TAP OPTIONS
The G4 series offers a range of interchangeable taps to suit the customer's needs.
Classic range
Arc / Cube range
Elite range
All-in-One range
Mixer range
These standalone taps offer instant boiling, chilled
and sparkling water* and are directly compatible with
the G4 Command-Centre.
The All-in-One tap may be used as alternatives to
the above HydroTap and mixer tap combinations*.
The mixer tap range may be used in conjunction with
any of the above to provide mixed hot and cold water
for sanitary use*.
Celsius range
The Celsius range offer instant boiling, chilled and
sparkling / boiling and chilled / boiling and ambient
/ chilled and sparkling / chilled or boiling* water
together with the an integral mixer to provide mixed
hot and cold water from the mains.
*Dependant upon model purchased.
