Zte D90 User manual

ZTE CORPORATION

D90 CDMA 1X-EVDO Mobile Phone

User Manual

Edition: 1st edition, Oct., 2006

Software version ZTED90V1.0.0B01

No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the

prior written permission of ZTE Corporation.

ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the right to make changes and improvements to any of the products described in this document

without prior notice.

For this product's Recycling Manual based on WEEE directive, please send email to inquiry or visit the website below to download:

WWW: http://ensupport.zte.com.cn

E-mail: [email protected]

LIMITED WARRANTY

ZTE warrants to the original purchaser that the cellular product and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and

conditions:

WHAT THIS WARRANTY COVERS:

The limited warranty extends only to the original purchaser (end user) and is not assignable or transferable to any subsequent purchaser/end user.

During the warranty period ZTE or officially appointed service agent will repair or replace any defective product or parts thereof at its discretion.

This limited warranty is applicable to the customer/end user that purchased the product from an official dealer in the United Kingdom.

The purchaser (end user) must retain the original purchase invoice/till slip in order to enforce this limited warranty.

WHAT THIS WARRANTY DOES NOT COVER:

Defects or damages resulting from the misuse of this product：

Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized repair, neglect, abuse,

accident, alteration, improper installation, blown fuses, food or liquid spillage, acts of God and shipping damage.

Breakage or damage to antennas unless caused directly by defects in material or workmanship.

The cost of delivery or transportation of the product to the dealer of officially appointed service center will be borne by the purchaser(end user).

Products received for repair by the dealer or authorized service center after the product warranty has expired.

Products that have had the serial number removed or defaced.

This limited warranty is in lieu of all other warranties, expressed or implied in terms of marketability or fitness for a particular use. specifically the company will accept no damage caused

by or due to failure of operation or malfunction of the product, or arising from the use or inability to use the product.

Damage resulting from the use of non-ZTE approved accessories.

Scratches and damage caused by normal use.

Products used outside published maximum rations.

Consumables such as fuses.

(12) Products that have been subject to an unauthorized removal or deactivation of the network operator-lock function.

Thank you for purchasing this D90 handset. In the unlikely event that your handset needs to be repaired please contact the Customer Services for information on how to return your

handset for repair.

Contents

FOR YOUR SAFETY............................................................................................................. 8

GENERAL CARE ..................................................................................................................8

AIRCRAFT SAFETY ..............................................................................................................9

HOSPITAL SAFETY...............................................................................................................9

GENERAL SAFETY...............................................................................................................9

ROAD SAFETY ..................................................................................................................10

VEHICLES EQUIPPED WITH AN AIR BAG ................................................................................12

EFFICIENT USE..................................................................................................................12

RADIO FREQUENCY ENERGY ..............................................................................................12

EMERGENCY SERVICES.....................................................................................................12

COPYRIGHT NOTICE..........................................................................................................13

GETTING STARTED........................................................................................................... 14

OVERVIEW........................................................................................................................14

PHONE AT A GLANCE..........................................................................................................14

KEY DEFINITION ................................................................................................................15

DISPLAY SYMBOLS ............................................................................................................16

TECHNICAL INFORMATION ..................................................................................................17

THE UIM CARD ................................................................................................................17

MEMORY CARD .................................................................................................................18

Using your phone’s Micro SD memory card...............................................................18

BATTERY .......................................................................................................................... 18

POWER ON/OFF YOUR PHONE............................................................................................20

UNLOCKING MOBILE PHONE................................................................................................20

CONNECTING TO THE NETWORK......................................................................................... 20

BASIC OPERATIONS.........................................................................................................21

MAKING A VOICE CALL........................................................................................................21

Using the keypad.......................................................................................................21

Making a call from Contacts.......................................................................................21

Dialing the number in the list .....................................................................................21

ANSWERING A CALL ........................................................................................................... 21

CONTACTS.........................................................................................................................23

LIST ENTRIES....................................................................................................................23

NEW ENTRY ......................................................................................................................24

GROUPS........................................................................................................................... 24

SPEED DIALS ....................................................................................................................25

SEARCH ...........................................................................................................................25

CALLS.................................................................................................................................26

CALL LOG .........................................................................................................................26

CALL TIMERS ....................................................................................................................26

MESSAGES ........................................................................................................................28

VOICE MAIL.......................................................................................................................28

TEXT AND MULTIMEDIA MESSAGE........................................................................................ 28

Send New..................................................................................................................28

