ZTE F866
UMTS/GSM/GPRS Mobile Phone
User Manual

Copyright © 2005 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any
means, electronic or mechanical, including photocopying and microfilm, without the prior written per-
mission of ZTE Corporation.
ZTE Corporation operates a policy of continuous development. ZTE Corporation reserves the right to
make changes and improvements to any of the products described in this document without prior
notice.
For this product’s Recycling Manual based on WEEE directive, please send email to inquiry or visit
the website below to download:
WWW: http://ensupport.zte.com.cn
E-mail: wee[email protected]
Edition: 1st edition, Oct., 2005

LIMITED WARRANTYLIMITED WARRANTY
LIMITED WARRANTYLIMITED WARRANTY
LIMITED WARRANTY
ZTE warrants to the original purchaser that the cellular product and its enclosed accessories will be free from
defects in material and workmanship, according to the following terms and conditions:
Section 1: WHAT THIS WARRANTY COVERS
1The limited warranty for the handset remains in effect for a period of 12 months based on the date of
purchase (except for the battery, where the warranty period shall be 6 months).
2The limited warranty extends only to the original purchaser (end user) and is not assignable or transfer-
able to any subsequent purchaser/end user.
3During the warranty period ZTE or officially appointed service agent will repair or replace any defective
product or parts thereof at its discretion.
4This limited warranty is applicable to the customer/end user that purchased the product from an official
dealer in the United Kingdom.
5The purchaser (end user) must retain the original purchase invoice/till slip in order to enforce this limited
warranty.
Section 2: WHAT THIS WARRANTY DOES NOT COVER
1Defects or damages resulting from the misuse of this product.
2Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture
or dampness, unauthorized modifications, unauthorized repair, neglect, abuse, accident, alteration,
improper installation, blown fuses, food or liquid spillage, acts of God and shipping damage.
3Breakage or damage to antennas unless caused directly by defects in material or workmanship.

4The cost of delivery or transportation of the product to the dealer of officially appointed service center
will be borne by the purchaser(end user).
5Products received for repair by the dealer or authorized service center after the product warranty has
expired.
6Products that have had the serial number removed or defaced.
7THISLIMITEDWARRANTYISINLIEUOFALLOTHERWARRANTIES,EXPRESSEDORIMPLIEDINTERMS
OF MARKETABILITY OR FITNESS FORAPARTICULAR USE. SPECIFICALLYTHE COMPANY WILLAC-
CEPT NO DAMAGE CAUSED BY OR DUE TO FAILURE OF OPERATION OR MALFUNCTION OF THE
PRODUCT,ORARISINGFROMTHEUSEORINABILITYTOUSETHEPRODUCT.
8Damage resulting from the use of non-ZTE approved accessories.
9Scratches and damage caused by normal use.
10 Products used outside published maximum rations.
11 Consumables such as fuses.
12 Products that have been subject to an unauthorized removal or deactivation of the network operator-
lock function.
Thank you for purchasing this ZTE F866 handset. In the unlikely event that your handset needs to be repaired
please contact 3 Customer Services for information on how to return your handset for repair by dialing 08707
330 333. Please have your IMEI number ready when you call (this can be found under the battery).

For your safety .................................................8
General Care ..................................................................................... 8
AircraftSafety ................................................................................. 10
HospitalSafety ................................................................................ 10
GeneralSafety ................................................................................. 10
RoadSafety ..................................................................................... 12
Vehicles equipped with an air bag ............................................... 13
Third party equipment .................................................................. 13
Efficientuse .................................................................................... 13
Radio frequency energy ............................................................... 13
Exposure to radio frequency energy.......................................... 14
Emergency Services..................................................................... 14
Declaration of Conformity ............................................................. 15
Copyright Notice ............................................................................ 15
Getting Started ..............................................16
Overview ......................................................................................... 16
KeyDefinition .................................................................................. 16
DisplaySymbols ............................................................................. 18
Technical Parameters ................................................................... 19
Installingthe USIMCard................................................................. 20
Battery ............................................................................................. 21
Power on/off Your Phone ............................................................. 24
Unlocking USIM Card and Mobile Phone .................................... 24
Connecting to the Network ...........................................................25
BasicOperations............................................26
Making a Voice/Video Call .............................................................. 26
Making a call from Contacts.......................................................... 27
Receiving a Voice Call .................................................................... 27
Receiving a Video Call ................................................................... 30
Messages .......................................................32
SMS ................................................................................................. 32
Createnew........................................................................................ 32
Inbox ................................................................................................32
Sent ..................................................................................................33
USIM ................................................................................................ 33
Drafts ................................................................................................34
Voicemail .........................................................................................34
Settings ............................................................................................34
MemoryInfo. ..................................................................................... 35
MMS ................................................................................................. 35
5
Contents
F866 User Manual I Contents

