ADJ WiFLY EXR QA5 IP User manual

User Instructions
Rev. 8/15
©2015 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building, and
electrical damages, injuries to any persons, and direct or indi-
rect economic loss associated with the use or reliance of any
information contained within this document, and/or as a result
of the improper, unsafe, unsucient and negligent assembly,
installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!
WiFLY EXR QA5 IP

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 3
• Rechargeable Lithium Battery
• Multi-Colors
• Five Operating Modes
• Electronic Dimming 0-100%
• Built in Microphone
• DMX-512 protocol
• 3-Pin DMX Connection
• 5 DMX Channel Modes: 4 Channel Mode, 5 Channel Mode, 6
Channel Mode, 10 Channel Mode, & 11 Channel Mode
• Built-In ADJ’s WiFly TransCeiver Wireless DMX
• ADJ RFC compatiable (Not Included)
• Power Cord Daisy Chain (See page 32)
WiFly EXR QA5 IP Warranty Registration
WiFly EXR QA5 IP Features
The WiFly EXR QA5 IP carries a 2 year limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper included in the shipping carton. If
the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our customer support number. All pack-
ages returned to the service department not displaying a R.A. number
on the outside of the package will be returned to the shipper.
The unit should be mounted using a mounting clamp (not provided),
axing it to the mounting bracket that is provided with the unit.
Always ensure that the unit is rmly xed to avoid vibration and slip-
ping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10
times the unit’s weight. Also, always use a safety cable that can hold
12 times the weight of the unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
WiFly EXR QA5 IP Installation
WiFly EXR QA5 IP Introduction
ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 2
Unpacking: Thank you for purchasing the WiFly EXR QA5 IP by ADJ
Products, LLC. Every WiFly EXR QA5 IP has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your x-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without rst
contacting customer support.
Introduction: The WiFly EXR QA5 IP is a rechargeable lithium battery
powered, DMX intelligent, LED par fixture with ADJ’s WiFly TransCeiver
with wireless DMX built-in. This unit give you the freedom to set up
your fixture where ever you wish without the restrictions of power or
DMX cabling. The built-in battery will keep charge for up to 6 hours (full
on) from a full, single charge. This xture can be used in a stand alone
mode or connected in a Master/Slave conguration. This wash has six
operating modes: Color Fade mode, Color Change mode, Auto mode,
RGBA Dimmer mode, Static Color mode, and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer support
line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do
not attempt any repairs yourself, doing so will void your manufac-
tures warranty. In the unlikely event your unit may require service
please contact ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 5
WiFly EXR QA5 IP Safety Precautions
ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 4
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken. Do not attempt to remove or break o the ground
prong from the electrical cord. This prong is used to reduce the risk
of electrical shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Never plug this unit in to a dimmer pack
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out`
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to the point they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
t he manufacturer. See page 32 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances (inclu-
d ing amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C. The appliance has been exposed to rain or water.
D. The appliance does not appear to operate normally or exhibits a
marked change in performance.
WiFly EXR QA5 IP IP Notice
IP65 RATED
An IP rated lighting fixture is one, which is commonly installed in outdoor
environments and has been designed with an enclosure that effectively
protects the ingress (entry) of external foreign objects such as dust and
water. The International Protection (IP) rating system is commonly expressed
as "IP" (Ingress Protection) followed by two numbers (i.e. IP65) where the
numbers define the degree of protection. The first digit (Foreign Bodies
Protection) indicates the extent of protection against particles entering the
fixture and the second digit (Water Protection) indicates the extent of
protection against water entering the fixture. An IP65 rated lighting fixture is
one, which has been designed and tested to protect against the ingress of
dust (6) and high-pressure water jets from any direction (5).
MARINE/COASTAL ENVIRONMENT INSTALLATIONS!
Please note although this fixture is IP rated, the fixture is NOT suitable for
marine and/or coastal environment installations. Installing this fixture in a
marine and/or coastal environment may cause corrosion and/or excessive
wear to the interior and/or exterior components of the fixture. Damages
and/or performance issues resulting from installation in a marine and/or
coastal environment will void the manufactures warranty and will NOT be
subject to any warranty claims and/or repairs.
Ensure ALL connections and end caps are properly sealed with a non-
conductive dielectric grease (available at most electrical suppl
iers) to
prevent water ingress/condensation and/or corrosion.
OPTIONAL CORROSION-RESISTANT COATING
Optional Corrosion-Resistant Coatings may be available for this fixture.
Please consult your Elation Professional sales representative for details.