Inbox..........................................................................................................................30

Outbox/Send.............................................................................................................. 30

Templates..................................................................................................................31

Drafts.........................................................................................................................31

Saved ........................................................................................................................31

Settings......................................................................................................................31

Memory info...............................................................................................................32

WEBALERT....................................................................................................................... 32

EMAIL...............................................................................................................................32

SHORT CODES................................................................................................................... 32

BROWSER..........................................................................................................................33

LAUNCHING AND NAVIGATING THE BROWSER .......................................................................33

Settings......................................................................................................................34

MULTIMEDIA ......................................................................................................................35

GET NEW.......................................................................................................................... 35

MUSIC..............................................................................................................................35

TV & RADIO..................................................................................................................... 35

RINGTONES...................................................................................................................... 35

WALLPAPER......................................................................................................................35

VIDEO ..............................................................................................................................36

CAMERA...........................................................................................................................36

Take photo and video.................................................................................................36

MYALBUMS ......................................................................................................................36

Sound Albums............................................................................................................37

Photo album...............................................................................................................37

Video album............................................................................................................... 37

Online album..............................................................................................................38

External Memory........................................................................................................38

MEMORY INFO ..................................................................................................................38

SHOP ..................................................................................................................................38

GAMES ...............................................................................................................................38

TOOLS ................................................................................................................................39

GET NEW.......................................................................................................................... 39

GPS SERVICES.................................................................................................................39

CALCULATOR....................................................................................................................39

ALARM CLOCK................................................................................................................... 40

Add alarm..................................................................................................................40

Alarm Options............................................................................................................ 41

Scheduler ..................................................................................................................41

NOTEPAD ......................................................................................................................... 41

EZ TIP CALC ....................................................................................................................42

WORLD CLOCK..................................................................................................................42

VOICE MEMO.....................................................................................................................42

SETTINGS........................................................................................................................... 42

SOUND.............................................................................................................................43

Ringers......................................................................................................................43

Keypad.......................................................................................................................43

Volume.......................................................................................................................43

Alerts .........................................................................................................................44

DISPLAY ........................................................................................................................... 44

GAMES/TOOLS..................................................................................................................44

OTHERS...........................................................................................................................45

Nav. Key Shortcuts ....................................................................................................45

Call setup................................................................................................................... 45

BLUETOOTH......................................................................................................................47

GPS................................................................................................................................47

SYSTEM ...........................................................................................................................48

Phone info .................................................................................................................48

System.......................................................................................................................48

Security......................................................................................................................48

Reset difault............................................................................................................... 49

OPEN/CLOSE AIRPLANE MODE...........................................................................................49

TEXT INPUT........................................................................................................................ 50

OVERVIEW........................................................................................................................50

TROUBLESHOOTING ........................................................................................................52

ANNEX GLOSSARY ........................................................................................................... 53

For your safety

General Care

A handset contains delicate electronic circuitry, magnets and battery systems. You should treat it with care and give particular attention to the following points:

Do not allow the handset, battery or accessories to come into contact with liquids or moisture at any

time. Do not immerse in any liquid.

Do not place the handset alongside computer disks, credit cards, travel cards and other magnetic

media. The information contained on disks or cards may be affected by the handset.

Do not place anything in the folded handset. Do not paint the handset.

Do not leave the handset or the batteryin places where the temperature could exceed 60 °C, e.g. on

a car dashboard or a windowsill, behind glass in direct sunlight, etc.

Do not remove the handset’s battery while the handset is switched on.

Take care not to allow metal objects, such as coins or key rings to contact or short-circuit the battery

terminals.

Do not dispose of battery packs in a fire. The handset’s Li-ION batteries may be safely disposed of

at a Li-ION recycling point.

Do not put the handset’s battery in your mouth, as battery electrolytes may be toxic if swallowed. Do not attempt to dismantle the handset or any of its accessories.

This equipment is fitted with an internal battery that can only be replaced by a qualified service

engineer.

There is a risk of explosion if the battery is replaced with an incorrect battery type. Dispose of the

used battery in accordance with the manufacturer’s instructions.

Do not put a battery into a microwave oven, dryer, or high-pressure container. Do not contact battery directly to an electric outlet or cigarette lighter charger. Use only authorized

charger units.

Do not pierce battery with a sharp object such as a needle. When the battery is thrown away, be sure it is non-conducting by applying vinyl tape to the (+) and

(-) terminals.

