ZIEHL-ABEGG ECQ User manual

ECQ
Electronically commutated motors for the drive
of fans
Operating Instructions
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
english

Content
1 General notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Validity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Meaning of the operating instructions . . . . . . . . . . . . . . . . . . . . . 3
1.3 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Exclusion of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.5 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Explanations of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Requirements placed on the personnel / due diligence . . . . . . . 5
2.4 Work on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Product overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Application operational area . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.2 Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Motor protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.4 Transport, storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.5 Disposal / recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1 Mounting the motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.2 Connection cable & junction box . . . . . . . . . . . . . . . . . . . . . . . . 8
4.3 Connection of the motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6 Service work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.1 Maintenance/servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7 Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.2 Manufacturer: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.3 Service address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Operating Instructions ECQ
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
2/12

1 General notes
Compliance with the following specifications also serves to ensure product safety.
Should the specified information, in particular with regard to general safety, transporta-
tion, storage, assembly, operating conditions, commissioning, service, maintenance,
cleaning and disposal/recycling not be observed, safe operation of the product may not
be guaranteed and can potentially pose a risk of death or injury to users and/or third
parties.
For this reason, deviations from the specifications below can lead to the loss of legal
materials defect liability as well as to liability of the buyer for the product rendered unsafe
by deviation from the specifications.
1.1 Validity
This document is valid for ECQ motors of size U (060).
The used motor size is recognisable from the type designation (
rating plate).
e.g. type: MI060-4QN.05N
In the case of motors with a quality mark (see rating plate), please note the related
specifications depending on the application location!
1.2 Meaning of the operating instructions
Before installation and start-up, read this manual carefully to ensure correct use!
We emphasize that these operating instructions apply to specific units only, and are in
no way valid for the complete system!
Use these operating instructions to work safely with and on the device. They contain
safety instructions that must be complied with as well as information that is required for
failure-free operation of the device.
Keep these operating instructions together with the device. It must be ensured that all
persons that are to work on the device can refer to the operating instructions at any time.
Keep the operating instructions for continued use. They must be passed-on to all
successive owners, users and final customers.
1.3 Target group
The operating instructions address persons entrusted with planning, installation, start-
up, maintenance and servicing, who have the corresponding qualifications and skills for
their job.
1.4 Exclusion of liability
To allow for future developments, construction methods and technical data given are
subject to alteration. We do not accept any liability for possible errors or omissions in the
information contained in data, illustrations or drawings provided.
We accept no liability for damage caused by misuse, incorrect use, improper use or as a
consequence of unauthorized repairs or modifications.
Operating Instructions ECQ General notes
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
3/12

1.5 Copyright
These operating instructions contain copyright protected information. The operating
instructions may be neither completely nor partially photocopied, reproduced, translated
or put on data medium without previous explicit consent from ZIEHL-ABEGG SE. In-
fringements are liable for damages. All rights reserved, including those that arise through
patent issue or registration on a utility model.
2 Safety instructions
2.1 Explanations of symbols
Safety instructions are highlighted with warning triangles and are depicted
according to the degree of hazard as follows.
Attention!
General hazardous area. Death or severe injury or significant property damage can
occur if the corresponding precautions are not taken!
Danger due to electric current
Danger by dangerous, electric voltage! Death or severe injury can occur if the
corresponding precautions are not taken!
Info
Important additional information and advice for user.
2.2 Product safety
The device conforms to the state of the art at the time of delivery and is fundamentally
considered to be reliable. The device and its accessories must only be used in a flawless
condition and installed and operated in compliance with the assembly instructions and/or
operating instructions. Operating outside the device's technical specifications (see name
plate and attachment / technical data) can lead to a defect in the device and additional
damage!
Info
A separate fault and performance monitoring-system with an alarm signal function is
necessary in order to prevent personal injuries and material damages during malfunc-
tions and in case the device fails. Substitute operation must be taken into consideration!
The design and installation of the system must comply with local regulations and
directives.
Operating Instructions ECQ Safety instructions
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
4/12

