Aaeon AOP-8150 User manual

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -1-
AOP-8150
Intel®ULV Celeron®650MHz Processor
Fanless Operator Panel
with 15” TFT LCD

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 2 -
Copyright Notice
This document is copyrighted, 2005. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, nor for any in-
fringements upon the rights of third parties, which may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy, AAEON,
assumes no liabilities resulting from errors or omissions in this document,
or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -3-
Acknowledgments
Award is a trademark of Award Software International, Inc.
VIA is a trademark of VIATechnologies, Inc.
IBM, PC/AT, PS/2 and VGA are trademarks of International Business
Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
ESS is a trademark of ESS Technology, Inc.
UMC is a trademark of United Microelectronics Corporation.
SMI is a trademark of Silicon Motion, Inc.
Creative is a trademark of Creative Technology LTD.
All other product names or trademarks are properties of their respective
owners.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 4 -
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 AOP-8150 series Fanless Operator Panel PC
• 10 Mounting Bracket & Screws
• 1 Power cord (optional)
• 1 Transfer board for CD-ROM (optional)
• 1 CD-ROM for manual (in PDF format) and drivers
If any of these items are missing or damaged, contact your distributor or
sales representative immediately.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -5-
1. Use a 3 V @ 200 mA lithium battery
2. Packing: please carry the unit with both hands, handle
with care
3. Maintenance: to properly maintain and clean the
surfaces, use only approved products or clean with a
dry applicator
4. Do not remove CompactFlash storage card while
reading from or writing into the storage card.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 6 -
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For plug-in equipment, the power outlet must be installed near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping
it or letting it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over voltage.
12. Never pour any liquid into an opening. This may cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, the equipment
should be opened only by qualified service personnel.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -7-
14. If one of the following situations arises, get the equipment checked
by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY DAMAGE
THE EQUIPMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED.REPLACE ONLY WITH THE SAME
OR EQUIVALENT TYPE RECOMMENDED BY THE
MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO
THE MANUFACTURER'S INSTRUCTIONS.
DISCLAIMER: This set of instructions is given according to IEC 704-1.
AAEON disclaims all responsibility for the accuracy of any statements
contained herein.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 8 -
Contents
Copyright Notice...........................................................2
Acknowledgments ........................................................3
Packing List..................................................................4
Safety & Warranty ........................................................6
Chapter 1 General Information............................................9
Introduction.................................................................10
Features.....................................................................11
Specification ...............................................................12
Dimension ..................................................................17
Chapter 2 Hardware Installation........................................18
CD-ROM Installation...................................................19
2.5" Hard Disk Drive Installation.................................23
PCI extension kit Installation.......................................28
Panelmount Installation..............................................33
Digital I/O 8 bit Connector (CN9)................................35
COM2 RS-232/422/485 Selection (JP4 & JP5)..........36
Chapter 3 BIOS Installation...............................................37
System Test and Initialization .....................................38
Award BIOS Setup .....................................................39
Chapter 4 Driver Installation..............................................42
Installation ..................................................................44
FAQ ............................................................................46

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -9-
General
Information
Chapter
1

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 10 -
Introduction
The AOP-8150 panel PC is a Ultra Low Voltage Low power Celeron
processor computer that is designed to serve as a human machine
interface (HMI) and as a multimedia computer. It is a PC-based system
with 15" color TFT LCD display, on-board Ethernet controller, multi-COM
port interfaces and an audio controller. In addition, its "fit anywhere"
design makes it very flexible and able to be used in many different kinds
of installations. It can be wall mounted, panel mounted or stood upright
on a desktop.
For system integrators, this simple, complete, compact and highly
integrated multimedia system let you easily build a panel PC into your
applications. Common industrial applications include factory automation
systems, precision machinery, and production process control. It is also
suitable for many non-industrial applications, including interactive kiosk
systems, entertainment management, and car park automation. Our
panel PC is a reliable, cost-effective solution to your application's
processing requirements.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -11-
Features
• 15” XGA color TFT LCD display
• Touchscreen, Mini PCI and 6-in-1 card reader support
• Slim and Fanless solution: All-in-one SBC with Intel®ULV
Celeron®650MHz CPU onboard
• Windows®CE.NET 4.2 and Windows®XP Embedded support
(optional)
• 10/100Base-T or Giga Ethernet (Optional)

