Zodiac eXO iQ 10 User manual

H0632500.B- 2019/11 - ES11--
More documents on:
www.zodiac.com
Instruc ons for installa on and use - English
Salt water chlorinator, pH/Redox regula on
Transla on of the original instruc ons in french EN
pH Link / Dual Link
eXO®/ eXO® iQ (LS)
GenSalt OT

1
WARNINGS
GENERAL WARNINGS
• Failure to respect the warnings may cause serious damage to the pool equipment or
cause serious injury, even death.
• Only a person quali ed in the technical  elds concerned (electricity, hydraulics or
refrigera on) is authorised to perform this procedure. The quali ed technician working
on the appliance must use/wear personal protec ve equipment (such as safety goggles
and protec ve gloves, etc.) in order to reduce the risk of injury occurring when working
on the appliance.
• Before handling the machine, ensure that it is switched o and isolated.
• The appliance is intended to be used with pools for a speci c purpose; it must not be used
for any purpose other than that for which it was designed.
• It is important that the appliance is operated by people who are competent and quali ed
(both physically and mentally), a er having read the instruc ons for use. All persons not
mee ng these criteria must not approach the appliance in order to avoid exposure to
dangerous elements.
• This appliance is not intended for use by individuals (including children) with impaired
physical, sensorial or mental abili es, or persons lacking in knowledge and experience,
unless they receive supervision or prior instruc ons on using the appliance from a person
responsible for their safety. Children must be supervised to ensure that they do not play
with the appliance.
• This appliance must not be used by children under 8 or by adults whose reduced physical,
sensory or mental capabili es, or whose lack of experience and knowledge, might cause a
hazard, unless they have been correctly instructed to understand the safe use and hazards
involved and are adequately supervised. Children must not be allowed to play with this
appliance. User cleaning and maintenance opera ons must not be carried out by children
without supervision.
• The appliance must be installed according to the manufacturer’s instruc ons and
in compliance with local standards in force. The installer is responsible for installing
the appliance and for compliance with na onal installa on regula ons. Under no
circumstances may the manufacturer be held liable in the event of failure to comply with
applicable local installa on standards.
• For any work other than the simple user maintenance described in this manual, the
product should be referred to a quali ed professional.
• Incorrect installa on and/or use may cause serious damage to property or serious injuries
(possibly causing death).
• All equipment, even postage and packing paid, travels at the risks and perils of the
recipient. The la er shall issue reserves in wri ng on the carrier's delivery slip if damage is
detected, caused during transport (con rma on to be sent to the carrier within 48 hours
by registered le er). In the event that an appliance containing coolant has been turned
on its side, men on your reserva ons in wri ng to the carrier.
• If the appliance su ers a malfunc on, do not try to repair it yourself; instead contact a
quali ed technician.
• Refer to the warranty condi ons for details of the permi ed water balance values for
opera ng the appliance.
• Deac va ng, elimina ng or by-passing any of the safety mechanisms integrated into
the appliance shall automa cally void the warranty, in addi on to the use of spare parts
manufactured by unauthorised third-party manufacturers.
• Do not spray insec cide or any other chemical ( ammable or non- ammable) in the
direc on of the appliance, as this may damage the body and cause a  re.
• Do not touch the fan or moving parts and do not place a rod or your  ngers in the vicinity
of the moving parts during opera on of the appliance. Moving parts can cause serious
injury or even death.
EN

