ADF Web HD67901-IP-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 1 of 35
User Manual
Revision 1.001
English
BAcnet Slave / HART Master - Converter
(Order Code: HD67901-I -A1, HD67901-MST -A1)
For Website information:
www.adfweb.com? roduct=HD67901
For rice information:
www.adfweb.com? rice=HD67901-I -A1
www.adfweb.com? rice=HD67901-MST -A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other HART products see also the following link:
Converter HART Master to
www.adfweb.com? roduct=HD67900 (Serial)
www.adfweb.com? roduct=HD67902 (CAN)
www.adfweb.com? roduct=HD67903 (CANopen)
www.adfweb.com? roduct=HD67904 ( eviceNet Slave)
www.adfweb.com? roduct=HD67905 (Ethernet)
www.adfweb.com? roduct=HD67906 (EtherNet/IP Slave)
www.adfweb.com? roduct=HD67907 (J1939)
www.adfweb.com? roduct=HD67908 (Modbus Slave)
www.adfweb.com? roduct=HD67909 (Modbus TCP Slave)
www.adfweb.com? roduct=HD67910 (MQTT)
www.adfweb.com? roduct=HD67911 (PROFIBUS Slave)
www.adfweb.com? roduct=HD67912 (PROFINET Slave)
www.adfweb.com? roduct=HD67913 (SNMP Agent)
Do you have your customer protocol? Then go to:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 2 of 35
IN EX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
OWER SU LY 8
FUNCTION MODES 9
LEDS 10
HART 11
ETHERNET 12
RS485 13
USE OF COM OSITOR SW67901 14
NEW CONFIGURATION / O EN CONFIGURATION 15
SOFTWARE O TIONS 16
SET COMMUNICATION 18
HART VARIABLES 20
SET BACNET ACCESS 22
EDE FILE 23
U DATE DEVICE 24
SCAN FUNCTION 26
WEBSERVER INTERFACE 28
MECHANICAL DIMENSIONS 32
ORDERING INFORMATIONS 33
ACCESSORIES 33
DISCLAIMER 34
OTHER REGULATIONS AND STANDARDS 34
WARRANTIES AND TECHNICAL SU ORT 35
RETURN OLICY 35
UP ATE OCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRA EMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision ate Author Chapter escription
1.000 18/06/2020 Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 3 of 35
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTEN E U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIE P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESI UAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 4 of 35
EXAMPLES OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 5 of 35
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67901 IP A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 6 of 35
Figure 1a: Connection scheme for HD67901 MSTP A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 7 of 35
CHARACTERISTICS:
The HD67901-xxxx-A1 are BACnet Slave / HART Master - Converters.
It allows for the following characteristics:
Triple isolation between BACnet - ower Supply, BACnet - HART, HART - ower Supply;
Two-directional information between BACnet bus and HART bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67901 software on your C in order to perform the following:
Define the parameters of BACnet line;
Define the parameters of HART line;
Define HART variables in read/write;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 8 of 35
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
V C
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
evice Consumption [W/VA]
HD67901-XXXX-A1 3.5
HD67901-XXXX-A1
Caution:
o n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 9 of 35
FUNCTION MO ES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 10 of 35
LE S:
The device has got six LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LE Normal Mode Boot Mode
1: Device State
(green) Blinks slowly (~1Hz) Blinks quickly: Boot state Blinks very slowly (~0.5Hz): update in progress
2: HART communication
(green) It blinks when HART communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Ethernet link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
4: BACnet communication
(green) It blinks when a BACnet request is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 11 of 35
HART:
“HART” is an acronym for Highway Addressable Remote Transducer. The HART rotocol makes uses Frequency Shift Keying (FSK) standard
to superimpose digital communication signals at a low level on top of the 4-20mA. This enables two-way field communication to take place
and makes it possible for additional information beyond just the normal process variable to be communicated to/from a smart field
instrument.
It is possible to provide the current loop for HART communication and an additional low power supply @ 24 V DC for feeding HART devices
by setting Dip-Switch D at ON position.
