen Head CAP Bolt
4
Navarre Pilot -564

10
YOWZA NAVARRE PILOT ELLIPTICAL
PARTS LIST
Item No.
Description
Qty.
Part No.
Navarre Pilot-600
601
4Pin Power Wire –Upper
1
Navarre Pilot-601
602
4Pin Power Wire –Lower
1
Navarre Pilot-602
605
1 Pin Power Connection Wire
3
Navarre Pilot-605
606
3C Power Wire
1
Navarre Pilot-606
607
2 Pin Hand Pulse Sensor Wire –Upper
2
Navarre Pilot-607
609
2 Pin Hand Pulse Sensor Wire –Lower
2
Navarre Pilot-609
612
Wireless receiver wire-300mm
1
Navarre Pilot-612
613
Membrane key
1
Navarre Pilot-613
614
Fan
1
Navarre Pilot-614
615
Wireless receiver
1
Navarre Pilot-615
616
Elevation Motor
1
Navarre Pilot-616
617
Speed Sensor
1
Navarre Pilot-617
618
Transformer
1
Navarre Pilot-618
619
Control Board
1
Navarre Pilot-619
620
Power Insert
1
Navarre Pilot-620
621
Power Switch
1
Navarre Pilot-621
622
Power Breaker
1
Navarre Pilot-622
623
Motor
1
Navarre Pilot-623
624
Magnetic Sensor
1
Navarre Pilot-624
627
Wire Cap KSS-5R2
2
Navarre Pilot-627
628
Motor connection wire 600mm
1
Navarre Pilot-628
632
Ipod dock connecting wire
2
Navarre Pilot-632
633
Speaker
2
Navarre Pilot-633
634
Amplifier PC board
1
Navarre Pilot-634
635
Audio Wire-300mm
1
Navarre Pilot-635
Navarre Pilot-700
701
Action Arm Lower Cover
4
Navarre Pilot -701
702
Pedal Arm Front Pivot Cover
2
Navarre Pilot -702
703
Incline Frame Front Cover
1
Navarre Pilot -703
704
Undercarriage Cover –Left
1
Navarre Pilot -704
705
Undercarriage Cover –Right
1
Navarre Pilot -705
706
Nylon Bushing
2
Navarre Pilot -706
707
Handle Moving Arm Cove
2
Navarre Pilot-707
708
Incline Frame Holder –Front
2
Navarre Pilot -708
709
Water Bottle Holder
1
Navarre Pilot -709
710
Ball Shaped Handlebar Grip Cover
2
Navarre Pilot -710
711
Ball Shaped Handlebar Grip
2
Navarre Pilot -711
A
2.5mm Allen Key
1
A
B
5mm T-Type Allen Key
1
B
C
8mm Allen Key
1
C
D
6mm Allen Key
1
D
E
Screwdriver
1
E
F
13&17 Wrench
1
F
G
13 &17 Combination Wrench
1
G
I
Power Cord
1
I
J
MP3 Audio Wire
1
J

11
http://www.yowzafitness.com/
ASSEMBLY
(A) Remove your Elliptical from the carton and place it on the floor in an open area.
(B) Remove the Elliptical and all the components and hardware from the box.
(C) Check the quantities of all components and hardware with the component and hardware lists on pages 4-5.
(D) Carefully separate all parts by size and type. This is critical as many are of similar size and shape. Use supplied ruler to size.
(E) After verifying inventory, if any parts are missing, please contact Yowza fitness at 877-969-9240.
.
CUT
CUT
CUT
3
1
2
4
5
6

12
YOWZA NAVARRE PILOT ELLIPTICAL
STEP1
ASSEMBLY
STEP1-A) Attach the Incline Frame Lower Cover (341, 342) to the incline frame.
STEP1-B) Carefully snap pieces together using plastic guides.
STEP1-C) Secure using cone point screw (408).
408
X4
341
342
342
341
408
408
408
Step 1
109

13
http://www.yowzafitness.com/
STEP2
ASSEMBLY
STEP2-A). Remove the Undercarriage Cover (704, 705) by carefully lifting pedal
Assembly and removing each piece one at a time. Be careful not to snap
Plastic push pins when taking apart. Verify that rear incline frame holder
(206) is securely tightened to Main Frame (112).
STEP2-B). Attach Incline Frame Set to the Main Frame, and hold the Incline Frame
Holder –Front (708) to the Incline Frame (109), secure using Allen head
CAP Bolts (511) with Spring Washer (517) on the Incline Frame Holder.
Don’t fully tighten Allen Head CAP Bolt (511) until STEP2-D
STEP2-C). Rotate the Incline Frame (109) to align the bolt holes with the mating bolt
Holes in the Incline Transmission Tube-Front (110).
Assemble the Incline Transmission Tube-Front (110) to the Incline Frame
(109).
STEP2-D1). Firstly, tighten the Allen Head Bolt (507), and make sure again that
already fully was matched here.
STEP2-D2). Then fasten the Nylon Nut (508) by 8mm Allen Key (D) and Wrench (F).
Fully tighten the Allen Head Bolt (511) by 8mm Allen Key.
511
X4
517
X4
507
X1
508
X1
112112
705705
704
Step 2-A
708
109
511
C
Step 2-B
F
109
508507
DStep 2-C
708
517
517
511
511
Step 2
507

