Zibro R 26 T User manual

R 26 T
2
14
26
38
50
62
74
MANUEL D’UTILISATION
GEBRAUCHSANWEISUNG
INSTRUCCIONES DE USO
OPERATING MANUAL
ISTRUZIONI D’USO
GEBRUIKSAANWIJZING
NAVODILA ZA UPORABO
3
2
5
4
>
1
y

Dear Sir, Madam,
Congratulations on your purchase of this heater. You have purchased a quality
product, which will serve you for many years to come. This, of course, provided
you use the heater correctly. Please read these Directions for Use first, to ensure
the maximum lifetime for your heater.
This appliance comes with a 48-month manufacturer’s warranty on all defects
in material or workmanship.
We wish you much warmth and comfort from your heater.
Yours sincerely,
PVG Holding b.v.
Customer Service Department
1 READ THE DIRECTIONS FOR USE FIRST.
2 IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.
3 BEFORE YOU START READING, FOLD OUT THE LAST PAGE. E E E E E E E E E E
4
38

GENERAL DIRECTIONS FOR USE
Below you will find the main steps to be taken for
using your heater. For more details, please refer to
the MANUAL (pages 41 ff.).
•As a fire precaution, the tank must be filled either
when the heater has been switched off or in
another room than the room where the heater is
installed.
•Always ensure that the tank is closed properly after
filling it at a safe distance from all sources of heat
and open flames (see chapter B).
•Store all fuel containers with their original caps
and seals in a cool and dark place.
•Fuel ages. Use new fuel at the start of every hea-
ting season.
•The use of Zibro Extra, Zibro Kristal or Zibro Bio as
a heating fuel assures you that you have a good
quality fuel.
•Before changing brands and/or types of fuel make
sure that the mobile heater first completely emp-
ties all of the remaining fuel inside the heater.
MAIN COMPONENTS
Safety button
Knurled wick
adjustment knob
Ignition button
Combustion
chamber
Combustion
chamber handle
Fuel indicator
Grill
Lid for removable
tank
Removable tank
Removable tank
fuel gauge
Ignition coil
Battery holder
A
B
C
4
E
F
G
H
I
J
K
L
3 BEFORE YOU START READING, FOLD OUT THE LAST PAGE. E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E
Remove all packaging materials (refer to Section A, Fig. A).
Fill the removable tank Iand wait 30 minutes before you
ignite the heater (refer to Section B, Fig. H).
Insert the batteries into the battery holder L
(refer to Section A, Fig. F).
Check whether the combustion chamber Dis fully upright
(refer to Section A, Fig. E).
Ignite the heater by turning the knurled wick adjustment
knob B as far to the right as possible and then gently push the
ignition button C (refer to Section C, Fig. K and L).
After igniting the heater it will take 10 to 15 minutes before
you can check if the heater burns well (refer to Section D).
Switch off the heater (refer to Section E).
1
2
3
4
5
6
7
4
39

