Zip HydroTap G5 Touch-Free Wave User manual

Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
1
Zip
HydroTap G5
Installation instructions
Faucets - Arc & Cube
Visit our website to
download the manuals
English French

2Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
Table of contents
SECTION 1: Using these instructions .................................................................2
1.1 Using these instructions................................................................................2
SECTION 2: Performance data & regulatory standards .....................................3
SECTION 3: Generic installation requirements ................................................ 4
3.1 Tools needed for faucet installation ............................................................ 4
SECTION 4: Installation - Arc & Cube ............................................................... 4
4.1 Positioning .................................................................................................. 4
4.2 Select height & spout position ....................................................................5
4.3 Set up the height and spout position ..........................................................5
4.4 Cut the hole ............................................................................................... 6
4.5 Mount the faucet........................................................................................ 6
4.6 Fit the tube kit ............................................................................................ 6
4.7 Secure the tube kit & fit the label.................................................................7
4.8 Command Centre connections...................................................................7
SECTION 5: Cleaning and maintenance ............................................................7
5. 1 Cleaning.......................................................................................................7
SECTION 1: Using these instructions
1.1 Using these instructions
Please refer to all safety and installation requirements detailed in the Quick
start guide provided with the HydroTap Command Centre, and HydroTap
Command Centre installation instructions found online, prior to installation of,
or any change to, the complete system.
Before commencing the installation,download
& read the HydroTap Command Centre
installation instructions
!
Read the
instructions
WARNING

Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
3
SECTION 2: Performance data & regulatory standards
• The ARC XX and Cube XX faucets have been certified by IAPMO R&T
against NSF/ANSI Standard 42, NSF/ANSI Standard 53, NSF/ANSI Standard
372, CSA B483.1, ASSE 1087, and ASSE 1023 when used as part of the BCS60,
BCS20, BCS Home, BC40, and BC Home systems.
•
• The ARC XX and CUBE XX faucets have been certified by IAPMO R&T
against NSF/ANSI Standard 42, NSF/ANSI Standard 53, NSF/ANSI Standard
372, CSA B483.1, and ASSE 1087 when used as part of the CS100 and CS
Home systems.
•
• XX = Chrome, Brushed Chrome, Matte Black, Rose Gold, Nickel, Brushed
Nickel, Gunmetal Gray, Brushed Gold faucet finish options.

4Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
SECTION 3: Generic installation requirements
Be aware of the risks of hazards which could cause harm when
using tools.
Assess the risks before starting the installation.
3.1 Tools needed for faucet installation
In addition to normal tools, the following (or equivalent equipment) will be
required, (not supplied).
• 1 ”, (35mm) diameter sheet metal hole punch for sinks.
• 1 ”, (35mm) diameter hole saw for worktops.
• Tube spanner for fixing the tap assembly.
!
SECTION 4: Installation - Arc & Cube
6.7“- 6.8”
(171 -174mm)
6.9” - 8.9”
(175 - 225mm)
4.1 Positioning
Position the faucet such that it dispenses into the sink bowl with
clearance for a cup or tea pot.
Ensure that faucets are positioned to minimise the risks of
scalding by dispensing boiling water while using the HydroTap.
!
Position Command Centre and faucet as close
together as possible. See below.
BC Compact

Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
5
4.2 Select height & spout position
2 fixed height options
!
see 4.1
* *
*
6.9”, (175mm)
8.9”, (225mm)
SECTION 4: Installation - Arc & Cube
Spring clip
Upper location
holes
Lower location
holes
Dimples
• Remove spout locating
screws, lower spout to
expose the spring clip.
• To reposition spout, prise
open spring clip.
• Slide spring clip up/down to
engage selected holes.
• Ensure dimples engage
simultaneously with the two
selected holes.
• Raise the spout (ensure USB
lead fits in undercut and
open ends of the clip).
• Align clip with locating
holes, & refit the 2 x locating
screws.
4.3 Set up the height and spout position
Spout locating
screws
6 fixed position options

6Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
SECTION 4: Installation - Arc & Cube
4.4 Cut the hole
• Cut a 1 ”, (35mm) hole in the worktop / sink.
• Make sure the faucet location will allow the spout to drain into the sink.
1 ”, (35mm)
4.6 Fit the tube kit vent connector must be fitted
Boiling, chilled sparkling Boiling chilled Chilled sparkling
Tube
connectors
Vent
connector
Insert
4.5 Mount the faucet
Upper o-ring
Lower o-ring
Base
ring
Rubber washer
Metal washer
Tap nut

Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
7
SECTION 4: Installation - Arc & Cube
4.7 Secure the tube kit & fit the label
Insert 0.4 “, (20mm)
Clamp tight
with
herbie clip
Align herbie clip with
vent connector Function label
surface
4.8 Command Centre connections
USB Connected to the faucet.
Boiling out Red silicone tube from faucet. Cut to length.
Chilled out
(BC) Blue silicone tube from faucet,
(BCS, CS) Blue JG pipe from faucet.
Cut to length.
Vent Clear silicone tube from faucet. Cut to length.
Sparkling out White JG pipe from faucet. Cut to length.
SECTION 5: Cleaning and maintenance
5. 1 Cleaning
• Wipe surfaces with a damp cloth and then wipe dry with a clean, dry cloth.
IMPORTANT!
• Do not use air-drying disinfectant sprays.
• This could cause permanent malfunction and void warranty.
!

8Quick Start Installation Guide
807112US v1.01 01.22 G5 HydroTap Arc Cube instructions
Distributed in US and Canada by: Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, IL 60018
www.us.zipwater.com
Call US Toll Free 1-833-233-2358 for assistance, service, spare parts or enquiries.
Manufactured by Zip Water (Australia) Pty Ltd
67 - 77 Allingham Street,
Condell Park NSW 2200
Australia
As Zip policy is one of continuous product improvement, changes to specifications may be
made without prior notice. Images in this booklet have been modified and may not be true
representations of the finished goods.
The terms “Zip” and “HydroTap” are registered trade marks of Zip Water (Aust) Pty Ltd.