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 7
ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 6
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on con-
ductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of compo-
nents, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do Not Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other prob-
lems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
WiFly EXR QA5 IP Battery Precautions
WiFly EXR QA5 IP Protective Vent

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 9
ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 8
life expectancy of the battery maybe shortened or the device
in which the battery is used may be damaged by electrolyte
gel leakage. If the batteries cannot maintain a charge for long
periods of time, even when they are charged correctly, this may
indicate it is time to change the battery.
6. Battery Disposal
Please dispose of battery according to local regulations.
WiFly EXR QA5 IP Battery Precautions
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawa-
ter, drinks such as soft drinks, juices, coee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ customer support
[phone].
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including dam-
ages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery per-
formance will deteriorate over time even if stored for a long
period of time without being used. In addition, if the various
usage conditions such as charge, discharge, ambient tempera-
ture, etc. are not maintained within the specied ranges, the
WiFly EXR QA5 IP Battery Precautions

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 11ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 10
WiFly EXR QA5 IP Set Up
Power Supply: The ADJ WiFly EXR QA5 IP contains an automatic
voltage switch, which will auto sense the voltage when it is plugged
into the power source. With this switch there is no need to worry about
the correct power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from
the controller to the fixture. DMX data is sent as serial data that trav-
els from fixture to fixture via the DATA “IN” and DATA “OUT” XLR ter-
minals located on all DMX fixtures (most controllers only have a DATA
“OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models of
dierent manufactures to be linked together and operate from a single
controller, as long as all xtures and the controller are DMX compli-
ant. To ensure proper DMX data transmission, when using several
DMX fixtures try to use the shortest cable path possibl e. The order
in which fixtures are connected in a DMX line does not influence the
DMX addressing. For example; a fixture assigned a DMX address of 1
may be placed anywhere in a DMX line, at the beginning, at the end,
or anywhere in the middle. When a fixture is assigned a DMX address
of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
DMX Cable Requirements: The WiFly EXR QA5 IP can be controlled
via DMX-512 protocol. The WiFly EXR QA5 IP has 5 DMX channel modes,
please see pages 14-15 for the dierent modes. The DMX address is set
on the back panel of the WiFly EXR QA5 IP.
Cable Requirements: This xture is designed with special cables for
both DMX and power. These cables are specically designed to maintain
the integrity of the IP rating. When using this xture outdoors be sure to
ONLY use the ADJ cables that have been manufactured to meet the IP
rating.
“First” DMX Cables - Special DMX “First” cable (part #WIF901-DMX
Cable) may be purchased from ADJ to provide a means of data com-
munication with standard DMX xtures for indoor use. These cables will
come with the IP rated twist lock connector on one end and either a
3-pin XLR male or female connector on the other depending on model.
WiFly EXR QA5 IP Set Up
Be sure to only use these cables for intergrading this xture in a standard
DMX chain.
“First” Power Cable – A special power “First” cable is included with
every xture. This cable is used to provide power to your xture. This
cable comes with the IP rated twist lock connector on one end and a
standard Edison 3-prong, grounded prong on the other end. Be sure to
only use this cable for power distribution and never attempt to connect
this cable to the DMX lines.
You can chain multiple xtures together through serial linking. Using
the IP rated signal cables provided through ADJ (part# WIF901-Power
Cable). Always be sure to daisy-chain your in and out data connec-
tions, never split or “Y” your DMX connections unless you are using an
approved DMX splitter such as the ADJ WiFly D6 Branch or the original
D6 Branch (Both not IP rated).
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OUT
3-PIN XLR
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Do Not Use
Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 13ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 12
WiFly EXR QA5 IP Operating Instructions
adjust the intensity of each color to make your desired color.
• Auto Mode - Will run a mixture of color fade and change.
• Color Change Mode - There are 16 color change modes to choose
from.
• Color Fade Mode - There are 16 color fade modes to choose from.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
RGBA Dimmer Mode:
1. Plug the fixture in and press the MODE button until “MANUAL” is
displayed. Then press the SET UP button to scroll through RGBA
colors.
2. When “RED:XXX” is displayed you are in Red dimming mode.
Press the UP and DOWN buttons to adjust intensity.
3. When “GREN:XXX” is displayed you are in Green dimming
mode. Press the UP and DOWN buttons to adjust intensity.
4. When “BLUE:XXX” is displayed you are in Blue dimming mode.
Press the UP and DOWN buttons to adjust intensity.
5. When “AMBR:XXX” is displayed you are in Blue dimming mode.
Press the UP and DOWN buttons to adjust intensity.
6. After you have adjusted the RGBA colors to make your desired
color you can then activate strobing by pressing the SET UP but-
ton to enter the strobe mode.
7. “STROB.XX” will be displayed, this is strobe mode. The Flash can
be adjusted between 00 (flash off) to 15 (fastest flash).
Color Change Mode:
1. Plug the fixture in and press the MODE button until “JUMP RUN
SNAP:XX” is displayed. “XX” represents a number between 01-16.
2. Use the UP and DOWN buttons to find your desired color change
mode.
3. Press the SET UP button and “SPEED:XX” will be displayed. Use
the UP and DOWN buttons to adjust the speed of the color
change.
Color Fade Mode:
1. Plug the fixture in and press the MODE button until “FADE RUN
FADE:XX” is displayed. “XX” represents a number between 01-16.
2. Use the UP and DOWN buttons to find your desired color fade
WiFly EXR QA5 IP Operating Instructions
Operating Power:
There are two ways to supply power to this unit; battery power or AC
power.
• AC Power - To run the unit using AC power, plug the unit into a
power source and activate the battery load on page 15. When using
AC power make sure the battery button is in the OFF position.
• Battery Power - To run the unit using Battery power, press the bat-
tery button located on the bottom of the fixture across from power
input connection. Follow the instructions on page 15 to activate the
battery load.
LCD Display Lock:
The display will lock after 30 seconds. Press and hold the MODE
button for at least 10 seconds to unlock the display and access the
menu.
Energy Saving Mode
This will decrease the LED’s brightness gradually when the battery
life is less than 80%, this is will extend the battery life.
1. To activate energy saving mode, press the MODE button until
“BATT LEV” is displayed.
2. Press the SET UP button until “BATT LEV SAVE:XX” is displayed.
“XX” represents either “ON” or “OFF”.
3. Press the UP or DOWN button so that “ON” is displayed. If “ON”
is displayed already then the fixture is already in energy saving
mode.
LED Display On/Off:
To set the LED display light to turn off after 20 seconds, press the
MODE button until “OPTION” is displayed. Press the SET UP button
so that BLGT:XXX” is displayed. “XXX” represents either ON or OFF.
Press the UP or DOWN buttons so that OFF is displayed. Now the
display light will turn off after 30s. Press any button to turn the dis-
play on again.
Operating Modes:
The WiFly EXR QA5 IP has six operating modes:
• Static Color Mode - There are 64 colors to choose from.
• RGBA Mode - Choose one of the four colors to remain static or

