ADTRAN Aastra 9133i IP User manual

NetVanta Unified Communications
Aastra 9133i IP
User Guide
619500103-1A
October 2009

Enterprise/Business Servers
2 Copyright © 2009 ADTRAN, Inc. 619500103-1A

Enterprise/Business Servers Trademarks
619500103-1A Copyright © 2009 ADTRAN, Inc. 3
Trademarks
Any brand names and product names included in this manual are trademarks, registered trademarks, or
trade names of their respective holders.
To the Holder of the Manual
The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change
the contents without prior notice.
In no event will ADTRAN be liable for any special, incidental, or consequential damages or for
commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Software Licensing Agreement
Each ADTRAN product contains a single license for ADTRAN supplied software. Pursuant to the
Licensing Agreement, you may: (a) use the software on the purchased ADTRAN device only and (b) keep
a copy of the software for backup purposes. This Agreement covers all software installed on the system, as
well as any software available on the ADTRAN website. In addition, certain ADTRAN systems may
contain additional conditions for obtaining software upgrades.
Service and Warranty
For information on the service and warranty of ADTRAN products, visit the ADTRAN website at
http://www.adtran.com/support.
901 Explorer Boulevard
P.O. Box 140000
Huntsville, AL 35814-4000
Phone: [phone]
Copyright © 2009 ADTRAN, Inc.
All Rights Reserved.

Conventions Enterprise/Business Servers
4 Copyright © 2009 ADTRAN, Inc. 619500103-1A
Conventions
Notes provide additional useful information.
Cautions signify information that could prevent service interruption or damage to
equipment.
Warnings provide information that could prevent injury or endangerment to human
life.

Aastra Model 9133i IP Phone User Guide
619500103-1A Copyright © 2009 ADTRAN, Inc. 5
Table of Contents
1 Aastra Model 9133i IP Phone Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Display Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the Aastra Web UI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Using Aastra 9133i IP Phone Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Key Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Placing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Answering Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Holding and Resuming Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Muting and Unmuting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Conferencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Transferring Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Ending Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Forwarding Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Changing the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting Do Not Disturb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Selecting a Ring Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Listing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Accessing Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3 Using NetVanta Unified Communications Server Features . . . . . . . . . 23
Using the UC Server Call Feature Access Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Parking Calls and Picking up Parked Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Picking up Calls Ringing at Another Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using the UC Server Conference Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Queuing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Aastra Model 9133i IP Phone User Guide
6 Copyright © 2009 ADTRAN, Inc. 619500103-1A

Aastra Model 9133i IP Phone Overview
619500103-1A Copyright © 2009 ADTRAN, Inc. 7
1 Aastra Model 9133i IP Phone Overview
This document is designed to outline the features and functions of the Aastra Model 9133i IP phone in
relation to the ADTRAN NetVanta UC Unified Communications Server™. It covers the following topics:
•Overview
•Display Features
•Using the Aastra Web UI
For information about installing and configuring this product, refer to the Installation and Configuration
Guide provided by ADTRAN.
1.1 Overview
This document is not intended to replace the Aastra Model 9133i IP Phone User Guide. For more detailed
information about the product, particularly its operation in the absence of UC server, please refer to the
Aastra User Guide.
1.2 Display Features
Navigation arrow keys
The arrow keys located below the display are navigation keys that allow you to scroll through and select
various options.
Programmable keys
There are two programmable keys, located to the far right of the dial pad, below the Swap key.
You can set the programmable keys with any of the following functions:
• Speeddial
• DND (do not disturb)
•XML
These keys can also be set up to quickly access features such as voicemail.
1.3 Using the Aastra Web UI
You can access the 9133i phone’s options using the Aastra Web UI. To access the Aastra Web UI, you need
to know the IP address of your phone.

Aastra Model 9133i IP Phone Overview
8 Copyright © 2009 ADTRAN, Inc. 619500103-1A
To find your phone’s IP address
1Press the Options button on the phone to enter the Option List.
2Use the Down key to scroll down the list of the options to Phone Status and press the Right Arrow
key to select.
3Select Network Port and press the Right Arrow key.
The IP address of your 9133i IP phone displays in the IP Address field.
To access the Aastra Web UI
1Open your Web browser and enter the phone’s IP address or host name into the address field.
2At the prompt, enter your user name and password and select OK.
The Network Status windows displays for the IP phone you are accessing.
3You can log out of the Aastra Web UI at any time by selecting LOGOFF.
For a user, the default user name is “user” and the password field is left blank.

