3-form SimpleSpec 300.11 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Contents Overview
(1)
Wall Template
(1) =
Glass Panel With Attached
Mounting Bracket KIT
(1)
Glass Sheet
(4)
LevelGlass
KShaped Proile
3151843
+
(6) =
LevelGlass Panel
Attachment KIT
3-15-1842-K
+
LevelGlass
JShaped Proile
3151842
(2) (2)
LevelGlass
LShaped Proile
3151844
(2)
LevelGlass Stop
Bracket
3151848
+ +
Self-Tapping Screw,
Pan Head Phillips
315185
(2)
LevelGlass
Wood Anchor
3151851
(8)
+
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Overview
300.11 allows you to highlight and accentuate the beauty of 3form glass without visible hardware. Using a structural adhesive
to attach a bracket permanently to the glass, the glass can engage with a series of brackets attached to the wall to create a
‘hardware free’ design and aesthetic.
48"
(1220mm)
16 sq. ft. max area
48"
(1220mm)
LevelGlass Panel
Attachment Kit
3-15-1842-K
Glass Panel with attached
mounting bracket KIT
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Installation
Required Tools
Drill Level
(Laser level recommended)
Pan Head Bits
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Installation
Attach Template to Wall
Ensure that wall is lat. Use laser level to ensure all
attachment brackets are on the same plane. Attach
Masonite template to the wall at the center.
Level template and add second screw. Wall attachment
brackets must be installed into blocking to hold weight
of glass. All weight is on the bottom 2 attachment
pieces. Ensure they can hold the weight applied.
a b
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Installation
Attach Brackets to Wall
Depending on blocking
location drill 2, #10
clearance holes in
J Brackets (3151842) and
L Brackets (3151844).
3-15-1842 (×2)
3-15-1844 (×2)
3-15-1851 (×2)
3-15-1844
3-15-1851 (×2)
3-15-1842
Make sure lower brackets are anchored to blocking.
a b
6
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Installation
Remove Wall Template
7
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Installation
Orient Glass, Lift and Place onto Bracketing
a b c
Angle the glass and lift into J bracket. As top engages, push bottom of
glass into L bracket.
Lower the glass on the L bracket.
8
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2017 | MANRTG30011 | REV 001 © 2017 3form, Inc. All rights reserved.
SimpleSpec 300.11tm Installation Manual
Ready To Go

Add Safety Brackets
Installation
3-15-1848
3-15-1850
1
2
