Zhone 6382-A1-xxx User manual

ADSL2+/ReachDSL 4 Port Switch Modem
6382-A1-xxx
✓Revolutionary
combination of standards
based ADSL and ReachDSL
on a single platform
✓DELT - Dual Ended Loop
Testing
✓Automatically selects
technology with best
performance - ADSL,
ADSL2, ADSL2+, or
ReachDSL 2.2
✓Speeds beyond 24 Mbps
using ADSL2+
✓Compatible with all
DSLAMs providing
standard ADSL, ADSL2,
and ADSL2+
✓Integrated telephone
filter
✓Bridge and router
configurations
ADSL2+/ReachDSL 4 Port Switch Bridge/Router
With Zhone's innovative, easy to use ADSL2+/R CPE family, service
providers can provide ADSL2+ service and ReachDSL service in the same
unit, ensuring coverage to the entire subscriber base.
The Zhone 6300 enhanced CPE are easily user-installed. The embedded
web-based user interface is designed to simplify ADSL deployment. All
products provide an Ethernet connection that is auto-sensing, eliminating
the worry about connection cable type (straight-through vs crossover). All
units include a built in POTS filter that eliminates the expense of an
external filter as well as reduces installation errors.
The 6300 enhanced CPE all default to a simple bridge. This and other
default settings make for a quick and easy installation that doesn't require
any configuration.
When operating in router mode, these gateways support DHCP
Server/Relay/Client, NAPT, as well as RIP, dynamic routing, port
forwarding, static routing, and ping initiation. For security, firewall
functions including PAP/CHAP and Packet Filtering are supported.
In addition, all of the CPE that make up the 6300 family support DELT, or
Dual End Loop Test. Because DELT is a dual-ended test, it requires
equipment that supports the DELT feature at both ends of the copper
loop.
DELT is primarily used for reactive tests on a loop after a modem has
been deployed—either to help troubleshoot a line or to capture a baseline
of loop characteristics at the time of installation.

Technical Specifications
ADSL2+/ReachDSL 4 Port Switch Modem
Dimensions
■1.2" H x 6" W x 4.4" D (3.05cm H x 15.24cm W
x 11.8cm D)
Weight
■1.5lbs (shipping weight)
Power
■100 VAC, 50 Hz
■110 VAC, 60 Hz
■220VAC, 50/60 Hz
Interfaces
■DSL Line: RJ11
■Phone: RJ11 (with integrated phone filter)
■Ethernet: 4 ports of 10/100BaseT
Standards Support
■ATM:
- RFC 1483/2684 Multiprotocol Encapsulation
over ATM
- Up to 8 PVCs, UBR, CBR, VBR
- OAM F5, F4 Loopbacks
■PPP
- RFC 2364 PPP over ATM
- RFC 2516 PPP over Ethernet
- PAP/CHAP
■Routing/Bridge
- IPv4, TCP, UDP, ICMP, ARP, RARP, proxy-ARP
- RIPv1, RIPv2
- Static Routing
- DHCP Server/Client/Relay
- DNS Proxy
- UPNP
- IGMP v1,v2 Snooping and Proxy
- IEE 802.1d transparent bridging
■Security
- NAPT
- Stateful Inspection Firewall
- PPP with PAP/CHAP
Protocol Support
■ANSI T1.413 (Full Rate ADSL)
■ITU G.992.1 (DMT)
■ITU G.992.2 (G.lite)
■ITU G.992.3 (ADSL2)
■ITU G.992.5 (ADSL2+)
■ITU G.994.1 (G.hs)
■ITU G.997.1
■Zhone ReachDSL 2.2
Management
■Web based User Interface
■Firmware Upgradeable via HTTP
■Telnet Server
■TFTP Server and Client
■SNMP
Bandwidth/Distance
■Downstream Speeds up to 24 Mbps using
ADSL2+ (2.2 Mbps with ReachDSL)
■Upstream speeds up to 2 Mbps with ADSL2+ (1
Mpbs with ReachDSL)
Regulatory Compliance
■FCC Part 68
■FCC Part 15
■CE
■UL
■TUV
■ReachDSL 2.2 Spectral Compliance:
- ANSI T1.417
- ANSI T1.413
- UK ANFP
- ETSI TR101 830-1
- Approved for all loops in Japan by the TTC
Operating Requirements
■Temperature: 32F to 104F (0C to 40C)
■Non-operating temperature: -4F to 149F (-20C
to 65C)
■Humidity: 5% to 95%, non-condensing
Ordering Information
6382-A1-200 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, N.A.
6382-A1-210 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, N.A., FCC Part 68 Approved
6382-A1-300 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, U.K.
6382-A1-302 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, EURO
6382-A1-304 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, India
6382-A1-600 ADSL2+/ReachDSL CPE Router (TI), 4 Port Ethernet Switch, Japan
