Zte Blade A52 User manual

Quick Start Guide
Quick Start Guide

1
Quick Start Guide (en)……………….……………2
Kurzanleitung (de) ……………….………………14
HızlıBaşlangıç Kılavuzu (tr) ……….….….…….27
Guía de inicio rápido (es) …….…………………39
Guia de início rápido (pt) ………….…………….52
Guida rapida all'uso (it) …………….……………65
Kratke upute (hr) …………………..…….……….78
Краток водич за користење (mk) …….……….90
Priročnik za hitro nastavitev (sl) ….….…………103
Кратко ръководство(bg) ……….………………116

2
ZTE Blade A52
Quick Start Guide

3
LEGAL INFORMATION
Copyright © 2022 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means,
electronic or mechanical, including photocopying and
microfilm, without the prior written permission of ZTE
Corporation.
Notice
ZTE Corporation reserves the right to make
modifications on print errors or update specifications in
this guide without prior notice.
We offer self-service for our smart terminal device users.
Please visit the ZTE official website (at
https://ztedevices.com) for more information on user
manual, self-service and supported product models.
Information on the website takes precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for
faults and damages caused by unauthorized
modifications of the software.
Images and screenshots used in this guide may differ
from the actual product. Content in this guide may differ
from the actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE
Corporation.
Android™ is a trademark of Google LLC.
The Bluetooth®word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any
use of such marks by ZTE Corporation is under license.
microSDXC Logo is a trademark of SD-3C,
LLC.
Other trademarks and trade names are those of their
respective owners.

4
Getting to Know Your Phone
Front camera
Touch screen
Earpiece
Volume key
Power key
Charging/
micro-USB jack
Headset jack
Back cameras
and flash
Speaker
Indicator light
nano-SIM
/
microSDXC
card tray
Proximity &
light sensor
Fingerprint
sensor

5
Setting Up Your Phone
The nano-SIM card(s) can be installed or removed while
the phone is turned on.
WARNING!
To avoid damage to the phone, do not use any other kind
of SIM cards, or any non-standard nano-SIM card cut
from a SIM card. You can get a standard nano-SIM card
from your service provider.
1. Insert the tip of the tray eject tool into the hole on the
card tray.
CAUTION:
Never replace the included tray eject tool with sharp
objects. Ensure that the tray eject tool is perpendicular to
the hole. Otherwise, the phone may be damaged.
2. Pull out the card tray. You can place a nano-SIM
card on the right card slot, and place a nano-SIM
card or a microSDXC card (optional) on the left card
slot, as shown. Carefully slide the tray back into
place.

6
NOTE:
If two nano-SIM cards are installed, both cards can
connect to the 4G, 3G, or 2G network, and either card
can be used for mobile data.
Charging the Phone
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls. You
should fully charge the battery as soon as possible.
WARNING!
Use only ZTE-approved chargers and USB cables. The
use of unapproved accessories could damage your
phone or cause the battery to explode.
WARNING!
Do not remove the back cover. The battery is not
removable. Removal may cause fire or explosion.
1. Connect the adapter to the charging jack. Ensure
that the adapter is inserted in the correct direction.
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully
charged.
NOTE:
If the battery is extremely low, you may be unable to
power on the phone even when it is being charged. In
this case, try again after charging the phone for at least
20 minutes. Contact the customer service if you still
cannot power on the phone after prolonged charging.

7
Powering On/Off Your Phone
Make sure the battery is charged before powering on.
•Press and hold the Power key to turn on your
phone.
•To power off, press and hold the Power key to open
the options menu, and touch >.
NOTE:
If the screen freezes or takes too long to respond, try
pressing and holding the Power key for over 10 seconds
to restart the phone.
Waking Up Your Phone
Your phone automatically goes into sleep mode when it
is not in use for some time. The display is turned off to
save power and the keys are locked to prevent
accidental operations.
You can wake up your phone by turning on the display
and unlocking the keys.
1. Press the Power key to turn the screen on.
2. Swipe up on the screen.
NOTE:
If you have set a fingerprint, an unlock pattern, a PIN or
a password for your phone, you’ll need to use your
fingerprint, draw the pattern, or enter the PIN/password
to unlock your screen.

8
Product Safety Information
Don’t make or receive phone calls while
driving. Never text while driving.
Keep your phone at least 5 mm away from
your body while making calls.
Small parts may cause choking.
Your phone can produce a loud sound.
To prevent possible hearing damage, do not
listen at high volume levels for long periods.
Exercise caution when holding your phone
near your ear while the loudspeaker is in use.
Avoid contact with anything magnetic.
Keep away from pacemakers and other
electronic medical devices.
Turn off when asked to in hospitals and
medical facilities.
Turn off when told to on aircraft and at airports.
Turn off when near explosive materials or
liquids.
Don’t use at gas stations.
Your phone may produce a bright or flashing
light.
Don’t dispose of your phone in fire.
Avoid extreme temperatures.
Avoid contact with liquids. Keep your phone
dry.
Do not attempt to disassemble your phone.