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 9
2 Using Aastra 9133i IP Phone Features
This chapter outlines the keys and features that are available on the Aastra phone. UC server supports the
following main features of the Aastra Model 9133i IP phone:
•Placing Calls
•Answering Calls
•Holding and Resuming Calls
•Muting and Unmuting Calls
•Conferencing
•Transferring Calls
•Ending Calls
•Redialing
•Forwarding Calls
•Changing the Volume
•Setting Do Not Disturb
•Selecting a Ring Tone
•Listing Calls
•Speed Dialing
•Accessing Voicemail

Aastra Model 9133i IP Phone Features
10 Copyright © 2009 ADTRAN, Inc. 619500103-1A
2.1 Key Descriptions
The following section describes the various 9133i phone key functions, and how they help you make and
manage your calls and caller information.
Hard keys
The following hard keys labeled on your phone are configured for the call-handling features.
These keys are static and cannot be programmed or changed. They are located to the right of the dial pad.
Callers
Conference
Transfer
Redial
Mute

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 11
There are also 3 line keys, labeled L1, L2, and L3, located below the hard keys.
The following keys are configured for managing phone features and settings:
• Options
• Directory
•Save

Aastra Model 9133i IP Phone Features
12 Copyright © 2009 ADTRAN, Inc. 619500103-1A
•Delete
These keys are static and cannot be programmed or changed. They are located to the far upper right of the
dial pad.
2.2 Placing Calls
This section describes ways to make calls on your 9133i phone, using your handset, speakerphone, or
headset.
To dial a number
1Take the handset off-hook by doing one of the following:
• Lift the handset (the phone automatically selects the next open line) and then enter the number.
• Press the speaker phone or headset button, and then enter the number.
• Press a line button, and then enter the number.
2If you are pre-dialing the number, enter the number and then press either the Dial softkey, the speaker
phone or headset button, or one of the four line/call appearance hard keys.
Making and receiving calls using a headset
Make sure that you have selected a headset audio mode by accessing the Options list available from the
phone.

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 13
To make or receive a call using a headset
1Plug the headset into the jack.
2Press the speaker phone/headset key to obtain dial tone or to answer an incoming call.
Depending on the audio mode selected from the Options list, a dial tone or an incoming call is
received on either the headset or handsfree speakerphone.
3Press the phone button to end the call.
2.3 Answering Calls
When a call rings at your extension, the Inbound Call screen appears. The line/call appearance light flashes
quickly for the incoming call.
When you answer the call, the screen changes to the Connected State menu. If you cannot answer the call,
depending on the setting at the system, the call is redirected, for example, to your voicemail box, if your
extension is configured for that.
To answer a call
1If you want handsfree operation, press the Pickup softkey or the line/call appearance button for the
incoming call.
2If you want handsfree or headset operation, press the button for handsfree or headset.
The setting that you have selected in the Options List for Audio Mode determines whether the call
goes to handsfree or headset operation.
3If you want handset operation, lift the handset.
2.4 Holding and Resuming Calls
When you put a call on hold, only your phone can retrieve the call.
To put a call on hold
1Make sure that you are connected to the call that you want to put on hold.
2Press the Hold softkey.
The line/call appearance light begins to flash slowly, and the screen displays “Hold” with the line
number the call is held at on your phone.
Automatic hold
When you are juggling multiple calls, you do not have to press the hold button to go from one call to the
next. The phone automatically puts the current call on hold when you press a new line/call appearance
button.

Aastra Model 9133i IP Phone Features
14 Copyright © 2009 ADTRAN, Inc. 619500103-1A
Retrieving a call from hold
If you have more than one call on hold, you can scroll through the held call information by pressing the
navigation arrow keys. To reconnect to a call, press the line/call appearance button when this call is being
held, or press the Pickup softkey.
2.5 Muting and Unmuting Calls
Press the microphone button to mute handset, headset, or handsfree. The speaker light flashes slowly and
the text “Mute” appears on the screen. You can still hear the caller, but the caller does not hear you. Switch
between mute and unmute by pressing the microphone button.
2.6 Conferencing
The 9133i phone supports up to three parties (including you) in a conference call. This is a 3-way call.
To create a conference call
1Make sure that you are connected to the first party that you want to include in the conference.
2Press the Conf button.
3Dial the number of the person that you want to add to the conference.
4Wait for the new party to answer.
You can consult with the new party before you add them to the conference.
5If you do not want to add the new party to the conference, press the telephone button while connected
to the new call.
This disconnects the new party, leaving the original call on hold.
To go back to the original call, press the line/call appearance button for this call.
6If you want to add the new party to the conference, press the Conf button again.
If you put a muted call on hold, the phone automatically takes the call off mute when you
reconnect to the call.
Only the conference originator can send dual-tone multi-frequency (DTMF) or touch tone
dialing to conference parties. DTMF tones can be used to interact with voicemail systems
and automated attendants.

