Zte WP560C User manual

Copyright Statement
Copyright ©2011 by ZTE Corporation
All rights reserved.
No part of this publication may be excerpted, reproduced, translated or utilized
in any form or by any means, electronic or mechanical, including photocopying
and microfilm, without the prior written permission of ZTE Corporation.
ZTE Corporation reserves the right to make modifications on print errors or
update specifications in this manual without prior notice.
Edition 1.0March 2011

Table of Contents
Introduction ............................................................................... 1
Safety Precautions .................................................................................... 1
Getting to Know Your FWT........................................................................ 3
Installing the FWT ..................................................................................... 5
Switching on / off the FWT ........................................................................ 8
Call Function............................................................................... 9
Making a Call ............................................................................................ 9
Dialing Extension Number....................................................................... 10
Dialing IP Number ................................................................................... 10
Receiving a Call ...................................................................................... 10
Mute........................................................................................................ 10
Menu Operations during a Call................................................................ 10
Emergency Call....................................................................................... 10
Messages .................................................................................. 11
Create Message...................................................................................... 11
Inbox ....................................................................................................... 11
Outbox .................................................................................................... 11
Erase Messages ..................................................................................... 11
Pref Msg ................................................................................................. 12
Voice Mail................................................................................................ 12
Message Settings.................................................................................... 12
Send To Multi .......................................................................................... 12
Contacts ....................................................................................13
Find......................................................................................................... 13
Add to Phone .......................................................................................... 13
Add to R-UIM .......................................................................................... 14
In Phone / In R-UIM ................................................................................ 14
Group View ............................................................................................. 14
Copy the Contacts................................................................................... 14
Speed Dial............................................................................................... 15

Memory Status ........................................................................................ 15
Erase All.................................................................................................. 15
Data Service ..............................................................................16
Settings ..................................................................................... 17
Auto Key Guard ...................................................................................... 17
Call Setting.............................................................................................. 17
Supp. Services........................................................................................ 18
Sound ..................................................................................................... 18
Display .................................................................................................... 19
Local Number.......................................................................................... 19
Alert ........................................................................................................ 19
Security................................................................................................... 19
Recent Calls...............................................................................21
View Recent Calls ................................................................................... 21
Delete All Calls........................................................................................ 21
Call Time ................................................................................................. 21
Extra ..........................................................................................22
Stop Watch.............................................................................................. 22
Alarm ...................................................................................................... 22
Scheduler................................................................................................ 22
Calculator................................................................................................ 23
Appendix ...................................................................................24
Input Methods ......................................................................................... 24
Troubleshooting ...................................................................................... 25

Introduction
1
Introduction
Thank you for choosing WP560C /WP560CD / WP960C /WP960CD Fixed
Wireless Terminal (FWT) of ZTE Corporation. To keep your FWT in the best
condition, please read this manual carefully before use and keep it well for
future use.
The pictures in this user manual are only used to demonstrate your terminal’s
functions, so they are maybe different from what you see on your FWT. Please
refer to your FWT if there are any differences.
Safety Precautions
During Operation
zThe FWT may interfere with heart pacemaker, hearing aid and other
electronic medical devices. Therefore please follow the instructions given
by your equipment suppliers or consult your doctor.
zDo not attempt to disassemble the FWT and battery by yourself.
Non-expert handling of the devices may cause damages.
zIf you want to clean your FWT, use only a dry, soft cloth with cleanser
containing no alcohol, benzene or acetone.
zDon’t drop the FWT or have it hit with great force.
zPlease turn off your FWT when you plug or unplug R-UIM card.
zPress and hold the key to turn off the FWT, instead of pulling out the
plug / socket directly.
Work Environment
zThe FWT can only be installed indoors.
zThe working temperature is -10℃~ +55℃, so don’t operate it outside the
range. Operation under too high or too low temperature might cause
problems.
zKeep the FWT from dust, furnace or gas stove.
zDon’t put it under humid environment to avoid dampness, otherwise the
circuit board may be eroded and you may lose the data.
zKeep the FWT away from magnetic field and static electricity.