2
Recycling
This symbol means that your appliance must not be thrown into a normal bin. It will be selecvely
collected for the purpose of reuse, recycling or transformaon. If it contains any substances that may be
harmful to the environment, these will be eliminated or neutralised.
Contact your retailer for recycling informaon.
WARNINGS ASSOCIATED WITH ELECTRICAL APPLIANCES
• The power supply to the appliance must be protected by a dedicated 30 mA
residual current device, complying with the standards and regulaons in force in
the country in which it is installed.
• Do not use any extension lead when connecng the appliance; plug the appliance
directly into a suitable wall socket.
• Before carrying out any operaons, check that:
- The voltage indicated on the appliance informaon plate corresponds to the
mains voltage.
- The power grid is adapted to the power requirements of the appliance, and is
grounded.
- The plug (where applicable) is suitable for the socket.
• In the event of abnormal operaon or the release of odours from the appliance,
turn it o immediately, unplug it from its power supply and contact a professional.
• Before any intervenon on the appliance, ensure that the laer is switched o
and disconnected from the power supply, in addion to any other equipment
connected to the appliance.
• Do not disconnect and reconnect the appliance to the power supply when in
operaon.
• Do not pull on the power cord to disconnect it from the power supply.
• If the power cord is damaged, it must be replaced by the manufacturer, its technician
or a qualied person to guarantee safety.
• Do not perform maintenance or servicing operaons on the appliance with wet
hands or if the appliance is wet.
• Clean the terminal block or the power supply socket before connecon.
• For any component or sub-assembly containing a baery: do not recharge or
dismantle the baery, or throw it into a re. Do not expose it to high temperatures
or direct sunlight.
• In stormy weather, unplug the appliance to prevent it from suering lightning
damage.
• Do not immerse the appliance in water (with the excepon of cleaners) or mud.

3
CONTENTS
❶ Speci ca ons 5
1.1 I Package contents 5
1.2 I Technical speci ca ons 7
❷ Installing the salt water chlorinator 8
2.1 I Installing the cell 8
2.2 I Installing the temperature sensor (depending on the model) 10
2.3 I Installing the  ow switch (chlorinator only without pH Link or Dual Link modules) 10
2.4 I Installing the control box 11
2.5 I Electrical connec ons 12
❸ Installing a pH Link or Dual Link module 19
3.1 I Installing the module 19
3.2 I Installing the POD kit 20
3.3 I Installing the  ow switch on the POD kit 23
3.4 I Installing the sensors on the POD kit 24
3.5 I Installing the pH minus injec on and suc on hoses 25
❹ Preparing the pool 27
4.1 I Balancing the water 27
4.2 I Adding salt 28
❺ Use 29
5.1 I User interface 29
5.2 I Con gura on before use 29
5.3 I Calibra ng the sensors (if an op onal "pH Link" or "Dual Link" module has been installed) 41
5.4 I Rou ne use 46
❻ Control using the iAquaLink™ app (depending on the model) 48
6.1 I Con guring the appliance before  rst use 48
❼ Care 50
7.1 I Cleaning the sensors 50
7.2 I Inspec ng and cleaning the electrodes 51
7.3 I Washing the pool  lter (backwashing) (depending on the model) 52
7.4 I Winterising 52
7.5 I Preparing the pool for re-use 52
EN

4
❽ Troubleshooting 53
8.1 I Appliance behaviour 53
8.2 I Wi-Fi LED behaviour 55
8.3 I E ects of the stabilising agent on chlorine and ORP 56
8.4 I HELP menu 56

5
❶ Speci ca ons
1.1 I Package contents
1.1.1 The appliance
eXO® (iQ) GenSalt OT
eXO® (iQ) GenSalt OT
AControl box
BElectroly c cell
CGlue-on adapter and union coupling kit for electroly c cell
DWall-moun ng bracket kit
EFlow switch with installa on kit
FTemperature sensor with installa on kit
GpH Link module (pH measurement and automa c adjustment)
H Dual Link module (pH and ORP measurement and automa c adjustment)
: Included
: Op onal extra
• Before handling the appliance, it is vital that you read this installa on and user
manual, as well as the "warnings and warranty" booklet delivered with the appliance.
Failure to do so may result in material damage or serious or fatal injury and will void
the warranty.
• Keep and pass on these documents for later consulta on during the appliance's
service life.
• The distribu on or modi ca on of this document in any way is prohibited, without
prior authorisa on from Zodiac®.
• Zodiac® is constantly developing its products to improve their quality. The informa on
contained herein may therefore be modi ed without no ce.
EN

