Aaeon AHP-1123 User manual

Touch Panel PC AHP - 1123
AHP-1123
Onboard Intel®Atom™D2550
1.86 GHz Processor
Touch Panel PC
With 12.1” TFT LCD
AHP-1123 Manual 2nd Ed.
May 11, 2015

Touch Panel PC AHP - 1123
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i

Touch Panel PC AHP - 1123
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
•AMI is a trademark of American Megatrends Inc.
•Intel®, and Atom™ are trademarks of Intel®Corporation.
•Microsoft Windows®is a registered trademark of Microsoft
Corp.
•IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.
ii

Touch Panel PC AHP - 1123
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
AHP-1123 Touch Panel PC
Mounting brackets and screws
DVD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.
iii

Touch Panel PC AHP - 1123
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from anyAC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
iv

Touch Panel PC AHP - 1123
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) OR ABOVE 60°C (140°F). IT MAY DAMAGE THE
EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.
v

Touch Panel PC AHP - 1123
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。
vi

Touch Panel PC AHP - 1123
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specification.............................................................. 1-4
1.4 Dimension .................................................................1-7
Chapter 2 Hardware Installation
2.1 Panelmount Installation............................................. 2-2
2.2 COM 1/2 RS-232/422/485 Serial Port Connector.....2-3
2.3 Hard Disk Drive Installation....................................... 2-4
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization ................................... 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Introduction................................................................ 4-3
Appendix A Programming The Watchdog Timer
A.1 Programming ........................................................A-2
A.2 ITE8783 Watchdog Timer Initial Program ............A-6
Appendix B I/O Information
B.1 I/O Address Map ..................................................B-2
B.2 1st MB Memory Address Map ...............................B-4
B.3 IRQ Mapping Chart ..............................................B-5
vii

Touch Panel PC AHP - 1123
B.4 DMA Channel Assignments .................................B-6
Appendix C AHCI Setting
C.1 Setting AHCI ....................................................... C-2
viii

Touch Panel PC
AHP-1123
Chapter 1 General Information 1- 1
General
Information
Chapter
1

Touch Panel PC
AHP-1123
Chapter 1 General Information 1- 2
1.1 Introduction
The AHP-1123 operator panel is an Intel®Atom™D2550 1.86 GHz
processor computer that is designed to serve as a human machine
interface (HMI). It is a PC-based system with 12.1" color TFT LCD
display, onboard Ethernet controller, multi-COM port interfaces and
an audio controller. With a built-in CFast™socket, the AHP-1123 is
as compact and user friendly as a multi-function computer. In
addition, its "fit anywhere" design makes it very flexible and able to
be used in many different kinds of installations. It can be Panel/
VESA 100 mounted.
For system integrators, this simple, complete, compact and highly
integrated system let you easily build an operator panel into your
applications. Common industrial applications include factory
automation systems, precision machinery, and production process
control. It is also suitable for many non-industrial applications,
including vending machine, and car park automation. Our operator
panel is a reliable, cost-effective solution to your application's
processing requirements.

Touch Panel PC
AHP-1123
Chapter 1 General Information 1-3
1.2 Features
12.1”500 Nits XGA TFT LED LCD
Onboard Intel®Atom™D2550 1.86GHz
Fanless Operation
IP65-rated Plastic Front Bezel & Metal Back Chassis
Supports Windows®7 32-bit/ Windows®XP Pro 32-bit/
Windows®Embedded Standard 7 32-bit/ Linux

Touch Panel PC
AHP-1123
Chapter 1 General Information 1- 4
1.3 Specification
System
CPU
Onboard Intel®Atom™D2550 1.86 GHz
Processor
System Memory
DDR3 800/1066 SODIMM x 1, up to
4GB (Default is 2 GB)
Ethernet
10/100/1000Base-TX, RJ-45 x 2
LCD / CRT Controller
Integrated in Processor
I/O Port
USB 2.0 x 4
RS-232 x 3
RS-232/422/485 x 1
LAN x 2
VGA x 1
3-pin terminal block for power input
Power button x 1
Storage Disk Drive
2.5”SATA Hard Disk Drive x 1, CFast™
socket x 1
Expansion Slot
MiniCard x 1 (internal)
OS Support
Windows®7 32-bit, Windows®XP Pro
32-bit, Windows®Embedded Standard 7
32-bit, Linux
Mechanical
Construction
IP65-rated plastic front bezel

