360 Yield 360 Y-DROP CASE 120 BOOM User manual

INSTRUCTIONS
360 YDROP®
CASE 120' BOOM
360 Y-DROP®REGISTRATION
Please visit productregistration.360yieldcenter.com
to complete the product registration for your
360 Y-DROP so we can better support our products
from day one and ensure you have the latest
upgrades, warranty parts and technical support.
Thank you!
360YIELDCENTER.COM
V1  11.30.2016

INSTRUCTIONS
360 YDROP
CASE 120' BOOM
2
INTRODUCTION
Before beginning, it’s important to know where each mounting bracket fits relative
to the row spacing involved. The 360 Y-DROP unit should be precisely centered
on the machine, as this is critical to the assembly of the system to the sprayer and
for mounting the system to your sprayer boom. There are, however, many boom
variations among all sprayer models. Your sprayer may not be identical to the model
in the following steps of the guide, and the pictures may not exactly reflect your
model. While these steps will help you install most of your 360 Y-DROP system,
you may need to custom-fit some components with your particular boom.
RECOMMENDED TOOLS
Ratchet wrench with 1/2" and 9/16" deep well sockets
3/8" 12-point socket
1/2" and 9/16" combination wrenches
#2 Phillips screwdriver (for the shield installation)
TORQUE VALUES
Refer to these torque values when tightening all fasteners
5/16" stainless U-bolt 15 ft/lbs
5/16" stainless Set screw 15 ft/lbs
3/8" carbon U-bolt 35 ft/lbs
5/16" carbon U-bolt 30 ft/lbs
5/16" carbon Stop bolt 30 ft/lbs
QUESTIONS
Call our Product Support team at 888-512-4890

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
3
ESTABLISH
DROP LOCATIONS
Figures 1 and 2
Step 1 Locate the center of the machine and
identify the location of all the drops. On
the sprayer boom, mark where each riser
mount will be located. This will ensure
that the extension tubes will not interfere
with the riser mounts.
Figure 3
Step 2 For the primary boom; starting at the
wing fold pivot pin, measure out and
make marks at 55", 115", 177", 217"
and 257" (all measurements are ±5").
Repeat for the other primary boom.
I.
Figure 1
Figure 2
Figure 3
55"
115"
177"
217"
257"

INSTALL MOUNT ASSEMBLIES
ON THE OEM PRIMARY BOOM
Figure 4
Figure 4 shows size and location of U-bolts for
OEM primary boom. The opposite arm of the
central section will follow the same pattern as
the arm shown.
Figure 5
Step 1 With the threads pointing up, install
U-bolt (1) on the bottom side of the OEM
primary boom.
Bag AK (3.5")
Bag AJ (3.0")
Bag AH (2.5")
Bag AS (6.0" Top Plate)
NOTE: An example of the first mounting location
is illustrated in the callout in Figure 4.
Step 2 Install bracket assembly (2) and flange
lock nut (3).
Hardware Kit D
Repeat Steps 1 and 2 for the other OEM mount
bracket kit.
Step 3 Install extension tube (4).
Step 4 Install boom bracket (5) onto the
extension tube.
Step 5 Install stop bolts (6) at both the front
and the rear of the extension tube.
Hardware Kit B
Figure 6
Shows the positioning for the strap (1) and two 3/8"
bolts and flange nuts (2) used for the OEM mount
bracket on the outside mount of the primary boom.
Figure 7
Step 6 Install stainless steel set screw and jam
nut assembly (1).
Hardware Kit D
Repeat Steps 1-6 for the remaining mount
assemblies on the OEM primary boom.
INSTRUCTIONS 360 YDROP
CASE 120' BOOM
II.
360YIELDCENTER.COM
4
Figure 4
Figure 5
Figure 6
Figure 7
1
4
6
5
3
2
1
2
1
1
Front of Machine

INSTALL CENTER SECTION
SQUARE TUBE
Figure 8
Refer to Figure 4 for U-bolt locations.
Step 1 With the threads pointing up, install
U-bolt (1) on the front OEM center
section boom.
Bag AD (1.5")
Bag AR (3.5")
Step 2 Place bracket assembly (2) into position
and install 3/8" flange nuts (3).
Repeat Steps 1 and 2 for the rear mount (4).
Step 3 Install extension tube (5) onto bracket
assemblies (2) and (4).
Figure 9
Step 4 Install boom bracket (1) onto
extension tube (2).
Step 5 Install stop bolts at both the front and
the rear of the extension tube (3).
Hardware Kit B
Step 6 Install stainless steel set screw and
jam nut assembly in boom bracket (4).
Repeat Steps 4-6 for left-hand mount on OEM
center section.
INSTRUCTIONS 360 YDROP
CASE 120' BOOM
III.
360YIELDCENTER.COM
5
Figure 8
54
3
1
2
Figure 9
2
34
1
1.5" 3.5"

