360 YIELD CENTER BANDIT KINZE 3000 User manual

INSTALLATION INSTRUCTIONS
KINZE 3000
PAGE 1  360YIELDCENTER.COM
V2  3.7.2019
STEP 2 |REMOVE CLOSING SYSTEM ARMS
Using a 9/16” socket, remove the bolt that holds the closing
wheel arm stop 5to the row unit between the gauge
wheels.
NOTE: The gauge wheels may need to be held up to remove
the bolt.
Using a 3/4” socket remove the nut from the carriage bolt
that secures the closing system arms on the row unit.
Remove carriage bolt and remove closing system arms 6
from the row unit. Discard carriage bolt, nut and washers.
Retain two piece bushing 7.
Remove spring from closing wheel arm stop and set closing
wheel arm stop to the side.
NOTE: Retain closing wheel arm stop in a safe location for
installation of closing system without 360 BANDIT.
HELPFUL TOOLS
• Hammer/Mallet
• Wrench Sizes: 3/4”, 9/16” and 15/16”
• Socket Sizes: 3/4”, 9/16” and 15/16”
• Impact
NEED HELP?
Call our Product Support Team at 888-512-4890.
STEP 1 |REMOVE CLOSING WHEELS
Release spring 1to remove tension from closing system.
Remove closing wheels with a 15/16” socket and wrench 2.
Retain the closing wheels, bolts, and nuts for re-installation
later in the instructions.
If present, remove insecticide attachment.
NOTES:
Removal of the closing wheels is necessary to facilitate the
ease of removing and reinstalling the spring.
If you are installing the optional chains kit, the bolts and
nuts 3can be discarded but the bushings 4need to be
kept.
1
2
345
6
7

STEP 6 | INSTALL DISK & HOSE GUIDES
NOTES:
Hose guides are labeled “L” left and “R” right. When
holding them in your hands with the ear tabs facing each
other, your left hand will be holding the left side hose guide
and your right hand will be holding the right side.
The supplied 3/8” x 1” bolt installed in the Bandit pin up
hole is to be used as a “zero” setting and as a stop in case of
spring disengagement.
Insert 5/8” X 3” bolt through the disk. Insert bushing 7
(large side first) and hose guide assembly 8(ear tab facing out).
Slide assembly into the lower hole on the bandit 9, aligning
the ear tab with corresponding upper hole 1and secure
with lock nut.
Tighten with 15/16” socket and wrench.
Using a mallet, install provided dust caps over bolt heads.
Route application hose through hole in top of 360 BANDIT
frame 1.
Repeat for other side.
STEP 5 |INSTALL SUPPORT STRAP
Remove the bolt on the bottom of the depth adjustment
assembly 1and discard.
Attach the support strap to the back holes 1on the
extension bracket with (2) 3/8” x 1-1/4” bolts and 3/8”
flange nuts from hardware kit #540615. Tighten bolts with
9/16” socket and wrench.
Secure the top of the support strap to the depth adjustment
assembly using the supplied 3/8” x 1-1/4” bolt 1and
washer from hardware kit #540615. Ensure all bracketry is
flush when bolt is installed.
NOTE: The extension bracket may need lifted up to align
bolt holes. Tighten the bolt down until there is a flat
connection between the support strap and the depth
adjustment assembly.
Tighten the nyloc nuts that were left loose in STEP 4 with
3/4” socket and wrench securing the BANDIT extension
bracket to the row unit 1.
INSTALLATION INSTRUCTIONS
KINZE 3000
PAGE 2  360YIELDCENTER.COM
13
14
15
16
STEP 3 | ASSEMBLE BANDIT ARM ASSEMBLY
(KIT #540560) & EXTENSION BRACKET
Slide the BANDIT arm assembly over the extension bracket,
ensuring BANDIT arms 8are facing in the rearward
direction, towards the spring hook 9.
Secure arm assembly to the front holes 1on the extension
bracket with (2) 3/8” X 1-1/2” bolts and 3/8” flange nuts.
Tighten with 9/16” socket and wrench.
STEP 4 |INSTALL EXTENSION BRACKET
NOTE: Leave nyloc nuts loose on both sides until after the
support strap is installed in STEP 5.
Align holes in extension bracket with the holes on the
row unit. Install flat washer on the 1/2” x 1-1/2” bolt from
hardware kit #540615. Slide bolt through extension
bracket and row unit hole (bolt head on the outside) 1.
Install another washer and hand tighten with nyloc nut
from hardware kit #540615. Do not tighten.
Repeat for other side.
10
11
88
9
8
10
8
11
12
8
12
8
13
8
14
8
15
17
18
19
20
16
17
18
19
20

STEP 7 |INSTALL CLOSING SYSTEM
Attach the tensioning spring on the closing system to the
spring hook on the BANDIT extension bracket.
NOTE: The amount of spacer washers required will dier
between planters/row units. Spacer washers have been
provided to fill the gap between the closing wheel arms and
the BANDIT extension bracket. Use the quantity of spacer
washers required for your system.
Align square holes in extension bracket with required
amount of spacer washers 1and holes in closing system
arms 1. From the inside to the outside, slide supplied
2-1/4” carriage bolt through all parts (carriage bolt head on
the inside). Secure all parts with the previously set aside
two-piece bushing 1and provided 1/2” nyloc nut. Tighten
with 1/2” socket. Adjust bushings according to OEM specs.
Using 15/16” socket and wrench, reinstall closing wheels.
NOTE: If the optional Chain Kit is being installed, do not
reinstall the closing wheels.
INSTALLATION COMPLETE STEP 5 |ASSEMBLE PLUMBING
NOTE: If hoses are not fully seated in the push to connect,
they will leak. Hoses seat 7/8” of an inch deep or until you
hear a snap.
Install orifice plates 1in the rubber grommets 1.
Assemble pluming components in the arrangement shown
above 1. The supplied push to connect adapter in the 360
BANDIT kit connects to 3/8” push to connect compatible hose.
Secure hoses to row unit with provided zip ties 1.
PLUMBING RECOMMENDATIONS:
To prevent excess fertilizer from dribbling out of the hoses
when product application is shut o, install one push to
connect polypropylene (Inlet x Outlet) 3/8” O.D. check valve
(not included) in the plumbing to each row prior to the 360
BANDIT orifices. Check valve is available at Dultmeier Sales
(Item #BUCV1103-P38).
A 50 mesh strainer (not included) can be used in the
complete plumbing system between tanks and 360
BANDIT to help prevent debris from blocking orifices.
PAGE 3  360YIELDCENTER.COM
24
25
26
21
INSTALLATION INSTRUCTIONS
KINZE 3000
21
22
22
23
23
24 25
26
27
27