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 15
To drop a party from the conference
1Use the navigational keys to navigate to the desired party’s call appearance menu, or press the Next
and Previous softkeys (if visible).
2Press the Drop softkey.
2.7 Transferring Calls
There are two types of call transfer: blind transfer and consultative transfer. A blind transfer transfers a call
to directly to another extension, and disconnects the call with the sender when the receiving party answers.
You can also consult with the person you are transferring the call to before you complete the transfer. For a
consultative transfer, remain on the line until the receiving party answers the call. After consulting with the
receiving party, you can either complete the transfer, or go back to the original call.
To blindly transfer a call to another extension
1Make sure that you are connected to the call that you want to transfer.
2Press the Xfer button.
3Enter the extension number of the person to which you want to transfer the call.
4If you decide not to transfer the call, go back to the original call by pressing the line/call appearance
button for the held call.
5Press the Xfer button again to initiate the transfer.
The transfer will complete once the receiving party answers the call.
You can optionally drop out of the transfer before the receiving party answers the call (effectively
resulting in a true blind transfer), by selecting the line/call appearance button for the original inbound
call, and pressing the Drop soft key.
To perform a consultative transfer to another extension
1Make sure that you are connected to the call that you want to transfer.
2Press the Xfer button.
3Enter the extension number of the person to which you want to transfer the call.
4If you decide not to transfer the call, go back to the original call by pressing the line/call appearance
button for the held call.
5Press the Dial soft key to initiate the consultative transfer.
6When the receiving party answers the call, press the Xfer button to complete the transfer.
If instead you would like to cancel the transfer and return back to the original caller, drop the current
call by pressing the Drop soft key, then press the line/call appearance button for the held call.
If you disconnect from the conference, the other two parties also disconnect.

Aastra Model 9133i IP Phone Features
16 Copyright © 2009 ADTRAN, Inc. 619500103-1A
2.8 Ending Calls
To end a call, make sure you are connected to a call, and press the telephone button or the Drop softkey. If
you are connected through the handset, you can also place the handset back on hook to end the call.
2.9 Redialing
Press the Redial button to automatically dial the number that was most recently dialed from your
telephone.
2.10 Forwarding Calls
The call forwarding feature on the IP phone allows incoming calls to be forwarded to another destination.
The phone sends the SIP message to SIP proxy, which then forwards the call to the assigned destination.
Call forwarding is disabled by default. You system administrator can enable call forwarding on a phone-
wide basis or on multi-line phones on a per-line basis. If you have configured call forwarding on an
individual line, then the settings for this line are used; otherwise, the phone-wide call forward settings are
used. You can have up to 9 lines configured for call forwarding.
Setting call forwarding
You can configure phone-wide call forwarding.
To configure phone-wide call forwarding from the IP phone
1Press the Options button on the phone to enter the Options list.
2Select Call Forward.
3Enter the Call Forward number destination to which you want your incoming calls to be forwarded.
4Enter the Call Mode that you want to set on your phone.
5Enter the Number of Rings you want to set before the call is forwarded
Valid values are 1 to 9.
6Press Enter to confirm the settings.
If you leave the Number field blank, call forwarding is disabled.

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 17
To configure phone-wide call forwarding from the Aastra Web UI
1Select Basic Settings > Call Forward.
2In the Mode field, select the mode you want to set on your phone.
3In the Number field, enter the call forward number for which you want your calls to be call
forwarded.
4In the Number of Rings field, enter the number of rings you want to set before the call is forwarded.
Valid values are 1 to 9.
5Select Save Settings to save the Call Forward settings.
The changes are dynamic and are immediately applied to the phone.
To configure per-line call forwarding settings from the Aastra Web UI
1Select a line on which you want to set Call Forwarding.
2In the Mode field, select the mode you want to set on the line.
3In the Forward Number field, enter the call forward number for which you want your calls on this
line to be call forwarded.
4In the Number of Rings field, select the number of rings on the line before the call is forwarded.
Valid values are 1 to 9.
5Select Save Settings to save the Call Forward settings.
The changes are dynamic and are immediately applied to the phone.
2.11 Changing the Volume
To change the ringer volume setting, press the volume button when the phone is on-hook and idle.
2.12 Setting Do Not Disturb
The system administrator can set a softkey to “Do not Disturb” (DND).
To disable call forwarding in the Aastra Web UI, set the mode to OFF and remove the
phone number in the Number field.
To disable call forwarding in the Aastra Web UI, set the mode to OFF and remove the
phone number in the Forward Number field.
To force a line to use the global settings, set the Mode field to Global.

