ADSL2+ Single Port Modem
1611-A1-xxx
✓Auto-connect feature will
automatically detect the
first usable PVC and
automatically detect
PPPoE, PPPoA, and Bridge
Protocol(with DHCP Server
available)
✓Configurable as either a
Bridge or Router
✓Filter traffic based on
Destination or Source IP
Address and MAC
Addresses
✓Traffic Class Rules based
on Protocol, Source IP,
Source Port, Destination
IP, Destination Port,
802.1p
✓Single Click DSL test - Tests
Ethernet connection and
ADSL Synchronization
along with ATM OAM F5
segment pings and
end-to-end pings.
✓Configured through
easy-to-use web interface
✓ADSL BER Test based on
idel cell bit error
protection
ADSL2+ Single Port Bridge/Router
The 1600 ADSL2+ family of endpoints deliver the required performance
for multimedia applications at very competitive price points. The 1600
ADSL2+ endpoints, in compact form factor, have been successfully used
for residential, business, in-building deployments such as hotel/motel,
temporary housing, and dormitory-campus installations for high-speed
internet access (HSIA) and video-on-demand services.
The Zhone 1600 ADSL2+ endpoints are easily user-installed. The
embedded web-based user interface is designed to simplify ADSL
deployment. All products provide an Ethernet connection that is
auto-sensing, eliminating the worry about connection cable type
(straight-through vs crossover).
Default settings make for a quick and easy installation that doesn't
require any configuration.
The modem, when operating in router mode, support DHCP
Server/Relay/Client, NAPT, as well as RIP, dynamic routing, port
forwarding, and static routing. For security, firewall functions including
PAP/CHAP authentication and IP filtering are supported.

Technical Specifications
ADSL2+ Single Port Modem
Dimensions
■W (5.03in) x D(4.33in) x H(1.18in)
Weight
■0.33lbs
Power
■Input 100 VAC, 50Hz
■Input 110 VAC, 60Hz
■Input 240 VAC, 50/60Hz
■Output 5VDC 1A
Interfaces
■DSL Line: RJ11
■Ethernet: 1 Port 10/100BaseT, Auto MDI/MDIX
■On/Off Power Switch
Standards Support
■ATM Support
- ITU-T I.610 F4/F5 OAM Send and
Receieve/Loop back
- Support for 8 PVC's
- RFC 1483/2684 (Bridged/Routed Ethernet over
ATM)
■Routing/Bridge Support
- Transparent Bridge Support
- DHCP Server/Relay/Client
- DNS Relay Agent
- Dynamic DNS Support
- DMZ support
- Static Routing
- RIPv1 and RIPv2
- Policy based QoS (TOS, 802.1p,
Source/Destination IP Address,
Source/Destination Port, Protocol)
■PPP Support
- PAP/CHAP authentication
- PPPoA
- PPPoE
■Security
- NAT for Basic Firewall support
- Ingress and Egress Packet Filtering
- Parental Control
- MAC Filtering
- Stateful Packet Inspection
Protocol Support
■ANSI T1.413 (Full Rate ADSL)
■ITU G.992.1 (DMT)
■ITU G.992.2 (G.lite)
■ITU G.992.3 (ADSL2)
■ITU G.992.5 (ADSL2+)
■ITU G.994.1 (G.hs)
■Annex L
■Annex M
Management
■Web-based Configuration GUI
■CLI
■Telnet Remote Management
■FTP/TFTP firmware upgrade and configuration
backup/restore
■Syslog Support
Regulatory Compliance
■FCC Part 15, Part 68
■CE
■UL
■TUV
■RoHS compliant
Operating Requirements
■Operating Temperature: 32F to 104F (0C to
40C)
■Storage Temperature: -4F to 149F (-20C to 65C)
■Humidity: 5% to 95%, non-condensing
Ordering Information
1611-A1-200 ADSL2+ CPE Router, 10/100BaseT, N.A.
1611-A1-302 ADSL2+ CPE Router, 10/100BaseT, EURO
