PANEL PC 1000 All-in-One PANEL PC User’s Manual
Introduction 1
C h a p t e r 1
Introduction
This chapter contains the general information and the detailed
specifications of the PANEL PC1000. Chapter 1 includes the following
sections:
$"General Description
$"System Specification
$"Dimensions
$"I/O Outlets
$"Utilities Supported
1.1 General Description
The PANEL PC 1000 super slim industrial PANEL PCs are mainly
designed for industrial automation and some space-constricted
embedded applications. For some space-concerned industries, a
traditional PC with a separate main system, display monitor and
keyboard is simply not integrated enough.
Ruggedly designed, the PANEL PC 1000 is 100% IBM PC/AT
compatible and it integrates super I/Os, VGA, 10.4” TFT, touch screen,
Ethernet, and packs special industrial features like watchdog timer,
CMOS double backup, all in a single system. The full PC
functionality coupled with its industrial-grade construction easily tailors
the system for any embedded applications and allows the system to
endure continuous operation in any hostile industrial environments
where stability and reliability are a must. Common applications of the
PANEL PC 1000 include tooling machine, POI terminal, stand-alone
KIOSK, medical instrument, mobile communication device and
banking system - to name just a few.
Designed by the PC experts for PC professionals, the PANEL PC
1000 is virtually the ultimate one-step solution for your space-limited
applications.

PANEL1000-370 All-in-One PANEL PC User’s Manual
Introduction
2
1.2 Specifications
Core System for system board
$"
CPU: Intel Celeron 300 up to 733 MHz;
Intel Pentium III 500 up to1.0Ghz
$"
System Chipset: Intel 440BX Core Logic Controller
$"
BIOS: Award BIOS, Y2K compliant
2Mbit Flash ROM, DMI, Plug and Play
$"
System Memory: One 168-pin DIMM (PC-100)
Maximum SDRAM of up to 256MB
$"
L2 Cache: Integrated in CPU
$"
Real Time Clock: Dallas STM48T86PC1 or latest product
$"
Watchdog Timer: System reset or Non-Mask Interrupt
software programmable Time interval and
jumper selectable;
64 levels, 0.5~8 / 5~80 / 50~800 / 100~1600
seconds
I/O System
$"
Standard I/O:
− 4 x serial ports with power; 3 x RS-232, 1 x
RS-232/422/485 jumper selectable
− 1 x parallel port, SPP/EPP/ECP
− 1 x External FDD Interface
− 2 x HDD Interface
− 1 x Keyboard Interface
− 1 x PS/2 Mouse Interface
− 2 x USB Ports
$"
Digital I/O: Input x 4, Output x 4
$"
Ethernet:
− 32-bit Plug & Play Fast Ethernet Controller
− RJ-45 connector
$"
Audio:
− ESS Solo-1 1938 32-bit PCI 2.1 Audio Drive controller
$"
VGA/Flat Panel Controller:
− AGP Interface C&T69000 controller with integrated 2MB
SDRAM
− Simultaneously supports CRT and flat panel displays

PANEL PC 1000 All-in-One PANEL PC User’s Manual
Introduction 3
Built-in Peripherals
$"Standard 100W power supply
$"2.5” Hard disk (540MB or up)
$"10.4” ELO anti-glare analog resistive touch screen with
RS- 232 controller sharing COM3
$"System cooling fan
NOTE: Optional DC power supplies rated at +12V, +24V and
+48V are also available. (See Appendix A)
System Specification
$"10.4” TFT with 640 x 480 resolution
$"External FDD interface
$"NEMA 4/12 sealed front panel
$"Heat dispensing design
$"PC/104 expansion Bus
$"One free slot for PCI/ISA expansion
$"Net weight: 4.2 KGS
$"Dimension (main body size):
− PANEL PC 1000
− 330 x 266 x 93 mm (with
one ISA or PCI expansion
card)
$"Operating Temperature Range: 0oC ~ 40oC
$"Relative Humidity: 5% ~ 95%; non-condensing
NOTE: For more detailed information on the system engine
board used in your PANEL PC, refer to the system board
User’s Manual that came with the system packaging.

PANEL1000-370 All-in-One PANEL PC User’s Manual
Introduction
4
1.3 Dimensions
PANEL1000-370 10.4" FLAT PANEL PC (unit: mm)

PANEL PC 1000 All-in-One PANEL PC User’s Manual
Introduction 5
1.4 I/O Outlets
The following figure shows the I/O arrangement of the PANEL PC
1000. The backside of the chassis contains most of the connectors.
1. Ethernet RJ-45 phone
jack
2. PS/2 mouse
3. Keyboard
4. External FDD
5. 4-channel Digital
Inputs/outputs
6. Parallel port
7. COM4
8. COM3
9. COM2
10. COM1
11. VGA port IF
12. AC inlet
13. Power switch
14. +5V/12V DC outlet

PANEL1000-370 All-in-One PANEL PC User’s Manual
Introduction
6
1.5 Utilities Supported
%"
Watchdog Utility
%"
Ethernet Utility
%"
VGA Drivers
%"
Touch screen Utility

PANEL PC 1000 All-in-One PANEL PC User’s Manual
System Configuration 7
C h a p t e r 2
System Configuration
This chapter details the system parts and components with figures.
Sections include
$"System Major Parts $"Panel Mount
2.1 System Configuration
2.1.1 Front View
The figure below shows the front views of PANEL PC1000.
3
1
2
1. Power LED
2. HDD LED
3. Ethernet LED

PANEL1000-370 All-in-One PANEL PC User’s Manual
8 System Configuration
2.2 Panel Mount
The PANEL PC 1000 is mainly designed for panel mount application.
To mount the PANEL PC 1000, the standard set of mounting kit
(included in the system packaging) is needed. Please refer to the
following figure.

