Introduction
System Overview
This manual was written to help you start using this product
as quickly and smoothly as possbile. Inside, you will find
the answers to solve most problems. In order for this
reference material to be of greatest use, refer to the
“expanded table of contents” to find relevant topics.
This board provides a total PC solution by incorporating the
System, I/O, and PCI IDE. The mainboard support single
AMD Thunderbird and Duron processors base PC ATX
system, ISA Bus, AMR Bus,PCI Local Bus, and AGP Bus to
upgrades your system performance.
It is ideal for multi-tasking and fully supports MS-DOS,
Windows, Windows NT , Windows ME, Windows 2000,
Novell, OS/2, Windows95/98, Windows 98SE , UNIX ,
SCO UNIX etc.
This manual also explains how to install the mainboard for
operation, and how to setup your CMOS configuration with
the BIOS setup program.

1-11-1
1-11-1
1-1
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.Motherboard Description
1.1 Features
1.1.1 Hardware
CPU
-Single AMD Socket 462 ThunderbirdTM / DuronTM.
-100/133MHz System Interface speed.
-AMD DuronTM processors 600~900MHz whith 100MHz FSB.
-AMD ThunderbirdTM processors 700~1.5GHz with in 100/133MHz
FSB.
Speed
-Supports 33MHz PCI Bus speed.
-Supports 4X AGP Bus.
DRAM Memory
-Supports 8/16/32/64....MB DIMM module socket.
-Supports Synchronous DRAM(3.3V)
-Supports a maximum memory size of 1.536GB with SDRAM.
Shadow RAM
-A memory controller provide shadow RAM and supports
8-bit ROM BIOS.
Green Function
-Support power management operation VIA BIOS.
-Power down timer from 1 to 15 mins.
-Wakes from power saving sleep mode at the press of
any key or any mouse activity.
Bus Slots
-Provide one ISA slot and one AMR slot and AGP slot.
-Five 32-bit PCI bus.

1-31-3
1-31-3
1-3
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
Universal Serial Bus
-Supports two back Universal Serial Bus(USB)Ports
and two front Universal serial Bus(USB)Ports.
Hardware Monitor Function
-CPU Fan Speed Monitor.
-CPU Temperature Monitor.
-System Voltage Monitor.
Flash Memory
-Support 2MB flash memory.
-Support ESCD Function.
IDE Bulit-in On Board
-Supports four IDE devices.
-Supports PIO Mode 5, Master Mode, high performance hard disk
drives.
-Support Ultra DMA 33/66/100 Bus Master Mode.
-Supports IDE interface with CD-ROM.
-Supports high capacity hard disk drives.
-Support LBA mode.
PCI-Based AC 97 Digital Audio Processor
-AC 97 2.1 interface.
-16 channels of high-quality sample rate conversion.
-16x8 channel digital mixer.
-Stereo 10 band graphic equalizer.
-Sound Blaster and Sound Blaster Pro emulation.
WOL/WOM (Wake On LAN & Wake On Modem)
Supports system power up from LAN/Modem ring up .
Smart Panel
Supports BIOS Port 80H POST Code output to debug LED.

1-41-4
1-41-4
1-4
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
I/O Bulit-in On Board
-Supports one multi-mode Parallel Port.
(1)Standard & Bidirection Parallel Port
(2)Enhanced Parallel Port (EPP)
(3)Extended Capabilities Port
-Supports two serial ports, 16550 UART.
-Supports one Infrared transmission (IR).
-Supports PS/2 mouse and PS/2 Keyboard.
-Supports 360KB, 720KB, 1.2MB, 1.44MB, and 2.88MB floppy disk
drivers.
1.1.2 Software
BIOS
-AWARD legal BIOS.
-Supports APM 1.2.
-Supports USB Function.
-Supports ACPI
Operation System
-Offers the highest performance forMS-DOS,Windows,
Windows NT, Windows 2000, Windows ME, Novell, OS/2,
Windows 95/98, Windows 98 SE, UNIX, SCO UNIX etc.
1.1.3 Attachments
-HDD UDMA66/100 Cable.
-FDD Cable.
-Flash Memory Written for BIOS Update.
-USB2 Cable (Option).
-Fully Setup CD Driver built in Utility(Ghost, Anitivirus,
Adobe Acrobat).
-This Manual.

