ABB Galaxy Millennium J2011002 User manual

Page 1
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
PRODUCT MANUAL
Galaxy Millennium® SC Controller
J2011002
Product Manual
Ordering code: 850015641

Page 2
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Notice:
The information, specifications, and procedures in this manual are subject to change without notice.
ABB assumes no responsibility for any errors that may appear in this document.
© 2012 abbpowerconversion.com
All International Rights Reserved
Printed in U.S.A.

Page 3
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
List of Contents
List of Figures.........................................................................................................................................5
List of Tables ..........................................................................................................................................7
Introduction............................................................................................................................................10
Product Description...............................................................................................................................12
Overview.........................................................................................................................................................12
Feature Summary..........................................................................................................................................15
Standard System Features ................................................................................................................15
Front Panel User Interface.................................................................................................................16
Local Serial Access..............................................................................................................................17
Remote Access ....................................................................................................................................17
Battery Management .........................................................................................................................18
Integrated Monitoring Inputs...........................................................................................................19
Integrated Outputs.............................................................................................................................19
Hardware........................................................................................................................................................20
Chassis............................................................................................................................................................20
Controller Cards ..................................................................................................................................21
Supporting Documents ...............................................................................................................................25
Front Panel .....................................................................................................................................................26
Default Display ....................................................................................................................................26
LCD ........................................................................................................................................................27
LEDs ......................................................................................................................................................27
Push-Button Keys................................................................................................................................28
Test Jacks.............................................................................................................................................28
Serial (PC) Port ....................................................................................................................................28
Alarm Buzzer........................................................................................................................................29
Contrast Adjust ...................................................................................................................................29
Display Menus................................................................................................................................................30
Configuration Menus..........................................................................................................................30
Control and Operations Menus ........................................................................................................32
History Menus .....................................................................................................................................33
Statistics Menus..................................................................................................................................33
Status Menus.......................................................................................................................................34
Installation..............................................................................................................................................36
Preparation ....................................................................................................................................................36
Safety and Precautions......................................................................................................................36
Installation Materials..........................................................................................................................36
Plan Rectifier Interface Cards First ID Settings .............................................................................36
Plan Wiring Transfer from Existing Controller ...............................................................................39
Prepare Galaxy SC Configuration File for MSC Use.......................................................................40
Record Customer Specified Minimum Configuration ..................................................................40
Remove Existing Controller.........................................................................................................................41
Galaxy SC Controller Removal...........................................................................................................42
MCS Controller Removal ....................................................................................................................60
Other Controller Removal ..................................................................................................................68

Page 4
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Install Controller ........................................................................................................................................... 75
Mount the MSC ................................................................................................................................... 75
Remove Controller Fuses................................................................................................................... 76
Install Circuit Cards............................................................................................................................ 77
Install Cabling...................................................................................................................................... 81
Remote Peripheral Monitoring (RPM) ............................................................................................. 92
Power-Up the Controller.................................................................................................................... 94
Configure Settings............................................................................................................................. 94
Install Parallel Rectifiers Regulation Fuses..................................................................................... 112
Acceptance Test............................................................................................................................................ 113
Introduction......................................................................................................................................... 113
Tools and Test Equipment ................................................................................................................ 113
Test Precautions ................................................................................................................................. 113
Test Sequences................................................................................................................................... 114
Troubleshooting .................................................................................................................................... 121
Controller Circuit card ................................................................................................................................. 121
Modem ........................................................................................................................................................... 121
Controller Alarm Descriptions.................................................................................................................... 122
Clear Events................................................................................................................................................... 127
Uninstall Devices .......................................................................................................................................... 127
Specifications ........................................................................................................................................ 128
General ........................................................................................................................................................... 128
Alarm and Control Signals........................................................................................................................... 131
Fuse Alarm Major (FAJ) - BSL-63 ...................................................................................................... 134
Fuse Alarm Minor (FAN) - BSL-65 ..................................................................................................... 134
Open String Alarm (OS) - BSL-72...................................................................................................... 135
Aux Major (AMJ) - BSL-64 .................................................................................................................. 135
Aux Minor (AMN) - BSL-66................................................................................................................. 135
Low Voltage Disconnect Active (LVD1) - BSL-84............................................................................ 135
Low Voltage Disconnect Active (LVD2/LVD2R) - BSL-61/62........................................................ 135
External Boost Option (TFLT/TBST/PBT) - BSL-67-69.................................................................. 135
Rectifier Hold OFF on Engine Option (RO/ROR) - BSL-77-78 ...................................................... 135
Rectifier External Sequence Option (TR1-TR4) - BSL-73/79/85/80........................................... 136
Auxiliary Port - TB1 ....................................................................................................................................... 136
Rectifier Interface......................................................................................................................................... 137
Features Reference................................................................................................................................ 139
Shunt Type..................................................................................................................................................... 139
Threshold Alarms.......................................................................................................................................... 140
Battery Temperature Measurement.......................................................................................................... 141
Load Share..................................................................................................................................................... 141
Mixed Load Share Mode .................................................................................................................... 142
Serial Load Share Mode..................................................................................................................... 143
None Load Share Mode...................................................................................................................... 143
Configuring Load Share Mode ......................................................................................................... 143
Network Access - LAN (Gateway)............................................................................................................... 143
Slope Thermal Compensation.................................................................................................................... 145
Battery Recharge Current Limit................................................................................................................. 145

