AAQ AutoLift AL-182093 User manual

Advance AutoQuip
2 McDonald Crescent | Bassendean WA 6054
Ph: 08 9279 1663 | Fax: [phone] | E: [e-mail] | W: www.aaq.net.au
- READ THE ENTIRE CONTENTS OF THIS MANUAL BEFORE
INSTALLATION AND OPERATION. BY PROCEEDING YOU AGREE THAT
YOU FULLY UNDERSTAND AND COMPREHEND THE FULL CONTENTS
OF THIS MANUAL. FORWARD THIS MANUAL TO ALL OPERATORS.
FAILURE TO OPERATE THIS EQUIPMENT AS DIRECTED MAY CAUSE
INJURY OR DEATH.
Specifications subject to change without notice.
Note: While all due care and attention has been taken in the preparation of this document, Advance AutoQuip shall not be liable for any inaccuracies or omissions
which may occur therein
INSTALLATION MANUAL & OPERATION
INSTRUCTIONS
READ FIRST
DO NOT use the
machine until you read
and understand all the
dangers, warnings and
cautions in this manual.
SINGLE POST HOIST
AutoLift AL-182093
Air / Hydraulic Single Post Vehicle Hoist
1360Kg Maximum Lifting Capacity
Design Registration Approval Number: N/A
Design Code: AS1418.9-1996

5/13
DEFINITION
1. It is a mobile hydraulic hoist, with a column structure, built
and manufactured to allow the operator to work on
wheels or under‐doorsatmen’sheight.Theraiseandrecent
movementare obtainedusingasleighfixedtoachainconnected
toahydraulic cylinder.
2. Hydra‐pneumaticpumpwithfootcontrolreduceddimensionsand
a remarkable ease of handling. Thanks to wheels an
easy displacementisitsmainfeature.
3. Ithasbeenprojectedforasureusethankstoaneasyandefficient
manualblock‐Thesafetypin.
4. Themanualsafetypinpermitsthecolumncarriagetobeblocked
duringtheworkingoperation.
5. Air‐hydraulicpumpoutputpressure:350bar(Max)
Basic Specification
Description Capacity Lifting Height Overall Height Overall Width Overall Length
AIR /
HYDRAULIC
CAR HOIST
1360Kg2”- 29/2”
50—750mm
52”
1320mm
28 1/8”
714mm
39 3/16”
995mm
Temperature:-10~40 degree
Net Weight: 127.5KGS
Gross Weight：135KGS
Packing Size:111×73×30cm
Fig.1

6/13
TECHNICAL DESCRIPTION
The hoist consists of:
1.
The Column - The basic part of the system consists of a specially
shaped column of folded metal sheet into which the lifting carriage
and cylinder are placed.
2. The Base - The base is D-shaped with fixed wheels at two of its ends
and another two swivel ones at the opposite ends. This ensures
stability and mobility.
2. Lifting Carriage - The carriage consists of a U-shaped structure, with
two axles containing each a wheel with dry bushings, which carry
the weight to hoist, a cover with a hole for the spindle, and a vertical
hook at the front for holding the different attachments.
3. Air-hydraulic foot pump – Behind the column, there is the
air-hydraulic foot pump. It supply the power to the cylinder for
lifting up the weight. It is controlled by the operator’s foot with
great convenience.
Fig. 2
INSTALLATION
STEP 1 Casters
Bolt the swivel casters on the rear of the basement. (Fig 3).
STEP 2 Column
Bolt the handle on the column then bolt the column on the basement (Fig.4).
STEP 3 Pump and hose
Put on the air-hydraulic foot pump. Connect the hose from pump to cylinder
(Fig. 5).
STEP 4 Wheel fork
Put on the wheel fork (Fig. 6) and the carriage lock bar.

7/13
Fig. 3
Fig.5 Fig.4
Fig.6
Now the hoist is ready for use.

