Aaeon PFM-336I User manual

PC/104 Module PFM-336I
PFM-336I
386SX-40
PC/104 CPU Card
With LCD & DiskOnChip®
PFM-336I Manual 1st Ed.
April. 2005

PC/104 CPU Card PFM-336I
i
Copyright Notice
This document is copyrighted, 2005. All rights are reserved.
The original manufacturer reserves the right to make
improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied,
translated, or transmitted in any form or by any means
without the prior written permission of the original
manufacturer. Information provided in this manual is
intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may
result from its use.
The material in this document is for product information
only and is subject to change without notice. While
reasonable efforts have been made in the preparation of
this document to assure its accuracy, AAEON assumes no
liabilities resulting from errors or omissions in this document,
or from the use of the information contained herein.
AAEON reserves the right to make changes in the product
design without notice to its users.

PC/104 CPU Card PFM-336I
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
 ITE is a trademark of Integrated Technology Express, Inc.
 IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 PFM-336I PC/104 CPU Card
• 1 Manual
• 1 Jumper Cap
• 1 8-pin (4 x 2 pin header) for Keyboard & PS/2 mouse
• 1 FDD Cable
• 1 IDE Cable
• 1 SVGA Adapter
• 1 Parallel Port Adapter
• 2 Serial Ports Adapter
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

PC/104 CPU Card PFM-336I
iii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Board Layout.............................................................2-3
2.3 Board Dimension.......................................................2-4
2.4 List of Jumpers..........................................................2-5
2.5 List of Connectors .....................................................2-6
2.6 Setting Jumpers ........................................................2-7
2.7 HDD LED (J1) ...........................................................2-8
2.8 Reset Switch (J2)......................................................2-8
2.9 DiskOnChip (DOC) 2000 Installation (J3).................2-8
2.10 LCD Power Select (J4)............................................2-9
2.11 Clear CMOS (J7).....................................................2-9
2.12 Shift Clock Select (J8).............................................2-9
2.13 RS-232/422/485 COM2 Setting (J5 & J6)...............2-10
2.14 IDE Hard Drive Connector (CN1)............................2-10
2.15 Keyboard Connector (CN2)..................................... 2-11
2.16 Display Connector (CN4 & CN6).............................2-11
2.17 Power Supply Connector (CN5)..............................2-12

PC/104 CPU Card PFM-336I
iv
2.18 Parallel Port (CN8)..................................................2-13
2.19 Serial Port (CN9 & CN11).......................................2-13
2.20 Floppy Drive Connector (CN10)..............................2-14
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 AMI BIOS Setup........................................................3-3
3.3 Standard CMOS Setup .............................................3-5
3.4 Advanced CMOS Setup............................................3-6
3.5 Advanced Chipset Setup...........................................3-7
3.6 PCI/Plug and Play Setup...........................................3-8
3.7 Peripheral Setup........................................................3-9

PC/104 CPU Card PFM-336I
Chapter 1 General Information
1-1
General
Information
Chapter
1

PC/104 CPU Card PFM-336I
Chapter 1 General Information
1
-
2
1.1 Introduction
The PFM-336I comes equipped with an embedded
microcontroller ALi M6117C which is Intel386SX-40
compatible. In addition, it comes with two serial ports
(RS-232), one bi-directional printer port supporting
SPP, ECP and EPP modes, and IDE HDD interface
and a floppy disk controller. With its industrial grade
reliability, the PFM-336I can operate continuously at
temperature up to 140°F (60°C).
The PFM-336I is specially designed as a compact
all-in-one CPU card which incorporates a PC/104
connector into its design, making non-passive
backplane SBC applications possible. The numerous
features provide an ideal price/performance solution
for high-end commercial and industrial applications
where stability and reliability are essential.
The PFM-336I features an SVGA interface which
supports CRT and Flat Panel (TFT, STN and Mono
displays), with 512KB onboard display memory.

PC/104 CPU Card PFM-336I
Chapter 1 General Information
1
-
3
1.2Features
nOnboard ALi M6117C, Intel386SX-40 compatible CPU
nOnboard 8Mbytes EDO DRAM
nC&T 65545 LCD controller with 512KB display memory

PC/104 CPU Card PFM-336I
Chapter 1 General Information
1
-
4
1.3Specifications
System
lCPU ALi M6117C, Intel80386SX-40 compatible
lChipset ALi M6117C
lIO Chipset ITE-8661
lBIOS AMI 128KB Flash BIOS.
lSystem Memory
Onboard 8MB EDO DRAM
lEnhanced IDE
Interface Supports up to two IDE devices.
lFDD Interface Supports up to two floppy disk drives, 5.25"
(360KB and 1.2MB) and /or 3.5" (720KB,
1.44MB and 2.88MB)
lSerial Ports One RS-232 and one RS-
232.422/485 serial
port. Ports can be configured as COM1,
COM2, COM3, COM4, or disabled
individually (16C550 equivalent)
lParallel port One bi-directional parallel port. Supports
SPP, ECP, and EPP modes.
lKeyboard/ PS2
Mouse
connector
8-pin (4x2, pin header) connector supports
PC/AT keyboard and PS/2 mouse
lWatchdog
Timer Ca
n generate a system reset, IRQ15 or NMI.
Software selectable time-out interval
(30.5us~512sec, 30.5us/step)

