3One data TNS5800D Series User manual

TNS5800D Series
Layer 3 Wall Mounting Industrial
Ethernet Switch
Quick Installation Guide
3onedata Co., Ltd.
Address:
3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Song
Bai Road, Nanshan
District, Shenzhen, 518108, China
Website:
www.3onedata.com
Te l :
[phone]
Fax:
[phone]
【Package Checklist】
Please check the integrity of package and accessories while
first using the switch.
1. Industrial Ethernet switch
2. Warranty card
3. Certification
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
This series of products are layer 3 wall-mounted industrial
Ethernet switches designed for the rail transit industry. Models
as follows:
Model I. TNS5800D-8P4GT-P110 (8 100M PoE M12 + 4
Gigabit M12, 110VDC power input)
Model II. TNS5800D-8GP4GT-P110 (8 Gigabit PoE M12 + 4
Gigabit M12, 110VDC power input)
Model III. TNS5800D-16P4GT-P110 (16 100M PoE M12 + 4
Gigabit M12, 110VDC power input)
Model IV. TNS5800D-16GP4GT-P110 (16 Gigabit PoE M12 +
4 Gigabit M12, 110VDC power input)
【Panel Design】
Front view
Model I
Model II
1. Power supply indicator (P1-P2)
2. Alarm indicator (ALM)
3. Running indicator (RUN)
4. Relay alarm output interface
5. Grounding screw
6. CONSOLE port
7. Lugs
8. Power input interface (P1-P2)
9. Ethernet port indicator (E1-E8, G1-G4)
10. Gigabit Bypass M12 interface (Bypass: G1-G2, G3-G4)
11. PoE indicator (E1-E8)
12. 100M PoE M12 interface (E1-E8)
13. Ethernet port indicator (G1-G12)
14. Gigabit Bypass M12 interface (Bypass: G9-G10,
G11-G12)
15. PoE indicator (G1-G8)
16. Gigabit PoE M12 interface (G1-G8)
Model III
Model IV
1. Power supply indicator (P1-P2)
2. Alarm indicator (ALM)

3. Running indicator (RUN)
4. Relay alarm output interface
5. Grounding screw
6. CONSOLE port
7. Lugs
8. Power input interface (P1-P2)
9. Gigabit Bypass M12 interface (Bypass: G1-G2, G3-G4)
10. PoE indicator (E1-E16)
11. 100M PoE M12 interface (E1-E16)
12. Ethernet port indicator (E1-E16, G1-G4)
13. Gigabit Bypass M12 interface (Bypass: G17-G18,
G19-G20)
14. PoE indicator (G1-G16)
15. Gigabit PoE M12 interface (G1-G16)
16. Ethernet port indicator (G1-G20)
【Mounting Dimension】
Unit: mm
Model I and Model II
Model III and Model IV
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Wall-mounted Device Mounting】
Model I and Model II
On the wall of device mounting, place the device onStep 1
the wall for reference or refer to the mounting
dimension to mark two screw positions.
Hang the device on the labeled wall, align the bolt toStep 2
the labeled position, then fix them with a certain gap.
Slide the device down to hang on the screw, thenStep 3
tighten the screw, and the installation is finished.
Model III and Model IV
On the wall of device mounting, place the device onStep 1
the wall for reference or refer to the mounting
dimension to mark two screw positions.
Nail screws on the wall and keep 7mm interspaceStep 2
reserved.
Hang the device on 4 screws and slide downward,Step 3
then tighten the screw. Mounting ends.
【Wall-mounted Device Disassembling】
Model I and Model II
Power off the device.Step 1
Hold the device steady and unscrew the screw onStep 2
the wall.
Take out the device, disassembling ends.Step 3
Model III and Model IV
Power off the device.Step 1
Unscrew the screw on the wall about 7mm.Step 2
Lift the device upward slightly; take out the device,Step 3
disassembling ends.

Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
then plug the power supply plug contact and power on.
Power OFF operation: First, remove the power plug,
then remove the wiring section of terminal block. Please
pay attention to the above operation sequence.
【Power Supply Connection】
110VDC power supply
This series device provides two independent DC
power supply inputs, which support reverse
connection protection and power redundancy
backup. The power supply interface adopts M12 A-Coded
4-Pin pin (male) connector. Power supply input range:
110VDC (66~156VDC). The pin definitions of M12 (male) are
shown as follows:
Pin No.
1
2
3
4
Definition
V1+
V2+
V1-
V2-
【
Relay Connection
】
This series device provides 1 M12 D-Coded 4-Pin
slot (female) that supports 1 relay alarm output. R1
and R2 are a set of normally open contacts of the device
alarm relay. They are open circuit in the state of normal non
alarm, closed when any alarm information occurs. For
example, they are closed when powered off, and send out
alarm. The relay supports the output of DC power supply
alarm information or network abnormality alarm. It can be
connected to alarm light or alarm buzzer or other switching
value collecting devices, which can timely inform operators
when the alarm occurs. The pin definitions of relay are shown as
follows:
Pin No.
1
2
3
4
Definition
R1
R2
NC
NC
【Console Port Connection】
The series of device provides 1 program debugging
port based on RS232 serial port which can conduct
device CLI command management after connecting
to PC. The interface adopts M12 D-Coded 4-Pin slot (female).
The pin definitions of M12 are shown as follows:
Pin No.
1
2
3
4
Definition
TX
RX
NC
GND
【Communication Interface Connection】
100M M12 Interface
The Model I and III device provide 10/100Base-T(X)
interfaces, the interface type is M12 D-Coded 4-Pin
slot (female). The definitions of M12 pin are as
follows:
Pin No. Definition Description
1 TX+ Positive send data of 100M
Ethernet
2 RX+ Positive receive data of 100M
Ethernet
3 TX- Negative send data of 100M
Ethernet
4 RX- Negative receive data of 100M
Ethernet
Gigabit M12 interface
This device provides 10/100/1000Base-T(X)
interfaces, the interface type is M12 X-Coded
8-Pin slot (female). The definitions of M12 pin are
as follows:
Pin No. Definition Description
1 D0+ (DA+) Positive bi-directional data of
Gigabit Ethernet group 1
2 D0- (DA-) Negative bi-directional data of
Gigabit Ethernet group 1
3 D1+ (DB+) Positive bi-directional data of
Gigabit Ethernet group 2
4 D1- (DB-) Negative bi-directional data of
Pin No. Definition Description
Gigabit Ethernet group 2
5 D3+ (DD+) Positive bi-directional data of
Gigabit Ethernet group 4
6 D3- (DD-) Negative bi-directional data of
Gigabit Ethernet group 4
7 D2- (DC-) Negative bi-directional data of
Gigabit Ethernet group 3
8 D2+ (DC+) Positive bi-directional data of
Gigabit Ethernet group 3
【Checking LED Indicator】
The device provides LED indicators to monitor its operating
status, which has simplified the overall troubleshooting
process. The function of each LED is described in the table
below:
LED
Indicate
Description
P1/P2
ON P1/2 is connected and running
normally
OFF P1/2 is disconnected and running
abnormally
ALM
ON
Power supply or port link has alarm
OFF Power supply or port link has no
alarm
RUN
ON
The device is powering on or the
device is abnormal.
OFF
The device is powered off or the
device is abnormal.
Blinking Blinking 1 time per second, system
is running normally
LINK
(E1-E16,
G1-G20)
ON
Ethernet port has established a
valid network connection
Blinking
Ethernet port is in an active
network status
OFF
Ethernet port has not established
valid network connection
POE
ON
POE port is powering other PD

LED
Indicate
Description
(E1-E16,
G1-G20)
devices normally
OFF POE port is not powering other PD
devices
【
Logging in to WEB Interface
】
This device supports WEB management and configuration.
Computer can access the device via Ethernet interface. The
way of logging in to device’s configuration interface via IE
browser is shown as below:
Configure the IP addresses of computer and theStep 1
device to the same network segment, and the
network between them can be mutually accessed
Enter device’s IP address in the address bar of theStep 2
computer browser.
Enter device’s username and password in the loginStep 3
window as shown below.
Click “Login” button to login to the WEB interface ofStep 4
the device.
Note:
The default IP address of the device is “192.168.1.254”.
The default username and password of the device are
“admin123”.
If the username or password is lost, user can restore it to
factory settings via management software; all modified
configurations will be cleared after restoring to factory
settings, so please backup configuration file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
Gigabit PoE M12 10/100/1000Base-T(X), M12
(Female), 8-Pin X-Coded,
automatic flow rate control,
full/half duplex mode, MDI/MDI-X
autotunning; The maximum
capacity of a single port is 30W
PoE power supply output. Pin 1
and 2 of PoE power supply are
positive, while pin 3 and 4 are
negative
Gigabit M12 10/100/1000Base-T(X),
M12(Female), 8-Pin X-Coded,
Automatic Flow Control, Full/half
Duplex Mode, MDI/MDI-X
Autotunning; support two groups
of Bypass
100M PoE M12 10/100base-T(X), M12 (Female),
4-Pin D-Coded, automatic flow
control, full/half duplex mode,
MDI/MDI-X automatic detection;
The single port supports up to
30W PoE power supply output.
Pin 1 and 3 of PoE power supply
are positive, while pin 2 and 4 are
negative
Console port CLI command line management
port (RS-232), M12(Female),
4-Pin D-Coded
Alarm interface
M12(Female), 4-Pin D-Coded,
support 1 relay alarm output, with
current load capacity of
1A@30VDC or 0.3A@125VAC
Indicator
Power indicator, alarm indicator,
running indicator, interface
indicator, PoE indicator
Switch Property
Backplane bandwidth
128G
Packet buffer size
12Mbit
MAC Address Table
16K
Power Supply
Power input 110VDC (66~156VDC)
Support reverse connection
protection
Connection Mode
M12 (Male), 4-Pin A-Coded
Power Consumption
Full-load(without PoE)
＜
20W
Full-load(with PoE)
＜
120W
Working Environment
Working temperature
-40~75
℃
Storage temperature
-40~85
℃
Working humidity
5%
～
95% (no condensation)
Protection grade
IP67(metal shell)
