Zip HydroTap G5 Touch-Free Wave User manual

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
1
Zip
HydroTap G5
Installation instructions
Celsius Plus All-In-One Pull-Out
All models
Visit our website to
download the manuals
Australia UK
Pull-Out Sprayer and Mixer

2Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
Table of contents
Contents
SECTION 1: Using these instructions .................................................................3
SECTION 2: Generic installation requirements ................................................ 4
2.1 Tools needed for tap installation ................................................................. 4
2.2 Water supply pressure requirements.......................................................... 4
SECTION 3: Installation - Celsius Plus AII-In-One (AIO) Pull-Out ..................... 4
3.1 Position the tap............................................................................................ 4
3.2 Position the Hose Management System, cut the tap hole.......................... 4
3.3 Align the Hose Management System...........................................................5
3.4 Install the Hose Management System Bracket ........................................... 6
3.5 Familiarise yourself with the mains connections..........................................7
3.6 Familiarise yourself with the Hose Management System connections........7
3.7 Familiarise yourself with the tap connections............................................. 8
3.8 Mount and secure the tap & connect together ......................................... 9
3.9 Install the Pull-Out hose ............................................................................10
3.10 Install the Hose Management System ......................................................11
3.11 Connect the water supply ......................................................................... 12
3.12 Familiarise yourself with the Command Centre connections ................... 12
3.13 Be careful with the sparkling pipework .................................................... 13
3.14 Post Installation......................................................................................... 13
SECTION 4: Cleaning and maintenance.......................................................... 14
4. 1 Cleaning .................................................................................................... 14
SECTION 1: Using these instructions
1.1 Using these instructions
Please refer to all safety and installation requirements detailed in the Quick
Start Guide provided with the HydroTap Command Centre, and HydroTap
Command Centre installation instructions found online, prior to installation of,
or any change to, the complete system.
Before commencing the installation, download
& read the HydroTap Command Centre
installation instructions.
!
Read the
instructions
WARNING

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
3
Be aware of the risks of hazards which could cause harm when
using tools.
Assess the risks before starting the installation.
2.1 Tools needed for tap installation
In addition to normal tools, the following (or equivalent equipment) will be
required, (not supplied).
• 50mm diameter hole saw to suit bench top type.
• Tube spanner (kit no. 93167) for fixing the tap assembly.
• Hose alignment tool (kit no. 96466).
SECTION 2: Generic installation requirements
3.1 Position the tap
Position the tap such that it dispenses into the sink
bowl with clearance to dispense all water options.
Ensure that taps are positioned to
minimise the risks of scalding by
dispensing boiling water while
using the tap.
SECTION 3: Installation - Celsius Plus AIO Pull-Out
• Check that there is enough space for the
tap and spout rotation (see adjacent).
Min - Max pressure, kPa (bar)
Australia UK
Celsius Plus AIO Pull-Out Tap 250 (2.5) - 700 (7.0) 250 (2.5) - 500 (5.0)
Optimal water pressure 350kPa
2.2 Water supply pressure requirements
508mm
211mm*
1300
50mm
hole 7mm
!
!
*to mixed
water outlet

4Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
3.2 Position the Hose Management System, cut the tap hole
Ensure that the tap dispenses into the sink with clearance to dispense all water
options.
Ensure that taps are positioned to minimise the risks of scalding
by dispensing boiling water while using the tap.
!
SECTION 3: Installation - Celsius Plus AIO Pull-Out
Tap
Hose
Management
System
Pull-Out
hose
• Position Command Centre and tap
as close together as possible.
• Ensure that the Hose Management
System is positioned correctly (see
adjacent).
• Cut a 50mm hole for the tap.
• Make sure the tap
location will allow the
spout to drain into
the sink. Note: the
sink is not shown,
to aid visualisation
of the installation)
• The Pull-Out hose must be
in line with the centre of the
50mm hole, this is important
for the performance of the tap,
with max. offset shown below.
• There is more allowable offset
the further the
Hose
Management
System is
moved
away from
the tap.
If fitting the Hose Management System lower in the cupboard,
check that there is enough space for the Command Centre.
150mm
min
10mm from
tap centre-line
30mm from
tap centre-line
50mm from
tap centre-line
TOP
*MIDDLE
*BOTTOM
!
*Check space available
for Command Centre.
400 approx
700 approx
> 700
the sink
is not
shown,
to
aid
visual-
isation
of the
installa-
tion Command
Centre