Do not disassemble or modify the battery. Do not drop, throw, or subject the handset to rough treatment.

Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is

detected during use, charge, or storage.

In the unlikely event of a battery leak, take care to keep the battery discharge away from your eyes

or skin. If the leakage does come into contact with the eyes or skin, please flush thoroughly in clean

water and consult with a doctor.

Do not use with a damaged or deformed battery. Do not solder a battery directly

Remove the battery whose life cycle has expired from equipment immediately. The earpiece may become warm during normal use. Also, the handset itself may become warm

while the battery is being charged.

When a handset is set to Vibration mode, the vibration can sometimes cause the D90 handset to

move.

Be careful not to place the handset near heat sources (such as a heater) or too close to the edge of

the table.

Use a damp or anti-static cloth to clean the handset. Do not use an ordinary dry cloth or electrostatic

cloth. Do not use chemical or abrasive cleaners as these could damage the case.

Third party equipment: The use of third party equipment, cables or accessories, not made or

authorized by ZTE, may invalidate the warranty of your phone and also adversely affect the phone’s

safety/operation.

Remember to make backup copies of all important data on your handset. Remember to recycle: the cardboard packing supplied with this handset is ideal for recycling.

Aircraft Safety

Switch off your phone when inside or near aircraft. The use of handsets in aircraft is illegal. It maybe

dangerous to the operation of the aircraft and it may disrupt the cellular network. Failure to observe

this instruction may lead to suspension or denial of phone service to the offender, or legal action, or

both.

Do not use the handset on the ground without the permission of the ground staff

Hospital Safety

Switch off your phoneand remove its battery in areas where the use of handsets is prohibited. Followthe instructions given by the respective medical facility regarding the use of handsets on their premises

General Safety

In some countries national law prohibits private copying of copyrighted material. Please check the

national legislation of the applicable country concerning the use of such material.

Many jurisdictions have laws and regulations about taking pictures in public or private areas and

regarding the processing and further use of such pictures. ZTE encourages its customers to obey all

laws and to honor the personal rights of others.

Please check roaming agreement availability with your network operator. The use of Mobile Phones is not allowed in some radiation sensitive areas, such as hospitals,

research centers and airplanes. The user is responsible to power-off the device. If there is any

uncertainty, the battery shall be removed.

Observe "Turn off mobile" signs, such as those near petrol stations, or explosives

and turn off handset/device.

If you have a heart condition, be careful with the settings of call vibration or tone volume.

Do not allow children to play with the handset, charger or batteries. Do not use the handset where blasting is in progress.

The operation of some medical electronic devices, such as hearing aids and

pacemakers, may be affected if a handset is used next to them. Observe any Note signs and

the manufacturer’s recommendations.

Take care not to put your phone in the back pocket of your trousers or skirt and then sit

on it. Also, do not put your phone at the bottom of bag where it may subject to excessive

weight or pressure. Doing so may damage the LCD and camera lens and cause them

malfunction.

Your phone contains metal, which may cause you an itch, a rash or eczema depending

on your constitution or physical condition.

Do not leave the battery pack empty or disconnected for a long time, otherwise some

data may be initialized.

Road Safety

You must exercise proper control of your vehicle at all times. Give your full attention to

driving.

Observe all of the recommendations contained in your local traffic safety

documentation.

Pull off the road and park before making or answering a call, if driving conditions so

require.

Check if local laws and/or regulations restrict the use of handsets while driving.

You MUST NOT stop on the hard shoulder of a motorway to answer or make a call,

except in an emergency.

Switch off your handset at a refueling point, such as a petrol station, even if you are not

refueling your own car.

Do not store or carry flammable or explosive materials in the same compartment as a

radio transmitter.

Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment can

advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio transmissions, consult your dealer and do not switch on the handset until it has

been checked by qualified approved installers.

Exposure to radio frequency energy

Radio wave exposure and SpecificAbsorption Rate (SAR) information

 The handset is designed to comply with safely, requirements for exposure to radio waves. This requirement is based on scientific guidelines that include safety margins designed to

assure the safety of all persons, regardless of age and health.

 The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using a standardized method with the

phone transmitting at its highest certified power level in all used frequency bands.

 While there may be differences between the SAR levels of various ZTE phone models, they are all designed to meet the relevant guidelines for exposure to radio waves.

 The SAR limit recommended is 1.6W/kg averaged over one(1) gramme of tissue.

