ZKTeco ZKSD4 Series User manual

User’s Manual for ZKSD4 Series Mini PTZ
Dome IP Camera
Document Version: 1.0
Date: 2012.12
Introduction
This document mainly introduces the functional features, installation process and
access methods of mini PTZ dome IPC.

Important Notices
Thanks for selecting our company’s IPC. Before use, please read through the user’s
guide to avoid any unnecessary damage!
All functions depend on the actual product. Since the product is subject to updating,
our company is not responsible for any difference from this guide and not liable for
any dispute over different technical parameters from this guide. The project is
subject to any change without notice.
To learn more, please visit our company’s website www.zkivision.com or local
office.

Table of Contents
I
Table of Contents
1 Overview................................................................................................................ 1
1.1 Product Description..................................................................................... 1
1.2 Product Features.......................................................................................... 1
1.3 Technical Parameters................................................................................... 3
1.4 ProductAppearance..................................................................................... 5
1.5 Connecting Terminal.................................................................................... 7
1.6 Basic Procedure........................................................................................... 8
2 Installation and Network Configuration ............................................................ 9
2.1 Hardware Installation................................................................................... 9
2.2 Network Connection.................................................................................. 13
3 Accessing device.................................................................................................. 15
3.1 Using WEB Browser ................................................................................. 15
3.2 Using RTSP Media Player ......................................................................... 16
3.3 Using Mobile Phone.................................................................................. 18
3.4 Using Video Surveillance Software ........................................................... 20
4 Extended Functions............................................................................................ 22

Overview
1
1 Overview
1.1 Product Description
The mini intelligent high-speed dome IP camera is developed using state-of-the-art
technologies and features high-performance digital signal processing (DSP). It is a
high-tech monitoring product integrated with a zoom lens, a universal
variable-speed Pan Tilt Zoom (PTZ), and a digital decoder.
This series camera features all-digital control and simple design, which minimizes
inter-component connections, improves system reliability, and facilitates installation
and maintenance.
The Web server embedded in the camera enables users to perform video monitoring
on their PCs through various TCP/IP-based networks.
This series camera can be used in indoor and outdoor locations with monitoring
requirements, such as jails, schools, factories, and residential areas. It is especially
applicable to the monitoring of moving targets and open places such as squares,
roads, and spacious halls.
1.2 Product Features
Is powered by a precise stepping motor, making the system stable, responsive,
and accurate
Implements fast locating, continuous tracking and scanning, and all-direction
monitoring
Adapts to changes in ambient lightness and target distance automatically

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
2
Provides the power-off memory function, which enables the camera to restore
to the original working status after it is powered off and then restarted, thereby
improving system security and reliability
All-digital design and power-off data protection (in which the system resumes
the original action after a power failure and restart)
Integrated design, compact structure, and high reliability
Power supply through a precise stepping motor, making the system stable,
responsive, and accurate
Ingenious mechanical drive device, which supports 360° continuous horizontal
rotation, 0º–90° vertical rotation, and 180° auto flip
Slow horizontal rotation at 0.5° every second while maintaining image
stability
Storage space for 255 presets
Six auto cruise tracks, with each one storing up to 16 presets
Integrated camera of high sensitivity and resolution
Auto focusing, auto Iris, auto lightness control, and auto white balance
Stepless speed change, human centered zoom, and auto speed matching
technology
Auto conversion between colored images and black and white images, auto
backlight compensation, and auto slow shutter
Camera that has 10x zoom and can automatically identify SONY and Samsung
brands
Double web indicator lamps for easy judgment of web status

Overview
3
Support of the proportional zoom function and auto adjustment of the
rotational speed according to the lens zoom multiple
Wire coming out from within, to better protect the wire
Double web indicator lamps for easy judgment of web status
Numerous additional functions, e.g. TF card and reset
No data loss in case of power-fail
Power-fail status memory; once the power is recovered, the system will
automatically be back to the previous status of the platform and lens
Hi3512 high-performance multimedia processor, supporting H.264 Main
Profile video coding
The highest resolution of images is to D1 (704 * 576) resolution
Dual code stream, suitable for various networks
Support the browsing by 20 users simultaneously, 10 in primary code stream
and 10 in secondary code stream
1.3 Technical Parameters
Product Name Mini PTZ IPC with 10x zoom Mini IR PTZ dome IPC
Product Model ZKSD420 ZKSD422
Cam Properties
Image Sensor
1/3"Super HAD CCD
Zoom Range 10-multiple optical zoom, 10-multiple electronic zoom
Optical lens F1.8(W)～3.1(T)；f=5.5～55mm
Minimum illuminance Normal mode: 1 Lux; Night mode: 0.1Lux(IR OFF )，0Lux( IR On )
Signal-to-noise ratio ≥48db(AGC OFF，Weight On)

