READ ME FIRST!
DSL setup instructions
For Zhone ADSL modem.
Package Contents
Included with your DSL modem/router you will find a DSL line filter. This filter should be
plugged directly into the wall phone jack. The filter has 2 jacks, one for the line to the phone
and one for the line to the DSL modem. Each jack is labeled accordingly. Follow the
Directions on page 4.
Follow the directions on this page to setup your computer correctly.
Be sure that your PC or Apple is configured to accept an IP address via DHCP, by:
•Windows XP: click on Start -> Run -> type in “ncpa.cpl” click “OK.”. Right click on
“Local Area Connection” Left click on “Properties” then double click on “Internet Protocol
(TCP/IP)”
Then, Click on the circle next to “Obtain an IP address automatically”
•Windows Vista\Windows 7: Click on Start then type ncpa.cpl in the search window
and press the enter key on your keyboard. Right click on “Local Area Connection” Left
click on Properties then double click on “Internet Protocol version 4”
Then, Click on the circle next to “Obtain an IP address automatically”
Click “OK” - then Click “OK” or “Close”
Open up your favorite web browser or email client and enjoy your Broadband Internet
connection!

•OS X operating system: Click on the apple logo in the upper left corner, select System
Preferences. Click Network. Next to the word “Show” select in the drop down menu
Built-in Ethernet. Under the TCP/IP tab be sure that next to the word Configure IPv4 in
the drop down menu “Using DHCP” is selected. You should be able to connect.
Label Color Function
Power Green Off: No Power, On: Power on
DSL Green Off: No connection or no signal
On: aDSL synced up successfully
Blink: aDSL sync up in progress
Internet Green Off: No data being transmitted
On: Data Being Transmitted
LAN Green Off: No Computer/Router Link
On: Computer/Router link established and active

To access your Zhone ADSL Modem for Custom Configurations.
Warning: for advanced users only!
To log into your Zhone ADSL modem, open your web browser. In the top address bar type
http://192.168.1.1, it will ask you for a username and password. The username is admin, the
password is your DSL phone number with a (-) example: 467-0000. You can make any
changes you may think are appropriate. If you lose DSL connectivity, push the reset button for
10 seconds, this will reset the modem to Sisqtel.net default settings.
To Set Your Modem to Bridged Mode for Routers.
Note: this step will erase your Sisqtel.net settings from the
modem!
Press and hold the reset button on the back of the modem for 70 seconds, this will put the
modem in Bridge mode. Now configure your Static IP information on your router or computer.

All Phone lines must be filtered for the best DSL
service. First plug your DSL two port filter into
your wall jack. Be sure to plug the phone side of
your filter into your phone and the computer
screen side of the filter (DSL/HPN) into your DSL
modem. If you need additional filters for your sat-
ellite receiver or other phones, please order from
the front office (530-467-6000 or 1-866-467-
6001).
Thanks Sisqtel.net

A Tradition of Excellence Since 1896
30 Telco Way
•
P.O. Box 157
•
Etna, CA 96027-0157
Phone [phone] •[phone] •Fax [phone]
Zhone Warranty
Should your Zhone 1511 aDSL modem, purchased from Siskiyou Telephone, fail within
the first 12 months from original purchase date, we will replace the modem with, at our
option, a new or reconditioned modem free of charge. The replacement modem will be
warranted through the 12th month of the original modem’s purchase date.
The failed modem must be returned to Siskiyou Telephone along with all power
supplies and cables. If the modem is not returned, you will be charged the current sales
amount.
Obvious abuse or neglect of modem voids this warranty. It is the customer's
responsibility to protect computers and modems from lightning or electrical damage.
