ZERO-X Titan User manual

PRODUCT CODE: ZX-TTN v1
Capture the skies.™
Extended Range Drone with Advanced Flight Systems
DRONE USER MANUAL

Capture the skies.™
3_
1 WELCOME ........................................................................................................ 4
BEFORE YOU GET UP IN THE AIR..................................................................... 4
GENERAL SAFETY............................................................................................. 4
BATTERY SAFETY.............................................................................................. 5
2 INTRODUCTION ........................................................................................ 6
2.1 PACKAGE CONTENTS................................................................................. 6
2.2 PRODUCT OVERVIEW ................................................................................. 7
TITAN DIAGRAM .......................................................................................... 7
REMOTE CONTROL .................................................................................... 8
3 SETTING UP YOUR TITAN ......................................................................... 9
3.1.0 CHARGING THE BATTERY .................................................................... 9
3.1.1 INSTALLING THE FEET .......................................................................... 9
3.1.2 INSTALLING THE BATTERY ................................................................... 9
3.1.3 CAMERA CONNECTION GUIDE........................................................... 10
3.1.4 INSTALLING A MICRO SD CARD (MICRO SD CARD NOT INCLUDED) ............ 10
3.1.5 REMOTE CONTROL BATTERY (AA BATTERIES NOT INCLUDED) ................... 11
3.1.6 FLIGHT SAFETY................................................................................... 11
3.1.7 WIFI CONNECTION AND APP SET UP................................................. 11
3.1.8 USING THE REMOTE CONTROL SMART PHONE HOLDER................ 12
4 FLYING YOUR TITAN .......................................................................... 12-14
4.1.0 TROUBLESHOOTING................................................................................14
4.1.1 ONE BUTTON TAKE OFF/LANDING.......................................................15
4.1.2 ALTITUDE HOLD ........................................................................................15
4.1.3 SPEED MODES...........................................................................................15
4.1.4 DIRECTIONAL LOCK .................................................................................16
4.4.5 OUT OF RANGE ALARM...........................................................................16
4.1.6 LOW BATTERY ALARM..............................................................................16
4.1.7 MOTOR LOCK DOWN ..............................................................................17
4.1.8 TRIMMING..................................................................................................17
5 APP NAVIGATION ................................................................................... 17
5.1.0 APP CONTROL SCREEN ..................................................................... 18
5.1.1 APP ICONS..................................................................................... 18-20
6 VIEWING AND TRANSFERRING PHOTOS AND VIDEOS........................ 21
7 MAINTENANCE....................................................................................... 21
7.1.0 REPLACING ROTOR BLADES ............................................................. 22
7.1.1 REPLACEMENT PARTS ....................................................................... 22
8 SPECIFICATIONS ..................................................................................... 22
9 WARRANTY ............................................................................................. 23

_4
Capture the skies.™
1. WELCOME
Thanks for purchasing a Zero-X Titan, get ready to have the time of your life!
We’re sure your Zero-X Titan will bring you a world of great experiences in
the air.
Please take the time to read the following safety warnings and operating
instructions carefully.
BEFORE YOU GET UP IN THE AIR
Connect the Titan battery to the included USB charging cable and insert the
USB charging cable into the supplied USB wall charger. While the battery
is charging the LED on the charging cable will glow red. Once charging is
complete the light will glow green. While the battery is charging please take
the time to read the instructions and familiarise yourself with the controls of
your Zero-X Titan.
GENERAL SAFETY
Please familiarise yourself with your local legislation regarding drone usage
before you begin using your Zero-X Titan.
Included in the package contents of your Zero-X Titan are the Australian
CASA guidelines, please read carefully and understand this information as
operating a drone outside of these guidelines may result in legal issues.
Zero-X takes no responsibility for operation of this product outside of what is
legally permissible in your local area.
• Do not fly your Titan any closer than 30 metres from people, animals or
buildings. Check to make sure you are no closer than 5.5 kilometres from
any airfields or airports.
For more information on CASA’s Australian legislation visit:
http://www.casa.gov.au/ For information outside Australia please visit the
website of your local aviation authority.
• Do not attempt to modify the Titan or any of its components in any way,
doing so will void your warranty and may affect the operation of the drone.
• Do not use the Titan in any conditions that could affect, damage or impair
your view of the Titan including rain, wind, snow, fog or low light. Avoid
getting your Titan wet, dusty or sandy. These elements will damage the
components of your Titan.
• Please do not attempt to touch the Titan when the Remote Control is
powered on, or if the rotor blades are turning.
• When flying your Titan, please keep in mind the privacy of others.