6
1.1.2 Op onal pH Link or Dual Link module
x3 x3 x3
x2
pH Link Dual Link
ApH Link or Dual Link module
BPOD kit
CHole saw for installing the POD kit
DThreaded sensor holder(s) x1 x2
EpH sensor + pH7 (x3) and pH 4 (x3) bu er solu ons
FORP sensor + 470 mV ORP bu er solu ons (x3)
G5-metre suc on and injec on hose
HBag of moun ng   ngs
(2 threaded caps, 1 ceramic weight with support  p, Te on tape)
: Included

7
1.2 I Technical speci ca ons
1.2.1 Salt water chlorinator
eXO® (iQ) 10
GenSalt OT 10 eXO® (iQ) 18 GenSalt OT 18 eXO® (iQ) 22 GenSalt OT 25 eXO® (iQ) 35
Nominal chlorine produc on 10 g/h 18 g/h 22 g/h 25 g/h 35 g/h
Nominal output current 2.8 A 3.6 A 5 A 5 A 7.2 A
Recommended salt
level - minimum salt
level
Standard
salinity
eXO®(iQ): 4 g/L - 3.3 g/L min.
GenSalt OT: 3.0 g/L min.
Low salinity
(LS) 2 g/L - 1.6 g/L min. /
Supply voltage 110 - 240V
50-60 Hz
Electrical power 200 W maximum
Protec on ra ng IP43
Cell throughput (minimum/
maximum) 5m³/h < 18m³/h
Maximum allowable pressure in
the cell 2.75 bar
Opera ng water temperature 5°C < 40°C
Frequency bands 2.400 GHz - 2.497 GHz
Radio output power +19.5 dBm
1.2.2 Op onal pH Link or Dual Link module
pH Link Dual Link
Supply voltage Extra-low voltage (connected to the control box)
Peristal c pump  ow rate 1.2 L/h
Maximum back pressure (injec on) 1.5 bar
pH and ORP sensor type Combined (pH=blue/ORP=yellow)
pH correc on pH minus only (hydrochloric acid or sulphuric acid)
pH minus dispensing Propor onal cyclic
pH sensor calibra on 1 point or 2 points (pH 4 and pH 7)
ORP sensor tolerances /10 ppm maximum (shock
chlorina on)
ORP sensor calibra on 1 point (470 mV)
Sensor cable length 3 metres
EN

8
❷ Installing the salt water chlorinator
2.1 I Installing the cell
• The cell must be installed on the piping a er the  ltra on system, a er any measurement sensors, and
a er any hea ng system.
Installing the chlorinator only
(Example with eXO® (iQ))
Installing the chlorinator + op onal module
(Example with eXO® (iQ))
• The cell must always be the last element placed on the pool return pipe (see diagram).
• It is always recommended to install the cell on a by-pass. This assembly is MANDATORY if the
fl ow is in excess of 18 m³/hour to avoid head loss.
• If you installed the cell on a by-pass, it is recommended to  t a check valve downstream from
the cell instead of a manual valve, to avoid any risk of incorrect con gura on which could
result in poor circula on inside the cell.
2.1.1 eXO® (iQ) cell
12.5 cm
21.5 cm
32 cm
11 cm
15.5
cm 21.5
cm
11 cm
21.5 cm
• Make sure that the cell is placed HORIZONTALLY. The water should  ow from the electric connec ons
towards the opposite side.
• Use the screw-on   ngs to  x the cell to the pipes.
• For Ø63 mm pipes, glue them directly to the screw-on   ngs. For Ø50 mm pipes, use glue-on PVC adapters
of the corresponding diameter (grey models; the white models are for 1 ½’’ UK pipes).
• Connect the cell power cord following the wire colour codes (red, black and blue connectors) and then re t
the protec ve cap. The two red wires can be connected to one or the other red terminals on the electrode.