Page 5
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
External Voltage Input (EXT-V) .................................................................................................................. 146
Backup and Restore Configuration........................................................................................................... 147
T1.317 Objects and Attributes .............................................................................................................. 150
User Defined Object Build example ................................................................................................ 179
Factory Defaults .................................................................................................................................... 181
Network Settings ......................................................................................................................................... 181
DIP Switch Settings...................................................................................................................................... 181
Voltage Threshold Ranges and Default Values........................................................................................ 183
Controller Alarm Severity, LED and Relay Default Values....................................................................... 184
Spare and Replacement Parts............................................................................................................... 186
Alarm and Control Signals Cross Reference ........................................................................................ 188
Safety ..................................................................................................................................................... 199
Safety Statements ....................................................................................................................................... 199
Warning Statements and Safety Symbols................................................................................................ 200
Precautions ................................................................................................................................................... 201
Contacts and Warranty ......................................................................................................................... 203
Customer Service Contacts........................................................................................................................ 203
Product Warranty ......................................................................................................................................... 203
Revision History..................................................................................................................................... 205
List of Figures
Figure 1 MSC Chassis ........................................................................................................................................11
Figure 2 MSC Controller Front.........................................................................................................................12
Figure 3 Controller Arrangements..................................................................................................................13
Figure 4 BJC Card Slots ....................................................................................................................................14
Figure 5 Front Panel ..........................................................................................................................................16
Figure 6 Controller Dimensions ......................................................................................................................20
Figure 7 Card Locations....................................................................................................................................21
Figure 8 MCR1B/2B Circuit Card .....................................................................................................................22
Figure 9 MSCB_FB Fuse Card ..........................................................................................................................22
Figure 10 Backplane ..........................................................................................................................................23
Figure 11 Modem BSM6 ....................................................................................................................................23
Figure 12 Alarm Termination Card BSL3_MSC..............................................................................................24
Figure 13 Rectifier Interface Card...................................................................................................................24
Figure 14 Remote Interface Module (RIM).....................................................................................................25
Figure 15 Default Display..................................................................................................................................26
Figure 16 Front Panel ........................................................................................................................................27
Figure 17 Configuration Menus 1 of 2.............................................................................................................30
Figure 18 Configuration Menus 2 of 2 ............................................................................................................31
Figure 19 Control and Operations Menus .....................................................................................................32
Figure 20 History Menus ..................................................................................................................................33
Figure 21 Statistics Menus...............................................................................................................................33
Figure 22 Status Menus 1 of 2..........................................................................................................................34
Figure 23 Status Menus 2 of 2 .........................................................................................................................35