6F866 User Manual I
Contents
Contents
Createnew........................................................................................ 35
CreatingaMMSslideshow................................................................ 37
ReceivingandreadingMMS.............................................................. 38
ViewingMMSin the inboxandoutbox .............................................. 38
Settings ............................................................................................ 39
Calls ..............................................................42
Calllog ............................................................................................ 42
Callinfo. .......................................................................................... 43
Settings .........................................................44
Screen ............................................................................................ 44
Handset ........................................................................................... 44
Security .......................................................................................... 45
Call ................................................................................................... 46
Calldivert ......................................................................................... 46
CallWaiting ...................................................................................... 47
CallBarring ....................................................................................... 47
Sendmynumber ............................................................................... 48
Openflip toanswer ........................................................................... 48
Anykey toanswer ............................................................................ 49
Multimedia .....................................................50
Photos............................................................................................. 50
Camera ............................................................................................. 50
Mypictures ....................................................................................... 51
My slideshows ................................................................................. 52
Memoryinformation ........................................................................... 52
Video ............................................................................................... 52
Videorecorder ................................................................................... 52
Mymovies ........................................................................................ 53
TVChannels..................................................................................... 54
Memoryinformation ........................................................................... 54
Audio............................................................................................... 54
Audiorecorder ................................................................................... 54
My music .......................................................................................... 55
Playlist ............................................................................................. 56
Memoryinformation ........................................................................... 56
Profiles ..........................................................58
Tools ..............................................................60
Alarm............................................................................................... 60

F866 User Manual I Contents
7
Contents
Stop Watch ..................................................................................... 60
Calculator ....................................................................................... 61
Currency Conversion ................................................................... 61
World Time..................................................................................... 62
Planet 3 .........................................................64
Home ............................................................................................... 64
Go to Webpage ............................................................................... 64
Bookmark List ................................................................................ 64
History............................................................................................. 65
PageMemo List .............................................................................. 65
PushMessages............................................................................... 65
Options ........................................................................................... 65
Calendar ........................................................66
Contacts ........................................................68
All records ..................................................................................... 68
Search ............................................................................................ 69
CreateNew ...................................................................................... 69
Group settings................................................................................ 70
SpeedDial ....................................................................................... 70
Memo info ....................................................................................... 70
Copyall ........................................................................................... 71
Moveall ........................................................................................... 71
Deleteall .......................................................................................... 71
Text Input ......................................................72
Overview ......................................................................................... 72
ABC and abc mode ........................................................................ 72
123 mode ........................................................................................ 72
Predictive text input ....................................................................... 73
Character Chart ............................................................................. 73
Troubleshooting .............................................74
Annex Glossary .............................................76

8
GeneralCare
A handset contains delicate electronic circuitry,
magnets and battery systems. You should treat it
with care and give particular attention to the
following points:
Do not allow the handset, battery or accessories
to come into contact with liquids or moisture at
any time. Do not immerse in any liquid.
Do not place the handset alongside computer
disks, credit cards, travel cards and other
magnetic media. The information contained on
disks or cards may be affected by the handset.
Do not place anything in the folded handset.
Do not paint the handset.
Do not leave the handset or the battery in places
where the temperature could exceed 60 °C, e.g.
on a car dashboard or a windowsill, behind
glass in direct sunlight, etc.
Do not remove the handset’s battery while the
handset is switched on.
Take care not to allow metal objects, such as
coins or key rings to contact or short-circuit
the battery terminals.
Do not dispose of battery packs in a fire. The
handset’s Li-ION batteries may be safely
disposed of at a Li-ION recycling point.
Do not put the handset’s battery in your
mouth, as battery electrolytes may be toxic if
swallowed.
Do not attempt to dismantle the handset or any
of its accessories.
This equipment is fitted with an internal battery
that can only be replaced by a qualified
service engineer.
There is a risk of explosion if the battery is
replaced with an incorrect battery type.
Dispose of the used battery in accordance
F866 User Manual I For your safety
For your safety