2.3 Requirements placed on the personnel / due diligence
Persons entrusted with the planning, installation, commissioning and maintenance and
servicing in connection with the frequency inverter must have the corresponding qual-
ifications and skills for these jobs.
In addition, they must be knowledgeable about the safety regulations, directives, rules
for the prevention of accidents and the corresponding national as well as regional and in-
house regulations. Personnel to be trained or instructed and apprentices are only
permitted to work on the device under the supervision of an experienced person. This
also applies to personnel undergoing general training. Comply with the legal minimum
age.
2.4 Work on the device
Info
Mounting, electrical connection, and start-up operation may only be carried out by an
electrical specialist in accordance with electrotechnical regulations (e.g. EN 50110 or
EN 60204)!
Danger due to electric current
•It is generally forbidden to carry out work on electrical live parts!
•The 5 electrical safety rules must be observed!
•The safe isolation from the supply must be checked using a two-pole voltage
detector.
•Opening of motor is prohibited. Loosening the screws will void the warranty!
•Any faults detected in the electric system/modules/operating equipment must be
corrected immediately. If these faults are not corrected, the device/system is
potentially very dangerous. The device/system must therefore not be operated when it
is faulty.
•Fuses must always be only replaced; never repaired or bridged. The specifications for
the maximum series fuse must always be adhered to (
Technical data). Only fuses
cited in the electrical circuit diagram may be used.
Attention, automatic restart!
•The motor may switch on and off automatically for functional reasons.
•Automatically restart after a power failure or mains disconnection!
•Wait until the motor has stopped before approaching.
Danger of being sucked in!
Do not wear loose or hanging clothing, jewellery, etc., tie together long hair and cover it.
Operating Instructions ECQ Safety instructions
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
5/12

3 Product overview
3.1 Application operational area
The fans / motors are not ready-for-use products, but conceived as components for
ventilation systems (type designation see rating plate). The fans / motors may only then
be operated when they are installed in accordance with their intended use, and safety
has been secured through protective devices in accordance with EN ISO 13857 (EN ISO
12100) or other structural protective measures.
Attention!
•They must not be used in hazardous areas for the transfer of gas, mist vapours or
mixtures. Nor must they be used for the transfer of solid components in the transfer
medium.
•If the motor/fan is used in applications where a ignitable atmosphere can form in the
event of a fault, e.g. due to leakage, the user must assess the risks of ignition and take
appropriate precautions to prevent ignition.
3.2 Functional description
ECQ motors from ZIEHL-ABEGG are highly efficient, electronically commuted motors
(EC) with an integrated controller. They are designed exclusively for driving axial fans.
The motors are designed for continuous operation (S1-operation) and are thermally
protected.
Depending on version motors with a fixed speed or motors with three speeds (
rating
plate).
Motors with three speeds
•Three pre-programmed speeds are possible (
rating plate) which are activated
depending on the connection of the additional control input at “L1” or “N”.
•With the “Motor Programmer” (accessory) and a PC with the appropriate software,
individual speeds and the rotation direction can be programmed.
Possible rotating directions
•CCW (counter-clockwise rotation) left-hand direction of rotation looking at the motor
shaft
•CW (clockwise rotation) right-hand direction of rotation looking at the motor shaft
3.3 Motor protection
The motor has devices to protect it from overloading, these include protection in case of
blocked rotor and overload protection with running motor.
On exceeding the maximum permissible operating temperature, this can lead to stopping
of the motor and can cause permanent damage!
Operating Instructions ECQ Product overview
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
6/12

