3One data IES6300 Series User manual

IES6300 Series
Managed Industrial Ethernet Switch
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District,
Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Package Checklist】
Please check the integrity of package and accessories while
first using the switch.
1. Industrial Ethernet switch
2. Quick installation guide
3. DIN-Rail mounting attachment
4. CD
5. Certification
6. Warranty card
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
This series of product is Gigabit managed DIN-Rail industrial
Ethernet switch. For convenience, This series of product
adopts the following number on the left in this guide, please
affirm the number of your product.
Model I. IES6300-8GT2GS2HS-2P48 (8 Gigabit copper
ports + 2 Gigabit SFP + 2 2.5G SFP, 12~48VDC
redundant power supply)
Model II. IES6300-8GP2GS2HS-2P24-120W (8 Gigabit PoE
copper ports + 2 Gigabit SFP + 2 2.5G SFP, 24VDC
redundant power supply, 120W PoE power
consumption)
Model III. IES6300-8GP2GS2HS-2P48-240W (8 Gigabit PoE
copper ports + 2 Gigabit SFP + 2 2.5G SFP, 48VDC
redundant power supply, 240W PoE power
consumption)
Model IV. IES6300-8GT2GS2HS-P220 (8 Gigabit copper
ports + 2 Gigabit SFP + 2 2.5G SFP, 220VAC/DC
AC power supply)
Model V. IES6300-8GT2HS-2P48 (8 Gigabit copper ports + 2
2.5G SFP, 12~48VDC redundant power supply)
Model VI. IES6300-8GP2HS-2P24-120W (8 Gigabit PoE
copper ports + 2 Gigabit SFP + 2 2.5G SFP, 24VDC
redundant power supply, 120W PoE power
consumption)
Model VII. IES6300-8GP2HS-2P48-240W (8 Gigabit PoE
copper ports + 2 2.5G SFP, 48VDC redundant
power supply, 240W PoE power consumption)
Model VIII. IES6300-8GT2HS-P220 (8 Gigabit copper ports +
2 2.5G SFP, 220VAC/DC AC power supply)
Model IX. IES6300-8GT2GS2HS-2DI2DO-2P48 (8 Gigabit
copper ports +2 Gigabit SFP + 2 2.5G SFP + 2DI +
2DO, 12~48VDC redundant power supply)
Model X. IES6300-8GP2GS2HS-2DI2DO-2P48-240W (8
Gigabit PoE copper ports + 2 Gigabit SFP + 2 2.5G
SFP + 2DI + 2DO, 48VDC redundant power supply,
240W PoE power consumption)
【Panel Design】
Top view, bottom view and rear view
Model I-III, Model V-VII, Model IX-X
Model IV, Model VIII
Front view
Model I Model II, Model III

Model IV Model V
Model VI, Model VII Model VIII
Model IX Model X
1. Terminal blocks for Power Supply P1/P2 Input
2. Terminal blocks for Power Supply L/N Input
3. Terminal blocks for relay alarm output RELAY
4. DIP switch
5. Console port
6. Grounding screw
7. DIN-Rail mounting kit
8. Power indicator
9. Running indicator (RUN)
10. Alarm indicator (ALM)
11. PoE indicator (G1-G8)
12. Ethernet port indicator (G1-G12)
13. 10/100/1000Base-T(X) copper port (G1-G8)
14. 10/100/1000Base-T(X) Gigabit PoE copper port (G1-G8)
15. I/O input and output interfaces (DI1-DI2, DO1-DO2)
16. I/O output indicator (DO1-DO2)
17. I/O input indicator (DI1-DI2)
18. 100/1000Base-X SFP slot (G11-G12)
19. 100/1000/2.5GBase-X, SFP slot(G9-G10)
20. Wall-mounting location hole
【Mounting Dimension】
Unit: mm
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【DIN-Rail Mounting】
The product adopts 35mm standard DIN-Rail mounting which
is suitable for most industrial scenes, mounting steps as
follows:
Check if the DIN-Rail mounting kit is installed firmly.
Insert the bottom of DIN-Rail mounting kit (one side
with spring support) into DIN-Rail, and then insert the
top into DIN-Rail.
Tips:
Insert a little to the bottom, lift upward and then insert to
the top.
Check and confirm the product is firmly installed on
DIN-Rail, then mounting ends.
【Disassembling DIN-Rail】
Power off the device.
After lifting the device upward slightly, first shift out
the top of DIN-Rail mounting kit, and then shift out the
bottom of DIN-Rail, disassembling ends.
Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
then plug the power supply plug contact and power on.
Power OFF operation: First, remove the power plug, then
remove the wiring section of terminal block. Please pay
attention to the above operation sequence.
【DC Power Supply Connection】
The DC device of the series provides 6-
pin 5.08mm pitch power supply terminal
blocks and power supply occupies the left
4 pins. It supports two independent DC
power supply systems, P1 and P2. The
series of device supports redundant