14
YOWZA NAVARRE PILOT ELLIPTICAL
STEP3
ASSEMBLY
STEP3-A). Assemble the Console Support Tube (101) to the Main Frame and secure
Using four M8x20 mm Allen Head CAP Bolts (504). Connect the 4Pin
Power Wire –Upper (601) to 4Pin Power Wire –Lower (602) by sliding
plastic extrusion on connector under plastic clip on second connector .
STEP3-B). Lift the Pedal Arm and attach the Undercarriage Cover (704, 705) to the
Main Frame, and secure using Flat point screw (506), Screw (509),
Screw (510).
STEP3-C). Attach the Incline Frame Front Cover (703) to the Incline Frame and
secures using two Screws (520).
504
X4
506
X4
509
X4
510
X4
520
X2
7 0 4
5 2 0
7 0 5
5 1 0
4 1 1
5 0 9
5 0 9
5 1 0
4 1 1
4 1 1
7 0 3
5 0 4
601
602
112
504 504
520 703
509
411
509
510
Step 3-C
Step 3-B
Step 3-A
704
Step 3

15
http://www.yowzafitness.com/
STEP4
ASSEMBLY
STEP4-A). Slide the 20x79.9 Bolt (505) through the Wave Washer (521) & 0.5mm
Washer (494) , Pedal Arm, and Pedal Swing Arm (108) then secure by
8mm Allen Key (C).
STEP4-B). Secure the Back Out Screw (516) to the Pedal Swing Arm (108) using the
2.5mm Allen Key (A)
NOTE: PLEASE FULLY TIGHTEN Screw (516).
STEP4-C). Press the Pedal Arm Front Pivot Cover (702) into the ends of the Pedal
Arm.
505
X2
494
X2
521
X2
516
X2
706
706
470 503 405 515
707
Step 4

16
YOWZA NAVARRE PILOT ELLIPTICAL
STEP5
ASSEMBLY
STEP5-A). Connect the Action Arm to the Moving Linkage and secure using the
M8x10mm Bolt (502) and M8x15mm Bolt (503) by 6mm
Allen Key (D). Do not over tighten or squeaking may occur.
SETP5-B). Assemble the Action Handlebar Lower Cover (701) to the Action
Handlebar and secure using the Cone Point Screw (501).
502
X2
503
X2
501
X4
106
505
494 521
A
516
106
702 106
Step 5-A
Step 5-B
Step 6-C 106
521
494
505
702
Step 5

17
http://www.yowzafitness.com/
STEP6
ASSEMBLY
STEP6-A). Connect the Moving Handlebar (102) to Console Upright Assembly (A2).
STEP6-B). Use M6x20mm Allen Head Bolt (514) to connect Moving Handlebar
(102).
STEP6-C). Tight the Allen Head Bolts (514) by 5mm Allen Key (B).
514
X6
104
501
501
701 701
502
503
118
Step 6
C502 104
503
118
Step 6-A
501
701
501
118
Step 6-B

18
YOWZA NAVARRE PILOT ELLIPTICAL
STEP7
ASSEMBLY
STEP7-A). First, take off two M6x15mm Screws (463) from the Button Control Panel
(A1).
STEP7-B). Open the Panel like step B picture.
STEP7-C). Connect 4Pin Power Wire –Upper (601) to the Panel, and connect 2 Pin
Hand Pulse Sensor Wire –Lower (609) to 2 Pin Hand Pulse Sensor Wire
–Upper(607)
STEP7-D). Use M6 Nylon Nut(461) to hold Button Control Panel (A1) on left and right
side by 13 &17 Combination Wrench (G)
461
X2
463
X2
461
609
609
601
607
607
Step 7
G
Step 7-A
Step 7-B
Step 7-C
607
607
609
609
601

19
http://www.yowzafitness.com/
STEP8
ASSEMBLY
STEP8-A). Attach the Water Bottle Holder (709), and secure using Cone point
screw (522) with Washer (518).
Your cross trainer is now fully assembled.
522
X1
518
X1
709
518
522
Step 8-1
518
522
709
Step 8