9
with the manufacturer’s instructions.
Do not put a battery into a microwave oven,
dryer, or high-pressure container.
Do not contact battery directly to an electric
outlet or cigarette lighter charger. Use only
authorized charger units.
Do not pierce battery with a sharp object such
as a needle.
When the battery is thrown away, be sure it
is non-conducting by applying vinyl tape to the
(+) and (-) terminals.
Do not disassemble or modify the battery.
Do not drop, throw, or subject the handset to
rough treatment.
Stop using the battery if abnormal heat, odor,
discoloration, deformation, or abnormal
condition is detected during use, charge, or
storage.
In the unlikely event of a battery leak, take care to
keep the battery discharge away from your eyes
or skin. If the leakage does come into contact
with the eyes or skin, please flush thoroughly in
clean water and consult with a doctor.
Do not use with a damaged or deformed battery.
Do not solder a battery directly
Remove the battery whose life cycle has expired
from equipment immediately.
The earpiece may become warm during normal
use. Also, the handset itself may become warm
while the battery is being charged.
When a handset is set to Vibration mode, the
vibration can sometimes cause the F866 handset
to move.
Be careful not to place the handset near heat
sources (such as a heater) or too close to the
edge of the table.
F866 UserManual I Foryour safety
For your safety

10
Use a damp or anti-static cloth to clean the
handset. Do not use an ordinary dry cloth or
electrostatically charged cloth. Do not use
chemical or abrasive cleaners as these could
damage the case.
Third party equipment: The use of third party
equipment, cables or accessories, not made or
authorized by ZTE, may invalidate the warranty
of your cellphone and also adversely affect the
phone’s safety/operation.
Remember to make backup copies of all
important data on your handset.
Remember to recycle: the cardboard packing
supplied with this handset is ideal for recycling.
Aircraft Safety
Switch off your phone when inside or near
aircraft. The use of handsets in aircraft is
illegal. It may be dangerous to the operation of
the aircraft and it may disrupt the cellular
network. Failure to observe this instruction
may lead to suspension or denial of cellphone
service to the offender, or legal action, or
both.
Do not use the handset on the ground without
the permission of the ground staff.
Hospital Safety
Switch off your phone and remove its battery in
areas where the use of handsets is prohibited.
Follow the instructions given by the respective
medical facility regarding the use of handsets on
their premises.
GeneralSafety
In some countries national law prohibits
private copying of copyrighted material.
Please check the national legislation of the
F866 User Manual I For your safety
For your safety

11
applicable country concerning the use of such
material.
Many jurisdictions have laws and regulations
about taking pictures in public or private areas
and regarding the processing and further use
of such pictures. ZTE encourages its custom-
ers to obey all laws and to honor the personal
rights of others.
Please check roaming agreement availability
with your network operator.
The use of Mobile Phones is not allowed in
some radiation sensitive areas, such as
hospitals, research centers and airplanes.
The user is responsible to power-off the
device. If there is any uncertainty, the battery
shall be removed.
Observe “Turn off mobile” signs, such as
those near petrol stations, or explosives and
turn off handset/device.
If you have a heart condition, be careful with the
settings of call vibration or tone volume.
Do not allow children to play with the handset,
charger or batteries.
Do not use the handset where blasting is in
progress.
The operation of some medical electronic
devices, such as hearing aids and pacemakers,
may be affected if a handset is used next to
them. Observe any Note signs and the
manufacturer’s recommendations.
Take care not to put your phone in the back
pocket of your trousers or skirt and then sit on it.
Also, do not put your phone at the bottom of bag
where it may subject to excessive weight or
pressure. Doing so may damage the LCD and
camera lens and cause them malfunction.
Your phone contains metal, which may cause
you an itch, a rash or eczema depending on your
constitution or physical condition.
F866 UserManual I Foryour safety
For your safety

