ACME Led Strobe 20 LED-ST20 User manual






LED‐ST20

UserManual
Pleasereadtheinstructionscarefullybeforeusing

1A


Contents

1.SafetyInstruction .....................................................................................................2
2.TechnicalSpecification..............................................................................................3
3.HowtoUsetheUnit .................................................................................................4
4.Troubleshooting........................................................................................................4
5.FixtureCleaning........................................................................................................5















2A

1.SafetyInstruction

WARNING
yPLEASEkeepthisUserManualforfutureconsultation.Ifyouselltheunittoanotheruser,be
surethattheyalsoreceivethisinstructionbooklet.
yPLEASEunpackandcheckcarefullythereisnotransportationdamagebeforeusingtheunit.
yBeforeoperating,ensurethatthevoltageandfrequencyofpowersupplymatchthepower
requirementsoftheunit.
yIt’simportanttogroundtheyellow/greenconductortoearthinordertoavoidelectricshock.
yTheunitmustbeinstalledinalocationwithadequateventilation,atleast50cmfromadjacent
surfaces.Besurethatnoventilationslotsareblocked.
yPLEASEdisconnectmainspowerbeforereplacementorservicing.
yPLEASEreplaceonlywiththesametype.
yMakesuretherearenotflammablematerialsclosetotheunitwhileoperating,asitisfire
hazard.
yPLEASEusesafetycablewhenfixesthisunit.
yIntheeventofseriousoperatingproblem,stopusingtheunitimmediately.Nevertrytorepair
theunitbyyourself.Repaircarriedoutbyunskilledpeoplecanleadtodamageormalfunction.
Pleasecontactthenearestauthorizedtechnicalassistancecenterandalwaysusethesametype
spareparts.
yDONOTtouchanywireduringoperationashighvoltagemightbecausingelectricshock.
Installation:
Youcaninstalltheunitonthetrussorceiling.Useclampstofixtheunittotruss.Alwaysensure
thattheunitisfirmlyfixedtoavoidvibrationandslippingwhileoperating.Alwaysensurethatthe
structuretowhichyouareattachingtheunitissecure.Alsoalwaysuseasafetycablethatcanhold
10timesoftheweightoftheunitwheninstallingthefixture.


Please read carefully the instruction, which includes important
information about the installation
,
usa
g
e and maintenance.

3A

Cautions:
1. Themachineshouldbekeptawayfrommoisture.
2. Alwaysusethesametypeofspareparts.
3. Alwaysremembertounplugtheunitfromthepowermainsbeforeanyserviceisdone.There
arenouserserviceablepartsinside.Serviceshouldbedonebyqualifiedpersonnelonly.

2.TechnicalSpecification
Featurewith4pcspowerful5WLEDforstrobeeffect
NONDMX,justplugandplay
Compacthousing,variablestrobespeedadjustablebypotentiometerattherearoftheunit
Idealforsmallapplications,likeclubs,bars,discos,parties,MobileDJs,etc
PowerVoltage:AC100V‐240V50/60HZ
PowerConsumption:12W
LightSource:4×5WWhiteLEDs
Dimension:212×107×177mm
Weight:1.1kgs


4A

3.HowtoUsetheUnit

○
1SafetyRing:Usedtokeeptheinstallationsafe.
○
2SoundSwitch:UsedtoturnOn/Offthesoundswitch.
○
3ManualStrobe:Usedtoadjustthestrobespeed.
○
4PowerCable:Usedtoconnecttothepowersupply.
4.Troubleshooting
Followingareafewcommonproblemsthatmayoccurduringoperation.Herearesome
suggestionsforeasytroubleshooting:
A.Thefixturedoesnotwork
1. Checktheconnectionofpowerandmainfuse.
2. Measurethemainsvoltageonthemainconnector.
B.Noresponsetothesound
1. Checkmicrophonetoseeifitisgoodbytappingthemicrophone.


5A

5.FixtureCleaning
Thecleaningofinternalandexternalopticallensesand/ormirrorsmustbecarriedout
periodicallytooptimizelightoutput.Cleaningfrequencydependsontheenvironmentinwhichthe
fixtureoperates:damp,smokyorparticularlydirtysurroundingcancausegreateraccumulationof
dirtontheunit’soptics.
yCleanwithsoftclothusingnormalglasscleaningfluid.
yAlwaysdrythepartscarefully.
yCleantheexternalopticsatleastevery20days.Cleantheinternalopticsatleastevery30/60
days.


























Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
89/336/EEC.
EN55103-1: 2009 ; EN55103-2: 2009; EN62471: 2008;
EN61000-3-2: 2006 + A1:2009 + A2:2009; EN61000-3-3: 2008.
&
Harmonized Standard
EN60598-2-17:1989 + A2:1991; EN60598-1:2008+ A11: 2009
EN 62471:2008; EN 62493: 2010
Safety of household and similar electrical appliances
Part 1: General requirements





































Innovation,Quality,Performance

