6304W ONU Gateway
Configuration Guide
Version 1.01
ubiQuoss Inc.
www.ubiQuoss.com
Specifications and product availability are subject to change without notice.
© 2017 ubiQuoss. All rights reserved.

6304W Configuration Guide
Contents
CHAPTER 1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CHAPTER 2 Logging into the Web GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHAPTER 3 Viewing Device Information . . . . . . . . . . . . . . . . . . . . . . . . .7
CHAPTER 4 Viewing WAN Interface Information. . . . . . . . . . . . . . . . . . .9
CHAPTER 5 Configuring WAN Interfaces . . . . . . . . . . . . . . . . . . . . . . . .11
CHAPTER 6 Configuring Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CHAPTER 7 Viewing Wi-Fi Information . . . . . . . . . . . . . . . . . . . . . . . . .19
CHAPTER 8 Configuring Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . .21
CHAPTER 9 Configuring NTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
CHAPTER 10 Configuring Static Routing. . . . . . . . . . . . . . . . . . . . . . . . . .27
CHAPTER 11 Restarting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
CHAPTER 12 Reverting to the Default Setting . . . . . . . . . . . . . . . . . . . . . .33
CHAPTER 13 Upgrading Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
CHAPTER 14 Configuring Backups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Contents
ii 6304W Configuration Guide
CHAPTER 15 Restoring Configuration Files . . . . . . . . . . . . . . . . . . . . . . . 39
CHAPTER 16 Performing Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

6304W Configuration Guide 1
CHAPTER 1 Getting Started
Default Settings
The following table lists the default settings for the four WAN interfaces to provide
triple play services.
TABLE 1-1. Default Settings
Interface Type VLAN Binding LAN Ports Service
1_TR069_R_VID_400 IPoE 400 TR-069
2_VOICE_R_VID_200 IPoE 200 PHONE1, PHONE2 Voice
3_INTERNET_R_VID_100 IPoE 100 LAN1, Wireless(2.4G/
5G)
Internet
4_OTHER_B_VID_300 Bridge 300 LAN2, LAN3, LAN4 IPTV

Getting Started
26304W Configuration Guide
FIGURE 1-1. Rear View

6304W Configuration Guide 3
CHAPTER 2 Logging into the Web GUI
Logging into the Web GUI
Follow these steps to log into the web GUI.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. User names and passwords are case-sensi-
tive.
TABLE 2-1. User Names and Default Passwords
Administrator User
User Name admin useradmin
Default Password admin useradmin

Logging into the Web GUI
46304W Configuration Guide
FIGURE 2-1. Login Screen
Changing Passwords
Follow these steps to change a password.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Management > User Info > User Info.

6304W Configuration Guide 5
Changing Passwords
FIGURE 2-2. User Info
6Select whether to change the user or admin password.
7Enter the user name, the new password, and then confirm the password.
8Click Save/Apply.

6304W Configuration Guide 7
CHAPTER 3 Viewing Device Information
Viewing Device Information
Follow these steps to view device information.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Status > Device Info > Device Basic Info. You can view the device type,
device ID, hardware version, and software version.

Viewing Device Information
86304W Configuration Guide
FIGURE 3-1. Device Basic Info

6304W Configuration Guide 9
CHAPTER 4 Viewing WAN Interface Information
Viewing WAN Interface Information
Follow these steps to view WAN interface information.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Status > WAN Info > IPv4 Info. You can view the interface description,
type, state, DNS address, and IPv4 address.

Viewing WAN Interface Information
10 6304W Configuration Guide
FIGURE 4-1. IPv4 Info

6304W Configuration Guide 11
CHAPTER 5 Configuring WAN Interfaces
Configuring WAN Interfaces
Follow these steps to configure a WAN interface.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Network > WAN > WAN Connection. You can add, modify or delete
WAN connection settings.

Configuring WAN Interfaces
12 6304W Configuration Guide
FIGURE 5-1. WAN Connection

6304W Configuration Guide 13
Configuring WAN Interfaces
•Connection Name
To add a new WAN connection, select Add new WAN.
To modify or delete a WAN connection, select the WAN connection.
•Service Mode
Select from Internet (nat), VoIP (voice), and Other (bridge).
•Binding Port
Select the LAN port to bind to the WAN interface.

Configuring WAN Interfaces
14 6304W Configuration Guide

6304W Configuration Guide 15
CHAPTER 6 Configuring Wi-Fi
Configuring Wi-Fi
Follow these steps to configure Wi-Fi.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Network > WLAN > WLAN. You can configure basic Wi-Fi features.

Configuring Wi-Fi
16 6304W Configuration Guide
FIGURE 6-1. WLAN

6304W Configuration Guide 17
Configuring Wi-Fi
Changing the Wi-Fi Password
Follow these steps to change the Wi-Fi password.
1Connect your device to LAN 1 or Wireless.
2Launch a web browser.
3Connect to 192.168.1.1. A login screen displays.
4Enter the user name and password. The home screen displays.
5Select Network > WLAN > WLAN.
6Click Advance. Security Settings are displayed.
7Select the SSID to change the password for.
The following table lists the default Wi-Fi passwords.

Configuring Wi-Fi
18 6304W Configuration Guide
FIGURE 6-2. Wi-Fi Security Settings
TABLE 6-1. Default Wi-Fi Passwords
Wi-Fi Password
5GHz 1234567890
2.4GHz 12345678