WHAT YOU NEED TO KNOW IN ADVANCE
ALWAYS MAKE SURE THAT THERE IS SUFFICIENT VENTILATION
Read this user manual carefully before using the appliance and keep it for future
reference. Install this device only when it complies with local/national legislation,
ordinances and standards. This product is intended to be used as a heater in resi-
dential houses and is only suitable for use in dry locations, in normal household
conditions, indoors in living room, kitchen and garage.
Regardless of the model, you must always make sure that the heater is used in a
room large enough to enable the heater to be used safely without extra ventila-
tion. If the room is smaller than required, you must always open a door or window
slightly (ensuring an opening of approx. 2.5 cm). It is important that every room
where the heater is used has sufficient air intake and efficient air outflow (both
openings must have a minimum cross section of 50 cm2). No modifications to the
safety system are allowed, as that will invalidate the guarantee that the air probe
will work properly. Consult your dealer in case of doubt.
Be aware that the grid and the top plate become hot. If the appliance is covered
there is a risk of fire. Due to high surface temperature, keep away from children.
SAFETY SYSTEM
When you have turned on the heater, if the room temperature is relatively low (19
to 20°C) it may automatically switch off. The cause of this is build-up of heat in the
heater. This is a logical consequence of the safety mechanism. This will not occur
when using the heater at lower ambient temperatures.
Especially for France: Your heater was designed to operate exclusively on fuel for
liquid fuel-operated mobile heaters in accordance with the Decrees of 08-01-1998
and 18-07-2002. The use of other fuels is forbidden. Ask your dealer or check our
website for the addresses of our retailers. The liquid fuel-operated mobile heater
is intended as an extra heater, and not as a continuous source of heat.
Especially for United Kingdom: Only use Class C1 paraffin fuel in accordance with
BS2869; Part 2, or equivalent.
The user must comply with the following instructions for proper use:
DO NOT
- use the liquid fuel-operated mobile heater in caravans, boats, and vehicle
cabins;
- use the liquid fuel-operated mobile heater in insufficiently ventilated rooms
(consult the table of properties for the minimum dimensions of the room to
be heated), underground rooms and / or at a height of over 1500 metres;
- modify the heater safety features.
The use of this type of heating in public rooms is subject to prior regulatory per-
mission. Obtain proper information on this in advance.
THE RIGHT FUEL
Your heater has been designed for use with high-quality water-free pure paraffin
oil, such as Zibro Extra or Zibro Kristal. Only fuels of this kind will ensure clean and
proper burning. Lower quality fuel may result in:
Eexcessive tar deposits on the glass fibre wick
Eincomplete burning
Ereduced heater lifetime
Esmoke and/or smells
Edeposits on the grid or mantle
Only the use of the
correct fuel will ensure
safe, efficient, and
comfortable use of your
heater.
4
40

E E E E E E
Using the right fuel is therefore essential for safe, efficient, and comfortable use
of your heater.
Damage and/or malfunctions of the heater due to the use of other than high qua-
lity water-free pure paraffin oil is not covered by the warranty.
Always refer to your local dealer for the right fuel for your heater.
A
MANUAL
A INSTALLING THE HEATER
1Carefully remove your heater from the box and check the contents.
In addition to the heater you also need to have:
Ea transportation cap
Ethese directions for use
Ea manual fuel syphon pump
Keep the box and the packaging materials (Fig. A) for storage and/or
transportation.
2Remove the other packaging materials:
Eemove the packaging material from the grill G. Lift the grill from the slot
(Fig. B) and pull it forward.
EPull both ends of the packaging to the rear and at the same time slightly
downwards (see Fig. C).
ERemove the combustion chamber from the heater and remove the pac-
kaging underneath (see Fig. D).
EPut the combustion chamber back into its place. The combustion chamber
is positioned correctly when it can be smoothly moved a little to the left
and to the right by its handle E(Fig. E). Close the grill: Slightly lift it to
reposition it in its slot.
EOpen the lid of the removable tank Hand remove the piece of cardboard.
3Fill the removable tank as indicated in Section B.
4Insert the batteries into their holder Lat the back of the heater (Fig. F).
Ensure that the positive and negative poles match the + and - marks indica-
ted on the battery housing.
This transportation cap
is packed separately in
the box. Only this cap
ensures trouble-free
transportation of the
heater after use.
Store it well!
4
41
B
D
C
E
F

++
5
The floor should be firm and completely level. Reposition the heater, when it is
not level. Do not correct the situation by placing books or other goods under the
heater. Please refer to the separate instructions in the carton box for fixing of
the heater.
6Your heater is now ready for use.
BFILLING FUEL
Fill the removable tank in a suitable place since there can always be some spillage.
Follow the procedure below:
1Make sure that the heater is switched off.
2Open the upper lid and lift the removable tank out of the heater (Fig. G).
Note: Some drops may leak from the tank. Put down the removable tank (cap
pointing upwards, handle on floor and screw off the fuel cap.
3Fill the removable tank using a fuel pump (refer to fuel pump operation
instructions.) Make sure that it is in a higher position than the removable tank
(Fig. H). Insert the ribbed hose into the opening of the removable tank.
4Check the removable tank fuel gauge while filling the tank (Fig. I). Stop filling
once the gauge indicates that the tank is full. Never overfill the tank, especi-
ally not when the fuel is very cold (fuel expands when it heats up).
5Let the remaining fuel in the pump flow back into the jerry can and carefully
remove the pump. Carefully screw the fuel cap back on the tank. Clean off
any spilled fuel.
6Check whether the fuel cap is straight and tightened properly. Reinstall the
removable tank in the heater (cap down). Close the lid.
C IGNITING THE HEATER
A new heater may give off some smells for a short while, when it is used for the
first time. You should therefore provide extra ventilation or ignite the heater
outside the living room.
When you use the heater for the first time, first put the filled removable tank into
place, and then wait approximately 30 minutes before you ignite the heater. This
allows the glass fibre wick to soak up the fuel. Follow the same procedure when you
have completely burnt up all fuel from the tank, and after the glass fibre wick has
been replaced.
Before igniting the heater, always check the fuel indicator Fto see whether the
removable tank needs filling up.
Always ignite the heater with the ignition coil K. Never use matches or a cigarette
lighter.
Follow the procedure below:
1Turn the knurled wick adjustment knob 2clockwise to its stop (Fig. K). If you
apply more pressure you may turn it slightly further; however, it will automati-
cally return to the startposition.
4
42
H
I
empty full
K
J
G