12
Do not leave the battery pack empty or discon-
nected for a long time, otherwise some data
may be initialized.
Road Safety
You must exercise proper control of your
vehicle at all times. Give your full attention to
driving.
Observe all of the recommendations contained
in your local traffic safety documentation.
Pull off the road and park before making or
answering a call, if driving conditions so
require.
Check if local laws and/or regulations restrict
the use of handsets while driving.
You MUST NOT stop on the hard shoulder of
a motorway to answer or make a call, except in
an emergency.
Switch off your handset at a refueling point,
such as a petrol station, even if you are not
refueling your own car.
Do not store or carry flammable or explosive
materials in the same compartment as a radio
transmitter.
Electronic vehicle systems, such as anti-lock
brakes, speed control and fuel injection
systems are not normally affected by radio
transmissions. The manufacturer of such
equipment can advise if it is adequately
shielded from radio transmissions. If you
suspect vehicle problems caused by radio
transmissions, consult your dealer and do not
switch on the handset until it has been
checked by qualified approved installers.
F866 User Manual I For your safety
For your safety

13
Vehicles equipped with an air bag
An air bag inflates with great force. Do not place
objects, including either installed or portable
wireless equipment, in the area over the air bag
or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed and
the air bag inflates, serious injury could result.
Third party equipment
The use of third party equipment, cables or
accessories, not made or authorized by ZTE,
may invalidate the warranty of your handset and
also adversely affect the handset’s operation.
For example, use only the ZTE mains cable
supplied with the AC charger.
Efficient use
The handset has an external antenna. For optimum
performance with minimum power consumption,
please do not cover the antenna with your hand.
Covering the antenna affects call quality, may
cause the handset to operate at higher power level
than needed, and may shorten talk and standby
times.
Radiofrequency energy
Your handset is a low-power radio transmitter and
receiver. When it is turned on, it intermittently
receives and transmits radio frequency (RF)
energy (radio waves). The system that handles
the call controls the power level at which the
handset transmits.
F866 UserManual I Foryour safety
For your safety

14
Exposure to radio frequency energy
Radio wave exposure and Specific Absorption
Rate (SAR) information.
The handset is designed to comply with safely,
requirements for exposure to radio waves. This
requirement is based on scientific guidelines
that include safety margins designed to assure
the safety of all persons, regardless of age and
health.
The radio wave exposure guidelines employ a
unit of measurement known as the Specific
Absorption Rate, or SAR. Tests for SAR are
conducted using a standardized method with
the phone transmitting at its highest certified
power level in all used frequency bands.
While there may be differences between the
SAR levels of various ZTE phone models, they
are all designed to meet the relevant guidelines
for exposure to radio waves.
The SAR limit recommended by the Interna-
tional Commission on Non-lonizing Radiation
Protection( ICNIRP), is 2W/kg averaged over
ten(10) gramme of tissue.
The highest SAR value for this model phone
tested by DASY3 for use at the ear is 1.7 W/
kg(10g).
Emergency Services
To make an emergency call in any
country:
1. Ensure that your handset is on and in service.
2. Press key as many times as needed to
clear the display and ready the device for
calls.
3. Enter the official emergency number for your
present location.
F866 User Manual I For your safety
For your safety

15
4. Press key to dial the number. Follow
instructions received and do not end call until
told to do so.
When the USIM card is not inserted or when the
dial lock function is on, Press Right soft key
[SOS] and then enter the official emergency
number for your present location. Press key
or key to dial the number.
Note:
Tell the operator which service you require: Police,
Ambulance, Fire Brigade, Coastguard or Mountain
Rescue Service. Give your position and, if possible,
remain stationary to maintain contact.
Due to the nature of the cellular system, the
connection of emergency calls cannot be
guaranteed. You should never rely solely on any
wireless device for essential communications like
medical emergencies.
Declaration of Conformity
We declare under our sole responsibility that the
product(s) detailed in this manual, and in
combination with our accessories, conform with
the essential requirements of European Union
Directive 1999/5/EC Radio and Telecommunica-
tions Terminal Equipment Directive requirements
3.1(a), 3.1(b), 3.2.
Copyright Notice
The video/audio recordings you make/download
are protected by copyright laws. They are for
personal use only and must not be otherwise
used without the permission of the copyright
owner.
F866 UserManual I Foryour safety
For your safety