 The highest SAR value for this model phone tested by MORLAB for use at the head is 0.972 W/kg(1g)

 The highest SAR value for this model phone tested by MORLAB for use at the body is 0.342W/kg(1g)

 SAR compliance for body-worn operations is restricted to belt-clips, holsters, or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm

separation between the device, including its antenna, and the users body

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to

operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help

Vehicles equipped with an air bag

An air bag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless

equipment is improperly installed and the air bag inflates, serious injury could result.

Third party equipment

The use of third party equipment, cables or accessories, not made or authorized by ZTE, may invalidate the warranty of your handset and also adversely affect the handset’s operation. For example, use

only the ZTE mains cable supplied with the AC charger.

Efficient use

For optimum performance with minimum power consumption, please do not cover the antenna with your hand. Covering the antenna affects call quality, may cause the handset to operate at higher power

level than needed, and may shorten talk and standby times.

Radio frequency energy

Your handset isa low-power radio transmitterand receiver.When it is turnedon, it intermittently receives and transmits radio frequency (RF) energy (radio waves). The system that handles the call controls

the power level at which the handset transmits.

Emergency Services

To make an emergency call in any country:

1 Ensure that your handset is on and in service.

2 Press key as many times as needed to clear the display and ready the device for calls.

3 Enter the official emergency number for your present location.

4 Press key to dial the number. Follow instructions received and do not end call until told to do so.

When the UIM card is not inserted or when the dial lock function is on, Press Right soft key [SOS] and then enter the official emergency number for your present location. Press key or keyto

dial the number.

Note:

Tell the operator which service you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain Rescue Service. Give your position and, if possible, remain stationary to maintain contact.

Due to the nature of the cellular system, the connection of emergency calls cannot be guaranteed. You should never rely solely on any wireless device for essential communications like medical

emergencies.

The video/audio recordings you make/download are protected by copyright laws. They are for personal use only and must not be otherwise used without the permission of the copyright owner.

Getting Started

Overview

Thank you for purchasing D90 CDMA 1X-EVDO Mobile Phone.

The D90 is capable of operating in CDMA networks. Your phone provides many functions which are practical for daily use, such as camera, MP3 player, video recorder, WAP, and more.

To guarantee the mobile phone always in its best condition, please read this manual carefully and keep it for further use.

Phone at a glance

1）Camera flash

2）Camera lens

3）Volume key

4）Camera key

5）Loundspeaker

6）out lens

7）battery cover

8）MicroSD card slot

9）Charger port（also for headset connector）slot

10）Strap holder

11）earpiece

12）Display

13）Microphone

14）Keypad

Key definition

Left soft key

Execute prompts that appear in the lower left corner of the screen directly above it. These prompts change according to the screen content.

Right soft key

Execute prompts that appear in the lower right corner of the screen directly above it. Shortcut key to access 3interface. These prompts change

according to the screen content.

Send key

Make and answer calls. Bring out call logs in standby mode.

End key

End a callscall and close down applications. Power on/off.

Left/Right/Up/Down/OK key

Up/Down key: Used for scrolling up and down lists, for example ‘Contacts’ lists or web pages; Used as shortcut keys in standby mode.

Left/Right key: Move the cursor left and right when editing; Used as shortcut keys in standby mode. Switch between different table menu.

OK key: Confirms actions/make selections. Execute prompts that appear in the lower middle of the screen directly above it.

0~9 Number key

Enter numbers and characters; Speed dial; Select options

when entering menu.

* key and # key

They have different functions in different modes or

function menus.

Input the alphabet

Camera key

Activates the camera when in the standby mode.

Display Symbols

Indicates the GPRS service is available. Indicates the amount of charge in your battery.

Indicates the 3G service is available. Indicates you have a missed call.

Indicates you have a new text message or a new multimedia message. Indicates the headset profile is activated.

Indicates you have a missed video call

Indicates you have a new E-mail. Indicates call forward is active

Indicates you have a new Wap push message. Indicates the ringtune is set to shut-off

Indicates the message memory is full. Indicates the handset is set to vibration with the earpiece connected.

Indicates the handset is set to vibration

Indicates the E-mail memory is full. Indicates the data communication in progress.

Indicates the Wap push message memory is full. Indicates the alarm clock has been set.

Indicates you are roaming.

Technical information

Handset

Type D90

Dimensions（W×L×H）49.5mm×89mm×24.5mm (antenna excluded)

Weight 108g (including battery)

Battery

Continuous standby time Upper Limit 200 hours (subject to network status)

Continuous talk time Upper Limit 150 minutes (subject to network status)

Charge time Approximately 3 hours

For other parameters about battery and charger, please refer to the sticker on real object.