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
6
INSTALL 360 YDROP
BOOM
Figure 10
Step 1 Assemble 5' boom sections (1) using the
8" boom connectors (2) and the supplied
hardware.
Hardware Bag CC
Step 2 Repeat Step 1 as needed in order to
assemble the entire 360 Y-DROP boom.
Step 3 Set the 360 Y-DROP boom assembly
onto boom bracket (3).
Repeat Steps 1 -3 for the remaining boom assemblies.
CAUTION: The 360 Y-DROP boom assembly may
weigh up to 150 lbs. (68 kg). Exercise caution and
enlist help for this process.
Figure 11
Step 4 In order to span the full length of the
center section 360 Y-DROP boom, you
will need to cut and drill one of the 5'
boom sections to 1'. Mount this 1' section
between two full 5' boom sections. Drill a
7/16" through hole centered 2" from the
outside edge.
Figures 12 and 13
Step 5 Install square U-bolt (1), the 5/16" extra
thick washers, and the 5/16" nuts over
the 360 Y-DROP boom (2).
Hardware Kit A
Step 6 Install stop bolt (3) at both the front and
the rear of the extension tube. Repeat for
remaining stop bolts.
Hardware Kit B
Step 7 Install stainless steel set screw and
jam nut assembly (4). See Figure 13 for
detail. Repeat for the remaining mount
assemblies on the primary boom.
IV.
Figure 10
Figure 11
Figure 12
Figure 13
1
2
4
4
3
3
1
2

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
7
INSTALL BREAKAWAY ASSEMBLY 
ONE PIECE
Figure 14
Step 1 Install breakaway assembly - one piece (1)
using the square U-bolts (2) and the extra
thick washer and Nylock nut. Repeat for
the remaining breakaway assemblies -
one piece.
Hardware Kit C
Figure 15
Figure 15 may show more or fewer mounts than
your installation. The alignment and quantity of the
mounts will depend on your row spacing.
Figure 16
Step 2 Install riser tube assembly (1) into the
breakaway assembly - one piece (2).
Step 3 Install pin (3).
Repeat Steps 2 and 3 for the remaining riser tube
assemblies.
NOTE: Included in most sprayer mount packages
are standard riser mounts to be used when primary
booms are folded and in transport mode. These
standard riser mounts should be mounted in
locations that allow you to relocate the drops away
from potential tire interference. See "Install Riser
Mounts Without Breakaway Assemblies" section on
next page for more instructions.
V.
Figure 14
Figure 15
Figure 16
1
2
2
3
1

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
8
INSTALL RISER MOUNTS WITHOUT
BREAKAWAY ASSEMBLIES (OPTIONAL)
Figure 17
Step 1 Install riser mount (1) using the square
U-bolts (2) and the extra thick washer
and Nylock nut. Repeat for the remaining
riser mounts.
Hardware Kit C
Figure 18
Figure 18 may show more or fewer riser mounts
than your installation. The alignment and quantity
of the riser mounts will depend on your row spacing.
Figure 19
Step 2 Install riser tube assembly (1) into the
riser mount (2).
Step 3 Install pin (3).
Repeat Steps 2 and 3 for the remaining riser tube
assemblies.
V.
Figure 17
Figure 18
Figure 19
1
2
2
3
1

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
9
Figure 20
Figure 21
Figure 22
INSTALL SHIELDS AND
RISER HOSES
Figure 20
Step 1 Install shield (1) onto riser tube (2).
Figure 21
Step 2 Install base unit (1) onto riser tube (2).
Figure 22
Step 3 Assemble drag hoses (1) to 360 Y-DROP
base and secure with hose clamps (2).
Figure 23
Step 4 Note the orientation of the drag hose
clamps. The tails should point inward.
VI.
Figure 23
2
2
1
1
2
1

INSTRUCTIONS 360 YDROP
CASE 120' BOOM
360YIELDCENTER.COM
All other trademarks are the property of 360 Yield Center, its ailiates and/or its licensors.
©2016 360 Yield Center. All rights reserved.
Figure 24
Figure 25
Figure 26
INSTALL SHIELDS AND
RISER HOSES (continued)
Figure 24
CAUTION: Do NOT use a drill or impact driver
for Steps 5 and 6.
Step 5 Install two ½" screws (1).
Step 6 Install two ¾" screws (2).
Step 7 Install rubber washer (3) into the “Y”.
Figure 25
Step 8 Install riser hose assembly (1) into the “Y”.
Figure 26
Step 9 Route riser hose assembly (1) as shown
in Figure 26.
Step 10 Install the riser hose assembly to the
OEM nozzle body.
Step 11 Use 3 equally spaced plastic ties to
secure the riser hose assembly.
Repeat Steps 1-11 for the remaining
360 Y-DROP Shields.
VI.
INSTALLATION COMPLETE.