1-51-5
1-51-5
1-5
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.2 Motherboard Installation
1.2.1 Motherboard Map

1-61-6
1-61-6
1-6
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.2.2 Motherboard Layout
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer

1-71-7
1-71-7
1-7
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer
1.3 Motherboard Connectors
1.Babk OandkI.O Cnnndbsnrr1.Babk OandkI.O Cnnndbsnrr
1.Babk OandkI.O Cnnndbsnrr1.Babk OandkI.O Cnnndbsnrr
1.Babk OandkI.O Cnnndbsnrr1.CCAtchn-InCnnndbsnr1.CCAtchn-InCnnndbsnr
1.CCAtchn-InCnnndbsnr1.CCAtchn-InCnnndbsnr
1.CCAtchn-InCnnndbsnr
3.IR Cnnndbsnr3.IR Cnnndbsnr
3.IR Cnnndbsnr3.IR Cnnndbsnr
3.IR Cnnndbsnr 4.Wakd-On MOCDM Cnnndbsnr4.Wakd-On MOCDM Cnnndbsnr
4.Wakd-On MOCDM Cnnndbsnr4.Wakd-On MOCDM Cnnndbsnr
4.Wakd-On MOCDM Cnnndbsnr
5.Wakd-On-LAN Cnnndbsnr5.Wakd-On-LAN Cnnndbsnr
5.Wakd-On-LAN Cnnndbsnr5.Wakd-On-LAN Cnnndbsnr
5.Wakd-On-LAN Cnnndbsnr 6.Frnns USB1Cnnndbsnr6.Frnns USB1Cnnndbsnr
6.Frnns USB1Cnnndbsnr6.Frnns USB1Cnnndbsnr
6.Frnns USB1Cnnndbsnr
7.Frnns OandkCnnndbsnr(J1(7.Frnns OandkCnnndbsnr(J1(
7.Frnns OandkCnnndbsnr(J1(7.Frnns OandkCnnndbsnr(J1(
7.Frnns OandkCnnndbsnr(J1(8.FanCnnndbsnrr(Fan1.1.3(8.FanCnnndbsnrr(Fan1.1.3(
8.FanCnnndbsnrr(Fan1.1.3(8.FanCnnndbsnrr(Fan1.1.3(
8.FanCnnndbsnrr(Fan1.1.3(
9.ICD Cnnndbsnrr9.ICD Cnnndbsnrr
9.ICD Cnnndbsnrr9.ICD Cnnndbsnrr
9.ICD Cnnndbsnrr10.Fknooy Cnnndbsnr10.Fknooy Cnnndbsnr
10.Fknooy Cnnndbsnr10.Fknooy Cnnndbsnr
10.Fknooy Cnnndbsnr
11.COU Frdq. Sdsshng(SW1.JO1(11.COU Frdq. Sdsshng(SW1.JO1(
11.COU Frdq. Sdsshng(SW1.JO1(11.COU Frdq. Sdsshng(SW1.JO1(
11.COU Frdq. Sdsshng(SW1.JO1(11.COU Rashn Sdkdbshnn(SW1(11.COU Rashn Sdkdbshnn(SW1(
11.COU Rashn Sdkdbshnn(SW1(11.COU Rashn Sdkdbshnn(SW1(
11.COU Rashn Sdkdbshnn(SW1(
13.ATX Onwdr Cnnndbsnr13.ATX Onwdr Cnnndbsnr
13.ATX Onwdr Cnnndbsnr13.ATX Onwdr Cnnndbsnr
13.ATX Onwdr Cnnndbsnr 14.AMR COCDC Sdkdbshnn(JO3(14.AMR COCDC Sdkdbshnn(JO3(
14.AMR COCDC Sdkdbshnn(JO3(14.AMR COCDC Sdkdbshnn(JO3(
14.AMR COCDC Sdkdbshnn(JO3(
15.CMOS FtnbshnnSdkdbshnn(JO1(15.CMOS FtnbshnnSdkdbshnn(JO1(
15.CMOS FtnbshnnSdkdbshnn(JO1(15.CMOS FtnbshnnSdkdbshnn(JO1(
15.CMOS FtnbshnnSdkdbshnn(JO1(
16.Jdyanarc Wakd to Sdsshng(JOX1(16.Jdyanarc Wakd to Sdsshng(JOX1(
16.Jdyanarc Wakd to Sdsshng(JOX1(16.Jdyanarc Wakd to Sdsshng(JOX1(
16.Jdyanarc Wakd to Sdsshng(JOX1(
13
1
7
8
10
9
4,5
16
8
8
12
2
6
14
11
3
15
11