Page 6
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Figure 24 RIC ID Setting ................................................................................................................................. 37
Figure 25 Galaxy SC Controller - Front......................................................................................................... 42
Figure 26 Galaxy SC Controller - Rear........................................................................................................... 42
Figure 27 LVLD Contactor EBV Card SW300 ............................................................................................... 47
Figure 28 LVBD Contactor Control BJN Card SW300 ................................................................................ 48
Figure 29 Galaxy SC Rectifier Fuses ............................................................................................................. 55
Figure 30 Galaxy SC TB2 and TB3.................................................................................................................. 57
Figure 31 Galaxy SC TB1 Plant Connections................................................................................................ 58
Figure 32 Galaxy SC Controller Fuses........................................................................................................... 58
Figure 33 MCS Alarm Circuit .......................................................................................................................... 60
Figure 34 MCS TB1 Alarm Connections........................................................................................................ 62
Figure 35 MCS Auxiliary Board (CP2)............................................................................................................ 64
Figure 36 MSC .................................................................................................................................................. 75
Figure 37 Fuse Card......................................................................................................................................... 76
Figure 38 Cards Front..................................................................................................................................... 77
Figure 39 Cards Rear....................................................................................................................................... 77
Figure 40 Card Connections.......................................................................................................................... 78
Figure 41 RIC ID Setting.................................................................................................................................. 79
Figure 42 Modem Card Wiring....................................................................................................................... 80
Figure 43 Remote Interface Module (RIM) - Side B.................................................................................... 81
Figure 44 Controller Connections Rear ....................................................................................................... 82
Figure 45 Controller Connections Front...................................................................................................... 82
Figure 46 BSL4_MSC Alarm Terminations................................................................................................... 84
Figure 47 Modem Connections ..................................................................................................................... 88
Figure 48 TB100............................................................................................................................................... 89
Figure 49 Shunt Reference Jumper - J5....................................................................................................... 90
Figure 50 Plant Connections Wire-set - 847411824 ................................................................................... 91
Figure 51 Controller Fuses ............................................................................................................................. 94
Figure 52 Controller Drawer .......................................................................................................................... 99
Figure 53 MSC Controller SW202 .................................................................................................................. 100
Figure 54 Rectifier Regulation Fuses ........................................................................................................... 112
Figure 55 DIP Switches................................................................................................................................... 181