+ + +
2Push in the ignition button C(Fig. L), but do not apply too much force.
Release the ignition button as soon as a flame is visible in the combustion
chamber D.
If the heater has been used only a few times and the wick adjustment knob is not
locked, first turn the wick adjustment knob (Fig. M) completely left, before putting
the wick in the highest position for ignition (Section C).
After having ignited the heater, always check whether the combustion
chamber Dis level, by sliding it slightly to the left and the right by its handle E
(Fig. E). This should be a smooth movement. If the combustion chamber is not
level, this will cause smoke and soot to develop.
DBURNING OF THE HEATER
After you have ignited the heater, it will take 10 to 15 minutes before you can check
whether the heater is burning well. Too high a flame may cause smoke and soot,
whereas too low a flame causes smells. The page opposite the folding page shows
the minimum and maximum permissible burning heights of the flame (Fig. Q). The
flame can be slightly adjusted with the knurled wick adjustment knob B(Fig. M).
Burning that is too low may be caused by:
E insufficient fuel (fill the tank)
E poor fuel quality (contact your dealer)
E insufficient ventilation (put window or door ajar)
E wastage of the wick (contact your dealer or replace the wick,
refer to section L)
ESWITCHING OFF THE HEATER
Let the heater burn at its lowest setting (Fig. M) for approximately one minute.
Then slowly turn the knurled wick adjustment knob Banti-clockwise to its stop.
The flame will extinguish after a little while.
In case of an emergency, switch off the heater by pushing in the safety button
A(Fig. N).
F MALFUNCTION, CAUSES AND SOLUTIONS
If any malfunctioning cannot be solved from the directions below, please contact
your dealer.
THE HEATER DOES NOT IGNITE
E The batteries are not positioned correctly in the holder.
Check (Fig. F).
E There is not enough power left in the batteries for the ignition.
Replace (Fig. F).
E You have run out of fuel from the tank or the wick has been replaced.
After having refilled and replaced the removable tank, wait for 30 minutes
before igniting the heater.
E You are pushing the ignition button Cwith too much force.
Push it in less forcefully (Section C).
E The ignition coil K is defective.
Contact your dealer.
4
43
L
M
N
F
E

