ADF Web HD67E15-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 1 of 28
User Manual
Revision 1.000
English
EtherCAT Slave / IEC61850 Server - Converter
(Order Code: HD67E15-A1)
For Website information:
www.adfweb.com? roduct=HD67E15
For rice information:
www.adfweb.com? rice=HD67E15-A1
Benefits and Main Features
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other EtherCAT Slave products see also the following link:
Converter EtherCAT Slave to
www.adfweb.com? roduct=HD67E00 (Serial)
www.adfweb.com? roduct=HD67E01 (Modbus Master)
www.adfweb.com? roduct=HD67E02 (Modbus Slave)
www.adfweb.com? roduct=HD67E03 (Modbus TCP Master)
www.adfweb.com? roduct=HD67E04 (Modbus TCP Slave)
www.adfweb.com? roduct=HD67E05 (BACnet Master)
www.adfweb.com? roduct=HD67E06 (BACnet Slave)
www.adfweb.com? roduct=HD67E07 (CAN)
www.adfweb.com? roduct=HD67E08 (CANopen)
www.adfweb.com? roduct=HD67E09 (DeviceNet Master)
www.adfweb.com? roduct=HD67E10 (DeviceNet Slave)
www.adfweb.com? roduct=HD67E11 (DMX)
www.adfweb.com? roduct=HD67E12 (Ethernet)
www.adfweb.com? roduct=HD67E14 (IEC61850 Master)
www.adfweb.com? roduct=HD67E16 (J1939)
www.adfweb.com? roduct=HD67E17 (MQTT)
www.adfweb.com? roduct=HD67E18 (NMEA0183)
www.adfweb.com? roduct=HD67E19 (NMEA2000)
www.adfweb.com? roduct=HD67E20 (OPC UA Client)
www.adfweb.com? roduct=HD67E21 (OPC UA Server)
www.adfweb.com? roduct=HD67E22 (PROFINET Master)
www.adfweb.com? roduct=HD67E23 (PROFINET Slave)
www.adfweb.com? roduct=HD67E24 (SNMP Manager)
www.adfweb.com? roduct=HD67E25 (SNMP Agent)
www.adfweb.com? roduct=HD67E26 (EtherNet/IP Master)
www.adfweb.com? roduct=HD67E27 (EtherNet/IP Slave)
www.adfweb.com? roduct=HD67E28 (S7comm Client)
www.adfweb.com? roduct=HD67879 (IO-Link Master)
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 2 of 28
INDEX
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
ETHERCAT 10
ETHERNET 11
USE OF COM OSITOR SW67E15 12
NEW CONFIGURATION / O EN CONFIGURATION 13
SOFTWARE O TIONS 14
SET COMMUNICATION 16
ETHERCAT SET ACCESS 18
IEC61850 ACCESS 20
TLS KNOWN CERTIFICATE 21
ETHERCAT ESI FILE 22
U DATE DEVICE 23
MECHANICAL DIMENSIONS 25
ORDERING INFORMATIONS 26
ACCESSORIES 26
DISCLAIMER 27
OTHER REGULATIONS AND STANDARDS 27
WARRANTIES AND TECHNICAL SU ORT 28
RETURN OLICY 28
UPDATED DOCUMENTATION
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST
WARNING
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1.000 18/09/2020 Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 3 of 28
SECURITY ALERT
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 4 of 28
EXAMPLE OF CONNECTION

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 5 of 28
CONNECTION SCHEME
Figure 1: Connection scheme for HD67E15-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 6 of 28
CHARACTERISTICS
The HD67E15-A1 are EtherCAT / IEC61850 - Converters.
It allows for the following characteristics:
Isolation between EtherCAT – IEC61850 – ower Supply;
Two-directional information between EtherCAT bus and IEC61850 bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION
You need Compositor SW67E15 software on your C in order to perform the following:
Define the parameters of EtherCAT line;
Define the parameters of IEC61850 line;
Define EtherCAT variables to read and write;
Define the list of IEC61850 variables available for the Client;
Export the ESI file for configuration of EtherCAT Master;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 7 of 28
POWER SUPPLY
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67E15-A1 3.5
HD67E15-A1
Caution
Do n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 8 of 28
FUNCTION MODES
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 9 of 28
LEDS
The device has got seven LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
2: EtherCAT comm. (green) It blinks when EtherCAT communication is running Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
3: IEC61850 comm. (green) It blinks when IEC61850 communication is running Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
4: Error state (green) ON An error in the communication busses occurs
OFF No errors are present
Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
5: EtherCAT state (green)
OFF EtherCAT Master not connected
Blinking EtherCAT Master is connecting
ON EtherCAT Master is connected
Blinks quickly Boot state
Blinks very slowly (~0.5Hz) update in progress
6: Ethernet1 link (green) ON Ethernet cable connected
OFF Ethernet cable disconnected
ON Ethernet cable connected
OFF Ethernet cable disconnected
7: Ethernet2 link (green) ON Ethernet cable connected
OFF Ethernet cable disconnected
ON Ethernet cable connected
OFF Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 10 of 28
ETHERCAT
EtherCAT (Ethernet for Control Automation Technology) is an Ethernet-based fieldbus system, invented by Beckhoff Automation.
The protocol is standardized in IEC 61158 and is suitable for both hard and soft real-time computing requirements in automation technology.
With EtherCAT, the standard Ethernet packet or frame (according to IEEE 802.3) is no longer received, interpreted, and copied as process
data at every node. The EtherCAT slave devices read the data addressed to them while the telegram passes through the device, processing
data "on the fly". In other words, real-time data and messages are prioritized over more general, less time-sensitive or heavy load data.
The converter has two EtherCAT ports, one is used as Input port (Connector7) and it will receive the incoming messages from the Master,
the other is used as Output port (Connector8) and i twill forward the messages to the others nodes of the network.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 11 of 28
ETHERNET
The Ethernet port is used for programming the device and for IEC61850 communication.
Ethernet connection and the updating of the converter must be made using Connector9 and/or Connector10 of the HD67E15-A1 with at least
a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to
connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the
device to a C/ LC/other is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 12 of 28
USE OF COMPOSITOR SW67E15
To configure the Converter, use the available software that runs with Windows called SW67E15. It is downloadable on the site
www.adfweb.com and its operation is described in this document. This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67E15, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
F
igure 2: Main window for SW67E1
5

