3M DBI SALA 2000005 Operator's manual

CE EN 362: 2004
CLASS B
CE Type Test CE Production Quality
Control
BSI
Kitemark Court
Davy Avenue
Knowlhill
Milton Keynes
MK5 8PP
United Kingdom
BSI
Kitemark Court
Davy Avenue
Knowlhill
Milton Keynes
MK5 8PP
United Kingdom
1
A
A
B
C
B
DD
2000005
Material: Alloy Steel
Throat Size: 3/4 in (19 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
B
C
DD
2000025
Material: Aluminum Alloy
Throat Size: 3/4 in (19 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
B
C
DD
2000112
Material: Alloy Steel
Throat Size: 11/16 in (17 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
B
B
C
A
D D
2000113
Material: Alloy Steel
Throat Size: 1-3/16 in (30 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
B
C
DD
2000114
Material: Alloy Steel
Throat Size: 2-3/16 in (56 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
Continued...
SELF-LOCKING
CARABINERS
Model Numbers: (See Figure 1.)
User Instruction Manual
FORM NO: 5908026
REV: A © 3M 2016

2
1
A
A
B
B
C
D
D
2000117
Material: Alloy Steel
Throat Size: 11/16 in (17 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
B
C
D
D
2000127
Material: Stainless Steel
Throat Size: 11/16 in (17 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
BCD
D
2000159
Material: Alloy Steel
Throat Size: 3/4 in (19 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
B
C
D
D
2000160
Material: Aluminum Alloy
Throat Size: 2/3 in (17 mm)
Minmium
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
BC
D
D
2000162
Material: Aluminum Alloy
Throat Size: 1 in (25 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
BCDD
2000184
Material: Aluminum Alloy
Throat Size: 7/10 in (18 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
Continued...

3
1
A
A
B
C
D
D
2000188
Material: Aluminum Alloy
Throat Size: 2 in (52 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
BCDD
2000300
Material: Alloy Steel
Throat Size: 2 in (52 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)
A
A
B
BCDD
2000301
Material: Stainless Steel
Throat Size: 2 in (52 mm)
Minimum
Breaking
Strength:
A. 5,000 lbs (22.2 kN)
B. 3,600 lbs (16 kN)
Gate Strength: C. 3,600 lbs (16 kN)
D. 3,600 lbs (16 kN)

4
!WARNING: This product is part of a Personal Fall Protection System.
The user must follow the manufacturer’s instructions for each component
of the system. These instructions must be provided to the user of this
equipment. The user must read and understand these instructions before
using this equipment. Manufacturer’s instructions must be followed for
proper use and maintenance of this equipment. Alterations or misuse of this
product or failure to follow instructions may result in serious injury or death.
IMPORTANT: If you have questions on the use, care, or suitability of
this equipment for your application, contact 3M Fall Protection.
IMPORTANT: Before using this equipment, record the product
identification information from the ID label in the ‘Inspection and
Maintenance Log’ at the back of this manual.
DESCRIPTION:
Figure 1 identifies 3M Fall Protection
®
Self-Locking Carabiners which can
be purchased separate from 3M Personal Protective Equipment (PPE)
1
and
used as connectors in a Fall Protection System. Figure 2 illustrates the
components of a Carabiner. Carabiners are self-locking connectors comprised
of a trapezoidal or oval shaped Body (A) with a Gate (B) on a Hinge (C) that
opens to attach the Carabiner around another object and, when released,
automatically closes across the Throat (D) to retain connection around the
object. A Lock (E) closes around the Nose (F) of the Carabiner to prevent the
Gate from involuntarily opening. Some Carabiner models are equipped with
a Retaining Pin (G) that provides a captive eye for connection of a Lanyard,
Lifeline, or similar component.
2
C
A
E
G
B
A
B
F
E
G
D
ABody BGate CHinge DThroat ELock FNose GPin
1 Integrated Connectors: Lanyards, SRLs, etc. are typically equipped with an integrated connector
(Snap Hook, etc.) with a captive eye. Integrated Connectors can not be removed from their
respective equipment without using a special tool or damaging the equipment. Use of Integrated
Connectors is documented in the Manufacturer’s instructions that come with the equipment.