Touch Panel PC
AHP-1123
Chapter 1 General Information 1-5
Mounting
Panel/ VESA 100
Dimension
12.5"(W) x 9.6"(H) x 2.5"(D) (317mm x
243mm x 63.5mm)
Carton Dimension
16.6"(W) x 15.9"(H) x 7.7"(D) (422mm x
404mm x 196mm)
Net Weight
7.9 lb (3.6 kg)
Gross Weight
10.1 lb (4.6 kg)
Environmental
Operating Temperature
32oF~122oF (0oC~50oC) (w/o airflow)
Storage Temperature
-4oF~158oF (-20oC~70oC)
Operating Humidity
5% to 90%@ 40oC, non-condensing
Vibration
1 g rms/ 5-500Hz/ Operation (HDD)
Shock
20 G peak acceleration (11 msec.
duration)
EMC
CE/FCC Class A
Power Supply
12V DC input
LCD
Display Type
12.1”, XGA TFT LCD
Max. Resolution
1024x768
Max. Colors
262K colors
Luminance (cd/m2)
500 nits
Contrast Ratio
700 :1
Viewing Angle
80o(H),70o(V)

Touch Panel PC
AHP-1123
Chapter 1 General Information 1- 6
Backlight
LED
Backlight MTBF (Hours)
50,000
Touch Screen
Type
5-wire analog resistive
Resolution
2048x2048
Light Transmission
> 80%
Lifetime
35 million activations

Touch Panel PC
AHP-1123
Chapter 1 General Information 1-7
1.4 Dimension

Touch Panel PC
AHP-1123
Chapter 2 Quick Installation Guide 2-1
Hardware
Installation
Chapter
2

Touch Panel PC
AHP-1123
Chapter 2 Quick Installation Guide 2 - 2
2.1 Panelmount Installation
The display panel can be mounted into the wall. You will need the
screws along with the mounting brackets, which be packed in the
accessory box. Follow the steps below:
Before you start to follow the instructions, please place the
display panel into the wall. See the following illustration on the
left.
Step 1:
STEP 1.螺絲套上彈簧固定在Mount
Bracket
STEP 2.Mount Bracket裝在凸型孔內
STEP 3.Mount Bracket往凸型方向前進
STEP 4.上緊螺絲固定在牆上
Place the mounting brackets and plug the screw.
Step 2:
STEP 1.螺絲套上彈簧固定在Mount
Bracket
STEP 2.Mount Bracket裝在凸型孔內
STEP 3.Mount Bracket往凸型方向前進
STEP 4.上緊螺絲固定在牆上
Aim the mounting set at the hole on the monitor.
Step 3:
STEP 1.螺絲套上彈簧固定在Mount
Bracket
STEP 2.Mount Bracket裝在凸型孔內
STEP 3.Mount Bracket往凸型方向前進
STEP 4.上緊螺絲固定在牆上
Move the mounting set to the narrow gauge and fix
it with screws.
Step 4:
STEP 1.螺絲套上彈簧固定在Mount
Bracket
STEP 2.Mount Bracket裝在凸型孔內
STEP 3.Mount Bracket往凸型方向前進
STEP 4.上緊螺絲固定在牆上
You’ve completed the preliminary when the
mounting set is tightened. Next, repeat the steps and tighten all
mounting set around the monitor until the monitor is firmly
mounting on the wall.
STEP 1.螺絲套上彈簧固定在Mount
Bracket
STEP 2.Mount Bracket裝在凸型孔內
STEP 3.Mount Bracket往凸型方向前進
STEP 4.上緊螺絲固定在牆上

Touch Panel PC
AHP-1123
Chapter 2 Quick Installation Guide
2 - 3
2.2 COM1/2/3 RS-232/422/485 Serial Port Connector
COM1/COM3 RS-232 (D-sub 9 male)
Pin
2BSignal
Pin
3BSignal
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
COM2 RS-232/422/485 (D-sub 9 male)
Pin
Signal
Pin
Signal
1
DCD
(422TXD-/485DATA-)
2
RXD (422RXD+)
3
TXD
(422TXD+/485DATA+)
4
DTR (422RXD-)
5
GND
6
DSR
7
RTS
8
CTS
9
RI/+5Volt/+12Volt
1
2
4
5
6
7
8
9
1
2
4
5
6
7
8
9

Touch Panel PC
AHP-1123
Chapter 2 Quick Installation Guide 2 - 4
2.3 Hard Disk Drive Installation
Step 1: Unfasten the screws of the heatsink
Step 2: Get the Bracket of Hard Disk Drive from the package