Introduction
2
zPlace the FWT out of the reach of small children. The FWT may cause
body injury if used as a toy.
zDon’t use the FWT outdoors during thunderstorms.
Battery &Power Adapter
zGenerally, your FWT is supplied by power adapter, and the backup battery is
used only on special occasions such as blackout or other circumstances.
The battery’s standby time depends on the network status.
zIf the battery is used for the first time, please pull out the power adapter,
supply your FWT with the battery alone until the battery capacity is
exhausted and your FWT is automatically powered off, then charge the
backup battery until it is fully charged, and then supply your FWT with the
battery alone until the battery capacity is exhausted and your FWT is
automatically powered off. Circulate the procedure for three times.
zDuring daily use, do not pull out the power adapter.
zThe battery could be normally charged under the temperature range of 10
℃~40℃. If the battery is charged under the temperature outside this range,
the battery performance might be compromised or even the battery might
be damaged.
zPlease press and hold the key to turn off the FWT and then unplug the
power adapter before replacing the battery.
zUse only the original power adapter and battery. Using the power adapter
from other manufacturers might damage the terminal. Don’t use the
adapter for other purposes.
zThe power adapter must be used within the specified AC voltage range.
zWhen the FWT is only supplied by the battery instead of the power adapter,
please charge the battery in time to avoid over-discharging caused by low
voltage.
zTake out the battery if you won’t use your FWT for a long period of time
and keep the battery well.
zDon’t use the power adapter if the power cable is damaged. Contact the
maintenance center immediately and replace the adapter.
zDispose the useless battery as required rather than throw it into the
general domestic dustbin.
Note:
If the battery is damaged, you should avoid the contact of the

Introduction
3
substances in the battery. If your skin has contacted these
substances, wash with a lot of clear water, and seek for help
from your doctors if necessary.
Getting to Know Your FWT
Handset
A
ntenna
Microphone
LED
Battery
cover
Data interface Power interface

Introduction
4
Keys
Keys Descriptions
MENU/SELECT Press this key to enter the main menu in idle mode;
Use this key to select or confirm.
MESSAGE Press this key to enter Messages menu in idle mode.
/EXIT
Press and hold this key to turn on /off FWT;
Press this key to reject upon an incoming call;
Press this key to return to the main menu;
Hang up the call.
Use Left / Right key to move the cursor;
In idle mode, press the Left key to enter Extra; and press
the Right key to enter Contacts .
Navigaiton keys
Use Up/Down key to select the menu option;
In idle mode, press the Up key to adjust the volume; and
press the Down key to enter Recent Calls.
CALL/REDIAL Press this key to dial a number or view the recent calls.
CLR/BACK Press this key to return to the previous menu;
Press this key to delete the inputs.
Handsfree key
In idle mode, press this key to enter handsfree status;
In other mode, press this key to return to the main menu.
Numeric Keys
Press these keys to input numbers and characters;
Under letter input method, press “1” key to enter common
symbols.
* Key
Under any kind of input method, press * key to enter the
list of symbols;
When only the numbers are allowed to input, press *key to
enter the symbol “*”;
In idle mode, press and hold * key to mute.
#Key
Under text input method, press # key to switch among
the input methods;
When only the numbers are allowed to input, press #key to
enter the symbol “#”;
In idle mode, press and hold #key to lock the keypad.

Introduction
5
Display Icons
Current signal strength Handset status indication
Unread short messages New voice mail
Keypad lockup indication Mute
Alarm on Supplied by external power
Supplied by battery
Installing the FWT
Installing the power adapter
Please connect the adapter with FWT’s power interface before connecting it
with external AC power supply.
Installing R-UIM card
(If your FWT doesn’t support R-UIM card, please skip this step.)
Note:
If your FWT supports R-UIM card, you should install R-UIM
card before use. Before installing R-UIM card, make sure your
FWT is turned off and the power adapter is disconnected.
Please install the R-UIM card before installing the battery.
1. Remove the battery cover 2. Push the R-UIM card into the card
holder in the direction indicated
by the arrow (pay attention to
R-UIM card’s cut corner position)

Introduction
6
Installing the battery
Note:
Before installing the battery, make sure your FWT is turned off and
the power adapter is disconnected.
1. Remove the battery cover 2. Install battery
3. After the battery is installed 4.Install the battery cover
Charging the battery
The accompanying rechargeable battery can be used after being unpacked.
To make the battery always in its best condition, please exhaust the capacity
of the battery and then fully recharge it for the first three times.
The power adapter will be firstly used to supply the FWT. After the power
adapter is inserted, the battery charging is automatically started. When the
power adapter is unable to supply the FWT (blackout or uninserted), the
battery will start to work.
When the battery capacity is low, “Low Battery” appears on the screen, and
there is a sound prompt. At this point, you should charge the battery in time.