1.0 APPLICATIONS
1.1 PURPOSE: Capital Safety Self-Locking Carabiners can be used as
Anchorage Connectors
1
or Connectors
2
in Fall Arrest, Restraint, Work
Positioning, Suspension, and Rescue systems.
1.2 STANDARDS: Capital Safety Carabiners conform to the national or
regional standard(s) identified on the front cover of these instructions.
1.3 TRAINING: This equipment is intended to be used by persons trained in its
correct application and use. It is the responsibility of the user to assure they
are familiar with these instructions and are trained in the correct care and use
of this equipment. Users must also be aware of the operating characteristics,
application limits, and the consequences of improper use.
1.4 LIMITATIONS: Always consider the following limitations when
installing or using this equipment:
!WARNING: Failure to observe the following limitations may
result in injury or death.
• Capacity: The Carabiners listed in Figure 1 are intended for use
by persons with a combined weight (person, clothing, tools, etc.)
of no more than 420 lbs (191 kg). Only one Personal Protective
System may be connected to the Carabiner at any time, except for
emergency situations.
• Hazards: Use of this equipment in areas where surrounding hazards
exist may require additional precautions to reduce the possibility of injury
to the user or damage to the equipment. Hazards may include, but are
not limited to: high heat, caustic chemicals, corrosive environments,
high voltage power lines, explosive or toxic gases, moving machinery, or
overhead materials that may fall and contact the user or Fall Protection
System.
□Corrosion: Use near seawater or other corrosive environments may
require more frequent inspection or service to ensure corrosion does
not affect performance of the Carabiner.
□Chemicals: Solutions containing acid or caustic chemicals, especially
at elevated temperatures, may cause damage to this equipment.
Consult Capital Safety if doubt exists concerning use of this equipment
where chemical hazards are present.
□Electrical: Do not install Carabiners where they, or the user, may
contact electrical power lines.
2.0 USE
2.1 FALL PROTECTION AND RESCUE PLAN: The employer must
have a Fall Protection and Rescue Plan in place. The plan should
provide guidelines and requirements for an employer’s managed
fall protection program, including policies, duties and training; fall
protection procedures; eliminating and controlling fall hazards;
rescue procedures; incident investigations; and evaluating program
effectiveness.
1 Anchorage Connector: A component or subsystem that functions as a coupling between the
anchorage and a fall protection, work positioning, rope access, or rescue system.
2 Connector: A component or element that is use to couple parts of the system.

6
2.2 INSPECTION FREQUENCY: Carabiners shall be inspected by the
authorized person
3
or rescuer
4
before each use (See Section 4).
Additionally, inspections shall be conducted by a competent person
5
other than the user. Extreme working conditions (harsh environment,
prolonged use, etc.) may necessitate more frequent competent person
inspections. The competent person shall use the Inspection Schedule
(Section 4) to determine appropriate inspection intervals. Inspection
procedures are described in Section 4. Results of the Competent Person
inspection should be recorded in the “Inspection and Maintenance Log”
on the back pages of these instructions.
!WARNING: If the carabiner has been subjected to fall arrest forces:
remove it from service, mark or tag as “UNUSABLE”, inspect and service as
instructed in Section 4. Continued use of the carabiner after fall arrest may
result in injury or death.
2.3 COMPATIBILITY OF CONNECTORS: Connectors are considered to be
compatible with connecting elements when they have been designed to
work together in such a way that their sizes and shapes do not cause
their gate mechanisms to inadvertently open regardless of how they
become oriented. Contact Capital Safety if you have any questions about
compatibility. See Figure 3 Uninentional Disengagement (Roll Out).
3
1. Force is applied to the
snap hook.
2. The gate presses against
the connecting ring.
3. The gate opens allowing the
snap hook to slip o.
Small ring or other
non-compatibly
shaped element
2.4 MAKING CONNECTIONS: Only self-locking snap hooks and/or
carabiners shall be used with this equipment. Ensure all connectors
are fully closed and locked and compatible. See Figure 4 Inappropriate
Connections.
DBI-SALA connectors (snap hooks and carabiners) are designed to be
used only as specified in each product’s user instructions. See Figure 4
for inappropriate connections. DBI-SALA snap hooks and carabiners
should not be connected:
A. To a D-ring which another connector is already attached.
B. In a manner that would result in a load on the gate.
3 Authorized Person: A person assigned by the employer to perform duties at a location where the
person will be exposed to a fall hazard.
4 Rescuer: Person or persons other than the rescue subject acting to perform an assisted rescue by
operation of a rescue system.
5 Competent Person: An individual designated by the employer to be responsible for the immediate
supervision, implementation, and monitoring of the employer’s managed fall protection program
who, through training and knowledge, is capable of identifying, evaluating, and addressing existing
and potential fall hazards, and who has the employer’s authority to take prompt corrective action
with regard to such hazards.

