Introduction 1
VPX3001
1 Introduction
1.1 Overview
The VPX3001 Series is a 3U VPX processor blade featuring the
3rd Generation Intel® Core™ i7 processor with Mobile Intel®
QM77 Express Chipset. The VPX3001 provides up to 8GB
DDR3-1066/1333 dual channel ECC memory soldered onboard,
one PCI Express x8 XMC.3 site with VITA 46.9 rear IO, and
onboard soldered 32GB SLC SATA solid state drive. Rear I/O via
P1 and P2 includes 2x 1000BASE-T or 2x 1000BASE-BX (BOM
option), 1x SATA 6 Gb/s, 1x SATA 3 Gb/s, 2x USB 2.0, 6x GPIO,
VGA, 1x RS-232, and 1x RS-232/422.
A VPX-R3001 Rear Transition Module is available to access rear
I/O signals and a 9-slot 3U VPX Test Frame is available for users
to validate VPX3001 functionality.
The VPX3001 Series is rugged conduction cooled with conformal
coating, making it ideal for mission critical applications in radar;
intelligence, surveillance and reconnaissance (ISR); and
UAV/UGV platforms.

2Introduction
Leading EDGE COMPUTING
1.2 Features
X3U VPX VITA 46, OpenVPX VITA 65, VPX REDI 48
X4HP (0.8") rugged conduction cooled 3U VPX blade with
conformal coating
XIntel® 3rd generation Core™ i7-3612QE Processor (4 cores,
6M cache, 2.1 GHz, 35W TDP)
XDual channel DDR3-1333/1666 SDRAM with ECC soldered
onboard, up to 8GB
XIntel® QM77 PCH
XIntel® HD Graphics 4000 with DX11, OpenGL 3.1 and OCL 1.1
XOnboard PCI Express x8 XMC site with VITA 46.9 rear I/O
XOnboard 32GB SLC SATA Solid State Drive
XData Plane: VITA 46.4 PCIe 2.0 x8, or 2x PCIe 2.0 x4 to P1,
supports NTB function
XControl Plane: VITA 46.6 2x 1000BASE-T or 2x
1000BASE-BX (BOM option)
XRear I/O:
ZP1: 2x 1000BASE-T or 1000BASE-BX (BOM option), 1x
SATA 6 Gb/s, 2x USB 2.0, 1x RS-2326x GPIO
ZP2: VGA, DVI, RS-232/422, XMC-x24s+x8d+x12d
XRAID 0/1/5/10 support
XuEFI BIOS 64Mb SPI flash
XModule Profile: MOD3-PAY-2F2T-16.2.5-3 or
MOD3-PAY-2F2U-16.2.3-3 (BOM option)
XSlot Profile: SLT3-PAY-2F2U-14.2.5 or
SLT3-PAY-2F2U-14.2.3 (BOM option)

Introduction 3
VPX3001
1.3 Block Diagrams
Figure 1-1: VPX3001 Functional Block Diagram
Quad-core 3rd Gen
Intel® Core™ i7
Intel® QM77
PCH
DMIFDI
DDR3-1600
XMC
PCIe 2.0 x8
PCIe Switch
PEX8619
PCIe 2.0 x8
LPC
F81216D
UART UART
RS-232
UART
32GB Flash
1x SATA 3Gb/s
BIOS
PCIe 2.0 x4
GbE
Intel 82580EB
1000BASE-T
1000BASE-T
[1000BASE-BX]
[1000BASE-BX]
2x USB 2.0
1x SATA 6Gb/s
VGA
P2P1P0
IPMC
IPMB
GPIO
COM1
P2
1000BASE-T
1000BASE-T
X24s+x8d+x12d
P2
DDR3-1600
BASE-T
[opt. BASE-BX]
1x PCIe x8
or
2x PCIe x4
GPIO 0-5
[1000BASE-BX]
[1000BASE-BX]