Page 7
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
List of Tables
Table 1 MSC Standard System Features........................................................................................................15
Table 2 Front Panel User Interface .................................................................................................................17
Table 3 Supporting Documents ......................................................................................................................25
Table 4 Push-Button Key Functionality..........................................................................................................28
Table 5 Rectifier Interface Cards First ID Settings ......................................................................................38
Table 6 Galaxy SC Basic Controller (BJA) HVSD DIP Switch Settings .......................................................43
Table 7 Galaxy SC Basic Controller (BJB) DIP Switch Settings...................................................................44
Table 8 Galaxy SC Intelligent Controller (BJH) DIP Switch Settings .........................................................44
Table 9 Galaxy SC Alarm Threshold Settings................................................................................................45
Table 10 Galaxy SC Plant Shunt Settings.......................................................................................................45
Table 11 Galaxy SC Low Voltage Disconnects Settings...............................................................................46
Table 12 Galaxy SC Slope Thermal Compensation Settings.......................................................................46
Table 13 Galaxy SC Rectifier Setpoints ..........................................................................................................47
Table 14 Galaxy SC High Voltage Shutdown Setting -48V..........................................................................49
Table 15 Galaxy SC High Voltage Shutdown Setting -+/-24V ....................................................................51
Table 16 MCS DIP Switch Settings..................................................................................................................64
Table 17 MCS-BD and LV2 Alarm Settings – S1..............................................................................................65
Table 18 MCS High Voltage Shutdown / Float – S2 .....................................................................................66
Table 19 MCS High Voltage Shutdown / Equalize – S3................................................................................67
Table 20 Other Controller DIP Switch Settings ............................................................................................68
Table 21 Other Controller Alarm Threshold Settings...................................................................................69
Table 22 Other Controller Plant Shunt Settings...........................................................................................69
Table 23 Other Controller Low Voltage Disconnect Settings ....................................................................69
Table 24 Other Controller Slope Thermal Compensation Settings ..........................................................70
Table 25 Other Controller Rectifier Float Setpoints ....................................................................................70
Table 26 MSC Interface Reference..................................................................................................................83
Table 27 Thermal Probe Types.........................................................................................................................85
Table 28 P3 Compatible Temperature Probe Cables...................................................................................85
Table 29 ABS Pin Numbers...............................................................................................................................86
Table 30 Minimum Configuration...................................................................................................................106
Table 31 Modem Settings Configuration.......................................................................................................110
Table 32 Network Settings Configuration.....................................................................................................111
Table 33 Controller Alarm Descriptions.........................................................................................................122
Table 34 MSC Specifications - General ..........................................................................................................128
Table 35 Alarm and Control - Signal Names and BSL Pins..........................................................................131
Table 36 Alarm - Descriptions, BLS Pins, and Signal Names......................................................................132
Table 37 Alarm and Control Inputs - Descriptions, BLS Pins, and Signal Names....................................134
Table 38 TR Leads and Associated Rectifiers...............................................................................................136
Table 39 Auxiliary Port - TB1.............................................................................................................................136
Table 40 Rectifier Cables..................................................................................................................................137
Table 41 Commercial Rectifier Wiring (H285-226 G62) ...............................................................................138
Table 42 Threshold Alarms...............................................................................................................................140
Table 43 Battery Temperature Source Priority.............................................................................................141
Table 44 Load Share Modes.............................................................................................................................141
Table 45 External Voltage Input Resistors ....................................................................................................146

Page 8
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Table 46 System Objects and Attributes...................................................................................................... 151
Table 47 DC Distribution Objects and Attributes........................................................................................ 153
Table 48 AC Distribution Objects and Attributes........................................................................................ 153
Table 49 Alarm Test Objects and Attributes................................................................................................ 154
Table 50 Plant Objects and Attributes .......................................................................................................... 154
Table 51 Bay Interface Card (BIC) Objects and Attributes ......................................................................... 157
Table 52 Boost Objects and Attributes ......................................................................................................... 157
Table 53 Rectifier Objects and Attributes .................................................................................................... 158
Table 54 Converter Objects and Attributes.................................................................................................. 160
Table 55 Ringer Objects and Attributes........................................................................................................ 161
Table 56 Battery Objects and Attributes ...................................................................................................... 162
Table 57 Disconnect Contactor Objects and Attributes ............................................................................ 164
Table 58 Standard Alarm Objects and Attributes ....................................................................................... 165
Table 59 Single Threshold Alarm Objects and Attributes.......................................................................... 167
Table 60 Dual Threshold Alarm Objects and Attributes............................................................................. 168
Table 61 Events Objects and Attributes........................................................................................................ 169
Table 62 Alarm Input Objects and Attributes............................................................................................... 170
Table 63 Data Switch Objects and Attributes.............................................................................................. 171
Table 64 Remote Peripheral Monitor Objects and Attributes................................................................... 172
Table 65 Distribution Current Objects and Attributes............................................................................... 173
Table 66 Controller Analog Input Objects and Attributes ......................................................................... 174
Table 67 Other Measurement Objects and Attributes ............................................................................... 174
Table 68 Reporting Objects and Attributes ................................................................................................. 175
Table 69 Remote Communication Objects and Attributes........................................................................ 176
Table 70 Configurable Statistics Objects and Attributes.......................................................................... 177
Table 71 TL1 Management Objects and Attributes ..................................................................................... 178
Table 72 System Objects and Attributes ...................................................................................................... 179
Table 73 MSC DIP Switch Settings ................................................................................................................. 182
Table 74 Enhanced Remote Security Features............................................................................................. 182
Table 75 Voltage Threshold Ranges and Default Values ............................................................................ 183
Table 76 Controller Alarm Severity, LED and Relay Default Values........................................................... 184
Table 77 Rectifier Alarm Defaults ................................................................................................................... 186
Table 78 MSC Spare and Replacement Parts................................................................................................ 186
Table 79 Galaxy SC Wiring Plan & Cross Reference ..................................................................................... 189
Table 80 MCS/CCS Wiring Plan & Cross Reference..................................................................................... 192
Table 81 ECS - 12U Wiring Plan & Cross Reference ...................................................................................... 194
Table 82 Wiring Transfer Plan - Other Controller......................................................................................... 195

