3-form SimpleSpec 400.46-Divy User manual

For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
Ready To Go
SimpleSpec -Divytm

Contents Overview
= +
1" Shelf Holder
SS: 315-754
BO: 3-15-2018
(2)
M6  12mm
Set Screw
315-776
(2)
(2)
1" Shelf Holder KIT
Stainless Steel: 315-754K
Black Oxide: 3152018
+
Cable Coupler
with Cover Plate
SS: 3151639
BO: 3-15-2004
(2)
M8 Thread
Rod, 25mm
3151754
(2)
=
(2)
Cable Coupler KIT
Stainless Steel: 3-15-1639-K
Black Oxide: 3-15-2004-K
(2)
3mm Cable
Stainless Steel: 315-723
Black Oxide: 3-15-2006
(2)
Single Panel Side
Bracket For Felt KIT
Stainless Steel: 3152012-K
Black Oxide: 3-15-2013-K
+
Single Panel Side
Bracket for Felt
SS: 3152012
BO: 3152013
(2)
Hex Drive Flanged Rounded
Head Screw, M650mm
SS: 3152017
BO: 3152016
(2)
=
(1)
72"24" Divy Felt Baffle
(2) =
Suspend Anchoring KIT
3-15-7000-K
+ +
M8 Threaded
Wood Insert
3150791
(2)
M8 Concrete
Anchor
3153011A
(2)
M8 Threaded
Rod, 50mm
3153032A
(2) +
M8 Thread
Rod, 25mm
3151754
(2)
M8 Toggle
Bolt Anchor
3150734
(2) +
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
2
Ready To Go
SimpleSpec -Divytm

Contents Overview cont...
For Each Additional Panel
(×1) 72"24" Divy Felt Bale
(×1) 3mm Cable
SS: 3-15-0723
BO: 3-15-2006
(×1) Suspend Anchoring KIT
3157000K
(×1) 1"Shelf Holder KIT
SS: 3150754K
BO: 3152018
(×1) Cable Coupler KIT
SS: 3-15-1639-K
BO: 3-15-2004-K
(×1) Double Panel Side Bracket For Felt KIT
Stainless Steel: 3152014K
Black Oxide: 3152015K
= +
Double Panel Side
Bracket for Felt
Stainless Steel: 3152014
Black Oxide: 3152015
Hex Drive Flanged Rounded
Head Screw, M650mm
Stainless Steel: 3152017
Black Oxide: 3152016
(2)(1)
Required Tools
Drill Metric Allen
Wrenches
Concrete or
Wood Bit
Cable Cutters Plumb-bobSuper Glue
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
3
Ready To Go
SimpleSpec -Divytm

Overview
"
mm
"
mm
Bale Width
"
mm
Bale Height
72"×24"
Divy Felt Bale
1" Shelf Holder KIT
SS: 3150754-K
BO: 3-15-2018
Single Panel Side
Bracket For Felt KIT
SS: 3152012K
BO: 3152013K
3mm Cable
SS: 3150723
BO: 3152006
Cable Coupler KIT
SS: 3151639-K
BO: 3-15-2004
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
4
Ready To Go
SimpleSpec -Divytm

Installation
Drill Ø10mm hole, minimum 65mm
deep.
Remove drilling debris with a blowout
bulb or with compressed air.
With screw in anchor (315311A), use a
hammer to insert anchor.
1Install Ceiling Anchor for the First Cable Assembly
*If anchoring in concrete follow Steps 1a-f, if anchoring in drywall follow Steps 1g-l. if anchoring in wood follow Steps 1m-n.
b ca Concrete Installation
e fd
Place a washer under the screw head. Torque the screw to 15 Nm. Remove screw.
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
5
Ready To Go
SimpleSpec -Divytm

Installation
1Install Ceiling Anchor for the First Cable Assembly cont...
Metal
Studs
Metal
Studs
h ig
Drill ؾ" (19mm) hole. Minimum
clearance behind wall = 1⅞" (48mm)
Position the metal channel parallel
with the plastic legs. Insert the metal
channel through the drilled hole into
the wall cavity.
Pull the metal channel irmly against the
inner wall cavity by tugging the plastic
pull ring.
Hollow Substrate Installation
k lj
Slide the plastic cap forward along the
legs until it is seated lush to the work
surface.
Snap the plastic legs o lush at the
plastic cap by pushing outward.
Note: Maximum torque on screw or rod
is 5 ft-lb.
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
6
Ready To Go
SimpleSpec -Divytm