power supply, two power supply can work at the same time.
The device will still run non-stop when one power supply fails.
The pin definitions of power supply are shown in the left figure.
This series supports 3 different power supply ranges. Please
notice the corresponding power supply type of the device in
case it damages the device.
12~48VDC redundant power supply
The power supplies of Model I, Model V and Model IX support
non-polarity connection, and the device can still work normally
after reverse connection. The definitions of power pin are
shown in the figure above, and the power input range is
12~48VDC.
24VDC redundant power supply
The power supplies of Model II and Model VI support anti-
reverse connection, which cannot power the device but won’t
damage it. The definitions of power pin are shown in the figure
above, and the power input is 24VDC.
48VDC redundant power supply
The power supplies of Model III, Model VII and Model X
support anti-reverse connection, which can cannot power the
device but won’t damage it. The definitions of power pin are
shown in the figure above, and the power input is 48VDC.
【AC Power Supply Connection】
This AC device provides 6-pin
5.08mm pitch terminal blocks,
power supply occupies the left 4
pins. The pin definitions of power supply are shown in the left
figure.
【Relay Connection】
This device provides 6-pin 5.08mm
pitch terminal blocks, relay occupies
the right 2 pins. Relay terminals are
a set of normally open contacts of the device alarm relay. They
are open circuit in the state of normal non alarm, closed when
any alarm information occurs. For example, they are closed
when powered off, and send out alarm. The product supports
1 relay alarm information output that can output DC power
supply alarm information or network abnormality alarm. It can
be connected to alarm light or alarm buzzer or other switching
value collecting devices, which can timely inform operators
when the alarm occurs.
【DIP Switch Settings】
The series of devices provide 4-bits DIP switch for
function setting, where "ON" is enable valid
terminal.
The definitions of DIP switch are as follows:
No
Definition
Operation
1 Restore Factory
Settings
Set the DIP switch to ON, the
device will root automatically
and restore to factory settings,
then turn off the DIP switch.
2-4
Reserved
—
【I/O Port Connection】
Model IX and Model X provide 8-pin
3.81mm pitch terminal blocks and 2
DI and 2 DO. This device can detect
and send I/O input status to
management software, operators can set the conditions of
alarm status via management software. When the I/O input
status meets the set alarm conditions, the I/O output alarm
would be triggered. The pin definitions of I/ O port are shown
as follows:
I/O port
PIN
Definition
DI digital signal input
channel 1
DI1+, DI1-
I/O signal
input
DI digital signal input
channel 2
DI2+, DI2-
DO digital signal output
channel 1
DO1+, DO1-
I/O relay
output
DO digital signal output
channel 2
DO2+, DO2-
【Console Port Connection】
The device provides 1 program debugging port
based on RS-232 serial port which can conduct
device CLI command management after
connecting to PC. The interface adopts RJ45 port, the RJ45
pin definition as follows:
Pin No.
2
3
5
Definition
TXD
RXD
GND
【Checking LED Indicator】
The device provides LED indicators to monitor its operating
status, which has simplified the overall troubleshooting
process. The function of each LED is described in the table
below:
LED
Indicate
Description
P1/P2/PWR
ON Power
supply is running
normally
OFF Power supply is disconnected
or running abnormally
ALM
ON Power supply or port link has
alarm
OFF
Power supply and port link
have no alarm
RUN
ON
Device is not started or
abnormal
Blinking
Blinking 1 time per second,
system is running normally
OFF
The device is powered off or
the device is abnormal.
LINK
(G1-G12)
ON Ethernet port has established a
valid network connection
Blinking Ethernet port is in an active
network status
OFF
Ethernet port has not
established valid network
connection
PoE
(G1-G8)
ON POE port is powering other PD
devices normally
OFF
POE is disabled or
disconnected
DI(1-2)
ON
I/O has input information
OFF
I/O has no input information
DO(1-2) ON
I/O has output alarm
information,
and it’s status is
on.