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
4
Aperture Automatic aperture; the electronic mode is preferential
Focus
Automatic focusing; the electronic mode is preferential
Infrared projection NO 25 m～30 m
Video Coding
Primary Processor
Hi3512
Operating System Embedded Linux
Video Compression Algorithm
H.264 main profile level 3
Audio Compression Algorithm G.726/G.711
Video Compression Code Rate
Primary Code Stream: 32~512 Kbits/s adjustable
Secondary Code Stream: 32~256 Kbits/s adjustable
Video Resolution
Primary Code Stream: 704x576, 352x288, 176x144 optional
Secondary Code Stream: 352x288, 176x144 optional
Video Frame Rate
NTSC: 1~30 frames optional ; PAL: 1~25 frames optional
Functional Interfaces
Motion Detection
Allow 4 independent detection areas
Memory Support TF card for video storage and image capture, 32G maximum
(optimal)
Network Interface
10Base-T/100Base-TX Ethernet interface
WiFi 802.11b/g wireless (optional)
Supported Network Protocols TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP,
DNS, DDNS, NTP, UPNP and RTSP, etc.
PTZ
Horizontal Speed
0.5º~180º/s
Vertical Speed 0.5º~180º/s
Default Speed of Preset Position
150º/s
Horizontal Rotation 360º continuous rotation
Vertical Rotation
0º~90º, with auto flip
Preset Position 255 preset positions and precision of preset positions is less than 0.1

Overview
5
degree
Scan Mode
Three scan modes: automatic /random/preset position cruise path
Preset Position Cruise 6 preset positions, with each one storing up to 16 presets
Track Memory
2-track memory
RS-485 Pelco-D、Pelco-P
Working Environment
Input Power DC12V，1.5A
POE Ethernet power supply: comply with 802.3af regulation (optional)
Maximum Power Consumption 10W
Working Temperature
-10~+50 °C
Working Humidity 10%~85%RH
Installation Mode
Wall-mounted / Pending mounted
net weight 1.5KG
1.4 Product Appearance
Stereoscopic Drawing
Wall-mounted Pending mounted
ZKSD420: Mini PTZ IPC with 10x zoom

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
6
Wall-mounted Pending mounted
ZKSD422: Mini IR PTZ dome IPC
Dimensional Drawing (in mm) (the ZKSD422 mini IR PTZ dome IPC is used
as an example )

Overview
7
1.5 Connecting Terminal
(1) Power Interface: used for connecting the power adapter. The voltage of series
products is DC12VAC and the current is not lower than 1.5A. Other power is
not allowed, in order to avoid damage of the cameras.
(2) Network Interface: 10/100M self-adapting Ethernet interface is used to
connect the camera with various network equipments, such as, switch, router
and hub. When it is connected to 10M network, the orange lamp is also on.
When it is connected to 100M network, the green lamp is always on.
(3) Reset Button: When the camera fails to function during incorrect operation or
accidental failure (e.g. forget IP address or password), or it is used in different
scenes, press down the button for above 5s after a delay of 30s from powering
on to restore the camera to its factory default. The default user’s name is
“admin”, the default password is “admin” and the default IP address is
“192.168.1.88”.
1
2
3

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
8
1.6 Basic Procedure
(1) Unpack and check whether any component is missing;
(2) Connect the camera to computer by means of patch cable;
(3) If your computer IP is in a network section different from camera IP, please set
it to the same network section as camera IP, such as, 192.168.1.87.
(4) Log in the camera through client software or browser to check whether the
video functions normally;
(5) Adjust the code stream and other video parameters;
(6) Modify the network parameters of camera and reboot the device;
(7) Repeat Step 3;
(8) Revisit the camera through client software or browser to check till the video
functions normally;
(9) Install the camera and adjust the camera angle to the appropriate area;
(10) Visit the camera through client software or browse for video monitoring.