Installation
1Install Ceiling Anchor for the First Cable Assembly cont...
2Attach First Cable Assembly
a b
SS: 3-15-0723
BO: 3-15-2006
SS: 3-15-1639
BO: 3-15-2004
SS: 3-15-1639
BO: 3-15-2004
3-15-1754
3-15-0791
SS: 3-15-1639
BO: 3-15-2004
n om
Drill Ø⁄" (Ø11.1mm) hole, minimum
20mm deep.
Use an Allen wrench to install the M8
Threaded Insert (315-791).
Wood Installation
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
7
Ready To Go
SimpleSpec -Divytm

Installation
aDo not tighten set screw!
SS: 3-15-2012
BO: 3-15-2013
(2×) Set Screws
3Dry-Fit Panel and Measure
SS: 3-15-2017
BO: 3-15-2016
bDo not tighten set screws!
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
8
Ready To Go
SimpleSpec -Divytm

Installation
(2×) Set Screws
SS: 3-15-2017
BO: 3-15-2016
cDo not tighten set screws!
d
3Dry-Fit Panel and Measure cont...
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
9
Ready To Go
SimpleSpec -Divytm

3Dry-Fit Panel and Measure cont...
Installation
SS: 3-15-2017
BO: 3-15-2016
eRemove Panel
4Anchor Second Cable Assembly
aRepeat Steps 12 for the
Second Cable Assembly.
bRepeat Step 3 and then Steps 13
for each additional panel.
5Attach the Panel
aPosition the single side brackets for felt (SS: 3152012;
BO: 3152013) 1½" below desired location of the top of the
panel. Tighten set screws to the cable.
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
10
Ready To Go
SimpleSpec -Divytm

1
2
1" (25mm)
SS: --
BO: --
Installation
bPosition the panel to desired location and ensure
it is level. Tighten set screws to the panel.
5Attach the Panel
6Finish Tensioner Assembly
Cut cable and put a drop of super glue at
end of cut cable to keep from fraying.
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
Installation Manual
11
Ready To Go
SimpleSpec -Divytm

Available Patterns
Product Description and Speciications
Features and Beneits
• 15 color options
• 6 base patterns
• Noise Reduction Coeicient
(NRC) up to 0.75
• Cost-eective decorative feature
• Easy to specify
• Easy to install
Cleaning Instructions
Divy Panels should be cleaned periodically. A regular, seasonal cleaning
program will dramatically help prevent noticeable weathering and dirt build-up.
To remove airborne debris and dust, it is recommended to periodically vacuum Divy Panels. Please
note the slight shedding of ibers from the Felt is normal and not indicative of any defect.
To treat liquid stains, remove spills immediately using a clean damp cotton cloth or with detergent
soap and warm water. Carpet and fabric cleaners can usually be used; always test an inconspicuous
area before the actual stain.
Do:
• Vacuum or use a soft brush to clean Divy Panels.
Do not:
• Use strong solvents, highly alkaline or abrasive cleaning agents.
• Do not completely saturate module with cleaning solution or water.
Panel Weight
 lbs
Material
Felt /" mm
Thickness Weight Flux
Sabine Absorption Coeicients




































Frequency, HZ Absorption Coeicient
Divy Panels have been independently tested and
meet the criteria for approved interior inishes as
described in the 2015 International Building Code®.
Material
Felt Flame Spread
Smoke Generated
Test-ASTM E


Divy
Class B: -

Result
Flammability and Smoke Test
Results - Building Code Approvals
Divy Panels can be speciied in any of 3form’s 15
Sola Felt options.
AriesAdmiral Burnt UmberArmor Cashmere
CitrineCast Ebony Hunter Mineral
RubyOxfordNickelMoon Zinc
Available Finishes
Sound Absorption Test Results
Felt Noise Reduction Coeicient
Material Test - ASTM C Result
Felt Sound Absorption Average
Accord - Parallel to 72" Direction
Margin - Parallel to 72"Direction
Net Plane
Quint - Parallel to 72"Direction
Vim - Parallel to 72"Direction
Accord - Parallel to 24"Direction
Margin - Parallel to 24"Direction
Quint - Parallel to 24"Direction
Vim - Parallel to 24"Direction
For more information, please visit 3-form.com or call 800.726.0126
SEPTEMBER 2019 | MANRTG40046 | REV 002 © 2019 3form, Inc. All rights reserved.
SimpleSpec -Divytm Spec Sheet
12
Ready To Go