PANEL PC 1000 All-in-One PANEL PC User’s Manual
System Installation 9
C h a p t e r 3
System Installation
This chapter describes the installation and the cable connection to the
system connectors. See system board User’s Manual that came with
your PANEL PC packaging for more details. Sections in this chapter
includes
$"CPU
$"DRAM
$"HDD
$"4 x Serial
Ports
$"Parallel Port
$"VGA
$"Ethernet
$"Digital I/O
$"Keyboard
$"PS/2 Mouse
$"External FDD
$"Expansion
Slot
$"System O/S
and
Software
Installation
The PANEL PC 1000 has a Pentium III little board with a free PCI/ISA
slot inside. It already builds in a Pentium III CPU, relevant DRAM and
a 2.5” HDD. These are all standard and the system is ready to play.
System performance can be increased by upgrading to a higher
performance CPU, higher capacity DRAM modules and hard disk
drive. The user can use the I/O ports located at the back side of the
chassis to connect external peripheral devices, such as a monitor,
serial devices, parallel printer…etc.
NOTE: Make sure the power cord is disconnected before any
installation. To install any internal device such as CPU,
DRAM and HDD, take out the rear chassis cover first.

PANEL1000-370 All-in-One PANEL PC User’s Manual
System Installation
10
3.1 CPU
The standard PANEL PC 1000 system already builds in Pentium
III-level CPU. When upgrading to a new CPU of the same level, follow
the instructions below;
1. To remove the existing CPU requires the use of a chip
puller.
2. Locate pin 1 at the corner of the CPU socket and align
the CPU’s pin 1 with the pin 1 on the socket.
3. Place the CPU in the socket. If the insertion of the CPU to
the socket is not easy, then check whether the notch on
the corner of the CPU and the notch on the socket are
properly aligned.
4. When a new CPU is installed, other settings on the system
control board including CPU type, CPU bus clock and
CPU voltage may need to be adjusted. Make sure all the
settings are correct for the installed CPU. (See the CPU
jumper settings in the CPU card User’s Manual that came
with the PANEL PC packaging).
3.2 DRAM
The system control board provides 1 x 168-pin DIMM sockets
supporting system memory up to 256MB.
To install the memory module;
1. Disconnect all power sources.
2. The memory module can only fit into the socket one way.
Holding the memory module with the notch on the upper
right corner, then insert the memory module at a 45°
Angle and push the module upright until it clicks into
place.
The system auto detects the new memory size and it is not necessary
to change the system configuration after installation.

PANEL PC 1000 All-in-One PANEL PC User’s Manual
System Installation 11
3.3 HDD
The standard PANEL PC 1000 already builds in a 2.5” hard disk drive.
If the user intends to remove the existing device for repair or for a
higher-capacity one, then follow the installation instructions below.
1. Take out the screws and remove the HDD bracket.
Mounting orientation of the HDD brackets on PANEL PC
1000 are not similar to each other. The four screws
mounting the PANEL PC 1000 HDD bracket sits at the
bottom of the bracket.
2. Reinstall the new hard disk driver to the HDD bracket and
screw the HDD bracket to the system compartment again.
The four rubber stands act as cushions to lessen the
vibration that usually causes damage to mechanical
devices like a hard disk driver.
3. Use the IDE cable to connect the HDD to the IDE pin
connector. Match pin 1 of the HDD and the pin 1 of the
cable.

PANEL1000-370 All-in-One PANEL PC User’s Manual
System Installation
12
3.4 4 x Serial Ports
The PANEL PC 1000 provides four onboard serial ports installed on
the bottom rear side of the chassis. Arrangements on PANEL PC
1000 specify COM1, COM2, COM3 providing RS-232 interface, and
with its RS-422/485 interface connected to COM4. Each serial port
comes with +5V/+12V power capabilities on both Pin 1 and Pin 9,
ready to accommodate a wide array of serial devices such as fax
modem, scanner, serial mouse, touch screen...etc. If the touch
screen option is included, its controller will share COM3.
COM1 to COM4 are all D-SUB 9-pin connectors. To attach to any
serial device, just plug in the device connector to the 9-pin D-SUB. In
terms of transmission distance, the RS-422/485 will perform better
than RS-232. In this case, the COM2 is suggested to be set to
RS-422/485 and the related jumpers have to be set correctly first (see
the system board User’s Manual). The RS-485 pin assignment is
listed below.
Signal Name
Pin # R2-422 RS-485
1 TX- DATA-
2 TX+ DATA+
3 RX+ No connector
4 RX- No connector
5 GND GND
6 No connector No connector
7 No connector No connector
8 No connector No connector
12 3 4 5
6789
9 No connector No connector