4Introduction
Leading EDGE COMPUTING
Figure 1-2: VPX-R3001 RTM Functional Block Diagram
RP0
RP1
RP2
VS1(DC12V), 8A/Slot
VS2(DC3V), 8A/Slot
VS3(DC5V), 16A/Slot
DC3V_AUX, 1A/Slot
DC12V_AUX, 1A/Slot
DC-12V_AUX, 1A/Slot
VBAT
NVMRO, SYSRESET#
1000BASE-BX x2 ports, SERDES (optional)
1000BASE-BX
1000BASE-T 1000BASE-T x2 ports
SATA x1 port
SATA
VGA x1 port
VGA
USB 2.0 x2 port
USB 2.0
RS232 x1 port
RS232
RS232 x1 port
RS232
GPIO x4 port
GPIO 0-3
XMC x1 port
XMC
PCIe x8 PCIe x8
JTAG
SMBus

Introduction 5
VPX3001
1.4 Model Number Decoder- Processor Blade
(A) CPU Code
Z3612 = Quad-Core Intel® i7-3612QE processor
Z3555 = Dual-Core Intel® i7-2655LE processor
(B) Memory Size Code
ZM8 = Onboard 8GB DDR3-1333/1600 memory
ZM16 = Onboard 16GB DDR3-1333/1600 memory
(C) SATA NAND Flash Size Code
ZS32 = Onboard 32GB
(D) Ruggedized Level Code
ZR1 = Conduction Cooled version with conformal coating
supporting -40°C to +75°C at card edge
ZR2 = Conduction Cooled version with conformal coating
supporting -40°C to +85°C at card edge
VPX3001/3612/M8/S32-R1
(A) (B) (C) (D)

6Introduction
Leading EDGE COMPUTING
1.5 Package Contents
The VPX3001 is packaged with the following components. If any
of the items on the contents list are missing or damaged, retain the
shipping carton and packing material and contact the dealer for
inspection. Please obtain authorization before returning any prod-
uct to ADLINK. The packing contents of the VPX3001 are
non-standard configurations and may vary depending on customer
requests.
Processor Blade
XVPX3001
ZCPU and memory specifications will differ depending on
options selected
ZThermal module is assembled on the board
Rear Transition Module
XVPX-R3001 RTM
Test Backplane
XtBP-VPX3000 test backplane
NOTE:
NOTE:
The contents of non-standard VPX3001 configurations may
vary depending on the customer requirements.
CAUTION:
This product must be protected from static discharge and phys-
ical shock. Never remove any of the components except at a
static-free workstation. Use the anti-static bag shipped with the
product when putting the board on a surface. Wear an
anti-static wrist strap properly grounded on one of the system's
ESD ground jacks when installing or servicing system compo-
nents.

Specifications 7
VPX3001
2 Specifications
2.1 VPX3001 Blade Specifications
VITA Standards • VITA 46.0 VPX Base Standard
• VITA 46.4 PCI Express on VPX Fabric Connector
• VITA 46.6 Gigabit Ethernet Control Plane on VPX
• VITA 46.9 PMC/XMC/Ethernet Signal Mapping to 3U/6U
VPX
• VITA 46.11(draft) System Management on VPX
• VITA 48.0 Ruggedized Enhanced Design Implementation
Mechanical Base Specification
• VITA 65 OpenVPX Architecture Framework for VPX
Mechanical • IEEE 1101.1-1998 - Mechanical Core Specifications for
Microcomputers
• IEEE 1101.2-1992 - Conduction Cooled VME Mechanics
•3U4HP(0.8")
• Board size: 100mm x 160mm
• P0, P1, P2 connectors; alignment key 1 & 2 equipped
Processor • Intel® Core™ i7-3612QE Processor, 2.1 GHz, 6MB LLC
cache, FCBGA1023, TDP 35W
• Intel® Core™ i7-3555LE Processor, 2.5 GHz, 4MB LLC
cache, FCBGA1023, TDP 25W
• Passive ruggedized heatsink
Chipset • Intel® BD82QM77 Platform Controller Hub (PCH)
Memory • Dual channel DDR3-1333/1600 ECC memory
• Soldered onboard with 256Mb*8*18 devices
• Up to 8GB
PCI Express • PCI Express 2.0 x8, or 2x PCIe x4 to P1 by switch setting
• Supports NTB function
Gigabit
Ethernet
• One Intel® 82580EB Gigabit Ethernet Controller
• Two 10/100/1000BASE-T port or two 1000BASE-BX
SerDes ports to P1 (BOM option)
Graphics • Integrated in Intel® Core™ i7 processor
• Intel HD Graphics 4000
• Analog VGA routed to P2
• Analog monitor support up to 2048x1536 at 75Hz
Table 2-1: VPX3001 Blade Specifications