9
2.1.2 GenSalt OT cell
16.5 cm
22.5 cm
27.5 cm
7.5 cm
27.5 cm
12.5 cm
• The cell must be installed on a horizontal pipe so as to guarantee that the water  ow passing therethrough
is primarily horizontal, and that the angle/slope does not exceed 30°. The pipe must have a free horizontal
length of at least 30 cm, on which the cell will be installed. The cell must also be installed as far as possible
from any right angle or curve formed in the piping ( ).
• Respect the water  ow direc on (see arrows ( )).
INLET OUTLET
30°
0°
30°
max. max.
• Dismantle the cell ( ).
• Posi on the EU pipe adapter (DN50 mm) upside down at the posi on where the pipe ( ) will be installed.
• Use a drill bit or centre-punch to mark the posi ons of the holes to be drilled on the pipe, remove the EU
pipe adapter (DN50 mm) and drill the holes using the hole saw supplied.
• Check that the edges are perfectly smooth and deburred (use abrasive paper for example).
• Clip together the lower and upper parts of the cell collar on the pipe at the holes, respec ng the water  ow
direc on (use the "EU" Ø50 adapter for a Ø50 mm pipe).
• Posi on the top transparent part of the cell (presence of a foolproof loca ng notch), posi on the
compression ring on the thread of the upper collar by aligning the point ( ) of the collar with the arrow
of the collar ( ), then  ghten  rmly by hand (do not use a tool).
• Connect the cell power cord in compliance with the wire colour codes (red, black and blue connector(s))
and then  t the protec ve cap. For GenSalt OT 10, the second red connector will not be connected; leave
it as it is before posi oning the protec on cover.
EN

10
2.2 I Installing the temperature sensor (depending on the model)
• The water temperature sensor displays the water temperature value on the appliance screen and manages
chlorina on according to the temperature. The sensor must measure the temperature of the water
upstream of any possible hea ng system.
• The sensor is designed to be mounted on rigid Ø50 mm, Ø63 mm or Ø1 ½’’ PVC pipes. Do not install on any
other type of pipe.
• Install the sensor either between the  lter pump and the  lter, or between the  lter and any other
downstream equipment, see “2.1 I Installing the cell”:
-Drill a hole in the pipe using a Ø9 mm (max. Ø10 mm) drill bit, then deburr the hole,
-Install the O-ring provided on the sensor body,
-Secure the sensor using the stainless-steel clamping collar provided. Do not use excess strength.
: Sensor
: O-ring
: Stainless steel clamping
collar
2.3 I Installing the fl ow switch (chlorinator only without pH Link or Dual Link modules)
In cases where a pH Link or Dual Link module is used, the  ow switch will be installed on the POD
Kit, see “3.3 I Installing the fl ow switch on the POD kit”
• The  ow switch and its 50 mm diameter  xture collar supplied as standard (63 mm diameter available
as a spare part) must be installed immediately before the cell and a er any valves present (). Use the
threaded adapter and the Te on tape provided to install the  ow switch on its  xture collar.
• Screw the  ow switch using using the clamping nut only (screw by hand!) ().
Clamping
nut
Direc on of water
 o w
Installa on on a by-pass In-line installa on
• Failure to comply with these instruc ons could lead to the destruc on of the cell! The
manufacturer cannot be held liable in this case.
• The fl ow switch has a direc on for installa on (arrow indicated on it showing the fl ow
direc on for the water). Make sure that it is correctly placed on its  xture collar so that it
stops the appliance's produc on when  ltering is stopped.

11
2.4 I Installing the control box
31.5 cm 9.6 cm
36.4 cm
• The control box must be installed in a dry ven lated technical room protected against frost, with no pool
maintenance products or similar products stored nearby.
• The control box must be installed at a distance of at least 3.5 m from the outside edge of the pool. Always
comply with the installa on codes and/or laws applicable at the place of installa on.
• It must not be installed more than 1.8 metres from the cell (maximum cable length).
• If the box is  xed to a post, a water ght panel must be  xed behind the control box (350x400 mm minimum):
-A ach the metal moun ng below to the wall or to the water ght panel using the screws and wall plugs
provided, (see  gure ).
-Fix the control box to the metal support by moving 1 (downwards) and 2 (rightwards) in order to lock the
box onto its support, (see  gure ).
Using Wi-Fi Direct mode (depending on the model): Use a smartphone (Se ngs/Wi-Fi menu) to check
that the home Wi-Fi network can be detected when choosing the best loca on for the control
box. A Wi-Fi extender or powerline adapters with Wi-Fi hotspot (not supplied) may be required in
some cases.
EN

12
2.5 I Electrical connec ons
Many devices can be connected to the control box in order to control the pool equipment ( lter pump, ligh ng, auxiliary
systems, etc.).
The appliance must be permanently plugged in to the power supply (power supply protected by a 30 mA residual current
circuit breaker).
• Turn the appliance o . Before beginning, disconnect all poten al power supplies to the
appliance.
2.5.1 Accessing the electrical terminal blocks
• Make sure that the appliance is powered o .
• Remove the aesthe c housing from the control box (clipped in place), (see  gure or depending on
the model).
• Remove the bo om protec ve cover from the appliance by unscrewing the 2 side screws (see  gure ).