Page 9
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
This page is intentionally blank.

Page 10
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Introduction
The Galaxy Millennium® SC controller (MSC) brings next generation features of the controller to
plants with legacy rectifiers. It provides integrated control and monitoring of plants with a mixture of
rectifier technologies by interfacing with parallel rectifiers (legacy, non-serial rectifiers) as well as all
Galaxy Protocol (GP) serial rectifiers and converters. It provides control, monitoring, and alarm
monitoring functions over a multi-drop serial interface that interconnects Galaxy Protocol (GP)
rectifiers, GP converters, Bay Interface Cards (BICs), and other serial devices. Galaxy Protocol
communication is via robust RS-485 serial buses. MSC has a plethora of I/O and monitoring options.
It can monitor and control battery plants containing up to 72 GP serial rectifiers, up to 16 serial
converters, up to 32 BICs, and up to 16 parallel rectifiers. A maximum combination of 90 GP nodes can
be directly managed on the rectifier serial bus. MSC performs many functions described more
thoroughly in following sections.
Feature Summary
• Alarm Detection, Identification, and Reporting
• System and Component Status
• System and Feature Configuration
• System Alarm Thresholds
• Battery Management (Slope Thermal Compensation/Recharge Current Limit)
• Battery discharge testing
• Reserve Time Prediction
• Selective high/low voltage shutdown
• Float/Boost Mode Control
• Low Voltage Disconnect Management
• Remote Access Control And Multiple Level Password Security
• Control and Operation
• Plant
• Rectifiers
• Parallel - Legacy ABB and non-ABB Ferro, SCR, and ABB ECS Switch Mode
• Serial GP Protocol - ABB Switch Mode
• History
• Statistics
Abbreviations
• MSC - Galaxy Millennium® SC controller
• SC - Galaxy® SC controller
• M2 - Galaxy Millennium® II controller
• GP - Galaxy Protocol (RS-485)

Page 11
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
This controller directly replaces existing rear access versions of the Galaxy® SC controller (SC),
including its application as replacement for other legacy controllers, e.g. MCS, CCS, etc. The MSC is
easier to use and adds additional functionality to the comprehensive feature set provided by the
existing SC. The separate Independent (Basic), Intelligent, and network interface circuit cards of the
existing SC have been updated and integrated into the standard M2, which is the intelligent core of
the MSC. This eliminates the need to manage multiple cards for features as well as plant voltage.
Standard communications features now include remote 10/100 Base-T network access to display
power system operating status and available information via the world wide web (internet) or your
enterprise network (intranet) using standard browsers.
Upgrading to the MSC is easy. Software features include and expand on those of the SC. Rectifier
interfaces continue to support legacy rectifiers with the same Remote Interface Modules (RIMs) as
the SC. MSC is physically backwards compatible with SC for ease of field upgrade.
Upgrading to the MSC adds newer and more available technologies to the power system. MSC
chassis, Figure 1, replaces the SC chassis.
Figure 1 MSC Chassis