IRREGULAR FLAME AND/OR SOOT AND/OR SMELLS
E The combustion chamber Dhas not been positioned correctly.
Use the handle Eto put it level, until you can easily slide it slightly to the left
and to the right and the chamber is level.
E You are using fuel which is past its ‘use by’ date.
Start every heating season with fresh fuel.
E You are using the incorrect type of fuel.
Refer to THE RIGHT FUEL (See Section ’What you need to know in advance’).
E Dust has gathered in the lower part of the heater.
Contact your dealer.
E The wick height is not correct.
Contact your dealer.
THE HEATER SLOWLY EXTINGUISHES
E The removable tank is empty.
See Section B.
E The lower reservoir is contaminated by moist.
Contact your dealer.
E The wick has hardened on the upper side.
Burn the heater until all fuel is used (Section G). Use the right fuel.
E You are using fuel which is past its ‘use by’ date.
Start every heating season with fresh fuel.
THE HEATER REMAINS BURNING LOW
E Wick position too low.
Contact your dealer.
E Before you refilled the tank, the heater had burnt up almost all the fuel.
After having refilled and replaced the removable tank, wait for 30 minutes
before igniting the heater.
E You are using the incorrect type of fuel.
Refer to THE RIGHT FUEL (See Section ’What you need to know in advance’).
E The room is insufficiently ventilated.
Leave a window or a door wide open for a while.
THE HEATER IS BURNING TOO HIGH
E You are using an incorrect, too volatile type of fuel.
Refer to THE RIGHT FUEL (See Section ’What you need to know in advance’).
E Wick position too high.
Contact your dealer.
G MAINTENANCE
Your heater needs hardly any maintenance. It is, however, important that you
remove dust and stains in time with a damp cloth, because otherwise these
may cause stains that are hard to remove. Under normal conditions, only three
components are subject to wear:
1. THE BATTERIES
You may replace the batteries yourself. Do not dispose of old batteries along with
the other domestic waste. Follow the locally applicable regulations regarding the
disposal of domestic chemical waste.
2. THE IGNITION COIL
The ignition coil will have a longer life, if you ignite the heater in the correct man-
ner. Replace the batteries in time and take care not to push in the ignition button
4
44
broken ignition coil

+ +
with too much force. If the filament is broken, the ignition coil must be replaced.
3. THE WICK
To extend the glass fibre wick life, you must occasionally let the heater burn until
the tank is completely emptied and the heater extinguishes by itself. Do this when
you notice that the flame is weakening. The burn-out will cause some smells, so it
is recommended that you take the heater outside of the living room.
Do not remove any heater components yourself. Always contact your dealer for
repairs.
Let the heater cool down first, before you start any maintenance or service work.
H STORAGE (END OF THE HEATING SEASON)
We recommend that you burn up all the fuel in the fuel tank at the end of the hea-
ting season and store the heater properly. Follow the procedure on the next page:
1Ignite the heater outside the living room and let it burn until all fuel is used.
2Let the heater cool down.
3Clean the heater with a damp cloth and then dry it with a dry cloth.
4Remove the batteries from the holder Land store them in a dry place.
5Store the heater in a dust-free place, if possible in its original packaging.
Unused fuel cannot be used for the next heating season. If there is still some
fuel left, do not throw it away, but dispose of it in accordance with the local
regulations for the disposal of domestic chemical waste. Always start the new
heating season with fresh fuel. When you start re-using the heater, follow the
instructions again (starting from Section A and as specified).
I TRANSPORTATION
Take the following measures to avoid fuel leakage during the transportation of
the heater:
1Let the heater cool down.
2Remove the removable tank Ifrom the heater and remove the fuel filter
(Fig. O). Some drops may leak from the filter; keep a cloth at hand. Store the
fuel filter and the removable tank outside the heater.
3Place the transportation cap into the position of the fuel filter (Fig. P).
Press it tight.
4Always move the heater in an upright position.
4
45
O
P
Transportation cap

J SPECIFICATIONS
Ignition electrical Dimensions (mm) width 428
Fuel paraffin (including base plate) depth 295
Capacity (kW)*3.0 height 453
Suitable space (m3)** 60-110 Accessories: manual fuel syphon pump,
transportation cap
Fuel consumption (l/hr)*0.313 Required batteries 2x R20kG, MN 1300
Fuel consumption (g/hr)*250 1.5V, size D
Burning time per tank (hr)* 12.8 Wick type F
Capacity removable tank (litres) 4.0
Weight (kg) 8.0
* At maximum setting
** Specified values are indicative
K WARRANTY PROVISIONS
Your heater comes with a 48-month warranty starting on the date of purchase.
Within this period all defects in material or workmanship will be repaired without
any charge. The following provisions shall apply regarding this warranty:
1We expressly dismiss all other claims for damages, including consequential
damages.
2Any repairs or replacements of components within the term of warranty will
not result in an extension of the term of warranty.
3The warranty will no longer apply, when the heater has been modified,
non-original parts have been used, or when it is repaired by third parties.
4The warranty will not apply to parts that are subject to normal wear, such as
the batteries, the ignition coil, the wick and the manual fuel pump.
5The warranty will only apply, when you present the original, dated proof of
purchase, provided no changes have been made to it.
6The warranty will not apply to damages caused by actions not in compliance
with the Directions for Use, neglect, and the use of an incorrect type of fuel,
or fuel past its use-by date. The use of incorrect fuel can even be dangerous*.
7Transportation costs and the risks involved during the transportation of the
heater or heater components will always be the responsibility of the
purchaser.
In order to avoid unnecessary costs, we recommend that you always read the
’Directions for Use’ carefully first. In case they offer no solution, please take the
heater to your dealer for repair.
* Highly inflammable substances may induce uncontrollable burning, causing flames to break out. Should this
happen, never try to move the heater, but always switch off the heater immediately (refer to Section E). In
cases of emergency you may use a fire extinguisher, but only a type B extinguisher: a carbon dioxide or powder
extinguisher.
4
46