Installation and Network Configuration
9
2 Installation and Network Configuration
2.1 Hardware Installation
Installation Notices:
(1) Read through the guide for installation prior to installation.
(2) Check whether any component is missing against the packing list, if yes,
please contact your supplier.
(3) Wire during power off. If the camera does not function normally during
operation, please cut off the power before check.
Notice: The wiring during power on may seriously damage the camera,
which will be disqualified from the guarantee.

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
10
(4) Please use the power (voltage 24V AC and rating current no lower than
1.5A) provided by the factory for the cameras. Much higher or lower voltage
and direct current power may cause the camera failure.
(5) Use the standard power cord when the power supply is too far away from the
camera, and consider the voltage drop caused by long distance.
(6) Read through the instructions for connecting terminal and wire strictly
according to interfaces. Any damage to the camera due to improper operation
will be disqualified from the guarantee.
(7) Mount the relay equipment in the middle to avoid signal attenuation when the
straight communication distance from the camera to the incoming equipment
exceeds 80m.
(8) Pay attention to provide lightning protection if the camera is mounted outdoor.
Do not touch the camera during lightning.
(9) Use the camera in the working conditions:

Installation and Network Configuration
11
Ambient temperature: -10 ℃~ +55 ℃; ambient relative humidity: 10% ~
85%RH.
(10) Please keep the lens and transparent cover clean. If the transparent cover is
dirty, please wipe it with clean soft cloth.
(11) Do not let the cameras aim at intense light source for long period of time, in
order to avoid the CCD failure, which results in no images or distorted images
displayed.
Installation Diagram
Wall mounting (Unit: mm):
1. Attach the installation template sticker to the wall on which the camera will be
installed and drill holes as required by the template.
2. Hammer two screws, suspend the mini high-speed dome on the screws, and
tighten the screws.
3. Use the other two screws to fix the camera body.

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
12
①
②
③
Pendant mounting (Unit: mm):
1. Attach the installation template sticker to the wall on which the camera will be
installed and drill holes as required by the template.
2. Tighten three anchor screws and fix the hoisting base on the ceiling.
Installation Template
Installation Template

Installation and Network Configuration
13
3. Drive three screws into the screw holes on top of the mini high-speed dome by
half, align the dome with the notch of the base, continue to drive the screws
into the screw holes of the base, and tighten the screws.
2.2 Network Connection
The device can be connected to network in two ways. The first way is to connect to
the network by means of Ethernet cable, and the second way is to connect to
wireless network (optional).
..............................Connect by Ethernet Cable
(1) Use Ethernet cables to connect the device to network or directly to computer.
(2) Connect the power supply of the device.
(3) During normal connection, if it is a 10M network, the orange lamp is always
on; if it is a 100M network, the green lamp is also on. The physical connection
with network is completed after the lamp shining.
(4) In the “Start” menu, select “Programs”--“Accessories”--“Command Prompt”,
and input the ping command to the device address (e.g.: type in “ping
192.168.1.88”). If “Request timed out” does not pop up, the device is
successfully connected to network.

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
14
Notice: 1) The default IP address is “192.168.1.88” and the default HTTP
port is 80. If needed to change IP address or port, refer to Network Setting in
WEB Server User Manual.
2) If the device is in a network section different from computer, refer
to How to Visit IPC on Internet in WEB Server User Manual for the
connection during different network sections.
..............................Connect to Wireless Network
Before starting the wireless network, connect the IPC to network by Ethernet cable,
visit the device through browser, enter “Network Settings” interface, and set the
wireless network connection following the operating procedure, as detailed in
Network Setting in WEB Server User Manual.

Accessing device
15
3 Accessing device
There are 4 methods can be used to access the device: WEB Browser, RTSP Media
Player, Mobile Phone and Video Surveillance Software (ZKiVision client software).
3.1 Using WEB Browser
1. Open a browser, type in the dynamic domain name or IP address of the device
(e.g. http://192.168.80.123), press "Enter" to open the following login interface:
2. Type in user’s name and password, and click “OK” and the guide page will
show as below:
3. Click Watch the video to enter Preview interface:

User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0
16
Note: When accessing the device via browser for the first time, it is necessary
to download the ActiveX. More details about how to use browser for video
surveillance, please refer to WEB Server User Manual in the supplied CD.
3.2 Using RTSP Media Player
1. Download and install a media player supporting RTSP protocol, e.g. VLC
media player.
2. Open the media player, select the menu “Media”—“Open Network Stream”,
pop up the input interface of URL.