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
5
For optimal performance of the pull-out hose, the Hose Management System
must be installed so that the pull-out hose is in vertical alignment with the tap
base.
The Hose Management System can be installed at different heights below the
tap hole. The Hose Management System is designed with a hinged bracket to
allow correct angled positioning below the tap hole.
SECTION 3: Installation - Celsius Plus AIO Pull-Out
1 2 3 4
Hose Alignment Tool
3.3 Align the Hose Management System
• Choose an approximate location on the wall to mount
the Hose Management System.
• Place Hose Alignment tool in the 50mm hole.
• From beneath the benchtop, extend the Hose
Alignment tool, to the desired height. It does NOT
need to be fully extended.
• Position the Hose Management System so that the
Pull-Out Hose is aligned with the Hose Alignment
tool.
• Mark the top and right side of the bracket using a
pencil. Measure the distance from the edge of the
wall to the top and to the bottom of the bracket to
ensure it is vertical to the wall.

6Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
• Complete fixing the bracket by
using remaining 3x screws.
• Ensure the bracket is mounted
vertically.
SECTION 3: Installation - Celsius Plus AIO Pull-Out
Butterfly Screw
Mounting
bracket
Hose Man-
agement
System
Feed hose
Pull-Out
hose
• Unscrew the bracket and the two
butterfly screws.
• Remove the mounting bracket from
the Hose Management System.
• Fit the bracket to the wall with
a single screw and check level.
Wood screws are supplied, if wall
mounting use appropriate fixings.
3.4 Install the Hose Management System Bracket
• Once the bracket is installed, rotate the Hose
Management System in the bracket to align
the Pull-Out hose with the tap hole in the
bench above.
• Fit the butterfly screws on the bracket but do
not tighten the butterfly screws at this stage.
• To feed the Pull-Out hose through the tap, see
3.9.

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
7
SECTION 3: Installation - Celsius Plus AIO Pull-Out
Mains
See 3.9
Hot Cold
Mains
3.5 Mains water connections
See 3.9
• The hose colours match to the tap
colour idents.
•RED - hot.
•BLUE - cold.
3.6 Hose Management
System connections
• The Feed hose connects to the
elbow connector on the straight
copper pipe.
• Pull-Out hose connects to the
tap spray head, see page 10.
Elbow
connector
Pull-Out
hose
Feed
hose
Straight copper
pipe
!
Feed hose and Pull-Out
hose are not
interchangeable.
Review section 3.5 to 3.7 to familiarise yourself with the tap assembly before
making connection.

8Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
SECTION 3: Installation - Celsius Plus AIO Pull-Out
3.7 Tap connections
Sparkling models
BLUE
Chilled
tube
CLEAR
Vent tube
RED
Boiling
tube
BCS Chilled
arrangement
3x metal
connecting
tubes
Command
Centre USB
Main tap
USB
Auxiliary tap
USB
USB,
see adjacent
Water connections
• The silicone tubes connect to the Command
Centre via the 3 metal connecting tubes:
USB connections
• The tap USBs
are supplied
connected
together.
• Connect the main
tap USB to the
Command Centre
USB.
Tube
identification
Red - Boiling
Clear - Vent
Blue - Chilled

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
9
SECTION 3: Installation - Celsius Plus AIO Pull-Out
3.8 Mount and secure the tap & connect together
Upper rubber
washer
Lower rubber
washer Steel washer
Brass nut
Connect feed hose
to elbow on the
bottom of the tap.
See 3.6
Elbow