Page 12
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Product Description
Overview
Galaxy Millennium® SC (MSC)
Figure 2 MSC Controller Front
MSC combines the features of the industry
benchmark M2 controller with the parallel
(Ferro / SCR / ECS) rectifier control capability
of Galaxy SC controller.
MSC replaces MCS, CCS, and Galaxy SC
controllers as well as controllers of other
manufacturers.
MSC can control up to 16 parallel (Ferro / SCR /
ECS) rectifiers and up to 72 switch mode
rectifiers.
MSC uses the same rectifier cables as the
Galaxy SC controller.
MSC can be supplied with an onboard M2
controller or utilize an M2 controller mounted in
a GPS plant or in a relay rack.
The front panel provides a backlit LCD display
with an easy-to-use, push-button, and menu-
driven interface.
The panel can be used to operate and program
basic functions and access real-time date,
history, statistics, and measured values.
Controller arrangements are shown in Figure 3.
MSC may be installed in new power systems or in operating power systems currently being managed
by installed controllers. ABB SC, MCS, and CCS controllers and controllers made by others are suitable
for upgrade to MSC.
MSC
(with Onboard M2)
MSC
without M2
Front Panel

Page 13
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Figure 3 Controller Arrangements1
1MSC-M2 = MSC without M2

Page 14
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
MSC Controller With On Board M2
Figure 4 BJC Card Slots
MSC has slots for (2)
BJC Rectifier Interface cards for legacy (parallel)
rectifiers.
BJC card slots
Front View with Onboard M2 Controller

Page 15
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Feature Summary
MSC adds support for parallel rectifiers (legacy, non-serial rectifiers) to the functionality of the M2
controller platform. This controller supports ABB’s most extensive controller feature set.
Standard System Features
Table 1 MSC Standard System Features
Monitoring and control of parallel
rectifiers
• Maximum of 16 parallel rectifiers (legacy, non-serial
rectifiers), ABB or commercial, including ECS SR 364
series
Monitoring and control of up to 90 RS-
485 serial connected GP devices
• Maximum of 2 BJCn_MSC cards (within the
Controller)
• Maximum of 90 serial switch mode rectifiers.
Supported rectifier families:
570, 595, 596, NP, CPS6000, QS, AC, and NE
• Maximum of 32 Bay Interface Cards (BICs)
• Maximum of 72 serial converters
• Maximum of 8 ringers
• Maximum of 6 LVD distribution cards
• Maximum of 8 VIM1s
Alarms
• Standard and custom User Defined system alarms
• Alarm test
• Alarm cut-off
• Multiple-level alarm severity: Critical, Major, Minor,
Warning, and Record-Only
Rectifiers • Automatic rectifier restart
• Reserve engine transfer
• High Voltage Shutdown
• Energy management
• Remote rectifier (on/off) control
• Automatic rectifier sequence control
• N + X redundancy check
• Digital voltage regulation and rectifier load share
Contactor/Disconnect Control • Low Voltage Load
• Low Voltage Battery
Interfaces • Enhanced Front Panel Display
• Local PC Port
• Modem
• LAN (Gateway)
• X.25/TL1

Page 16
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Table 1 MSC Standard System Features
Monitoring and Control • Up to 512 monitoring / relay channels via optional
RPMs
• Up to 18 mid string voltages via optional ES771A, 1-
Wire®, Mid-string Voltage modules - 3 voltages per
module
• Up to 18 battery temperatures via optional 1-Wire®
QS873A modules
• On board external voltage channel
• On board 4-20mA transducer channel
Maintenance Tools • User Programmable Alarms
• History
• Statistics
• Diagnostics
• Derived Channels
• Inventory Management
• Configuration Backup/Restore
Memory • Non-Volatile
• Battery Backed
• Remote and Local Software Upgrade
Front Panel User Interface
Figure 5 Front Panel