Current loop for HART is required when there is not an external device in the bus that provides it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 12 of 35
ETHERNET:
The updating of the converters and BACnet/I communication must be made using Connector4 of the HD67901-XXXX-A1 with at least a
Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to
connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the
device to a C/ LC/other is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 13 of 35
RS485 (for BACnet MS/TP version):
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 14 of 35
USE OF COMPOSITOR SW67901:
To configure the Converter, use the available software that runs with Windows called SW67901. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67901, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window
for SW6790
1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 15 of 35
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “BACnet Slave / HART Master” in order
to configure another device in the same manner, it is necessary to maintain the folder
and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 16 of 35
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67901 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 17 of 35
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 18 of 35
Figure 3
a
: “Set Communication” window
SET COMMUNICATION:
This section define the fundamental communication parameters of HART and BACnet
buses.
By ressing the “Set Communication” button from the main window for SW67901 (Fig.
2) the window “Set Communication” appears (Fig. 3).
In the section “BACnet Slave” is possible to select the type of BACnet to use from:
BACnet/I (uses Ethernet);
BACnet MS/T (uses RS485).
The means of the fields for the “HART Master” section are:
In the field “Address” the type of Master is defined;
In the field “Retry Limit” the maximum number of retries in case of missing
response from HART device is defined;
If selected “BACnet/I ” the means of the fields for “BACnet” are:
In the fields “IP A RESS” the I address of BACnet/I side of the converter is
defined;
In the fields “SUBNET Mask” the SubNet Mask of BACnet/I side of the converter
is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature is
used for going out of the net;
In the field “Port” the port used for BACnet communication is defined. The default
port used for BACnet communication is 47808, but is possible to insert any value;
In the field "BACnet evice Name" the name of BACnet/I side of the converter is
defined;
In the field “ evice Identifier” the ID of BACnet/I side of the converter is
defined;
If the field “BACnet description up to 32 chars” is checked, the description of
the BACnet objects can be up to 32 chars.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 19 of 35
Figure 3b: “Set Communication” window
The means of the fields for the “Web ages” section are:
In the field “User” the user name for webserver’s authentication is defined;
In the field “Password” the password for webserver’s authentication is defined.
If selected “BACnet MS/T ”, the means of the fields for “BACnet” are:
In the field “Baudrate” the data rate of the BACnet line is defined;
In the field “Parity” the parity of the line is defined;
In the field “BACnet evice Name” the name to give to the BACnet node is
defined;
In the field “MAC Address” the MAC of BACnet node (from 0 to 254) is defined;
The field “Max Master” specifies the highest allowable address for master nodes.
The value shall be less than or equal to 127;
The field “Max Info Frames” specifies the maximum number of information
frames the node may send before it must pass the token;
In the field “ evice Instance” the of the BACnet MS/T side of the converter is
defined;
In the field “Network” the BACnet MS/T network number is defined;
If the field “BACnet description up to 32 chars” is checked, the description of
the BACnet objects can be up to 32 chars.
The means of the fields for the “Ethernet Update” section are:
In the fields “IP A RESS” the I address of the converter is defined;
In the fields “SUBNET Mask” the SubNet Mask of the converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature is
used for going out of the net.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
BAC
net
Slave / HART Master
Document code: MN67901_ENG Revision 1.000 age 20 of 35
Figure 4: “HART Variables” window
HART VARIABLES:
By ressing the “HART Variables” button from the main window for SW67901 (Fig. 2) the window “Definition of HART Variables List”
appears (Fig. 4).
This section is used to define the HART variables to read/write with the BACnet Master.
The means of the fields are:
If the field “Enable” is checked, the HART variable is enabled;
In the field “ evice Address” the address of HART device is defined;
In the field “Preamble Count” the number of bytes for the synchronization is defined;
If the field “Type” the type of HART parameter is defined;
In the field “Var/Cmd Number” the identification of variable/command to read/write is defined. From HART standard, the most used
numbers are:
o246: rimary Variable;
o247: Secondary Variable;
o248: Tertiary Variable;
o249: Quaternary Variable.