7
NOTE: Large throat snap hooks should not be connected to standard
size D-rings or similar objects which will result in a load on the gate
if the hook or D-ring twists or rotates, unless the snap hook complies
with CE EN362:2004. Check the marking on your snap hook to verify
that it is appropriate for your application.
C. In a false engagement, where features that protrude from the
snap hook or carabiner catch on the D-ring, and without visual
confirmation seems to be fully engaged to the anchor point.
D. Directly to webbing or rope lanyard for tie-back (unless specifically
provided by the manufacturer).
E. To any object which is shaped or dimensioned such that the snap
hook or carabiner will not close and lock, or where roll-out could
occur.
4
OTHER RESTRICTIONS:
• Do not make connections where the hook locking mechanism can
come into contact with a structural member or other equipment
and potentially release the hook.
• Do not attach connector into a loop or thimble of a wire rope or
attach in any way to a slack wire rope.
• The connector must be free to align with the applied load as
intended - regardless of the size or shape of the mating connector.
• A carabiner may be used to connect to a single or pair of soft
loops on a body support such as a body belt or full body harness,
provided the carabiner can fully close and lock. This type of
connection is not allowed for snap hooks.
• A carabiner may be connected to a loop or ring connector that
is already occupied by a choker style connector. This type of
connection is not allowed for snap hooks.
2.5 ANCHORAGE STRENGTH: The anchorage strength required is
dependent on the application type.
A. FALL ARREST: Anchorages selected for fall arrest systems shall
have a strength capable of sustaining static loads applied in the
directions permitted by the system of at least 12 kN (2,700 lbs)
per EN 795.

8
3.0 OPERATION AND USE
WARNING: Do not alter or intentionally misuse this equipment. Consult
3M when using this equipment in combination with components or
subsystems other than those described in this manual. Some subsystem
and component combinations may interfere with the operation of this
equipment. Use caution when using this equipment around moving
machinery, electrical hazards, chemical hazards, and sharp edges.
WARNING: Consult your doctor if there is reason to doubt your fitness to
safely absorb the shock from a fall arrest. Age and fitness seriously affect
a worker’s ability to withstand falls. Pregnant women or minors must not
use 3M carabiners.
WARNING: Follow the manufacturer’s instructions for associated
equipment (full body harness, lanyard, lifeline, etc.) used in your personal
fall arrest, restraint, work positioning, suspension, or rescue system.
3.1 CARABINER OPERATION
A. CONNECT DOUBLE ACTION CARABINER: Connect the carabiner
to the connection point, rotate the gate clockwise and push to
the center of the carabiner. When positioned around a connection
point, release gate to close and lock.
See Figure 5.
5
Step 1 Step 2

9
B. CONNECT TRIPLE ACTION CARABINER: Connect the carabiner
to the connection point, rotate the gate clockwise, then pull gate
up and push to the center of the carabiner. Position around a
connection point, then release gate to close and lock. See Figure 6.
6
Step 1 Step 2 Step 3
3.2 USE CONSIDERATIONS
When making a connection using a carabiner, the mating connector
must be compatible in size and shape. Improper loading directions can
cause the hook to fail or the gate to open, releasing the load. Do not
use hooks that will not completely close over the attachment object.
Do not connect carabiners to carabiners, or snap hooks to carabiners.
Do not install more than one snap hook or carabiner into a single
connection ring or opening (except for emergency situations). Do not
connect snap hooks or carabiners to objects or openings that may
abrade or wear the hook material.