Capture the skies.™
5_
IMPORTANT INFORMATION - PLEASE READ BEFORE USE
BATTERY SAFETY
When handled incorrectly, Lithium polymer batteries can be dangerous
and can potentially harm and do damage to persons or property. Zero-X
does not accept any liability for damage to persons or property if the
battery is not correctly charged, stored or protected.
• Always unwind all cables before charging.
• Do not over charge the battery. Once the charging process is completed,
remove the battery from the charger as soon as possible.
• Only use the included or replacement Zero-X Titan chargers and
batteries.
• You must charge the Lithium polymer battery in a safe area away from
flammable materials.
• The battery is only to be charged under adult supervision, do not leave
charging batteries unattended. You should always remain in constant
observation to monitor the charging process and react immediately to
any potential problems that may occur.
• Do not charge the battery in temperatures hotter than 40°C or colder
than 0°C.
• Do not cover the batteries when charging. Do not leave batteries in
direct sunlight.
• After each flight & or crash, please check battery for any damage or
swelling.
• If the battery is damaged, leaking, making noise, punctured or malformed
in any way DO NOT attempt to use it. Please dispose of the battery
immediately and safely in the correct manner.
• Do not bend, puncture, crush or scratch the drone’s battery. Do not store
batteries in your pockets, on your person or in extreme temperatures.
• After flying/discharging the battery you must allow it to cool to ambient/
room temperature before recharging.
• If at any time during the charge or discharge process the battery begins
to balloon or swell, discontinue charging or discharging immediately.
Quickly and safely disconnect the battery, then place it in a safe, open
area away from flammable materials to observe it for at least 15 minutes.
Continuing to charge or discharge a battery that has begun to balloon
or swell can result in a fire. A battery that has ballooned or swollen even
a small amount must be removed from service completely.
• Never plug in a battery and leave it to charge unattended overnight.
• Non-compliance with the above warnings may result in the failure of the
battery.

_6
Capture the skies.™
2. INTRODUCTION
2.1 PACKAGE CONTENTS
2
9
8
1
4
57
6
3
1. Titan Drone
2. Remote Control
3. USB Charger
4. Battery
5. Drone Feet
6. AC wall charger
7. Rotor Blades
8. User Guide
9. Screwdriver

Capture the skies.™
7_
2.2 PRODUCT OVERVIEW
TITAN DIAGRAM

_8
Capture the skies.™
REMOTE CONTROL DIAGRAM
3. SETTING UP YOUR ZER0-X TITAN
3.1.0 CHARGING THE BATTERY
PLEASE NOTE: YOUR ZERO-X DRONE COMES WITH A CERTIFIED ZERO-X
USB AC CHARGING ADAPTER FOR 240v CHARGING OF YOUR DRONE
BATTERY. USE OF A NON ZERO-X CERTIFIED USB AC CHARGING ADAPTER
WILL VOID YOUR WARRANTY AND MAY DAMAGE BOTH YOUR BATTERY
AND DRONE.
Fully unwind the included USB charging cable and plug the USB end
into the included Zero-X Certified USB AC charging adapter.
When connected to a charging source the LED light in the charger will
glow green. Connect the drone battery to the charging cable and the
light will turn red indicating charging is in process.

Capture the skies.™
9_
The LED on the USB charging cable will begin to glow green again
once charging is complete. To keep the battery life as long as possible
avoid removing the battery from the charging cable before charging is
complete. If you have just finished flying your Titan drone, please allow
the battery to cool down for at least 30 minutes before recharging.
• When the Titan battery has finished charging it is advised that
the battery is removed from the charger as soon as possible.
Overcharging will damage the battery and effect the flight time.
• The Titan battery can take up to 90 minutes to fully charge. If the
battery has been on charge for any longer than 2 hours and the
indicator on the charging cable is not showing that the battery is
charged, please remove the battery from the charger.
• When connecting the USB cable with the battery, make sure to
follow the guides on the battery connector as these are designed
to only be inserted in one direction. Forcing the connection in the
incorrect direction, may cause damage to the battery and charging
cable.
• When flying the Titan, low battery will be indicated when the remote
control starts beeping and the lights on the Titan start flashing.
3.1.1 INSTALLING THE FEET
Place the feet on the
underside of the Titan
in the position shown
below. With the feet in
position use the included
screws to secure the feet
in position.
3.1.2 INSTALLING THE TITAN
BATTERY
1. Slide the fully charged battery into the battery slot on the rear of
the Titan Drone with the battery sticker facing upward.
2. Make sure the battery clicks into place and is secure.
3. Hold the power button for two seconds to power up the Titan
drone