Page 17
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Table 2 Front Panel User Interface
LCD • 8-line by 40-character (240 x 64) backlit display with digital
contrast adjust
Menu Driven User Interface • Re-designed user friendly menu driven LCD with similar push-
button membrane switch interface
• Menu structure similar to other ABB controllers
Audible Alarm Buzzer • Integrated on display assembly
• May be Enabled/Disabled
LEDs • 12 individual user configurable status LEDs: Critical, Major,
Minor, Normal, AC System, Battery, Controller, Distribution,
Rectifier, Remote Modules, Modem, and Battery On Discharge
Test Jacks • Used to verify displayed system bus voltage
Local Port2• DB-9 RS-232 system port for local terminal access or event log
printing
• ANSI T1.317 serial access
• EasyView Windows-based software for configuration and
reporting
• Ground referenced
Compatibility • Backwards compatible to existing Galaxy SC
2Connection to the Local Port disables modem communication.
Local Serial Access
Local Port - see Front Panel User Interface section above
Ethernet Port - Browser Interface - standard and custom web pages for browsers (HTTP)
Remote Access
Integrated 10/100Base-T
Ethernet Network capability • Supports TCP/IP Version 5, SNMP Version 2c, SMTP, TL1, DHCP,
Telnet, FTP
• Browser Interface - standard and custom web pages for
browsers (HTTP)
• Compatible with Galaxy Manager®
• Standard shielded RJ-45 interface referenced to chassis
• DHCP Client, Server, and Static addressing modes
Optional Modem3• Remote access via internal BSM6 Modem option (33.6k bps
Modem)
• Remote access capability via external Modem
• Callback security
TL1 • Configurable RS-232/485 port for remote via TL1/X.25
Easy View PC User Interface • Windows-based software, for configuration and reporting
through local terminal or
• Modem connections
Security • Multiple password-protected security levels
• DIP Switches
• Enhanced Security Features enable or disable many controller
features
3Connection to the Local Port disables modem communication.

Page 18
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Battery Management
Slope Thermal Compensation
(STC)
• High temperature compensation
• Low temperature compensation
• Step temperature
• STC Enable/Disable
• Low temperature Enable/Disable
• mV/°C adjustments
Recharge Current Limit • Control recharge rate for batteries
Reserve Time Prediction • Supports a variety of batteries
• Use configurable Low Reserve Time Alarm
• Integrated “At Rate Calculator” for estimation purposes
Battery Discharge Testing • Manual
• Periodic
• Plant Battery Test (PBT) input driven
• Battery Discharge trace data
Float/Boost Mode Control • Manual Timed Boost- Locally T1.317 and remotely initiated
• External Timed Boost
• Battery Thermal Protect module Boost (BTP)
• Auto Boost terminated by time or current
• Manual front panel Boost
Temperature Disconnect • Programmable high temperature
Emergency Power Off • User programmable

Page 19
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Integrated Monitoring Inputs
System • Voltage and Current monitoring
System Shunts • Maximum of 2 (more with BICs and RPMs)
• Battery or Load
• Battery or Return Side
4-20 mA • Single channel Input
External Voltage Input • Single Channel Input
• External resistors for: 5, 30 and 60 Vdc ranges
Temperature Probe • 4 Channels
• 1 – 10/30k Thermal Probe Inputs
• 3 – 10k Thermal Probe Inputs
Binary Inputs • 22 Inputs
• Engine signal inputs
• Battery test inputs
• External Float/Boost control
• 2 User programmable
Remote Peripheral Monitoring • Integrated serial bus
• Maximum 300 meter serial bus
• 512 channels maximum
• Transducer interface
• Battery, Shunt, Voltage, Temperature, and Binary monitoring
• Control Relays
• Channels can be programmed for custom alarms
1-Wire® Monitoring • Integrated serial bus
• 6 ES771 Mid-string Voltage modules maximum
1 voltage per module
• 18 QS873A Temperatures probes maximum
1 temperature per probe
Integrated Outputs
Traditional Office Alarms • 19 Form C alarm outputs
• 2 User programmable relay outputs
Alarm Battery Supply • 1.3A Fused

Page 20
© Copyright 2023 ABB. All rights reserved. Millennium SC_MAN Rev 2.0
Hardware
Chassis
MSC mounts in frames – 19, 23, and 25 inch. See Figure 6. It is designed to be physically backwards
compatible with existing Galaxy SC rear access controllers for field replacements or upgrades.
Figure 6 Controller Dimensions
