Zoeller APak User manual

© Copyright 2020 Zoeller Company All rights reserved.
All electrical and safety codes must be followed including the National Electrical Code and all applicable local codes.
SPECIFICATIONS
This alarm unit monitors liquid levels in lift pump chambers, sump pump basins, holding tanks, and other non-potable water applications (See Figure
A). APak™Outdoor High Water Alarm features a green Power On LED, red alarm LEDs, an audible buzzer, one set of normally closed and normally open
Auxiliary contacts, and a Silence/Reset/Test toggle switch. The APak™Outdoor High Water Alarm can be wired to a 120 V, 60 Hz, electrical power
source. This product is rated as NEMA 4X. To maintain rating, use only equivalent rated conduits and install in accordance with applicable standards.
Tighten enclosure screws once a year, (recommended torque of 0.45 Nm or 4 in-lbs.) and perform any required maintenance to ensure protection. 15A
household circuit breaker required.
ALARM UNIT INSTALLATION / WIRING
1) Drillopeningsonthebottomoftheenclosuresufcienttoaccommodatetheappropriateconduitadapter.Followguidelinestoensureawater
tighttwhereapplicable.
2) Installunitindesiredlocationusingmountingangesonenclosure.
3) Remove the 4 cover screws to access the terminal contacts and the auxiliary contacts.
4) Wire line and neutral to terminal contacts 1 & 2 and connect earth ground to the ground lug located on metal backplate (See Figure B).
5) Wiremechanicaloatswitchtoterminalcontacts3&4(SeeFigureB).
6) Terminal contacts 5, 6, 7 are provided as an optional wiring junction point for the pump. 115/230V, 20A max.
7) Auxiliary contacts may be used to control other alarm circuits and are rated for 115V, 60Hz, 5A resistive load.
APak™Outdoor High Water Alarm
ELECTRICAL SHOCK HAZARD.
DISCONNECT POWER BEFORE SERVICING
Product information presented
here reects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
TEL: [phone] • 1 (800) 928-PUMP • FAX: [phone]
Visit our web site:
zoeller.com
FM3287
1220
Supersedes
New
ALARM UNIT
CONDUIT
ALARM “ON” LEVEL
ALARM “OFF” LEVEL
PUMP “ON” LEVEL
PUMP “OFF” LEVEL
Figure A

© Copyright 2020 Zoeller Company All rights reserved.
CONTROL/MECHANICAL SWITCH WIRING
Connectthetwoconductorsfromthehighwateroatswitchtoinputterminalsasdescribedaboveforthealarmunit(seeFigureB).Thealarmswitch
operates on low voltage to reduce shock hazards. The auxiliary contacts may be used to control another alarm circuit away from the location of the
APak™Outdoor High Water Alarm system.
OPERATION AND TESTING
Checkandtestyourinstallationbyliftingtheoatmanually.ThealarmunitwillindicateanalarmconditionbybuzzerchirpingandlightingtheredLEDs.
Thealarmmaybesilencedfor24hoursbybrieypressingtheSilencetoggleswitch.Oncesilenced,theRedLEDswillremainonbutthebuzzerwillnot
sound. Once the high-water condition is remedied, the alarm should be reset by holding the Silence toggle switch for 2 seconds. Hold the Silence toggle
switch up to Test once per week to verify proper operation.
Figure B
TERMINAL BLOCK
TERMINAL BLOCK LABEL
GROUND LUG
AUXILIARY CONTACTS
(4) ALARM LED
POWER ON LED
ALARM BUZZER
TEST
TOGGLE
SWITCH
SILENCE/
RESET
LINE NEUTRAL FLOAT FLOAT

© Copyright 2020 Zoeller Company All rights reserved.
INSTALL MECHANICAL FLOAT SWITCH (011833)
1) Place cord into clamp and secure to discharge pipe as shown in clamp detail (see Figure C).
NOTE: Do not install the cord under the hose clamp.
2) Tighten the hose clamp with a screwdriver.
NOTE: Do not over tighten; over-tightening may cause damage to the plastic clamp.
3) Makesuretheoatcableisnotallowedtotouchtheexcesshoseclampbandduringoperation.
4) Theoatswitchmustbesuspended7”(17.8cm)belowdesiredactivationlevel(seeFigureD).
5) Becertainthatinstallationofoatallowsforunobstructedrangeofmotion.
IN A LIFT PUMP
Installoatswitchatalevelabovewherethepumpwillenergize.Ifapumpfailurecauseshigh-levelcondition,theAPak™Outdoor High Water Alarm
System will activate (see Figure A).
IN A HOLDING TANK
Suspendoatswitchintotank7”(17.8cm)belowdesiredalarmlevel.APak™OutdoorHighWaterAlarmSystemwillactivateifoatascendstoalarm
level (see Figure D).
Model Number 91104-0001
Item Description Qty Part #
1 Clamp, #36 worm-SS 1 001766
2Switch,mechanicaloat 1011833
Zoeller Company cannot be responsible for damages caused by faulty or negligent installation of this device. We respectfully suggest you
engagetheservicesofaqualied,licensedelectricianorserviceperson.
2
7"
ALARM
LEVEL
CLAMP
DETAIL
7” (17.8 cm)
TETHER LENGTH
FOR ALARM FLOAT
Figure C Figure D
CLAMP DETAIL
