ActronAir Serene 2 User manual

Serene 2
Wall Hung Split System
Owner's Manual
Model Numbers:
WRC-026CS/WRE-026CS
WRC-035CS/WRE-035CS
WRC-050CS/WRE-050CS
WRC-072CS/WRE-072CS
WRC-085CS/WRE-085CS
IMPORTANT NOTE:
Please read this manual carefully before operating your air conditioning unit.
That’s better. That’s Actron.

Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
Owner's Manual Wall Hung Split System
2
Table of Contents
. General Information ..................................................................................................................
. Safety Instructions ....................................................................................................................
. Unit Specification and Features ..................................................................................................
. Unit Parts 
. Achieving Optimal Performance 
. Features 
. Setting Vertical Angle of Air Flow 
. Setting Horizontal Angle of Air Flow 
. Sleep Operation 
. Manual Operation .....................................................................................................................
. Care and Maintenance .............................................................................................................
. Troubleshooting .....................................................................................................................

Owner's Manual Wall Hung Split System
Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
3
. General Information
CONGRATULATIONS on your purchase of an ActronAir air conditioning unit! This unit has been designed and engineered
to provide optimum air conditioning and to achieve maximum energy efficiency.
Your air conditioning system has been manufactured from the highest quality materials. Numerous “in house” and
“external” inspections and test procedures were conducted to your air conditioning unit to ensure satisfactory operation.
This guide provides operation instructions specific to your split indoor unit. Read this manual thoroughly to ensure safe
operation of your air conditioning system.
. Safety Instructions
•Only licensed HVAC technicians* should service this air conditioning equipment. Improper service or alteration by
an unqualified technician could result in significant and major damage to the product or property which may render
your warranty null and void. Such unqualified service could also lead to severe physical injury or death. Follow all safety
instructions in this literature and all warning labels that are attached to the equipment.
•Prevailing WH&S regulations must be observed and will take precedence to the safety instructions contained on this
manual. Safe work practices and environment must be the paramount importance in the performance of all the service
procedures.
•This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised
by a responsible person to ensure that they can use the appliance safely. Young children should be supervised to ensure
that they do not play with the appliance.
*Qualifications required will be appropriate Electrical, Refrigeration and Refrigerant Handling License and Training
dependent on local State/Territory regulations.
DANGER
Hazardous Voltage - Risk of Electrocution.
Turn Off the power from main isolator before proceeding with any service and maintenance work of the unit. Observe proper
LOCK-OUT/TAG-OUT (LOTO) procedures for electrical appliances in order to prevent accidental switching-on of the power
supply. Extreme care and caution must be observed should there be a need to work on live circuit.
WARNING
• If any abnormal situation arises (like burning smell), turn of the power supply and call your HVAC technician for instructions
to avoid electric shock, fire or injury.
• DO NOT let the indoor unit or the controller get wet. It may cause electric shock or fire.
• DO NOT insert fingers, rods or other objects into the air inlet or outlet. This may cause injury, since the fan may be rotating
at high speeds.
• DO NOT use a flammable spray such as hair spray, lacquer or paint near the unit. This may cause fire or combustion.

Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
Owner's Manual Wall Hung Split System
4
CAUTION
• DO NOT inspect the unit by yourself. Ask a qualified HVAC technician to perform the inspection.
• To prevent product deterioration, do not use the air conditioner for preservation purposes (storage of food, plants, animals,
works of art, etc.).
• DO NOT operate the air conditioner with wet hands. It may cause electric shock.
• DO NOT touch the evaporator coils inside the indoor unit. The evaporator coils are sharp and may cause injury.
• DO NOT place items that might be affected by moisture damage under the indoor unit. Condensation can occur at a relative
humidity of 80%.
• DO NOT expose heat-producing appliances to cold air or place them under the indoor unit. This may cause incomplete
combustion or deformation of the unit due to the heat.
• If the air conditioner is used together with other heating devices, thoroughly ventilate the room to avoid oxygen deficiency.
• DO NOT climb onto or place objects on top of the outdoor unit.
• DO NOT operate the air conditioner when using fumigant insecticides. The chemicals may become layered with the unit and
endanger those who are hypersensitive to chemicals.
• DO NOT let children play with the air conditioner.
• DO NOT operate the air conditioner in a wet room (e.g. bathroom or laundry room). This can cause electrical shock and cause the
product to deteriorate.
WARNING
This air-conditioning unit contains R-32 refrigerant (CLASS A2L) which is mildly flammable. Refer to R-32 Safety Manual, provided
with the unit.
NOTE
• Service, maintenance, repairs and decommissioning of this unit must be performed by a licensed HVAC technician; qualified
to handle R-32 refrigerant.
• R-32 refrigerant is odourless, if the refrigerant gas comes into contact with fire, it may emit a poisonous gas.
• Do not continuously operate open flames and ignition sources in the room.