1-81-8
1-81-8
1-8
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.3.1 Front Panel Connector (J1)
J1 PANEL Connector
Speaker Connector (SPEAKER)
An offboard speaker can be installed onto the motherboard as a
manufacturing option. An offboard speaker can be connected to
the motherboard at the front pannel connector. The speaker
(onboard or offboard) provides error beep code information dur-
ing the Power Self-Test when the computer cannot use the video
interface. The speaker is not connected to the audio subsystem
and does not receive output from the audio subsystem.
Hard Drive LED Connector (HDLED)
This connector supplies power to the cabinet IDE activity LED.
Read and write activity by devices connected to the Primary or
Secondary IDE connectors will cause the LED to light up.
SMI Suspend Switch Lead (EXTSMI)
This allows the user to manually place the system into a suspend
mode of Green mode. System activity will be instantly decreased
to save electricity and expand the life of certain components
when the system is not in use. This 2-pin connector (see the
figure) connects to the case-mounted suspend switch. If you do
not have a switch for the connector, you may use the "Turbo
Switch” instead since it does not have a function. SMI is
activated when it detects a short. It may require one or two
pushes depending on the position of the switch. Wake-up can be
controlled by settings in the BIOS but the keyboard will always
allow wake-up (the SMI Suspend Switch Lead cannot wake-up
the system). If you want to use this connector, the "Suspend
Switch" in the Power Management Setup of the BIOS SOFT-
WARE section should be on the default setting of Enable.
SPEAKER
PW_BN
1
2
RSTSW
EXTSMI
HDLED PW_LED
+
++
SMI_LED
KBLOCK
+
+
++

1-91-9
1-91-9
1-9
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
ATX Power Switch (PW_BN)
The system power is controlled by a momentary switch
connected to this lead. Pushing the button once will switch
the system ON. The system power LED lights when the
system's power is on .
Power LED Lead (PW_LED)
The system power LED lights when the system power is on.
Keyboard Lock (KBLOCK)
The header is for setting keyboard locked.
Reset Switch Lead (RSTSW)
The connector can be connected to a momentary SPST type
switch that is normally open. When the switch is closed, the
motherboard resets and runs the POST.
SMI_LED Lead (SMI_LED)
The system SMI_LED lights when the system suspend is on.
1.3.2 Floppy Disk Connector (FDD)
This connector supports the provided floppy drive ribbon
cable. After connecting the single end to the board, connect
the two plugs on the other end to the floppy drives.
1.3.3 Hard Disk Connectors (IDE1/IDE2)
These connectors support the provided IDE hard disk ribbon
cable. After connecting the single end to the board, connect
the two plugs at the other end to your hard disk.
If you install two hard disks, you must configure the second
drive to Slave mode by setting its jumper settings. BIOS now
supports SCSI device or IDE CD-ROM boot up (see "HDD
Sequence SCSI/IDE First" & "Boot Sequence" in the BIOS
Features Setup of the BIOS SOFTWARE) (Pin 20 is removed
to prevent inserting in the wrong orientation when using
ribbon cables with pin 20 plugged) .

1-101-10
1-101-10
1-10
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.3.4 ATX 20-pin Power Connector (ATX)
This connector supports the power button on-board. Using
the ATX power supply, functions such as Modem Ring Wake-
Up and Soft Power Off are supported on this motherboard .
This power connector supports instant power-on
functionality, which means that the system will boot up
instantly when the power connector is inserted on the board.
1.3.5 Infrared Connector (IR1)
After the IrDA interface is configured, files can be
transferred from or to portable devices such as laptops,
PDAs, and printers using application software.
Pin Signal Pin Signal
1 3.3V 11 3.3V
2 3.3V 12 -12V
3 GND 13 GND
4 5V 14 PS-ON
5 GND 15 GND
6 5V 16 GND
7 GND 17 GND
8 PW-OK 18 -5V
9 5V_SB 19 5V
10 12V 20 5V

1-111-11
1-111-11
1-11
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.4 Back Panel Connectors
1.4.1 PS/2 Mouse /Keyboard CONN.
The motherboard provides a standard PS/2 mouse / Keyboard
mini DIN connector for attaching a PS/2 mouse. You can
plug a PS/2 mouse / Keyboard directly into this connector.
1.4.2 USB Connectors: USB & USB1
The motherboard provides a OHCI(Open Host Controller
Interface)Universal Serial Bus Roots for attaching USB
devices such as a keyboard, mouse and other USB devices.
You can plug the USB devices directly into this connector.
Pin Signal
1 +5V_SB
2 USBP0-(USBP1-)
3 USBP0+(USBP1+)
4 GND
PS/2 Keyboard
(6-pinFem ale)
Serial
Port(9-pin
Male)
COM1COM2SPEAKERMIC
LINE
IN
PS/2 Mouse
USB
Parallel
(Printer)
Port
(25-pinFem ale)
MIDI/(GAME)
Port
(15-pinFem ale)
USB