Mains Charger

Input 100-240V, 50/60Hz,200mA

Output: 5.0V 700mA max

The UIM Card

Your phone has a UIM card slot located underneath the battery. However, the UIM is not functional in this phone model. Avoid placing anything into the card slot.

Memory card

Your phone allows you to use a micro SD memory card and an adapter to expand the phone’s available memory space. This digital card makes it easy to exchange images, music and

voice data quickly between SD compatible devices.

Using your phone’s Micro SD memory card

Your phone is equipped with a micro SD memory card(secure digital) to expand your phone’s available space, it allows you to easily store images, videos, music files, and voice data in

your phone.

Battery

1. Removing the Battery

Ensure that your handset is switched off and the charger is disconnected before removing the battery.

Slide the back cover toward the bottom of the phone, lift up and remove. Then insert your finger into the finger grip and lift the battery away from the handset.

2. Installing the Battery

Place the bottom of the battery into position, push down on the upper section of the battery until it clicks into place and then set the back cover. Make sure that the back cover latch is secure.

Note:

The handset automatically switches off if the battery voltage is too low.

Batteries have a limited life span. If the battery does not last as long as it used to, the battery may be coming to an end. Replace the battery with a new one of the same type.

When not using the battery for a long period, remove it from the phone and store it in a cool dry place.

3. Charging the battery

Your phone is powered by a rechargeable battery. The battery is not fully charged when you buy your phone but there may be enough power in the battery to turn the phone on. Note that a new battery’s

full performance is achieved only after three complete charge and discharge circles. Charge the battery by following the procedure indicated below.

With the battery in position on the

phone connect the lead from the charger to

the bottom of the phone.

Connect the charger to a standard AC

wall socket.

If the battery is charging whilst the

phone is turned on, the battery indicator on

the status line will animate If the battery is

charging when the phone is off the screen

will display a charging animation that

indicates the phone is charging. If the

phone is not used for a long time or the

battery is completely flat it may take a few

minutes before this indicator appears.

When the battery is fully charged, a

full battery power level icon will be

displayed.

When charging, ensure the power

cable is kept clear of walkways and does

not cause a hazard.

4. Battery Information and Care:

Using unauthorized charger may cause danger and violate the authorization and warranty rules of the phone.

Please charge the battery in time when it no longer provides acceptable performance. Do not use any charger or battery which is damaged.

Notes：

1. Do not charge the battery when the back cover is removed.

2. Do not disassemble the battery.

3. Do not short-circuit the battery. Accident short-circuiting can occur when a metallic object (coin, key or pen ) causes direct connection of the + and – terminals of the battery.

4. Do not dispose of battery packs in a fire. The handset’s Li-ION batteries may be safely disposed of at a Li-ION recycling point. Do not dispose as household waste.

5. Do not attempt to dismantle the handset or any of its accessories.

6. Do not put a battery into a microwave oven, dryer, or high-pressure container.

7. Do not contact battery directly to an electric outlet or cigarette lighter charger.

8. Do not pierce battery with a sharp object such as a needle.

9. Stop using the battery if abnormal heat, odor, discoloration, deformation, or abnormal condition is detected during use, charge, or storage.

10. Keep the battery’s metal contacts clean.

11. Battery life will vary due to usage patterns and environmental conditions. It will decrease if exposed to extreme hot or cold temperatures.

12. The phone’s talking time and standby time are based on ideal working environments. The use of extended backlighting, Browser, and network conditions affect battery life and talk/standby

time.

Power on/off Your Phone

Press and hold the End key to power on/off the phone. The mobile will then display the following prompts:

Enter password: If handset lock code has been activated. The default password is 0000.

Once the necessary security conditions have been fulfilled the handset will register with the network.

Warning: Do not power the phone on when wireless phone use is prohibited or when it may cause interference or danger.

Unlocking mobile phone

By setting the handset lock code, you can protect your phone and UIM card against unauthorized use.

Method to unlock the phone: key in handset lock code and then press OK key.

Note: If you forget your handset lock code, please contact with your dealer or the authorized local customer service center. Please refer to Section “Settings----Security”.

Connecting to the Network

After the phone and UIM card are unlocked, the mobile phone will automatically search for the network. When the phone has successfully registered on a network the network service provider’s name/logo

appears on the display.