10 Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
• Connect the Pull-Out hose to
the spray nozzle.
• Push in firmly until it clicks into
position.
• Feed the Pull-Out hose
through the black flexible
spiral ducting at the base of
the tap until the connector
comes out of the tap spout.
• The Pull-Out hose cannot
be detached from the Hose
Management System.
Hose Management
System - Pull-Out
hose
Flexible spiral
ducting
Spray nozzle
Hose Management
System - Pull-Out
hose
Tap spout
3.9 Install the Pull-Out hose
SECTION 3: Installation - Celsius Plus AIO Pull-Out

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
11
SECTION 3: Installation - Celsius Plus AIO Pull-Out
3.10 Install the Hose Management System
• Fix the Hose Management System in place
by tightening the top and bottom butterfly
screws.
• The feed hose is supplied attached to the
check valve.
Check valve
Feed hose

12 Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
3.11 Connect the water supply
Braided hose to
Command Centre
MAINS inlet
All fittings are supplied apart from the isolation valve.
2x male adaptor
!
Valves and fittings must be sealed with PTFE tape.
1/2” BSP adaptor
Strainer
Mains water
isolation valve
(not supplied)
Connect together
Braided hose
to mixer tap
See 3.5
Hot water isolation valve
(not supplied)
Braided hose
to mixer tap
See 3.5
SECTION 3: Installation - Celsius Plus AIO Pull-Out
3.12 Familiarise yourself with the Command Centre connections
Mains In Mains potable water supply.
USB Connected to the tap.
Boiling out Red silicone tube from tap. Cut to length.
Chilled out (BCS) Blue JG pipe from tap. Cut to length.
(BC) Blue silicone tube from tap. Cut to length.
Vent Clear silicone tube from tap. Cut to length.
Sparkling out White JG pipe from tap. Cut to length.
Mains Water Requirements:
Minimum water pressure (static) 250kPa
Optimal water pressure (static) 350kPa
Operating water temperature 60°C
Maximum allowable water temperature 70°C
!

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
13
SECTION 3: Installation - Celsius Plus AIO Pull-Out
3.13 Be careful with the sparkling pipework
• Silicone tubes are soft and easily deformed. It is essential to avoid kinks,
loops and sags.
• Loosely cable-tie the rigid sparkling pipework to an adjacent braided hose
to avoid kinks and squeezing.
3.14 Post installation
IMPORTANT!
!
After installation is complete, it is very important to check if the Pull-Out tap is set up
and functioning correctly.
• Check the boiling water icon turns off when the spray hose is pulled out
indicating that boiling water cannot be dispensed, see HydroTap G5 User Guide
in Celsius Plus AIO & Pull-Out section on page 10.
• If it does not turn off, the tap has been incorrectly configured or there is a fault
with the safety interlock mechanism. Contact Zip on 1800 947 827 for a service
check.

14 Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
SECTION 4: Cleaning and maintenance
4. 1 Cleaning
• Wipe surfaces with a damp microfiber cloth and then wipe dry with a clean,
dry microfiber cloth.
IMPORTANT!
• Do not use air-drying disinfectant sprays.
• These could cause permanent malfunction and void warranty.
!

Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
15
NOTES

16 Quick Start Installation Guide
809806 v1.00 07.23 G5 Celsius Plus AIO Pull-Out Instructions
www.zipwater.com
Zip Water UK
Trafalgar House, Rash’s Green,
Dereham, Norfolk, NR19 1JG
0345 6 005 005
[email protected].uk
specify.zipwater.co.uk
Refer to User Guide for operation and maintenance.
Zip Water
67 - 77 Allingham Street, Condell Park NSW 2200
Postal: Locked Bag 80, Bankstown 1885
Australia
Tel [phone]
Free call 1800 947 827 (1800 ZIP TAP)
As Zip policy is one of continuous product improvement, changes to specifications may be made without
prior notice. Images in this booklet have been modified and may not be true representations of the
finished goods.
The terms “Zip” and “HydroTap” are registered trade marks of Zip Heaters (Aust) Pty Ltd.
WMK25927
AS/NZS 3718