1-111-11
1-111-11
1-11
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer
Front Two USB Connectors: USB1
USB1
1
3
5
7
9
VCC
P2-
P2+
GND
GND
2
4
6
8
10
GND
GND
P3+
P3-
VCC

1-131-13
1-131-13
1-13
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.5 Serial and Parallel Interface Ports
This system comes equipped with two serial ports and one
parpllel port. Both types of interface ports will be explained
in this chapter.
The Serial Interfaces: COM1/COM2
The serial interface port is sometimes refered to as an RS-
232 port or an asynchronous communication port. Mice,
printers, modems and other peripheral devices can be
connected to a serial port. The serial port can also be used
to connect your computer system. If you wish to transfer
the contents of your hard disk to another system it can be
accomplished by using each machine’s serial port.
The serial port on this system has one 9-pin connector.
Some older computer systems and peripherals used to be
equipped with only a 25-pin connector. Should you need to
connect your 9-pin serial port to an older 25-pin serial port,
you can purchase a 9-to-25 pin adapter.
COM1/COM2

1-141-14
1-141-14
1-14
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
Parallel Interface Port
Unlike serial ports, parallel interface ports have been
standardized and should not present any difficulty interfacing
peripherals to your system. Sometimes called a Centronics port,
the parallel port is almost exclusively used with printers. The
parallel port on your system has a 25-pin, DB 25 connector(see
the picture below).
PS/2 Keyboard
(6-pinFem ale)
Serial
Port(9-pin
Male)
COM1COM2SPEAKERMIC
LINE
IN
PS/2 Mouse
USB1
Parallel
(Printer)
Port
(25-pinFem ale)
MIDI/(GAME)
Port
(15-pinFem ale)
Signal DB9 Pin DB25 Pin
DCD 1 8
RX 2 3
TX 3 2
DTR 4 2 0
GND 5 7
DSR 6 6
RTS 7 4
CTS 8 5
RI 9 22

1-151-15
1-151-15
1-15
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer
1.6 CPU Installation
1.6.1 CPU Installation Procedure: Socket 462
1. Pull the lever sideways away from the socket then raise
the lever to a 90-degree angle.
2. Locate Pin 1 in the socket and look for the white dot or
cut edge in the CPU. Match Pin 1 with the white dot/cut
edge then insert the CPU.
3. Press the lever down to complete the installation.
4. Make sure the spec of the heatsink is good enough.
Socket 462
Notch

1-161-16
1-161-16
1-16
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer
1.6.2 CPU Clock Frequency Setting: SW1/JP1
Overclocking is operating a CPU/Processor beyond its
specified frequency. JP1 jumper is used for the CPU Front
Side Bus Frequencies from 100MHz to 133MHz.
Pin JP1 Assignment
On CPU FSB=100MHz
(Default)
Off CPU FSB=133MHz
SW1 1 2 3 4 CPU (MHz) PCI (MHz)
0 1 0 0 100 33.33
0 1 1 0 133 33.33
1
1
3
4
0:0:
0:0:
0: 1:1:
1:1:
1:
OffOff
OffOff
Off OnOn
OnOn
On

1-171-17
1-171-17
1-17
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
USB
COM1
COM2
IR1
FAN3
JP2
FAN2
VIA
VIA
J1
1
FAN1
AMR SLOT
AGP SLOT
JP3
ISA SLOT
PCI1
PCI2
PCI3
PCI4
PCI5
DIMM3 DIMM2 DIMM1
462
JP1
JPX1
GAME1
Speak out
Line in
MIC in
Printer
“**” is default.
1.6.3 CPU Ratio Selection: SW2
SW2 jumper is used for the CPU Ratio selection.
0:0:
0:0:
0: 1:1:
1:1:
1:
OffOff
OffOff
Off OnOn
OnOn
On
Ratio SW2 0 1 2 3 4
Auto ** 1 0 0 0 0
Manual
5.0 0 1 1 0 1
5.5 0 0 1 0 1
6.0 0 1 0 0 1
6.5 0 0 0 0 1
7.0 0 1 1 1 0
7.5 0 0 1 1 0
8.0 0 1 0 1 0
8.5 0 0 0 1 0
9.0 0 1 1 0 0
9.5 0 0 1 0 0
10.0 0 1 0 0 0
10.5 0 0 0 0 0
11.0 01111
11.5 00111
12.0 0 1 0 1 1
12.5 0 0 0 1 1
4
3
1
1
0