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 13 of 28
NEW CONFIGURATION / OPEN CONFIGURATION
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “EtherCAT Slave / IEC61850 Server -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 14 of 28
SOFTWARE OPTIONS
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67E15 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 15 of 28
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 16 of 28
SET COMMUNICATION
This section define the fundamental communication parameters of two buses, EtherCAT and
Ethernet.
By ressing the “Set Communication” button from the main window for SW67E15 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
The means of the fields for “EtherCAT Slave” are:
In the field “Revision Number” the revision number of the converter is defined;
In the field “Slave Name” the name of the converter is defined;
In the field “Node Address” the ID of the converter is defined.
The means of the fields for “IEC61850 Server” are:
In the fields “IP Address” the I address for IEC61850 side of the converter is
defined;
In the fields “SubNet Mask” the SubNet Mask for IEC61850 side of the converter is
defined;
In the fields “Gateway” the default gateway of the net is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of
the net;
In the field “Port” the port used for IEC 61850 communication is defined;
If the field “Password” the password used for accessing to IEC 61850 variables is
defined.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 17 of 28
The mean of the field for “TLS (Transport Layer Security) Server” is:
If the field “Enable TLS” is checked, the TLS protocol for secure connection is enabled;
In the field “Key” the key for the authentication is defined;
In the field “Key Password” the password for decrypting the key is defined;
In the field “Server Certificate” the certificate for the server is defined;
In the field “Root Certificate” the root of the server is defined;
If the field “Enable Only Known Certificates” is checked, the converter will accept just connection from known Clients (defined in
the section “TLS Known Certificate”).

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 18 of 28
Figure 4a: “EtherCAT Slave Set Access

Slave T
o Master” window
ETHERCAT SET ACCESS
By ressing the “EtherCAT Set Access” button from the main window for SW67E15 (Fig. 2) the window “EtherCAT Slave Set Access”
appears (Fig. 4).
This section is used to define the EtherCAT variables readable by the EtherCAT Master (Slave To Master) and the EtherCAT variables
writeable by the EtherCAT Master (Master To Slave).
S LAVE T O M ASTER
The means of the fields are:
If the field “Enable” is checked, the EtherCAT variable is enabled;
In the field “Type” the data format of the EtherCAT variable is defined;
In the field “Lenght” the dimension of the EtherCAT variable is defined;
In the field “Name” the name of the EtherCAT variable is defined;
In the field “Init Value” the default value of the EtherCAT variable is defined;
In the field “Position” the starting address of the EtherCAT array where the variable is mapped is defined;
In the field “Start Bit” the starting bit of the selected osition where the variable is mapped is defined;
In the field “Mnemonic” a description of the variable is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 19 of 28
Figure 4b: “EtherCAT Slave Set Access  Master To Slave” window
M ASTER T O S LAVE
The means of the fields are:
If the field “Enable” is checked, the EtherCAT variable is enabled;
In the field “Type” the data format of the EtherCAT variable is defined;
In the field “Lenght” the dimension of the EtherCAT variable is defined;
In the field “Name” the name of the EtherCAT variable is defined;
In the field “Position” the starting address of the EtherCAT array where the variable is mapped is defined;
In the field “Start Bit” the starting bit of the selected osition where the variable is mapped is defined;
In the field “Mnemonic” a description of the variable is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherCAT Slave /
IEC61850
S
erver
Document code: MN67E15_ENG Revision 1.000 age 20 of 28
Figure
5
: “IEC 61850 Access” window
IEC61850 ACCESS
By ressing the “IEC61850 Access” button from the main window for SW67E15 (Fig. 2) the window “Set Variables Access for IEC 61850”
appears (Fig. 5).
This section is used to define the IEC 61850 variables from/to which take/map the data of EnOcean devices.
The means of the fields are:
If the field “Enable” is checked, the IEC 61850 variable is enabled;
In the field “Name” the name of the IEC 61850 variable is defined;
In the field “Type” the data format of the IEC 61850 variable is defined;
In the field “Lenght” the dimension of the IEC 61850 variable is defined;
If the field “Read Only” is checked, the IEC 61850 variable is just in reading. Otherwise, it is writeable too;
In the field “Position” the starting byte of the internal memory arrays from/to which taking/mapping the data is defined;
In the field “Start Bit” the starting bit of the byte of the field “ osition” is defined;
In the field “Conversion” the conversion of the data is defined. This option is used to convert the data format between EtherCAT and
IEC 61850;
In the field “Molt. Factor” a multiplicative factor of the value is defined;
If the field “Swap” is checked, the bytes’ order is reversed;
If the field “Swap Word” is checked, the words’ order is reversed;
In the field “Mnemonic” a description of the variable is defined.