OFF
I/O has no output alarm
information, and it’s status is
off.
【Logging in to WEB Interface】
This series of devices supports WEB management and
configuration, and computers can access devices through
Ethernet interfaces. The way of logging in to device’s
configuration interface via IE browser is shown as below:
Configure the IP addresses of computer and the
device to the same network segment, and the
network between them can be mutually accessed
Enter device’s IP address in the address bar of the
computer browser: https://192.168.1.254
Enter device’s username and password in the login
window as shown below.
Click the “login” button. Change the initial password
when logging into the device for the first time, after
that, relog into the device to access the device's Web
interface.
Note:
The default IP address of the device is “192.168.1.254”.
The default user name and password of the device are
“admin”.
When logging in to the device for the first time, the
system will prompt to change the initial password of the
default user; The length of the new password string must
be greater than or equal to 8 and be composed of two or
more kinds of uppercase letters, lowercase letters,
numbers and special characters.
If the user name or password is lost, the factory settings
can be restored through management software of the
device; or make a physical loopback between Port 1 and
Port 2 within the first minute when the switch restarts.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
Gigabit PoE copper port 10/100/1000Base-T(X), RJ45,
Automatic Flow Control, Full/Half
Duplex Mode, MDI/MDI-X
Autotunning. PoE power supply
pin: V+, V+, V-, V- correspond to
pin 1, 2, 3, 6. The maximum
output power of single port: 30W
Gigabit copper port 10/100/1000Base-
T(X), RJ45,
Automatic Flow Control, Full/Half
Duplex Mode, MDI/MDI-X
Autotunning
Gigabit SFP slot 100/1000Base-X self-
adaption or
forced mode, SFP slot
2.5G SFP slot 100/1000/2.5GBase-X self-
adaption or forced mode, SFP slot
I/O port Support 2 inputs and 2 outputs, 8-
pin 3.81mm pitch terminal blocks,
support dry contact input relay
output
Console port CLI command management port
(RS-232), RJ45
Alarm interface 6-
pin 5.08mm pitch terminal
blocks, alarm occupies the right 2
pins, supports 1 relay alarm
information output, and the current
load
capacity is 1A@30VDC or
0.3A@125VAC
Indicator Running indicator, alarm indicator,
power supply indicator, interface
indicator, PoE indicator, I/O output
indicator, I/O input indicator
Switch Property
Backplane bandwidth
30G
Packet buffer size
4Mbit
MAC Address Table
8K
Power Supply
Access terminal block 6-
pin 5.08mm pitch terminal
blocks, power supply occupies 4
pins
Power input

Model I, V, IX: 12~48VDC,
non-
polarity, redundant
backup, built-
in 3A
overcurrent protection

Model II, VI: 24VDC PoE,
anti-
reverse connection,
redundant backup, built-in 5A
overcurrent protection
Model III, VII, X: 48VDC PoE,
anti-
reverse connection,
redundant backup, built-in 5A
overcurrent protection

Model IV, VIII: 220VAC/DC
Power Consumption
No-load
≤5.76W@48VDC
Full-load ≤ 12W@48VDC (without PoE
load)
≤ 132W@24VDC (with 120W PoE
load)
≤ 252W@48VDC (with 240W PoE
load)
Working Environment
Working temperature
-40~75℃
Storage temperature
-40~85
℃
Working humidity
5%
～
95% (no condensation)
Protection grade
IP40 (metal shell)