3.4 Transport, storage
Attention!
•Use the original packaging materials when transporting the device.
•Do not transport the fan by the connecting cable!
•Avoid shocks and impacts to the device during the transport.
•Avoid extreme humidity, heat or exposure to cold (
Technical Data).
•Pay attention to possible damage of the packaging or the equipment.
•Store the fan / motor in the original packaging in a dry area protected from the weather
and protect it from dirt and weather until final installation.
•Protect the motor against ultraviolet radiation.
•Avoid prolonged storage; we recommend a maximum of one year (consult the
manufacturer before starting if stored for longer).
•Inspect the bearing for proper operation prior to installation.
3.5 Disposal / recycling
Disposal must be carried out professionally and in an environmentally friendly way in
accordance with the respective national legal stipulations.
"Separate the materials by type and in an environmentally-friendly way.
"If necessary, commission a specialist company with the waste disposal.
4 Installation
4.1 Mounting the motor
Attention!
•Check the device for damage, e.g. cracks, dents or damage to the electric cables,
before assembly. Start-up is not allowed in the case of transport damage!
•Mounting is only to be undertaken by trained service personnel. The system
manufacturer or the machine builder and/or the user is responsible that the inherent
installation and security information are harmonized with the valid standard and
guidelines (EN ISO12100 / 13857).
•The custom designs must suit the prevailing conditions.
•During assembly of the fan impellers or other components, no inadmissible pressure
may be applied to the motor bearing.
•If the motor is used to drive fan impellers or other components, please note the
maximum permissible speeds of the impeller or the component to be driven.
•The maximum permissible mass of the impeller or the component to be driven is
0.3 kg. Greater masses must be inquired about at ZIEHL-ABEGG and confirmed in
writing.
•Tighten the fastenings with the specified torques.
Operating Instructions ECQ Installation
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
7/12

Dimensions [mm]
03060-NN04
17.11.2021
Info
The 7 holes in the motor's plastic housing (for self-tapping screws Ø 4.2) are designed for
one-time use.
4.2 Connection cable & junction box
Info
In demanding environments (wet rooms, outdoor installation), connection cables must
have water draining pipe elbows. If using a junction box, install this lower than the motor
to ensure that water cannot penetrate through to the controller housing from the
connection cables.
4.3 Connection of the motor
Danger due to electric current
•The mains voltage must comply with the EN 50160 quality characteristics and the
defined standard voltages in IEC 60038!
•Connect the motor only to electrical circuits that can be disconnected with an all-pole
isolating switch.
•The device owner is responsible for the EMC of the entire plant according to the
locally applicable standards.
Operating Instructions ECQ Installation
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
8/12

Connection diagram for motors with one speed
KT00047B
18.11.2015
M
1 ~
ECQ
BU
rpm 1
BN
N
L1
N, L1 Line voltage see rating plate
BN brown
BU blue
Connection diagram for motors with three speeds
KT00047A
14.04.2016
M
1 ~
ECQ
BU
rpm 1
BN
BK
C
N
L1
M
1 ~
ECQ
BU
BN
BK
C
N
L1
M
1 ~
ECQ
BU
BN
BK
C
N
L1
rpm 2
rpm 3
N, L1 Line voltage rating plate
C Control input speed
BK black
BN brown
BU blue
rpm 3 Speed step 3
rpm 2 Speed step 2
rpm 1 Speed step 1
If the black wire is connected with the brown
wire, the motor runs at speed step 3
If the black wire is connected with the blue wire,
the motor runs at speed step 2
If the black wire is not connected, the motor runs
at speed step 1
Danger due to electric current
A dangerous voltage (maximum line voltage is applied at the black connecting wire
(speed control input) when it is not used (speed step 1). Therefore this wire must be
connected to a terminal for insulation.
Operating Instructions ECQ Installation
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
9/12