4.0 INSPECTION AND MAINTENANCE LOG
Serial Numbers:
Model Numbers:
Inspection Date: Inspected By:
Inspection: (See Section 2.2 for Inspection Frequency) User Competent
Person
Inspect the snap hook or carabiner for damage. Look carefully for cracks,
sharp edges, burrs, dents, or deformities. Check for bending or distortion.
Inspect the snap hook or carabiner for excessive corrosion. The gate and lock
should operate smoothly, with no difficulty. Gates must fully close and engage
nose of hook. See Figure 1.
Inspect markings. Markings should be present and fully legible.
Inspect each system component or subsystem according to
manufacturer’s instructions.
Record the inspection date and results in the in the inspection and
maintenance log.
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:

11
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:
Corrective Action/Maintenance: Approved By:
Date:

ISO
9001
USA
3833 SALA Way
Red Wing, MN 55066-5005
Toll Free: 800.328.6146
Phone: [phone]
Fax: [phone]
[e-mail]
Brazil
Rua Anne Frank, 2621
Boqueirão Curitiba PR
81650-020
Brazil
Phone: [phone]
[e-mail]
Mexico
Calle Norte 35, 895-E
Col. Industrial Vallejo
C.P. 02300 Azcapotzalco
Mexico D.F.
Phone: [phone]
[e-mail]
Colombia
Compañía Latinoamericana de Seguridad S.A.S.
Carrera 106 #15-25 Interior 105 Manzana 15
Zona Franca - Bogotá, Colombia
Phone: [phone]
[e-mail]
Canada
260 Export Boulevard
Mississauga, ON L5S 1Y9
Phone: [phone]
Toll-Free: 800.387.7484
Fax: [phone]
[e-mail]
EMEA (Europe, Middle East, Africa)
EMEA Headquarters:
5a Merse Road
North Moons Moat
Redditch, Worcestershire
B98 9HL UK
Phone: + 44 (0)1527 548 000
Fax: + 44 (0)1527 591 000
[e-mail]
France:
Le Broc Center
Z.I. 1re Avenue - BP15
06511 Carros Le Broc Cedex
France
Phone: + 33 04 97 10 00 10
Fax: + 33 04 93 08 79 70
[e-mail]
Australia & New Zealand
95 Derby Street
Silverwater
Sydney NSW 2128
Australia
Phone: +(61) 2 8753 7600
Toll-Free : 1800 245 002 (AUS)
Toll-Free : 0800 212 505 (NZ)
Fax: +(61) 2 8753 7603
[e-mail]
Asia
Singapore:
69, Ubi Road 1, #05-20
Oxley Bizhub
Singapore 408731
Phone: +65 - 65587758
Fax: +65 - 65587058
[e-mail]
Shanghai:
Rm 1406, China Venturetech Plaza
819 Nan Jing Xi Rd,
Shanghai 200041, P R China
Phone: [phone]
Fax: [phone]
[e-mail]
www.capitalsafety.com
LIMITED LIFETIME WARRANTY
Warranty to End User: CAPITAL SAFETY warrants to the original end user (“End User”) that its
products are free from defects in materials and workmanship under normal use and service. This
warranty extends for the lifetime of the product from the date the product is purchased by the End
User, in new and unused condition, from a CAPITAL SAFETY authorised distributor. CAPITAL SAFETY’S
entire liability to End User and End User’s exclusive remedy under this warranty is limited to the
repair or replacement in kind of any defective product within its lifetime (as CAPITAL SAFETY in its
sole discretion determines and deems appropriate). No oral or written information or advice given by
CAPITAL SAFETY, its distributors, directors, officers, agents or employees shall create any different or
additional warranties or in any way increase the scope of this warranty. CAPITAL SAFETY will not accept
liability for defects that are the result of product abuse, misuse, alteration or modification, or for defects
that are due to a failure to install, maintain, or use the product in accordance with the manufacturer’s
instructions. THIS WARRANTY IS THE ONLY WARRANTY APPLICABLE TO OUR PRODUCTS AND IS IN
LIEU OF ALL OTHER WARRANTIES AND LIABILITIES, EXPRESSED OR IMPLIED.