8/13
SAFTY INSTRUCTIONS AND WARNINGS:
1: DO NOT exceed the rated capacity:1360Kg.
2: DO NOT stand under the work place when the hoist is working.
3: This hoist is mainly for lifting. Operator only can work with the
support of jack stand. Also make sure the surround situation is
safe.
4: After lifting, operator only can start work by locking the
carriage with safety lock-bar.
OPERATING INSTRUCTIONS
1. Ensure that the vehicle’s rigidity is adequate for lifting.
2. Move the hoist with the handlebar.
3. Put the wheel fork under desired position, i.e. at the front or rear wheel of
the vehicle you want to lift.(Fig.7)
4. Connect the compressed air hose to air-hydraulic foot pump.
Fig.7 Fig.8
5. Before lifting the vehicle, make sure the engine is turned off. Check for
clearance around vehicle. Loosen the handbrake and put the
transmission in neutral.
6. Press down the foot lever to lift up the wheel to desired height of the vehicle
is reached (Fig. 8)
7. Lock the carriage by putting the safety bar into the column then release the
lever.(Fig. 8)
8. To lower down the vehicle, first press down the foot lever again to lift up the
carriage a little. Take out the safety bar. Then release the lever. The vehicle
will lower down by its gravity.
9. In case you want to lift the vehicle by the body frame instead of by a wheel,

9/13
you will have to replace the holding device.
To do this, follow the next steps:
a. Lift up the far end of the wheel fork, then take it out from the groove on
the carriage.
b. Insert the frame adaptor into the groove (Fig. 9).
Fig.9 Fig.10
10.While using the frame adapter to lift up the vehicle, remember to position
the adapter on the gravity center line of the vehicle. That is to lift up the
whole side of the vehicle.(Fig.10)
Suggestion:
a. The position on the frame near under the vehicle’s side-view mirror is a
good place for the adapter..
b. Remember that the holding place has to be a strongest area of the
frame with stability. Never to be in the center of the vehicle or at the
back.

10/13
PARTS DRAWING

11/13

12/13

PARTS CODE LIST
ITEM CODE DESCRIPTION QTY NOTE
1 ES04-00010-000 Handle sleeve 3
2 5206-00016-000 Hex nylon locknut 3
3 5302-00016-000 Flat washer 2 φ16
4 SL01-05000-000 column cover 1
5 SL01-01000-000 Column 1
6 5302-00006-000 Flat washer 18 φ6
7 5104-06012-000 Hex bolt 8 M6*12
8 SL01-00002-000 block wheel 2
9 SL01-00001-000 long bolt 2
10 SL01-00022-000 Bush 1
11 SL01-00007-000 Hex bolt 1 M16*195
12 SL01-00014-000 Oil pipe 1
13 SL01-00015-000 Extension connector 1
14 QY030S-00 Air-Hydraulic Foot Pump 1
15 SL01-00008-000 lock bar 1
16 SJ01-00033-000 βpin 1
17 5202-00016-000 Hex nut 2 M16
18 SL01-02000-000 Chain basement 1
19 SL01-00020-000 Protective brush 2
20 5110-06008-000 Cross recess head screw 16 M6*8
21 5304-00025-000 Circlip for shaft 2 φ25
22 SL01-00006-000 Wheel axle 1
23 SL01-12002-000 Oil less bearing 1
24 SL01-12001-000 roller 1
25 5109-06010-000 socket screws with flat point 1 M6*10
26 SL01-00004-000 Roller seat 1
27 SL01-00017-000 Protective housing 1
28 SL01-11001-000 Roller(Ⅲ） 2
29 SL01-11002-000 Oil less bearing 2
30 5304-00020-000 Circlip for shaft 8 φ20
31 5104-12040-000 Hex bolt 6 M12*40
32 5306-00012-000 Spring washer 6 φ12
33 5302-00012-000 Flat washer 6 φ12
34 5102-08020-000 Hex bolt 8 M8*20
35 5302-00008-000 Flat washer 16 φ8
36 SL01-00012-000 swivel Caster 2
37 5206‐00008‐000Hex nylon locknut 8 M8
38 5304‐00016‐000Circlip for shaft 4 φ16
39 SL01‐00011‐000Wheel axle 2