8 Specifications
Leading EDGE COMPUTING
XMC • One PCIe 2.0 x8 conduction cooled XMC.3 site
• XMC I/O connector compliant to VITA 46.9,
X24s+X8d+X12d
Front Panel I/O • Reset button
• Power LED
Storage
Interfaces1
• Onboard SATA NAND flash on SATA 3 Gb/s, up to 32GB
• One SATA 6 Gb/s port to P1
BIOS • AMI EFI BIOS, 64Mbit SPI flash memory
P1 Interface • 1x SATA ports
• 2x USB 2.0
•1xRS-232
•6xGPIO
•PCIex8
• 2x 1000BASE-T Gigabit Ethernet Ports or 2x 1000BASE-BX
SerDes Port
P2 Interface •VGA
• RS-232/422
• XMC X24s+X8d+X12d
Environmental • Operating Temperature:
R1: -40°C to +75°C at card edge
R2: -40°C to +85°C at card edge
• Storage Temperature: -50°C to 100°C
• Humidity: 95%, non-condensing
• Shock: Sawtooth 40G, 11ms, each axis, operating
• Vibration: 15Hz-2KHz, 12Grms, random, each axis,
operating
• Altitude: 60,000 feet, operating
EMI • CE EN55022
• FCC Class A
Table 2-1: VPX3001 Blade Specifications

Specifications 9
VPX3001
2.2 VPX-R3001 RTM Specifications
Note: Specifications are subject to change without prior notice.
VITA Standards • VITA 46.10 Rear Transition Module on VPX
Mechanical • 100mm x 80mm
Faceplate I/O • VGA port
• 2x 1000BASE-BX connectors
Onboard
Interfaces
• 2x 1000BASE-T vertical connectors
• 1x SATA 6Gb/s ports
• 2x 5 pin header for RS-232 x2
• 2x 5 pin header for USB x2
• 2x 5 pin header for JTAG
• 1x 5 pin header for SMBus
• 8x pin headers for GPIO
•XMCport
• 4x status LEDs for GPIO
• 1x reset push button
Table 2-2: VPX-R3001 RTM Specifications

10 Specifications
Leading EDGE COMPUTING
2.3 Power Consumption
This section provides information on the power consumption of the
VPX3001 Series when using Intel® Core i7 processors with Dual
Channel 8GB DDR3-1333 soldered memory and soldered onboard
32GB SATA SSD. The VPX3001 is powered by 12V, 5V and 3.3V.
Power consumption at 100% CPU usage was measured by running
PassMark BurnInTest and Intel Thermal Analysis Tool (TAT).
Quad-Core Intel® Core™ i7-3612QE 2.1 GHz, 6MB cache, 35W
*Windows 7 (Typical) power consumption running BurnInTest at 100%
loading.
**Windows 7 (Max loading) power consumption running Intel TAT test at
100% loading.
Item
BIOS EIST/C-state Enabled BIOS EIST/C-state Disabled
Current(A)/
Voltage(V) Power(W) Current(A)/ Voltage(V) Power(W)
S1
1.69/5
0.47/12
0.69/3.3 16.367 1.67/5
0.47/12
0.71/3.3 16.333
Windows 7
(idle)
2.04/5V
0.11/12V
0.68/3.3V 13.764 2.04/5V
0.34/12V
0.67/3.3V 16.491
Windows 7
(typical)*
2.55/5V
2.18/12V
0.64/3.3 41.022 2.61/5V
1.45/12V
0.69/3.3 33.177
Windows 7
(max loading)**
2.81/5V
3.29/12V
0.68/3.3 55.774 2.43/5V
3.08/12V
0.67/3.3 51.321