9
Only use approved accessories.
For pluggable equipment, the socket-outlet
shall be installed near the equipment and shall
be easily accessible.
Don’t rely on your phone as a primary device
for emergency communications.
Specific Absorption Rate (SAR)
Your mobile device is a radio transmitter and receiver. It
is designed not to exceed the limits for exposure to radio
waves recommended by international guidelines. These
guidelines were developed by the independent scientific
organization ICNIRP and include safety margins
designed to assure the protection of all persons,
regardless of age and health.
The guidelines use a unit of measurement known as
Specific Absorption Rate, or SAR. The SAR limit for
mobile devices is 2 W/kg and the highest SAR value for
this device when tested at the head was 0.306 W/kg*,
and when tested at the body was 1.582 W/kg* with 5 mm
distance. As mobile devices offer a range of functions,
they can be used in other positions, such as on the body
as described in the user manual**.
As SAR is measured utilizing the device’s highest
transmitting power, the actual SAR of this device while
operating is typically below that indicated above. This is
due to automatic changes to the power level of the
device to ensure it only uses the minimum power
required to communicate with the network.
* The tests are carried out in accordance with EN 50360,
EN 50566, EN 50663, EN 62209-1 and EN 62209-2.
** Please see body worn operation in the user manual.

10
Specification
EUT tested
radios
application
GSM900/1800
WCDMA Band 1,8
FDD LTE Band 1,3,7,8,20
TDD LTE Band 38
802.11b/g/n
Bluetooth V5.1+EDR/LE
GPS
WCDMA Version Rel.9
LTE Version Rel.12
Maximum RF
output power
GSM900: 33.12 dBm
GSM1800: 29.90 dBm
WCDMA Band 1: 23.4 dBm
WCDMA Band 8: 23.8 dBm
FDD LTE Band 1: 24.3 dBm
FDD LTE Band 3: 23.9 dBm
FDD LTE Band 7: 23.1 dBm
FDD LTE Band 8: 24.3 dBm
FDD LTE Band 20: 25.3 dBm
TDD LTE Band 38: 24.7 dBm
802.11b/g/n: 15.87 dBm
Bluetooth EDR: 7.91 dBm
Bluetooth LE: 4.33 dBm
GPS(RX Only)

11
CE Caution
Battery Caution
•There is a risk of explosion if battery is replaced by
an incorrect type.
•Dispose of used batteries according to the
instructions.
•Do not dispose of a battery into fire or a hot oven, or
mechanically crush or cut a battery. Doing so can
result in an explosion.
•Leaving a battery in an extremely high temperature
surrounding environment can result in an explosion
or the leakage of flammable liquid or gas.
•A battery subjected to extremely low air pressure
may result in an explosion or the leakage of
flammable liquid or gas.
USB Port
This product shall only be connected to a USB interface
of version USB 2.0.
Proper Use
As described in this guide, your device can be used only
in right location. If possible, please do not touch the
antenna area on your device.
Do not expose your device to extreme temperatures
lower than -10 °C and higher than +45 °C.

12
Disposal of Your Old Appliance
1. When this crossed-out wheeled bin
symbol is attached to a product, it
means the product is covered by the
European Directive 2012/19/EU.
2. All electrical and electronic products
should be disposed of separately from
the municipal waste stream via
designated collection facilities
appointed by the government or the
local authorities.
3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the
environment and human health.
For this product’s recycling information based on WEEE
directive, please send an e-mail to [email protected]

13
EU DECLARATION OF CONFORMITY
Hereby, ZTE Corporation declares that the radio
equipment type ZTE Blade A52 is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following Internet address:
https://certification.ztedevices.com
ErP Conformity
The external power supply of this product conforms to
the Energy-related Product Directive (ErP) 2009/125/EC
of the European Parliament and the Council.
The detailed ErP information is available on ZTE website
https://certification.ztedevices.com.