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 12 -
Specification
System
• Display 15” XGA (1024 x 768) color TFT LCD
• CPU Board - Intel®ULV Celeron®650MHz CPU
- Support DDR Memory up to 1GB
• Memory Onboard 256MB, support DDR
Memory
up to 1GB
Mini PCI socket
• Disk Drive space Slim CD-ROM / Combo / DVD
2.5” HDD (Anti-vibration)
• Expansion One 6-in-1 card reader
One Mini PCI slot
One PCI slot (Optional)
• I/O
 Serial Port 5 x RS-232, 1 x RS-232/422/485
4 x USB 2.0 ports
1 x parallel port
1 x VGA port
1 x PS/2 keyboard, 1 x PS/2 mouse
 Audio Mic In, Line in, Line out, S/P DIF Out
(for 5.1 channel audio)
 Ethernet One 10/100Base-T RJ-45 connector

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -13-
One 10/100Base-T or One Giga
RJ-45
connector (Optional)
One DB-15 connector for digital IO
(Support 4 in + 4 out)
• Front Panel Resistive touchscreen
• Other Support Mini PCI Wireless LAN with
Antenna (Optional)
Support Mini PCI Capture card
(Optional)
One PCI expansion kit (Optional)
• Power Supply 75W, AT, AC-in 100/240V
• OS support Windows®2000, Windows®XP, Linux
Red Hat, Windows®CE.NET 4.2 &
Windows®XP Embedded (Optional)
LCD
• Model AOP-8150HT series
• Display Type 15” color TFT LCD
• Max. Resolution 1024 x 768
• Max. Colors 262,144
• Dot Size 0.297mm x 0.297mm
• Luminance 250 cd/m2
• Viewing Angle 150o(H) 145 o (V)

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 14 -
• Back Light MTBF 30,000hrs
Touchscreen
• Type 8-wire, analog resistive
• Light Transmission 75%
• Resolution 2048 x 2048
• Interface RS-232 (COM 4)
• Lifetime 1 million activations
Mechanical
• Construction Plastic chassis (IP65 certified front
panel)
• Front Panel Color PMS 2965C (Dark Blue)
• Mounting Panelmount, VESA 100mm, Desk
Top
Stand (Optional)
• Dimension 16” (W) x 12.2” (H) x 2.6” (D)
(407mm x 310.5mm x 65mm)
• Cutout Size 394 x 297.5 mm
• Gross Weight 6 Kg

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -15-
Note: All AAEON's LCD products are manufactured with High
precision technology. However, in all LCD panels there maybe a
small number of defective pixels that do not change color. This is
a normal occurrence for all LCD displays from all manufacturers
and should not be noticeable or objectionable under normal
operation. AAEON qualify the LCD panel following industry
standard: total 7 dead pixels on a screen or if there are 3 within 1
inch square area of each other on the display.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 16 -
Rear Side
Front Side
10/100 Base-T Ethernet
Connector
CRT D-Sub
Parallel Port
COM 3 COM 2
4 USB 2.0 ports
COM 1
COM 5
COM 6
Digital I/O
Line out/Line in/Mac in

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -17-
Dimension
407.0
310.5
391.0
294.5
65.0
Cutout Size: 394 x 297.5 mm
93.6 407.0
310.5
391.0
294.5
With PCI extension kit

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 18 -
Hardware
Installation
Chapter
2

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual Rev.A 2nd Ed -19-
CD-ROM Installation
1. Disassemble the plastic cover of the monitor.

Fanless Operator Panel AOP-8150
AOP-8150 Series User Manual V1.0 - 20 -
2. Lock the transfer board (the board is at accessory box)
Lock the CD-ROM with the bracket