Owner's Manual Wall Hung Split System
Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
5
. Unit Specification and Features
03.01. Unit Parts
AIR FILTER
PULL OUT
LOUVRE
REMOTE CONTROL
HOLDER
REMOTE
CONTROL
INTUITIVE
PROXIMITY SENSOR
DISPLAY WINDOW
FRONT
PANEL
Humidity
Boost
Display Code Display Code Explanation
Display window for indicating temperature, operation features and error codes.
Displayed for three seconds when:
• TIMER ON is set
• IONISER, SWING, TURBO, ECO, BREEZE AWAY, INTUITIVE PROXIMITY SENSOR
or QUIET feature is turned on
Displayed for three seconds when:
• TIMER OFF is set
• IONISER, SWING, TURBO, ECO, BREEZE AWAY, INTUITIVE PROXIMITY SENSOR
or QUIET feature is turned off
Displayed when the system is defrosting
Displayed when Active Clean feature is turned on
Displayed when Freeze Protection mode is turned on
Displayed when ECO+ feature is activated
Displayed when Easyconnect is installed
Displayed when Indoor unit is in mode conflict with another operating indoor unit
(applicable to multi-split “MRC” installations only)
NOTE
Refer to remote manual for full features list.

Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
Owner's Manual Wall Hung Split System
6
03.02. Achieving Optimal Performance
Optimal performance for the COOL, HEAT, and DRY mode can be achieved in the temperature ranges shown
in the table below. If the unit is used outside of these ranges, certain safety protection features will activate and
cause the unit to perform at a reduced capacity.
COOL Mode HEAT Mode DRY Mode
Indoor Temperature 17°C - 32°C 0°C - 30°C 10°C - 32°C
Outdoor Temperature -15°C - 60°C 25°C - 30°C 0°C - 60°C
NOTE
To further optimize the performance of the unit, do the following:
• Keep doors and windows closed.
• Limit energy usage by using TIMER ON and TIMER OFF functions.
• Do not block air inlets or outlets.
• Regularly inspect and clean air filters.
03.03. Features
NOTE
Refer to remote manual for full features list.
Auto-Restart
If the unit loses power, it will automatically restart with the prior settings once power has been restored.
Anti-mildew
When the unit is turned off after COOL, AUTO or DRY mode, the unit will continue to operate a low power to dry up
condensed water to prevent mildew growth.
Easyconnect Control (Optional)
Allows you to control the unit using a mobile phone and a wireless connection. Installation is required to be undertaken
by a licensed technician. Easyconnect is an accessory that may be purchased separately.
Louvre Angel Memory
When turning on your unit, the louvre will automatically resume its former angle. Aim the louvre higher to avoid direct
airflow. This setting is found under the SET menu.
Active Clean Function
It washes away dust, mold and grease when it adheres to the heat exchanger, by automatically freezing and then rapidly
thawing frost. Active Clean function is used to produce more condensed water to improve the cleaning effect. After
cleaning, the internal blower fan operates with hot air to blow-dry the evaporator and prevent the growth of mold.
When this function is turned on, the indoor unit will display CL. After 20 to 45 minutes, the unit will turn off
automatically and Active Clean function will be deactivated.

Owner's Manual Wall Hung Split System
Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
7
Breeze Away
This feature stops direct air from blowing onto you.
Refrigerant Leakage Detection
The indoor unit will automatically display EL0C when it detects refrigerant leakage. Switch system off and contact
service or installer.
Intuitive Proximity Sensor
This feature detects the occupancy of the people in the room. When in COOL mode, if you are away for 30 minutes, the
unit will automatically lower the frequency of the unit to save energy. The unit will automatically resume operation after
sensing activity in the room.
LED Display
Press the LED button on the remote control to turn off the indoor unit panel display and cancel the 'beep' noise.
Freeze Protection
When the unit is on HEAT mode and indoor temperature drops below 8 °C - FP will be displayed and system will enter
freeze protection mode.
03.04. Setting Vertical Angle of Air Flow
While the unit is on, use the SWING button on the remote control to set the vertical angle airflow direction. Refer to
Remote Control manual for more details.
03.05. Setting Horizontal Angle of Air Flow
While the unit is on, press and hold the SWING button on the remote control to set the vertical angle airflow direction.
Refer to Remote Control manual for more details.
NOTE
• When using COOL or DRY mode, do not set vertical louvre to the minimum angle for long periods of time. This can
cause water to condense on the louvre blade, which may drop on your floor or furnishings.
• When using COOL or HEAT mode, setting the vertical louvre to the minimum angle can reduce the performance of
the unit due to restricted air flow.
• Do not move louvre by hand. This will cause the louvre to become out of sync. If this occurs, reset mains power supply
isolator to restart the unit. This will reset the louvre.
CAUTION
Do not put your fingers in or near the blower. The high-speed fan inside the unit may cause injury.

Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
Owner's Manual Wall Hung Split System
8
03.06. Sleep Operation
The SLEEP function is used to decrease energy usage while you sleep and do not need the same temperature
settings to stay comfortable. This function can only be activated via the remote control.
Press the SLEEP button when you are ready to go to sleep. When in COOL mode, the unit will increase the
temperature by 1°C after 1 hour, and will increase an additional 1°C after another hour. When in HEAT mode, the
unit will decrease the temperature by 1°C after 1 hour, and will decrease an additional 1°C after another hour.
It will hold the new temperature for 7 hours, then the unit will turn off automatically.
NOTE
The SLEEP function is not available in FAN or DRY mode.
Page 10 
The SLEEP function is used to decrease energy
use while you sleep (and don’t need the same
temperature settings to stay comfortable). This
function can only be activated via remote control.
Press the SLEEP button when you are ready to
go to sleep. When in COOL mode, the unit will
increase the temperature by 1°C (2°F) after 1
hour, and will increase an additional 1°C (2°F)
after another hour. When in HEAT mode, the unit
will decrease the temperature by 1°C (2°F) after
1 hour, and will decrease an additional 1°C (2°F)
after another hour.
It will hold the new temperature for 7 hours, then
the unit will turn off automatically.
Note: The SLEEP function is not available in
FAN or DRY mode.
Sleep Operation
Set
temperature
Saving energy during sleep
1hr 1hr
7 hours
timer o
+/- 1 C/2 F
SLEEP Operation
+/- 1 C/2 F
Fig. 3.1
•
Unit
Specifications
and Features
SLEEP Operation
Set
Temperature
7 hours
Timer Off
±1°C ±1°C
Saving Energy During Sleep

Owner's Manual Wall Hung Split System
Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
9
. Manual Operation
How to operate your unit without the remote control
In the event that your remote control fails to work, your unit can be operated manually with the MANUAL CONTROL
button located on the indoor unit (shown in image below). Note that manual operation is not a long-term solution, and
that operating the unit with your remote control is strongly recommended.
To operate your unit manually:
1. Locate the MANUAL CONTROL button as shown on the image on the next page.
2. Press the MANUAL CONTROL button one time to activate FORCED AUTO mode. The display will show 24.0c.
3. Press the MANUAL CONTROL button again to activate FORCED COOLING mode. The display will show fC.
4. Press the MANUAL CONTROL button a third time to turn the unit Off.
FORCED AUTO MODE
The unit will go to AUTO mode with 24˚C set point.
FORCED COOL MODE
The outdoor unit will run at minimum capacity and indoor fan in low speed. After 30 minutes, the system will go to AUTO
mode with 24˚C set point.
CAUTION
The manual button is intended for testing purposes and emergency operation only. Please do not use this function unless
the remote is lost and it is absolutely necessary. To restore regular operation, use the remote control to activate the unit.
MANUAL CONTROL
BUTTON

Owner's Manual - Wall Hung Split System
Doc. No.9590-4011 Ver. 2 210622
Owner's Manual Wall Hung Split System
10
. Care and Maintenance
NOTE
Apart from filter cleaning, all other general maintenance and care of systems should be undertaken by a licensed technician.
Maintenance Procedures
This section describes the procedures that must be performed as a part of normal maintenance program. Regular
servicing of equipment by licensed technician is highly recommended. Regular servicing of your unit helps in maintaining
its optimum performance and reliability. The checklist and service periods provided on this manual are guides only,
as some sites may require more frequent servicing. Always disconnect electrical power to the unit before performing
these procedures. It is always a safe practice to observe all safety warnings and cautions when conducting maintenance
tasks.
DANGER
Live Electrical Connections!
It may be necessary to work with live electrical components on certain maintenance tasks. Only licensed electricians and
qualified technicians are allowed to perform these tasks.
Beware of Rotating Fan Blades!
Always make sure that all power supply, to the Outdoor Fans are turn Off and isolated.
Observe WH&S safety procedures, do not wear loose clothing and any jewellery when working near the fans.
Wear PPE whenever performing any maintenance procedures.
Observe all necessary procedures when working in a confined space.
WARNING
Hazardous Voltage !
Always make sure that all power supply, including remote controls, are disconnected before performing maintenance.
Observe proper LOCK-OUT/TAG-OUT procedures to ensure that power cannot be inadvertently energised. Failure to
disconnect power before maintenance procedures can result in serious injury and/or death.
This unit is charged with R-32 mildly flammable refrigerant.
Annual Maintenance Checklists
•Perform general maintenance inspections.
•Perform scheduled start-up checks.
•Leak test refrigerant circuits.
•Inspect contacts of all contactors and relays. Replace all worn contacts as required.
•Inspect, clean and tighten all electrical connections.
•Check fans for balanced operation. Make sure that there are no loose screws / bolts, no fan blades interference and no
damage to the fans and guards.
•Inspect the air filters, clean or replace as required.
•Clean and repaint any corroded panel section.
•Ensure no blockage of airflow through variable speed drive.