Introduction
7
Attaching the handset
Connecting the FWT to PC (only for WP560CD and WP960CD)
Wall-Mount Installation

Introduction
8
Switching on / off the FWT
Switch on the FWT
Hold the key until the power-on animation appears on the LCD.
The FWT will automatically detect whether R-UIM card is inserted or available, and
then the following will be displayed on the screen:
Enter PIN: if you set PIN code for R-UIM card.
Searching: search for available network.
Switch off the FWT
Hold the key until the power-off animation appears on the LCD.

Call Function
9
Call Function
Making a Call
Directly Make a Call
1. Using the handset or hand-free key
In idle mode, pick up the handset or press key;
Dial the number after hearing the dialing tone;
Press the CALL key or wait for several seconds to dial automatically;
Hang up the handset or press key to end the call.
2. Preset dial
Dial the number directly in idle mode;
Press the CALL key to make the call;
Press the EXIT key after the conversation is over.
Make a Call from Contacts
1. Press the MENU key in idle mode to enter menu and select Contacts;
2. Select Find or In Phone, search for the contact you desire;
3. Press the CALL key to dial the default number;
4. If you want to dial other type of number of the contact, press the SELECT
key to view the details, and press Up/Down key to select the number, and
then press the CALL key to dial.
Make a Call from Recent Calls
1. In idle mode, press the CALL key to enter the list of recent calls;
2. Select the number you want to dial and press the CALL key to make a call.

Call Function
10
Dialing Extension Number
1. Input the direct number in idle mode, press the Right key to select Pause
and then press the SELECT key to add a “P” after the direct number;
2. Input the extension number and press the CALL key to dial.
Dialing IP Number
1. Input the number in idle mode, press the Right key to select IP and then
press the SELECT key to add “IP access number”;
2. Press the CALL key to dial.
Receiving a Call
Upon an incoming call, pick up the handset or press key to answer the call.
Mute
1. During the calling, press Left/Right key to select Mute , and then press
the SELECT key, the other side can’t hear your voice;
2. Press the SELECT key again to return to the conversation.
Menu Operations during a Call
During the calling, press the Left/Right key to select Menu and then enter
submenus. the call won’t be ended during the menu operations.
Emergency Call
As long as your FWT can detect CDMA digital network signal, you could dial
the emergency call numbers preset in the FWT to seek for help in case of
emergencies.

Messages
11
Messages
If your FWT supports R-UIM card, you could move the messages from the
inbox to R-UIM card. If your FWT doesn’t support R-UIM card, please skip the
contents about R-UIM card in this chapter.
Create Message
1. Enter Create Message, after inputting the text, select Continue (select
Priority to set the level);
2. Input the recipient’s number directly or select from Contacts;
3. After selecting Continue, you could:
Send: send out the message now.
Save: save as draft.
Send to multireceiver: send out the message to multiple recipients.
Inbox
1. Enter Inbox, select the message, and press the SELECT key to view the
details;
2. Press the Up/Down key to turn up/down the page, press Left/Right key to
select Reply / Forward / Next / Erase / Sender / Move to R-UIM.
Outbox
The sent messages, unsent messages and the messages to be sent will be
stored in the Outbox.
Erase Messages
You could delete Entire InBox, Entire OutBox, Entire R-UIM or Old InBox.