_10
Capture the skies.™
3.1.3 CAMERA
The camera for the Titan will need to be connected. Once installed,
it is advised that this camera is not removed and reconnected as this
can potentially damage the camera connection.
1. To attach the camera align the notches on the top of the camera
with the slots on the under side of the Titan drone and slide the
camera back into position ensuring that the camera is secure.
2. To connect the Micro USB connection, connect one end of the
supplied cable to the camera while supporting the camera with
your other hand. Then Connect the other end of the micro USB
cable to the Titan drone.
3.1.4 INSTALLING A MICRO SD CARD
1. With the Titan facing away
from you, insert the Micro
SD Card (Micro SD Card not
included) into the side of the
camera ensuring that the text
side of the Micro SD Card is
also facing away from you.
2. While supporting the camera,
gently press the card in until you hear the lock click into place.

Capture the skies.™
11_
3.1.5 REMOTE CONTROL
1. Ensure that the Remote
Control power switch is in
the OFF (down) position.
2. Remove the battery cover
on the rear of the Remote
Control by sliding it
downward.
3. Insert 4 x AA batteries (AA
Batteries not included)
making sure that they are in the orientation specified.
4. Do not mix new and old batteries or different types of batteries.
3.1.6 FLIGHT SAFETY
Before flying your Titan make sure that you are in a safe setting. CASA
restrictions regarding flying drones require the drone be no closer
than5.5kms from any airport or airfield whilst flying. Drones should
also not be flown over populated areas or any closer than 30 metres
from vehicles people or animals.
It is also required that you check your surroundings before taking off
making sure there are no obstacles or dangers in the area, including
overhead power lines and bodies of water. If there are hazards present
in your intended area of flight, please consider an alternative location.
3.1.7 WIFI CONNECTION AND APP SET UP
To use your Apple or Android smart-phone as a FPV screen you will
need to wirelessly connect your smartphone to your Titan over WiFi.
This is done during the set up and launching of the Titan and requires
you to have the Zero-X Titan App installed.
1. To find the Zero-X Titan App search ‘Zero-X Titan’ on the Apple
App store if you are using an iPhone, or on the Google Play store if
you are using an Android phone.
2. Download the Zero-X Titan App.
3. Once the App is downloaded and installed on your Smartphone,
switch on your Titan by holding the power button for two seconds
and move your Smart-phone to be within two metres of the drone.
4. When the Titan is switched on (without the remote controller
switched on) The lights on the arms of the Titan will flash. While
these lights are flashing the WiFi signal will start up be available for
connection.
5. In your Smart-phone’s WiFi settings find the and select the ZX
TITAN WiFi connection.
6. Open the Zero-X Titan App.
7. Press the App Control button on screen to access FPV mode

_12
Capture the skies.™
3.1.8 USING THE REMOTE CONTROL SMART PHONE HOLDER
1. Extend the Phone cradle from the top of the drone
2. Flip down the bottom grip of the phone cradle
3. Lift the top grip and place your smart phone horizontally between the
two grips.
4. Release the top grip making sure that your smart phone is securely in
position.
4. FLYING YOUR TITAN
GETTING STARTED, POWERING UP, PAIRING, CALIBRATING AND
UNLOCKING THE MOTORS
1. After installing a fully charged battery and installing 4 x AA batteries (AA
batteries not included) into the remote control and conducting a complete
check of your surroundings, hold the power button on the Titan for two
seconds.
2. Once on, the LED lights on the arms of the Titan should flash signalling no
connection to the Remote Control.
3. On your Android or Apple Smart-phone, open
your WiFi settings and connect to the ZX Titan
WiFi connection. Once connection is made,
open the Zero-X Titan app on your Smart-
phone.
4. Position your phone in the remotes smart phone
holder.
5. Switch the remote controls power switch to the
up On position. The remote control should beep
once to indicate power up has been successful.
6. To activate the connection between the remote control and the Titan, move
the Left Thumbstick (Acceleration/Yaw) on the Remote Control to the lowest
(down) position hold for one second and then return the Left Thumbstick to
the middle resting position. The remote should beep three times, the lights
on the arms of the Titan should shine solid and the power indicator light on
the Remote Control will shine solid indicating that the connection has been
successful.