11 TIPS FOR SAFE USE
1 Children should be supervised to ensure that they do not play with the
appliance.
2 Do not move the heater when it is burning or still hot. Do not refill nor
service the heater when it is burning or still hot.
3 Position the front of the heater at a distance of minimum 1.5 metres
from walls, curtains, and furniture.
4 Do not use the heater in dusty rooms. You will not have optimum
burning in such rooms. Do not use the heater in the immediate
surrounding of a bath, a shower or a swimmingpool.
5 Switch off the heater, before you leave or go sleeping.
6 Store and move fuel only in suitable tanks and jerrycans.
7 Make sure that the fuel is not exposed to heat or extreme temperature
changes. Always store the fuel in a cool, dry and dark place (sunlight
will affect the quality).
8 Never use the heater in places where harmful gasses or fumes may be
present (e.g. exhaust gasses or paint fumes).
9 Beware that the grid of the heater becomes hot. If the appliance is
covered there is a risk of fire.
10 Always make sure that there is sufficient ventilation.
11 This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of expe-
rience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
4
47
20cm
100cm
50cm
150cm
50cm

4
48
REPLACEMENT OF THE WICK
L ENSURE THAT THE HEATER IS OFF AND COMPLETELY
COOL BEFORE STARTING TO REPLACE THE WICK.
1Open the lid and remove the removable tank.
2Remove the batteries from the battery holder.
3Open the front grill. Remove the combustion chamber
from the heater. Close the grill.
4Pull the knurled wick adjustment knob off the heater.
5Unscrew the three cabinet screws on the back and sides
of the heater. Pull the cabinet forward slightly, and
then remove it from the base plate.
6Unscrew the four wing nuts from the wick holder.
7Lift up the wick holder and the wick mechanism.
8Remove the screw on the stem holding the bracket and
remove the bracket.
9Turn right the stem to the end and remove the wick
sleeve (with wick).
10 Turn the wick sleeve counterclockwise and lift the wick
sleeve up. Remove it from the primary air tube.
11 Squeeze the wick to loosen the three wick pins and
remove the wick from the wick sleeve. Ensure that you
are wearing gloves and that you have a container in
which to put the old wick.

4
49
12 Install the wick to the wick sleeve according to the allo-
wed direction engraved on the wick sleeve.
13 Install the wick sleeve (with wick) to the primary air
tube. And then turn the wick sleeve clockwise to set in
the handle arm.
14 Install the bracket. Then tighten the screw which is hol-
ding the stem.
15 Put the wick holder chassis back into position.
16 Screw the four wing nuts hand tight.
17 Place the knurled wick adjustment knob on the wick
mechanism. Turn the knob as far to the right as possi-
ble. Press the tip-over switch. Check that the wick can
be lowered completely. Repeat this check a number of
times. If the wick cannot be lowered completely it has
not been placed correctly. If this is the case, repeat the
procedure from No. 12. Pull the knurled wick adjust-
ment knob off the heater.
18 Put the cabinet back into position and tighten the three
screws. Put the knurled wick adjustment knob back into
position. Now put the combustion chamber back into
position. Check that it is level by sliding it slightly to the
left and the right by its handle. Close the grill.
19 Put the filled removable tank into position. Put the bat-
teries into the battery holder (ensure that the positive
and negative poles match the + and – marks indicated
on the battery housing). Wait 30 minutes after repla-
cing the tank and batteries before using the heater.