13/13
ITEM CODE DESCRIPTION QTY NOTE
40 SL01‐00010‐000Wheel 2
41 SL01-04000-000 basement 1
42 5105-06020-000 socket head cap screw 4 M6*20
43 SL01-00013-000 Sliding block 2
44 SL01-00003-000 Chain 1
45 SJ13-00030-000 βpin 2
46 SL01-00016-000 chain shaft 2
47 SL01-09001-000 Roller(Ⅰ） 2
48 SL01-10001-000 Roller(Ⅱ） 2
49 5302-00020-000 flat washer 4 φ20
50 SL01-03000-000 carriage body 1
51 SL01-00005-000 Oil connector 1
52 5903-00014-000 Combined Washer 1
53 JP17-04005-000 Throttle valve 1
54 QY02-02101-000 Spring 1
55 JP17-04004-000 Liner 1
56 SL01-07000-000 cylinder 1
56-1 SL01-07004-000 Guide circle 1
56-2 SL01-07002-000 Guide ring 2
56-3 SL01-07100-000 cylinder body 1
56-4 SL01-07003-000 Piston rod 1
56-5 5901-00335-000 O-ring 1
φ33.5*φ3.55
56-6 SL01-07001-000 Piston 1
56-7 5901-00300-000 seal 1
φ40*φ30*65
57 SL01-00019-000 Shaft 1
58 SL01-06000-000 wheel fork 1
59 SL01-08000-000 frame adapter 1
60 SL01‐13000‐000handle1
61 SL01‐00023‐000board1
63 SL01‐14000‐FJ2option2#1
63-1 SL01‐14100‐FJ2frame(3) 1
63-2 5105‐08016‐000socketscrew4
63-3 SL01‐14001‐FJ2rubberpad1
64 SL01‐16000‐FJ3option(3#)1
66 SL01‐09002‐000bearing4