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 15ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 14
WiFly EXR QA5 IP Operating Instructions
scroll through the DMX Channel modes.
4. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX con-
troller.
Battery Life:
This is used to check/display the battery life.
1. Plug the fixture in and press the MODE button until “BATT LEV
XXX” is displayed. “XXX” represents the remaining battery life. If
“BATT LEV ----” is displayed, it means either the battery is dead or
your running the unit on AC power.
Battery Load:
This is used to activate the PC board On.
1. Press the MODE button until “BATT LEV” is displayed.
2. Press the SET UP button until “BATT LEV LOAD:XX” is displayed.
“XX” represents either “ON” or “OFF”.
3. Press the UP or DOWN button so that “ON” is displayed. If “ON”
is displayed already then the PCB is active.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “OPTION
BLGT:XX” is displayed. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “SYSRESET” is displayed.
3. Press the UP and DOWN buttons simultaneously to reset to
default settings.
ADJ RFC:
This function is used to activate and deactivate the ADJ RFC (Remote
Control). When this function is activated you can control the fixture
using the ADJ RFC. Please see the next page for ADJ RFC controls
and functions.
1. Plug the fixture in and press the MODE button until “OPTION” is
displayed.
2. Press the SET UP button until “RFXX” is displayed. “XX” repre-
sents either “ON” or “OFF”.
3. Press the UP or DOWN buttons to either activate the remote func-
WiFly EXR QA5 IP Operating Instructions
mode.
3. Press the SET UP button and “SPEED:XX” will be displayed. Use
the UP and DOWN buttons to adjust the speed of the color
fade.
Auto Run Mode:
In this mode the WiFly EXR QA5 IP will run a auto program.
1. Plug the fixture in and press the MODE button until “AUTO RUN
FAD+SNAP” is displayed.
2. Press the SET UP button and “SPEED:XX” will be displayed. Use
the UP and DOWN buttons to adjust the speed of the Auto Run.
Static Color Mode:
1. Plug the fixture in and press the MODE button until “CLR MACS
COLOR:XX” is displayed. “XX” represents a number between
00-64.
2. Use the UP and DOWN buttons to scroll through the 64 colors
and find you desired color. After you have found your desired
color you can activate strobing by pressing the SET UP button to
enter the strobe mode.
3. “STROB:XX” will be displayed, this is strobe mode. The strobing
can be adjusted between “00” (flash off) to “15” (fastest flash).
DMX Mode:
Operating through a DMX controller gives the user the freedom to
create their own programs tailored to their own individual needs. This
function also allows you to use your fixtures as spot lights. The WiFly
EXR QA5 IP has 5 DMX modes: 4 Channel mode, 5 Channel mode,
6 Channel mode, 10 Channel mode, and a 11 Channel mode. See
pages 19-26 for each mode’s DMX traits.
1. This function will allow you to control each individual fixture’s
traits with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“DMX MODE ADDR:XXX” is displayed. “XXX” represents the dis-
played DMX address. Use the UP or DOWN buttons to scroll
through and find your desired DMX address.
3. After you have set your DMX address press the SET UP button so
that “CHAN:XX” is displayed. “XX” represents the current DMX
Channel mode that is displayed. Use the UP or DOWN buttons to