PC/104 CPU Card PFM-336I
Chapter 1 General Information
1
-
5
lSSD Support DiskOnChipup to 1GB
lDMA 7 DMA channels (8237 equivalent)
lInterrupt 15 interrupt levels (8259 equivalent)
Display
lChipset C&T 65545
lDisplay Memory 512KB
lDisplay Type Supports non-interlaced CRTand LCD
(TFT, DSTN and Mono).
lResolution Up to 800 x 600 @ 256 colors
Expansion Interface
lPC/104 One 16-bit 104-pin connector onboard
for PC/104 module expansion
Mechanical and Environment
lDimension 3.77”(L) x 3.54”(W)
lWeight 0.61b (0.25kg)
lOperating
Temperature 0~60°C (32~140°F)
lPower Supply
Voltage +5V(4.75V to 5.25V)

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide Part No.2007336I10 April 2005 2 - 1
Quick
Installation
Chapter
2
Guide

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 3
2.2 Board Layout
CN6
J4
J8
CN4
U4
CN8
CN9
BT1
CN1
J3
CN2J1
J2
U3
U8
CN3
CN7
CN5
CN10
CN11
J5
J6
J7
U17

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 4
2.3 Board Dimension

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 5
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
J1 HDD LED
J2 Reset Switch
J3 DOC Address Setting
J4 LCD Power Select
J5 COM2 RS-232/422/485 select
J6 COM2 RS-232/422/485 select for Data In
J7 Clear CMOS
J8 Shift Clock Select

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 6
2.5 List of Connectors
The board has a number of connectors that allow you to configure
your system to suit your application. The table below shows the
function of each of the board's connectors:
Connectors
Label Function
CN1 HDD Connector
CN2 KB/PS2 Connector
CN3 PC/104 Connector
CN4 SVGA Connector
CN5 Power Connector
CN6 LCD Connector
CN7 PC/104 Connector
CN8 Printer Connector
CN9 COM1 Connector
CN10 Floppy Disk Connector
CN11 COM2 Connector

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 7
2.6 Setting Jumpers
You configure your card to match the needs of your
application by setting jumpers. A jumper is the simplest kind
of electric switch. It consists of two metal pins and a small
metal clip (often protected by a plastic cover) that slides over
the pins to connect them. To “close” a jumper you connect
the pins with the clip.
To “open” a jumper you remove the clip. Sometimes a jumper
will have three pins, labeled 1, 2 and 3. In this case you
would connect either pins 1 and 2 or 2 and 3.
123
Open Closed Closed 2-3
A pair of needle-nose pliers may be helpful when working
with jumpers.
If you have any doubts about the best hardware configuration
for your application, contact your local distributor or sales
representative before you make any change.
Generally, you simply need a standard cable to make most
connections.

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 8
2.7 HDD LED (J1)
You can connect a LED to indicate that an IDE device is in use.
J1 Function
1 -R/W IDE (LED Cathode)
2 Pull high (LED Anode)
2.8 Reset Switch (J2)
You can connect an external switch to easily reset your computer.
This switch restarts your computer as if you had turned off the
power then turned it back on.
J2 Function
1 Reset
2 GND
2.9 DiskOnChip (DOC) 2000 Installation (J3)
1-2 3-4 5-6 DOC Address
Off Off On D000
Off On Off D400
Off On On D800
On Off Off DC00
Off Off Off Disable

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 9
2.10 LCD Power Select (J4)
You can use J4 jumper to select the voltage setting for the LCD
power. To select a certain voltage level close the corresponding pin
numbers with a pin cap. Pin 1-2 will provide +5V of power and pin
2-3 will provide +3.3V of power.
J4 Function
2-3 +3.3V
1-2 +5V (Default)
2.11 Clear CMOS (J7)
Warning:
To avoid damaging the computer, always turn off the power supply
before setting “ Clear CMOS.” Before turning on the power supply,
set the jumper back to “Normal.”
J7 Function
1-2 Clear CMOS
2-3 Normal (Default)
2.12 Shift Clock Select (J8)
J8 Function
2-3 Ashclk
1-2 Shclk

PC/104 CPU Card PFM-336I
Chapter 2 Quick Installation Guide 2 - 10
2.13 RS-232/422/485 COM2 Setting (J5 & J6)
J5 J6 Function
1-2, 4-5, 7-8, 10-11 1-2 RS-232 (Default)
2-3, 5-6, 8-9, 11-12 3-4 RS-422
2-3, 5-6, 8-9, 11-12 5-6 RS-485
2.14 IDE Hard Drive Connector (CN1)
Pin Signal Pin Signal
1 Reset 2 GND
3 HD7 4 HD8
5 HD6 6 HD9
7 HD5 8 HD10
9 HD4 10 HD11
11 HD3 12 HD12
13 HD2 14 HD13
15 HD1 16 HD14
17 HD0 18 HD15
19 GND 20 NC
21 NC 22 GND
23 IOW# 24 GND
25 IOR# 26 GND
27 IORDY 28 BALE
29 VCC 30 GND
31 IRQ14 32 -I/O 16
33 SA1 34 NC
35 SA0 36 SA2
37 HDCS0 38 HDCS1
39 -ACT 40 GND
41 VCC 42 VCC
43 GND 44 NC
