WORK SAFETY
when using rotary tools
Important instructions and warning notes:
1. For your own safety, please read the operating manual before putting an appliance into operation.
2. Pay attention to the safety and work regulations of the employers mutual insurance association.
3. Provide good lighting, safety glass shields, eye protection and an eective extraction system at the workplace.
4. Check before starting up an electrical appliance if the mains voltage corresponds to the data on the type plate.
5. Remove the collet chuck and service tools before switching the device on.
6. Motor handpieces are intended exclusively for dry machining.
7. Check before using the motor handpiece if the tool is seated rmly and cannot be pulled out.
8. Use exclusively functional, certied tools (drill bits, milling bits, cutting disks, polishing tools, grinding tools, etc.)
and observe the tool manufacturer’s instructions for use, e.g. maximum permissible speed of rotation, and that the
tools are clamped over their entire length.
9. Make sure that the motor handpiece does not start unintentionally or run on unsupervised.
10. Operate the motor handpiece only with a clamped tool or pin.
11. Do not turn the collet chuck lock while the handpiece is rotating.
12. Clean the collet chuck regularly according to the instructions (never blow compressed air into the motor handpiece).
13. Use only rotating tools that are intended for use in dental laboratories and with the corresponding materials.
14. Set the handpiece to the desired speed before applying it to the workpiece to be machined.
15. When working with rotary tools, avoid levering or applying excessive working pressure (risk of overheating or tool
breakage).
16. It is essential to keep to the working speeds specied by the manufacturer.
17. Avoid overheating of the material that you are machining.
18. Place the motor handpiece in the handpiece holder after use. In this way you can protect the tools against breakage
and yourself against injury.
19. Clean the rotary tools regularly in accordance with the manufacturer‘s recommendations.
20. Repair and maintenance work on the electrical part of the appliance may be carried out
only by qualied technical personnel.
21. Electrical appliances may not be used in a damp or wet environment.
22. Appliances must be secured against unintentional use in case of defects or damage
where safe operation is no longer ensured.
B00246 / 11-2018

Instructions for use and notes on safety
when using rotary tools
in the dental laboratory
Their daily use involves a lot of risks and hazards. The measures listed below will help to avoid
accidents, support you in your daily work and prolong the service lives of your drilling and grin-
ding tools.
Chuck damaged or dirty.
The tool slips.
Test the concentricity
by rolling on
a level surface.
Gearing damaged. Elimination
of instruments
with imbalance.
Inspection:
Inspect all rotary instruments on a regular basis, ideally using a magnifying glass with 10x magni-
fication, and use them only if they are in perfect working order.
Typical errors when using rotary tools:
The maximum speed specied by the manufacturer must not be exceeded. The correct working
pressure prolongs the service life of rotary tools and optimises the grinding performance.
Breakout
on a sintered diamond wheel
Cause: jamming,
incorrect setting down,
negligent care.
Tool shaft bent
Cause: tool not inserted deep enough
into the collet chuck,
speed too high.
Caution: risk of injury!
Diamond wheel
broken
Cause: incorrect setting down
of the motor handpiece
on the workbench,
working without handpiece holder.
Polishing tool
broken
Cause: incorrect setting down of the
motor handpiece on the workbench,
working without handpiece holder.
Milling bit broken
Cause: motor handpiece
fell down.
Milling bit not held firmly enough
in the collet chuck
Cause: milling bit was not inserted
deep enough into the collet chuck.
Chuck cleaning
Regular cleaning of the collet chuck
with a small brush prolongs
the service life of the collet chuck
and the motor handpiece.
Chuck cleaning
Regular cleaning of the collet chuck
with a small brush helps
to prevent accidents.
Inspection and care of motor handpieces
The service lives of your motor handpieces and tools
are prolonged by the following measures:
■Service your motor handpieces on a weekly basis.
Above all, the collet chuck must be removed and cleaned regularly.
■Dirty collet chucks close inadequately and the tools used cannot be clamped
along their full length as is necessary (see photo).
■When working, the tools„wander“ out of the collet chuck, can break or are flung
in an uncontrolled manner through the room.
■Check the functionality of the collet chuck
and always close it using a tool or a protection pin.
Milling bit is not inserted deep enough into the collet chuck.
Caution: risk of injury!
Milling bit correctly clamped.