Advance AutoQuip
2 McDonald Crescent | Bassendean WA 6054
Ph: 08 9279 1663 | Fax: [phone] | E: [email protected] | W: www.aaq.net.au
ADVANCE AUTOQUIP WARRANTY
GENERAL WARRANTY INFORMATION:
ADVANCE AUTOQUIP’S OBLIGATION UNDER THIS WARRANTY IS LIMITED TO REPAIRING OR
REPLACING ANY PART OR PARTS RETURNED TO THIS FACTORY, TRANSPORTATION CHARGES
PREPAID, WHICH PROVE UPON INSPECTION TO BE DEFECTIVE AND WHICH HAVE NOT BEEN
MISUSED. DAMAGE OR FAILURE TO ANY PART DUE TO FREIGHT DAMAGE OR LACK OF
MAINTENANCE IS NOT COVERED UNDER THIS WARRANTY. ADVANCE AUTOQUIP RESERVES THE
RIGHT TO DECLINE RESPONSIBILITY WHEN REPAIRS HAVE BEEN MADE OR ATTEMPTED BY OTHERS,
OR WHERE NON GENUINE PARTS HAVE BEEN USED. THIS WARRANTY DOES NOT COVER
DOWNTIME EXPENSES INCURRED WHEN UNIT IS IN REPAIR. ADVANCE AUTOQUIP ARE NOT LIABLE
FOR POSSIBLE ISSUES, DAMAGES, ACCIDENTS ETC RESULTING FROM FAILURE TO FOLLOW THE
OPERATION OR INSTALLATION INSTUCTIONS CONTAINED IN THE MANUAL OR ON THE EQUIPMENT.
THE MODEL NAME AND SERIAL NUMBER OF THE EQUIPMENT MUST BE PROVIDED WITH ALL
WARRANTY CLAIMS. THIS WARRANTY STATEMENT CONTAINS THE ENTIRE AGREEMENT BETWEEN
ADVANCE AUTOQUIP AND THE PURCHASER UNLESS OTHERWISE SPECIFICALLY EXPRESSED IN
WRITING. THIS NON-TRANSFERABLE WARRANTY APPLIES TO THE ORIGINAL PURCHASER ONLY. THIS
WARRANTY IS APPLICABLE TO UNITS LOCATED ONLY IN AUSTRALIA. CONTACT ADVANCE
AUTOQUIP FOR SPECIFIC WARRANTY PROVISIONS FOR UNITS LOCATED OUTSIDE OF THESE
COUNTRIES.
NOTE: THE EQUIPMENT IS NOT TO BE USED FOR WASH DOWN PURPOSES OR TO BE INSTALLED IN AN
OUTDOOR ENVIRONMENT WHERE IT IS SUBJECT TO WEATHER OR WATER DAMAGE. WARRANTY
WILL BE IMMEDIATELY VOID.
STRUCTURAL COMPONENTS:
ALL STRUCTURAL AND MECHANICAL COMPONENTS OF THIS UNIT ARE GUARANTEED FOR A
PERIOD OF FIVE YEARS, FROM THE DATE OF INVOICE, AGAINST DEFECTS IN WORKMANSHIP
AND/OR MATERIALS
WHEN LIFT IS INSTALLED AND USED ACCORDING TO RECOMMENDATIONS.
POWER UNIT:
POWER UNIT COMPONENTS (PUMP AND RESERVOIR) ARE GUARANTEED A PERIOD OF ONE YEAR,
FROM THE DATE OF INVOICE, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN
THE LIFT IS INSTALLED AND USED ACCORDING TO RECOMMENDATIONS.
ELECTRICAL COMPONENTS:
ALL ELECTRICAL COMPONENTS (INCLUDING MOTOR) ARE GUARANTEED A PERIOD OF ONE YEAR
FOR PARTS ONLY (EXCLUDING LABOR), FROM THE DATE OF INVOICE, AGAINST DEFECTS IN
WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS INSTALLED AND USED ACCORDING TO
RECOMMENDATIONS.
PNEUMATIC (AIR) COMPONENTS:
ALL PNEUMATIC (AIR) COMPONENTS (I.E. AIR CYLINDERS AND POPPET AIR VALVES) ARE
GUARANTEED FOR ONE YEAR FOR PARTS ONLY (EXCLUDING LABOR), FROM THE DATE OF
INVOICE, AGAINST DEFECTS IN WORKMANSHIP AND/OR MATERIALS WHEN THE LIFT IS INSTALLED
AND USED ACCORDING TO RECOMMENDATIONS.
EXCLUSIONS:
WARRANTY DOES NOT INCLUDE CONSUMABLE ITEMS SUCH AS HYDRAULIC OIL, LIFTING PADS, OIL
SEALS, VEE BELTS AND SLIDING BLOCKS.
THIS WARRANTY SUPERSEDES ALL OTHER WARRANTY POLICIES PREVIOUSLY STATED AND IN ALL OTHER ADVANCE AUTOQUIP’s
PRODUCT SPECIFIC LITERATURE.