16
Overview
Thank you for purchasing F866 UMTS/GSM/GPRS Mobile Phone.
The F866 is capable of operating in UMTS (Universal Mobile Telecommunication System), also known as
3G, GSM (Global System for Mobile Communications) or 2G, and GPRS (General Packet Radio Service)
or 2.5G and can realize seamless handover between different networks.
Empowered by the latest 3G technology, F866 is so powerful and versatile, it converges real-life
experiences with real-time connectivity by sharing highlights of your day.
This dual mode 3G, tri-band GSM phone is also equipped with high-end business tools that will enhance
your professional life. Enjoy the rush of high-speed, broadband-quality connectivity wherever you go.
Right soft key
Execute prompts that appear in the lower right
corner of the screen directly above it. Shortcut
key to access 3interface. These prompts
change according to the screen content.
F866 UserManualI GettingStarted
Getting Started
Key Definition
Left soft key
Execute prompts that appear in the lower left
corner of the screen directly above it. These
prompts change according to the screen
content.

17
Send key
Make and answer calls. Bring out call logs in
standby mode.
End key
End a callscall and close down applications.
Power on/off.
Clear key
Delete characters when editing.
Back key
Take you back to your previous screen.
Left/Right/Up/Down/OK key
Up/Down key: Used for scrolling up and
down lists, for example ‘Contacts’ lists or
web pages; Used as shortcut keys in
standby mode.
Left/Right key: Move the cursor left
and right when editing; Used as shortcut
keys in standby mode. Switch between
different table menu.
OK key: Confirm actions/make
selections. Execute prompts that appear in
the lower middle of the screen directly
above it.
TV key
Short cut key to TV channels offered through
the web browser.
Triangle key
Short cut to the browse interface.
F866 UserManual I GettingStarted
Getting Started

18
Video call key
Make or answer a video call. Lists call logs in
standby mode.
~0~9 Number key
Enter numbers and characters; Speed dial;
Select options when entering menu.
* key and # key
They have different functions in different modes
or function menus.
Volume keys
Adjust the earpiece volume during a call.
Camera key
Activate the camera when in the standby mode.
Display Symbols
Indicates the GPRS service is available.
Indicates the 3G service is available.
Indicates you have a new text message.
Indicates you have a new multimedia message.
Indicates you have a new E-mail.
Indicates you have a new Wap push message.
Indicates the message memory is full.
Indicates the multimedia message memory is full.
Indicates the E-mail memory is full.
Indicates the Wap push message memory is full.
Indicates you are roaming.
Indicates the amount of charge in your battery.
Indicates you have a missed call.
Indicates the headset profile is activated.
Indicates you have a missed video call.
Indicates call forward is active.
Indicates the ringtune is set to shut-off.
F866 UserManualI GettingStarted
Getting Started

19
Indicates the handset is set to vibration with
the earpiece connected.
Indicates the handset is set to vibration.
F866 UserManual I GettingStarted
Getting Started
Technical Parameters
Handset
Type F866
Dimensions (W x L x H) 50mm x 93.6mm x 25.4mm (antenna excluded)
Battery
Continuous standby time Upper Limit 200 hours (subject to network status)
Continuous talk time Upper Limit 200 minutes (subject to network status)
Charge time Approximately 3 hours
For other parameters about battery and charger, please refer to the real objects.
Mains Charger
Input 100-240V, 50/60Hz,200mA
Output: 5.0V 700mA max
Indicates the data communication in
progress.
Indicates the alarm clock has been set.

20
Installing the USIM Card
Your USIM card stores your phone number, service details, phonebook and can store text messages. It
must be inserted into your phone to use these services.
If the USIM card is removed then the handset becomes unusable until a valid USIM is inserted. The holder
for the USIM card is located underneath the battery.
Your USIM card can only be used in handsets that are enabled for 3G services. Any attempt to use the
USIM card in other handsets may prevent you from being able to use it correctly.
Note:
Make sure to disconnect the charger and other accessories from your phone and remove the battery before inserting and
removing your USIM card. Don’t touch the metal surface of the USIM card in case that information in the card may be
lost or destroyed. Do not bend or scratch your USIM card. Keep the card away from electricity and magnetism.
F866 UserManualI GettingStarted
Getting Started