Capture the skies.™
13_
7. Calibrate the Titan by holding the Right
Thumbstick (Pitch/Roll) in the bottom right
position. This ensures that the Titan stays level
and flies straight. The Lights on the Titan will
flash fast while calibrating. Keep holding the
Thumbstick in the bottom right position until
calibration is complete.
If the Titan starts to fly abnormally, it may need to be recalibrated. To
recalibrate the Titan turn the Remote Control and Titan off and then restart
the Flying Your Titan process.
When calibrating the Titan, please ensure that the Titan is on a level surface.
8. Once the remote is paired and the Titan
is calibrated, the motors will need to be
unlocked before you fly. To unlock the motors
move the left thumbstick to the right and
downward position while also moving the
right thumbstick to the left and downward
position as shown in the diagram.
When done correctly the rotor blades will spin waiting for take off
PLEASE NOTE: For a quick take off that will skip the step of unlocking the
motors, press the auto take off button on the remote control after
calibration. This will instruct the Titan to take off and hover at shoulder
height.

_14
Capture the skies.™
Once the remote has been paired with the Titan drone, do not approach the
drone until the remote has been powered off.
4.1.0 TROUBLE SHOOTING
Do not approach the drone again until the remote has been powered
off. If for any reason the Titan does not work after following the
launching steps, please check the following.
a) The Titan battery is fully charged, correctly connected and not
damaged.
b) The batteries in the Remote Control are of the same brand, have
an equal amount of charge and have enough charge to power
the remote control correctly (Using an assortment of batteries will
affect the performance of the Remote Control).
c) The connection between the Remote Control and the Titan may
not have been completed correctly. Ensure that when activating
the connection, the Left Thumb stick (Acceleration/Yaw) is moved
all the way to the bottom and then returned to the middle. If this is
not completed the connection will not activate.
Once these points have been checked turn both the Titan and the
Remote Control off and start the launching process again.

Capture the skies.™
15_
4.1.1 ONE BUTTON TAKE OFF/LANDING
The one button take off and landing button allows you to easily get
your drone off the ground and land.
TO TAKE OFF:
Follow the powering up and pairing instructions in this manual. Once
the drone is paired to the controller press the one button take off/
land button, and the drone will take off and hover at about shoulder
height.
TO LAND:
While flying to bring the drone down, quickly press the one button
take off/land button. The drone will then descend and land.
EMERGENCY LANDING:
If you need to bring the drone down in an
emergency, while flying, hold the one button take
off/land button. The motors will stop completely
and the Titan will fall to the ground.
PLEASE NOTE: When using any land function,
make sure that there are no obstacles, people or
animals under the drone.
Do not use the emergency stop function unless
it is an emergency situation as this will cause the
motors to lock, and the drone to free fall.
4.1.2 ALTITUDE HOLD
Altitude hold allows the drone to hover and maintain a constant
height making aerial photography easy.
To use altitude hold, allow the left thumb stick to fall back to its default
middle position.
4.1.3 SPEED MODES
The Titan drone has three speed modes.
To cycle through the speed modes, use the speed button on the rear
of the controller. Each mode will be identifiable by a series of beeps.
Low Speed Mode: One beep
Medium Speed Mode: Two beep
High Speed Mode: Three Beeps

_16
Capture the skies.™
4.1.4 DIRECTIONAL LOCK
Directional lock allows you to lock the controllable forward direction
so that no matter which way the drone is facing, pressing forward on
the right thumb stick will always send the drone in the direction you
have assigned as forward. To set directional lock follow the instructions
below.
1. After powering up the Titan and pairing the controller, place the
Titan facing the direction that you want to assign as forward.
2. Move directly behind the Titan, facing the same direction as the
drone.
3. Press the Directional Lock button to set your forward direction.
Directional Lock will now be set and your preferred orientation will be
set.
PLEASE NOTE: Do not attempt to set Directional Lock when you are
already flying. Be sure to remember your set orientation when you are
flying in Directional Lock mode
4.1.5 OUT OF RANGE ALARM
The remote will give a warning when the Titan is leaving the
controllable range of the Remote Control.
This warning will be issued in a series of double beeps “beep beep…
beep beep…”.
When this alert is active, please direct the drone back towards the
controller.
4.1.6 LOW BATTERY ALARM
When the Remote Control battery is low the Remote Control will
issue a slow series of beeps, signalling that the batteries need to be
replaced.
When the Titan battery is running low, the remote will issue a fast
series of beeps, signalling that the battery needs to be recharged.
PLEASE NOTE: Do not ignore low power warnings as this may result
in unplanned landings.