E E E E E E E E E E E E E E E E E E E E E E E E E E E E E
E E E E E E E E E E E E E E E E E
FQ
7
1-3 cm.
37
1 LISEZ PRÉALABLEMENT LE MANUEL D’UTILISATION.
2 EN CAS DE DOUTE, CONTACTEZ VOTRE REVENDEUR.
3 POUR LIRE, DÉPLIEZ LA DERNIÈRE PAGE. E E E E E E E E E E E E E 3 POUR LIRE, DÉPLIEZ LA DERNIÈRE PAGE. E E E E E E E E E E E E E

E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E E
A B C
D
G
E
J
F
L
K
H
I
FQ

D Benötigen Sie weitere Informationen oder treten Probleme auf, besuchen Sie bitte unsere Website www.zibro.com, oder setzen Sie sich mit
unserem Kundendienst in Verbindung (Telefonnummer auf www.zibro.com).
For alle yderligere oplysninger eller ved eventuelle problemer med apparatet henvises til www.zibro.com eller det lokale Kundecenter (telefon-
numre findes i www.zibro.com).
Si necesita información o si tiene algún problema, visite nuestra página Web www.zibro.com, o póngase en contacto con el servicio cliente
(hallará el número de teléfono en www.zibro.com).
F Si vous souhaitez obtenir des informations supplémentaires ou si vous rencontrez un problème, rendez-vous sur notre site Web (www.zibro.
com) ou contactez le notre service client (vous trouverez l’adresse et numéro de téléphone sur www.zibro.com).
Jos haluat huoltoapua, lisätietoja tai laitteen kanssa tulee ongelmia, tutustu verkkosivustoon osoitteessa www.zibro.com tai kysy neuvoa PVG
kuluttajapalvelukeskuksesta (www.zibro.com).
If you need information or if you have a problem, please visit the our website (www.zibro.com) or contact our sales support (you find its phone
number on www.zibro.com)
I Per informazioni e in caso di problemi, visitate il sito Web www.zibro.com oppure contattate il Centro Assistenza Clienti (per conoscere il numero
di telefono, consultate www.zibro.com).
N Hvis du trenger informasjon, eller hvis du har et problem med produktet, kan du gå til nettsidene www.zibro.com. Alternativt kan du kontakte
med PVG’ forbrukertjeneste (telefonnummeret i www.zibro.com).
Als u informatie nodig hebt of als u een probleem hebt, bezoek dan de onze website (www.zibro.com) of neem contact op met de afdeling
sales support (adres en telefoon op www.zibro.com).
P Se necessitar de informações ou se tiver problemas, visite o Web site www.zibro.com ou contacte o Centro de Assistência (número de telefone
o www.zibro.com)
W przypadku problemów i w celu uzyskania szczegółowych informacji odwiedź stronę internetową Zibro dostępną pod adresem www.zibro.
com lub skontaktuj się z Centrum kontaktów Zibro (www.zibro.com)
S Om du behöver service eller information eller har problem med apparaten kan du besöka www.zibro.com eller kontakta Zibro kundtjänst (du
hittar telefonnumret på www.zibro.com).
Če želite dodatne informacije, obiščite spletno mesto podjetja na naslovu www.zibro.com ali pokličite na telefonsko (www.zibro.com).
Daha fazla bilgiye ihtiyaç duyarsanız veya bir sorunla karşılaşırsanız, www.zibro.com adresindeki Zibro Internet sitesini ziyaret edin veya ülkenizde
bulunan Zibro müşteri merkeziyle iletişim kurun (telefon numarasını: www.zibro.com).
--- --- -- ----
-- -- --- -----
-- -- --- -----
-- ---- -- ----
-- -- --- -----
-- -- --- -----
--- --- -- ----
-- ---- -- ----
www.zibro.com
Distributed in Europe by PVG Holding B.V.
R 26 T
PVG Traffic avg©110518 man_R26T
New 06/11
Zibro® is registered trademark of TOYOTOMI Co., Ltd. for paraffin heaters.
ZIBRO brand paraffin heaters are made in Japan and imported by PVG Holding B.V.
Printed in Japan
7997000903