13
2.5.2 Iden fying the func ons to be connected
Terminal
block
messages Type Cable
clamp Func ons eXO® (iQ) GenSalt OT With pH Link or Dual Link
SENS Input -Connec on for the control board
for pH Link and Dual Link modules / /
PUMP Input -Connec on for the pH regula on pump
for pH Link and Dual Link modules / /
CELL Output 1 Connec on for the electroly c cell
UI Output -Connec on for the display
TEMP Input 3 Connec on for the temperature sensor /
Flow Input 2 Connec on for the  ow switch
iAL RS485 Input 4Func on not used – do not wire / / /
VSP RS485 Output 5 Connec on dedicated to controlling the
Zodiac® variable-speed  lter pump /
/ - Func on not used – do not wire / / /
COVER Input 7 Connec on for the roller shu er/cover for
automa cally managing the LOW func on
SLAVE Input 8 Connec on for an external appliance for the ON/OFF control of the chlorinator (automa c
regula on, etc.) /
AUX 2 12-
24V Output 9
Connec on dedicated to the ON/OFF control
of a low-voltage device. Connec on used to
control a hea ng system. This connec on
does not power the device: it manages the
ON/OFF func on.
AUX 1 230
VOutput 10
Connec on dedicated to the ON/OFF control
of a high-voltage device. This connec on
does not power the device: it manages the
ON/OFF func on.
/
PUMP
230V Output 11 Connec on dedicated to the power supply to the pool  lter pump.
MAINS Input 12 Mains power supply to the appliance
110-240 VAC - 50/60 Hz
: Connec ons made during manufacture : Mandatory connec ons to be made : Func on to be connected (op onal)
EN

14
2.5.3 Electrical connec on steps
• Iden fy the func ons to be connected and locate the posi on of the cable clamp, see “2.5.2 Iden fying
the func ons to be connected”.
• Check that the cables used comply with the intended use and with the regula ons in force.
• Iden fy the input for each desired func on at the bo om of the control box:
pH = blue
pH = blue
ORP = yellow
View from below of a control box with an installed module
• Pass the cable into the associated cable gland or pierce a hole in the PVC diaphragm (made of rubber) using
a screwdriver of an appropriate diameter.
• Iden fy the terminal block dedicated to the desired func on using the iden  ca on zones:
Low-voltage
part
High-voltage
part
• Install a cable clamp (supplied) to mechanically hold the cable against the appliance's frame; the position
of the cable clamp is shown, see “2.5.2 Identifying the functions to be connected”.
• If the  lter pump (single- or variable-speed pump) is connected to the chlorinator, it must be grounded
using the dedicated grounding stud by crimping an appropriately-sized lug for the wire (not supplied).