Capture the skies.™
17_
4.1.7 MOTOR LOCK DOWN
When the rotor blades are stopped by an obstacle the motors will go
into protective lock down.
To unlock the motors make sure the rotor blades are clear from debris
and put the Titan back on the ground. Once you are ready to fly again
pull the left thumb stick back and the motors will release.
4.1.8 TRIMMING
Trimming is used to balance out
your drone if it is drifting when
flying.
To adjust the trimming please
follow the steps below.
1. Make sure that the Remote
Control and Titan are switched
on and correctly paired.
2. Hold the Trimmer button on the
rear of the Remote Control.
3. While still holding the Trimmer button use the right thumb stick to
counter the direction that your Titan is drifting.
4. As you are adjusting the trimming the beep tone will go lower the
more that you trim in any directing.
PLEASE NOTE: If Trimming is not fixing the drones drifting, you
may need to re calibrate your drone by turning off the drone and
the controller and restarting the instructions in the Getting Started
section of this manual.
5. APP NAVIGATION
Once you have connected your Smart-phone to the Titan via WiFi and
launched the Zero-X Titan App, you will be able to access the App’s App
Control screen. This screen has all of the control options and settings, as well
as access to the on screen control system.
If you want to only use your smart phone to control the Titan drone, use the
‘App Control’ setting and press the button to show the on screen controls.
To use the App to assist the controls on the remote control, use the ‘Control
Assist’ setting and press the button to show the on screen controls. In this
mode the controller must be used for take-off.

_18
Capture the skies.™
5.1.0 APP CONTROL SCREEN
5.1.1 APP ICONS
HOME PAGE
When selected, this will take you back to the home page
FPV
This will split the screen into two so that it can be used in a smart
phone compatible VR headset (Headset not included).
This mode should be used with the controller.
Please obey your local aviation laws when using FPV mode.
FLIGHT PATH TRACING
This allows you to trace a flight path for the drone to follow.
Please make sure you have enough space where you are flying for
the drone to follow your drawn path.
EMERGENCY STOP
Pressing this will cause the Titan’s motors to stop and the drone will
fall to the ground.
Only use this in the case of an emergency.
MICRO SD CARD
This will show is a micro SD card is inserted in the Titan’s on board
camera.
When there is no Micro SD Card detected the icon will be displayed.
When a Micro SD Card is detected the icon will be displayed.

Capture the skies.™
19_
REMOTE CONTROL SIGNAL
Displays the Titan’s WiFi signal strength.
SETTINGS
Settings will allow you to set your transmission resolution and trimming.
ON SCREEN CONTROLS
This will give the option of Stick Controls or Tilt Controls
STICK CONTROLS
Allows you to control the Titan with two on screen virtual thumb sticks.
TILT CONTROLS
Allows you to control with a virtual left thumb stick and the right thumb
stick can be controlled by tilting your smart phone
VIDEO
Selecting this will start a video recording.
Selecting this will capture a photo.
DIRECTIONAL LOCK
Selecting this will engage Directional Lock mode.
Please read the Directional Lock section of this manual before activating
Directional Lock.
MEDIA
This will take you to all recorded files both on your phone and saved
to the Micro SD Card installed in your Titan drone (Micro SD Card not
included).
SPEED MODE
Select your required speed mode.

_20
Capture the skies.™
ONE BUTTON TAKE OFF
This button will launch the drone.
When selected, the drone will take off and hover at about shoulder
height.
ONE BUTTON LANDING
This button will initiate the automatic landing sequence.
Please be sure there is no obstructions, people or animals under the
drone when this is selected.
ALTITUDE HOLD
Shows the drones current altitude.
DRONE BATTERY INDICATOR
This displays the drone’s battery level.