5 Commissioning
Attention!
•Before first-time start-up, check the following:
1. Installation and electrical connection have been properly completed?
2. Connection data complies with the specifications on the rating plate?
3. That any installation remnants and foreign bodies that may be present have been
removed?
Attention!
•Start-up may only begin when all safety instructions have been verified and any
hazards have been ruled out.
–Check direction of rotation.
–Check for quiet, low vibration operation. Strong vibrations due to erratic operation
(unbalanced), e.g. caused by transportation damage or improper use, can lead to
failure.
6 Service work
6.1 Maintenance/servicing
Attention!
•Observe the safety information!
•No maintenance work at running motor!
•Any faults detected in the electric system/modules/operating equipment must be
corrected immediately. If these faults are not corrected, the device/system is
potentially very dangerous. The device/system must therefore not be operated when it
is faulty.
•Fuses must always be only replaced; never repaired or bridged. The specifications for
the maximum series fuse must always be adhered to (see Technical data). Only fuses
cited in the electrical circuit diagram may be used.
•The fan or motor is maintenance-free due to the use of ball bearings with “life-time
lubrication”. The grease service life (see Technical data) may be lower than the
theoretical value stated there (F
10h
) if particular operating conditions such as
vibrations, humidity or soiling in the bearing, unfavourable control modes, etc. are
present.
•The connecting cable may only be changed by authorised ZIEHL-ABEGG SE
personnel.
•Regular inspection, if necessary with cleaning, is necessary to prevent imbalance due
to ingress of dirt.
–Watch out for vibration free motion.
–Maintenance interval in accordance with the degree of contamination of the
impeller!
Operating Instructions ECQ Commissioning
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
10/12

6.2 Cleaning
Danger due to electric current
•Voltage supply for motor must be interrupted and secured against restoration!
•Do not use any aggressive cleaning agents when cleaning.
•Make sure that no water gets into the inside of the motor and electronics.
7 Enclosure
7.1 Technical data
Line voltage*
(
Rating plate)
1 ~ 230 V, 50/60 Hz
1 ~ 120 V, 50/60 Hz
Power consumption (P1) Version with one speed: max 18 W
Version with three speeds: max. 34 W
Power output (P2) Version with one speed: max 9 W
Version with three speeds: max. 20 W
Speed 1 / 2 / 3
rating plate
Maximal line fuse 4 A
Max. load limit integral of cut-in
current approx.
0.118 A
2
s
Permissible minimum and maxi-
mum ambient temperature for
operation
-40...+50 °C
Permissible temperature range
for storage and transport
-40...+80 °C
Permissible rel. humidity 85 % no condensation
Electromagnetic compatibility for
the standard voltage 230 / 400 V
according to IEC 60038
Interference emission according to EN 55014-1 (domestic household
applications)
Interference immunity according to EN 61000-4-4 (industrial applications)
Harmonics current In accordance with EN 61000-3-2
Please ask manufacturer for the individual harmonic oscillation levels of
the current as a percentage of the fundamental oscillation of the rated
current.
Ball bearings grease service-life
(F
10h
)
The device is designed with a life time for the bearings and a bearings
service-life of at least 40.000 h when S operated at full power in the
maximum permissible ambient-temperature environment.
Connection Version with one speed: H03VV-F 2 x 0.5 mm
2
Version with three speeds: H03VV-F 3 x 0.5 mm
2
Protection class of motor ac-
cording to EN 60529
IP55
Operating Instructions ECQ Enclosure
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
11/12

For motors with one speed and corresponding quality mark
(
rating plate)
Authorization: FILE No.
E347018
UL 1004-7
Electronically-Protected
Motor - Component
For motors with three speeds and corresponding quality mark
(
rating plate)
Authorization: FILE No.
E123518
UL 1004-3
Thermal-device-protected
Motor - Component
7.2 Manufacturer:
Our products are manufactured in compliance with valid international standards and
regulations.
If you have any questions about how to use our products or if you are planning special
applications, please contact:
ZIEHL-ABEGG SE
Heinz-Ziehl-Straße
D-74653 Künzelsau
Phone [phone]
Fax [phone]
[e-mail]
7.3 Service address
Please refer to the homepage at www.ziehl-abegg.com for a list of our subsidiaries
worldwide.
Operating Instructions ECQ Enclosure
L-BAL-F061-GB 2022/20 Index 005 Part.-No. 00702130-GB
12/12