15
2.5.4 External connecons: what products should be connected?
The chlorinator must be protected by a circuit breaker of the same type as that used for a lter pump (for
example a ltraon control panel).
If the chlorinator is powered by a ltraon control panel, the mers must be manually set to 24/7 mode. The
chlorinator manages all mers and must receive a connuous power supply.
12 - 24 V contact
230 V contact
RS485 cable (supplied
with the pump)
230 V power
supply
230 V power
supply
All types of auxiliary device
12 - 24 V
All types of auxiliary
device
230 V
FloPro™ VS All lter pump models
Heang (heat pump, heat
exchanger, electric heater),
booster pump, etc.
maximum 8 A
Transformer for lighng,
booster pump, etc.
maximum 8 A
Variable-speed pump
maximum 8 A
Single-speed pump or
variable 3-speed pump of
type FloPro™ e3.
maximum 8 A
2.5.5 Connecng to a lter pump (depending on the model)
The chlorinator can power and control the lter pump.
In such a case, the chlorinator must be powered via an electrical protecon that is calibrated for a lter pump.
Possible controls:
- For a single-speed pump (SSP): ON/OFF with 2 mers,
- For a FloPro™ VS variable-speed pump (VSP): ON/OFF/RPM with 4 mers.
(see installaon manual for the Zodiac™
FloPro® VS lter pump)
RS485 Cable
(supplied with the pump) Power supply
230 V
230 V power
supply
FloPro™ VS All lter pump models
Variable-speed pump
maximum 8 A Single-speed pump for all models or compable
Zodiac® variable-speed
pump.
maximum 8 A
GREEN
YELLOW BLACK
RED
RED BLACK YELLOW
GREEN
(Terminal block at the level of the FloPro™ VS pump)
EN

16
2.5.6 Connec ng to an auxiliary device = AUX 1 - Dry contact provided for disconnec on from the 230V
power supply (depending on the model)
The chlorinator manages a dry contact calibrated for disconnec on from the 230V power supply. The power
supply is separated with its own protec on (circuit breaker calibrated to suit the equipment controlled or its
transformer – max. 8 A).
Preferred connec on for NL LED spotlights.
Possible controls: ON/OFF with  mer for all monochroma c spotlights, ON/OFF/Colour with NL RGBW LED
spotlights
230 V contact
All types of auxiliary
device
230 V
Transformer for ligh ng,
booster pump, etc.
maximum 8 A
Preferred connec on for Zodiac® NL LED spotlights (see
installa on manual)
: 230 VAC/12 VAC
(50/60 Hz) transformer
: Electrical protec on
: Auxiliary relay for
external controller or
switch
With 2 spotlights With 1 spotlight

17
2.5.7 Connecng to a heang system = AUX2 - 12-24V
12 - 24 V contact
All types of auxiliary
device
12 - 24 V
Heang system
with remote on/o control
1. Use an appropriate length of a 2 x 0.75 mm²
cable (not supplied).
2. Use this cable to connect the appliance contact
(AUX2) to the remote on/o control of the
heang system (see connecon details in the
associated installaon manual).
3. Turn the heang system on. Set the
temperature setpoint of the heang system
to its maximum (and set to the desired mode
if there are several heang modes available).
The chlorinator will use the water temperature
measured by its sensor to manage the acvaon
of the heang system according to the
temperature setpoint.
12
AUX 2 (12-24 V)
A = Chlorinator
B = Heang system
A
Connecon of a heang system
with remote on/o control
2 x 0.75 mm
Heang system
without remote on/o control
1. Use an appropriate length of a 2 x 0.75 mm² cable
(not supplied).
2. Disconnect one of the 2 ow switch (D) wires from
the terminal block of the heang system (B) (refer to
the manual if necessary).
3. Connect the wire from terminal 1 of the
chlorinator (A) in place of the ow switch (D) wire
that was disconnected from the terminal block of
the heang system (B).
4. Connect the disconnected ow switch wire (step
2) with the wire from terminal 2 of the chlorinator
(A) using a suitable connecon terminal (C).
5. Turn the heang system on. Set the temperature
setpoint of the heang system to its maximum (and
set to the desired mode if there are several heang
modes available). The chlorinator will use the water
temperature measured by its sensor to manage the
acvaon of the heang system according to the
temperature setpoint.
12
AUX 2 (12-24 V)
A = Chlorinator
B = Heang
system
C = Connecon
terminal block
D = Flow switch
A
Connecon of a heang system
without remote on/o control
2 x 0.75 mm
EN

18
2.5.8 Reassembling the appliance
• Posi on the bo om protec ve cover (or the pH Link/Dual Link module) on the appliance and screw in the
2 side screws (see  gure ).
• Clip the aesthe c housing of the control box in place (see  gure " a" or " b" depending on the model).
a b
• If a pH Link or Dual Link module has been installed, do not reconnect the electricity supply
un l the module, the POD kit and the pH minus injec on pipe have been installed.