14
ZTE Blade A52
Kurzanleitung

15
RECHTLICHE INFORMATIONEN
Copyright © 2022 ZTE CORPORATION.
Alle Rechte vorbehalten.
Dieses Benutzerhandbuch darf ohne die vorherige
schriftliche Zustimmung der ZTE Corporation weder
ganz noch in Auszügen zitiert, vervielfältigt, übersetzt
oder in jedweder Form und unter Verwendung jedweder
Mittel, seien es elektronische oder mechanische,
inklusive der Erstellung von Fotokopien und Mikrofilmen,
verwendet werden.
Hinweis
Die ZTE Corporation behält sich das Recht vor,
Druckfehler und technische Daten in diesem Handbuch
ohne Vorankündigung zu korrigieren bzw. zu
aktualisieren.
Für kundige Anwender bieten wir auch die Möglichkeit
der selbstständigen Fehlerbehebung an. Bitte besuchen
Sie die offizielle ZTE-Website (unter
https://ztedevices.com), um weitere Informationen zum
Benutzerhandbuch, zur selbstständigen Fehlerbehebung
und zu den unterstützten Produktmodellen zu erhalten.
Informationen auf der Webseite haben Vorrang vor
denen in diesem Dokument.
Haftungsausschluss
Die ZTE Corporation übernimmt ausdrücklich keine
Haftung für Fehler und Schäden, die durch nicht
autorisierte Veränderungen an der Software verursacht
wurden.
Die in dieser Anleitung verwendeten Bilder und
Screenshots können vom tatsächlichen Produkt
abweichen. Inhalte in diesem Handbuch können vom
tatsächlichen Produkt oder der Software abweichen.
Eingetragene Marken
ZTE und die ZTE-Logos sind eingetragene
Markenzeichen der ZTE Corporation.
Android™ ist eine Marke von Google LLC.
Die Marke Bluetooth®und die Logos sind Eigentum der
Bluetooth SIG, Inc. und jegliche Nutzung dieser Marken
durch die ZTE Corporation ist lizenziert.
Das microSDXC-Logo ist eine Marke von SD-
3C, LLC.
Sonstige Markenzeichen und Handelsnamen sind
Eigentum ihrer jeweiligen Inhaber.

16
Erstes Kennenlernen Ihres Telefons
Frontkamera
Touchscreen
Hörer
Lautstärketaste
Ein/Aus-
T
aste
Lade-/Micro-
USB-Anschluss
Kopfhörer-
Anschluss
Rückseitige
Kameras und
Blitz
Lautsprecher
Anzeigelämpchen
nano-SIM
/
microSDXC-
Kartenfach
Näherungs- und
Lichtsensor
Fingerabdruck-
Sensor

17
Einrichten Ihres Telefons
Die nano-SIM-Karte(n) kann/können bei eingeschaltetem
Telefon eingelegt und entfernt werden.
WARNUNG!
Um das Telefon nicht zu beschädigen, verwenden Sie
keine SIM-Karten anderer Art und keine aus einer SIM-
Karte gefertigte nano-SIM-Karte, die nicht dem Standard
entspricht. Eine Standard-nano-SIM-Karte erhalten Sie
bei Ihrem Serviceanbieter.
1. Führen Sie die Spitze des Auswurfwerkzeugs in das
Loch des Kartenfachs ein.
ACHTUNG:
Ersetzen Sie niemals das im Lieferumfang enthaltene
Auswurfwerkzeug durch scharfe Objekte. Stellen Sie
sicher, dass das Auswurfwerkzeug senkrecht zur
Öffnung steht. Andernfalls kann das Telefon beschädigt
werden.
2. Ziehen Sie das Kartenfach heraus. Legen Sie, wie
dargestellt, eine nano-SIM-Karte in das rechte
Kartenfach und eine nano-SIM-Karte oder
microSDXC-Karte (optional) in das linke Kartenfach
ein. Schieben Sie das Fach vorsichtig an seinen
Platz zurück.

18
HINWEIS:
Wenn zwei nano-SIM-Karten installiert sind, können sich
beide Karten mit dem 4G-, 3G-oder 2G-Netzwerk
verbinden und jede Karte kann für mobile Daten
verwendet werden.
Aufladen des Telefons
Der Akku des Telefons sollte genügend Leistung haben,
um das Gerät einzuschalten, ein Signal zu finden und ein
paar Anrufe zu tätigen. Sie sollten den Akku so bald wie
möglich voll aufladen.
WARNUNG!
Verwenden Sie nur von ZTE zugelassene Ladegeräte
und USB-Kabel. Die Verwendung von nicht
zugelassenem Zubehör kann Schäden am Telefon sowie
eine Explosion des Akkus verursachen.
WARNUNG!
Entfernen Sie nicht die Abdeckung. Der Akku kann
nicht herausgenommen werden. Beim
Herausnehmen besteht Brand- oder
Explosionsgefahr.
1. Stecken Sie den Stecker des Ladegeräts in die
entsprechende Buchse am Telefon. Stellen Sie
sicher, dass der Stecker mit der richtigen
Ausrichtung in die Buchse gesteckt wird.