Messages
12
Pref Msg
There are several preferred messages saved in the FWT. You could directly
send it, edit it or insert it while creating a new message.
Voice Mail
When you are unable to answer the call, you could make the other party leave a
message to you through voice mail service, and then listen to your voice mail.
In idle mode, hold “1” key to dial the preset voice mail number.
Note:
This function requires network support.
Message Settings
Voice Mail Number: add voice mail number, please consult your local
telecom operator for the specific number.
Message Alert: you could select Alert Once or Alert & Remind.
Auto Erase Inbox: you could select Enable.If the inbox is full, the
terminal will automatically erase the old messages
once receiving a new message.
LifeTime: LifeTime indicates the period, in which the FWT saves your
messages when you fail in switching on the FWT upon the
receipt of a new message.
Delivery ACK: this is to confirm if the FWT has already sent the
message or not. You can activate or deactivate this
function.
Send To Multi
1. Select Add Receiver to add up to 10 recipients. Input the recipient’s
number directly or select from Contacts ;
2. After selecting the recipients, select List OK and then input the text and
send the message.

Contacts
13
Contacts
The contacts’ information could be saved either in the terminal or R-UIM card.
You could classify the contacts saved in the terminal and manage the contacts’
information.
Note:
If your terminal doesn’t need R-UIM card, the contacts’
information could be saved only in the terminal. Please skip the
section that is related to R-UIM card.
Find
Search by name
Input the name and then select Find to view all relevant contacts.
Search by number
1. Press the SELECT key and the Right key to select Mode;
2. Select According to number, input the number, select Find to view all
relevant contacts.
Add to Phone
1. Select from Phone / Email / Address / Web Page ;
2. Add the relevant information, and then select Next ;
3. Input the contact’s name, and then select Next ;
4. Select Options to perform the following operations:
Add New: add new information.
Edit Name: edit the contact name.
Classify Contact: classify the contacts into different groups.
Erase Contact: delete new contacts.

Contacts
14
Add to R-UIM
The new entries added into R-UIM card could only record contact’s name and
single phone number.
In Phone / In R-UIM
Select In Phone or In R-UIM to view all contacts saved in terminal or R-UIM
card.
Modify a Contact
1. Select the desired contact , and press the SELECT key to view details;
2. Select Options and then select Edit name or Add New;
3. Select the phone number of the contact, and press the SELECT key, you
can Edit or Erase the number.
Delete a Contact
1. Select the desired contact, and press the the SELECT key to view details;
2. Press Options and then select Erase Contact.
Send a message to a Contact
1. Select the desired contact and press the SELECT key to view details;
2. Select the phone number and press the SELECT key, then select Send text
msg.
Group View
Select Group View to view the contacts in certain group.
Copy the Contacts
Copy one
1. Select the contact, and press the SELECT key to view the details;
2. Select the number and press the SELECT key to select Save on R-UIM /
Save on Phone.

Contacts
15
Copy All
Select Sync to RUIM to copy from Phone to R-UIM; select Sync from RUIM
to copy from R-UIM to Phone.
Speed Dial
The FWT provides 8 speed dial numbers ranging from 2 to 9.
Add
1. Select the contact , and press the SELECT key to view details;
2. Select the number, press the SELECT key to select Add to Speed Dial.
Make a call using speed dial number in idle mode
In idle mode, press and hold the corresponding numeric key of speed dial
number to dial directly.
View all speed dial numbers
Select Speed Dial List to view all speed dial numbers.
Memory Status
You can check the current memory status of the phonebook.
Erase All
Select In Phone or In R-UIM to delete.

Data Service
16
Data Service
(only for WP560CD and WP960CD)
Through the connection of your FWT and PC, you can get High-speed Packet
Data Dial-up Internet Access, and receive /send a fax.
Please refer to <Data Services User Guide> in USB installation CD.

Settings
17
Settings
Auto Key Guard
Auto Key Guard could prevent the misoperations caused by wrong keypress.
As the keypad is locked, press the SELECT key and * key to unlock.
Call Setting
Originate Mode
You can choose the originate mode. You can select:
After 3s: make a call 3 seconds after inputting the number.
After 6s: make a call 6 seconds after inputting the number.
Sent Press: make a call only by pressing the CALL key .
Call Restrict
Specified: set call barring of 5 incoming calls and outgoing calls.
National: set call barring of domestic long-distance outgoing calls
(number started with “0”).
International: set call barring of International long-distance outgoing
calls.
Origination: set call barring of all outgoing calls (emergency number
and service number allowed).
Password: change call restrict password.
Note:
You need input the password (initial password is 0000) to enter
National, International and Origination.
Hot Line
If hotline mode is activated, dial any number to call the hotline number (not
including emergency number).