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 17ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 16
tion (On) or deactivate it (Off).
WiFLY Address Setting/WiFly On/Off:
This function is used to set the WiFly address and activate/deactivate
the WiFly function. The address must match the address that is set to
your WiFly TransCeiver or WiFly controller.
1. Plug the fixture in and press the MODE button until “WIFI SET
ADDR: XX” is displayed. “XX” represents a number between
00-14.
2. Use the UP or DOWN buttons to find and set your desired WiFly
address. The address must match the address that is set to your
WiFly TransCeiver or WiFly controller.
3. After you have found and set your WiFly address, press the SET
UP button to activate WiFly. “WIFI SET STAT: XXX” will now be
displayed. Use the UP or DOWN button to set the display to “On”
to activate WiFly. To deactivate WiFly set the display to “Off”.
DMX State:
This mode can be used as a precaution mode, that in case the DMX
signal is lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You can also
set this as the operating mode you would like the unit to return to when
power is applied.
1. Plug the fixture in and press the MODE button until “DMX MODE
ADDR:XXX” is displayed.
2. Press the SET UP button until “DMX MODE NO: XXXX” is dis-
played. “XXXX” represents the current DMX state that is displayed.
3. Use the UP or DOWN buttons to select the operating mode you
would like the unit to start up in when power is applied or the
DMX signal is lost.
• AUTO - If the DMX signal is lost or power is applied, the unit will auto-
matically into Auto Run.
• BLACK - If the DMX signal is lost or power is applied, the unit will
automatically go into stand by mode.
• HOLD - If the DMX signal is lost the xture will stay in the last DMX
set up. If power is applied and this mode is set, the unit will automati-
WiFly EXR QA5 IP Operating Instructions
cally go into the last DMX set up.
Dimmer Curve Setting:
This is used to set the dimming curve used with DMX mode. See
page 29 for the different dimming curves.
1. Plug the fixture in and press the MODE button until “DMX MODE
ADDR:XXX” is displayed.
2. Press the SET UP button until “DELAY:X” is displayed. “X” repre-
sents the displayed dimmer curve (0-4).
• 0 - Standard
• 1 - Stage
• 2 - TV
• 3 - Architectural
• 4 - Theatre
3. Press the UP or DOWN buttons to scroll through and select your
desired dimming curve
WiFly EXR QA5 IP Operating Instructions

ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 19
ADJ Products, LLC - www.adj.com - WiFly EXR QA5 IP User Manual Page 18
WiFly EXR QA5 IP Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-
Slave setup. In a Master-Slave set up one unit will act as the control-
ling unit and the others will react to the controlling units built-in pro-
grams. Any unit can act as a Master or as a Slave however, only one
unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the
unit. Use standard XLR data cables to link your units together.
Remember that the Male XLR connector is the input and the
Female XLR connector is the ouput. The first unit in the chain
(master) will use the female XLR connector only. The last unit in
the chain will use the male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. On the “Slave” units press the MODE button until “Slave Mode” is
displayed. The unit is now set as the “Slave” unit. Each slave unit
must be set to the same setting.
4. Connect the rst “Slave” unit to the “Master”, and the “Slave” unit
should now start to follow the “Master”.
WiFly EXR QA5 IP WiFly Set Up
WiFly EXR QA5 IP WiFly Master-Slave Set Up
With this feature you are able to control the unit with DMX without the
need of XLR cables. Your DMX controller must be connected to a ADJ
WiFly Transceiver to use this function. You are able to communicate
up to 2500 feet/760 meters (open line of sight).
1. Follow the instructions on pages 15-16 to set the WiFly address
and to activate WiFly. The address must match the address set
on the WiFly WiFly Transceiver.
2. After you have set the WiFly address, follow the DMX instructions
on page 14 to select your desired DMX Channel mode and set
your DMX address.
3. Apply power to the ADJ WiFly Transceiver. The fixture must be set
up first before you apply power to WiFly Transceiver.
4. If everything is set up properly and the fixture is receiving a
Wireless signal, you should now be able to control it with a DMX
controller.
This feature will let you link units to run in a master-slave mode with-
out the use of XLR cables.
1. Follow the instructions on pages 15-16 to set the WiFly address
and to activate WiFly. The addresses on each fixture must be the
same.
2. After you have set the WiFly address, select your “Master” unit
and set your desired operating mode.
3. For the “Slave” unit(s), put the unit in Slave mode. See page 12
Master-Slave configuration when setting the unit as a Slave.
4. If everything is set up correctly, the “Slave” units will start follow-
ing the “Master” unit.