This Safety Operating Procedure does not necessarily cover all possible hazards associated with the machine and should be used in conjunction with
other references. It is designed to be used as an adjunct to the operation in the safety procedures and to act as a reminder to the operatior prior to
machine use.
SAFETY OPERATING PROCEDURES
Vehicle Hoist
DO NOT use this machine unless the operator has been
thoroughly instructed in its safe use and operation.
Safety glasses must be worn at all
times in work areas. Long and loose hair must be contained.
Sturdy footwear must be worn at all
times in work areas. Close fitting/protective clothing must be worn.
Rings and jewellery must not be
worn. Do not stand on hoist whilst hoist is in operation.
A vehicle hoist must not be operated unless it has a current certificate of inspection.
PRE-OPERATIONAL SAFETY CHECKS
1. Ensure that vehicle hoist has operating and maintenance instructions permanently located
and clearly visible.
2. The equipment must be used in accordance with manufacturer’s instructions.
3. Check the capacity of the hoist compared to the weight of the vehicle. If vehicle is too
heavy, do not proceed.
4. Ensure the area is clean and clear of grease, oil, and objects that may be a slip/trip hazard.
5. Familiarise yourself with and check all machine operations and controls.
6. Check all safety devices are in good condition.
7. Ensure support arms are capable of being locked in position.
8. Ensure rubber pads are in good condition on all load points.
9. Faulty equipment must not be used. Immediately report suspect equipment.
OPERATIONAL SAFETY CHECKS
1. Centre vehicle on hoist, ensuring that the weight is evenly distributed to the front and rear.
2. Identify the correct jacking points.
3. Only one person shall operate the hoist at a time.
4. Ensure hoist area is clear of people and equipment before operating.
5. Never leave the hoist running unattended.
6. Check vehicle stability by looking at the jacking points.
7. Engage and check for the correct engagement of the locks.
8. At the completion of work lower the vehicle hoist and ensure all equipment is left in a safe
position.
HOUSEKEEPING
1. Switch off equipment.
2. Leave the equipment and work area in a safe, clean and tidy state.
POTENTIAL HAZARDS
Falling objects Trapping hazards Crushing hazards Entanglement hazards

COMMISSIONINGREPORT
1. DetailsofCustomer
CustomerName:
InstallationAddress:
2. HoistDetails
ModelNo:
HoistType:
InstallationDate:
3. CommissioningReport Yes No N/A Comments
SafetydevicesincorporatedintothedesignofthevehicletoAS/NZS1418.9
VisualcheckallweldscompletedandcomplytorequirementofAS/NZS1554
Visualcheckcarriedoutforleaks
Visualcheckcarriedoutforleaks
Safetylockstestedforcorrectoperation
Checkedforgoodworkingorder
Suppliedwiththehoistandingoodworkingorder
Checkedforcorrectoperation
Hoistcheckedwithloadforcorrectoperationandspeedcontroltested
Checkedwireropesforcorrectinstallationandtension
Concretefloorisasuitabledepthforinstallation
SafetyDevices
Welds
HydraulicEquipmentandControls
PneumaticEquipmentandControls
SafetyLocks
SupportPads
WheelStops
HoistMotionLimits
LoadTestandSpeedCheck
WireRopes
ConcreteFloor
2McDonald Crescent
BassendeanWA6054
P:0892791663|E:[email protected]
1

COMMISSIONINGREPORT
Vehiclehoistoranypartoftheloadispositionednolessthan600mmawayfromany
fixedstructure
Provisionshavebeenmadeforeffectiveclearancesabovethevehiclewhenthehoistis
initsfull
y
raised
p
osition.
Make&ModelNumber
Serialnumber
RatedCapacity
Referencetomaintenance
Operationinstructions
ScrewandNutGaps
Hoistcomplianceplateshowingdesignregistration
Vehiclehoisthasbeentestedandallsafetydevices,limitswitchesandcontrolfunction
interlockshavebeentestedforcorrecto
p
eration.
Theinstallerhasdemonstratedtheoperationofthevehiclehoisttotheowneror
o
p
erator
Lockoffisolatingswitchinstalled
Emergencystopbuttoninstalled
3. DetailsofElectricalContractor
TradingName:
Address:
4. Signature
I,
b
eingt
h
epersonresponsi
bl
e
f
orcomp
l
etingt
h
ecommissioningreport
h
aveexercise
d

reasonableskillandcompetencywhencompletingthereportandherbycertifythatthevehicle
hoisthasbeencommissionedfitforuseaspertheAustralian/NewZealandStandard1418.9:1996
VehicleHoists.
Name:
Date:___________________________________________________________
LocationofVehicleHoist&VehicleClearances
Markings‐HoistCheckedforRelevantMarkingIncluding:
FunctionalTest
Demonstration
ElectricalEquipmentandControls
ECLicenceNumber:
TelephoneNumber:
2