Aastra Model 9133i IP Phone Features
18 Copyright © 2009 ADTRAN, Inc. 619500103-1A
If DND is set on a softkey, the key switches DND ON and OFF. If the phone shares a line with other
phones, only the phone that has DND configured is affected.
The second line on the menu of the IP phone shows when DND is configured. When a call comes in on the
line, the caller hears a busy signal or recorded message, depending on the server configuration.
2.13 Selecting a Ring Tone
You can configure ring tones and ring tone sets on the IP phone. There are several distinct ring tones that a
user can select from to set on the IP phones. You can enable and disable these ring tones on a global or per-
line basis.
The following table identifies the valid settings and default values for each type of configuration method.
To configure a ring tone using the IP Phone UI
1Press Options on the phone to enter the Options List.
2Select Tones.
3Select Set Ring Tone.
4Select the type of ring tone (Tone 1 through Tone 5, or Silent).
Table 1. Ring tone settings table
Configuration Method Valid Values Default Value
IP Phone UI Global:
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Silent
Global:
Tone 1
Aastra Web UI Global:
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Silent
Per-Line:
Global
Tone 1
Tone 2
Tone 3
Tone 4
Tone 5
Silent
Global:
Tone 1
Per-Line:
Global

Aastra Model 9133i IP Phone Features
619500103-1A Copyright © 2009 ADTRAN, Inc. 19
5Select Set and then Select Next.
6Select Tone Set.
7Select the country for which you want to apply the tone set.
Valid values are Australia, Europe, France, Germany, Italy, UK, and US. The default is US.
8Select Set.
The ring tone and tone set you select is immediately applied to the IP phone.
To configure a ring tone using the Aastra Web UI, global configuration
1Select Basic Settings > Preferences > Ring Tones.
2In the Ring Tones section, select a country from the “Tone Set” field.
Refer to the Ring Tone Settings Table for valid values.
3Select Save Settings to save your settings.
These changes are not dynamic. You must restart your IP phone for the changes to take affect.
4Select Operation > Reset.
In the Restart Phone field, select Restart to restart the IP phone and apply the ring tone.
To configure a ring tone using the Aastra Web UI, per-line configuration
1Select Basic Settings > Preferences > Ring Tones.
2In the Ring Tones section, select a line for which you want to set a ring tone.
3Select a value from the “LineN” field.
4Select Save Settings to save your settings.
These changes are not dynamic. You must restart your IP phone for the changes to take affect.
5Select Operation > Reset.
In the Restart Phone field, select Restart to restart the IP phone and apply the ring tone.
2.14 Listing Calls
The IP phones have a “Callers List” feature that stores the name, phone number, and incremental calls, for
each call received by the phone.
You can view, scroll, and delete line items in the Callers List using the IP phone UI. You can also directly
dial from a displayed line item in the Callers List. You can download the Callers List to your desktop for
viewing using the Aastra Web UI.
When you download the Callers List, the phone stores the callerlist.csv file to your computer in comma-
separated value format. Use any spreadsheet to open and view the file. The file displays the name, phone
number, and the line on which the call was received.

Aastra Model 9133i IP Phone Features
20 Copyright © 2009 ADTRAN, Inc. 619500103-1A
To use the Callers List from the IP phone
1Press Services on the phone to display the Services menu.
2From the Services menu, select Callers List.
3Use the up/down arrows to scroll through the line items in the Callers List.
4If you want to dial the entry displayed in the Callers List, pick up the handset, press the handsfree key,
or press a line key.
To delete a Callers List line item
1Select the line item that you want to delete.
2Press the Delete softkey.
To save a line item to a programmable key for speed dialing
1Press the Save softkey.
2Enter the line number at the Save to? prompt that is already configured for speed dialing at the
softkey.
To exit the Callers List
• Press the Services key.
2.15 Speed Dialing
The system administrator might also have set up custom softkeys as speed dials. Speed dial softkeys can
dial a star code for a feature on the system or a phone number or a set of digits. A customized label displays
inside the phone’s display for each softkey. If you press a custom softkey, the phone goes off-hook and
dials the star code or the number set up for this softkey.
2.16 Accessing Voicemail
The voicemail feature on the 9133i IP phone allows you to use a line, configured with a phone number for
dialing out, to connect to a voicemail server. For each assigned voicemail number, there can be a minimum
of 0 or a maximum of 1 voicemail access phone number.
To the left of a line item, a telephone icon displays with the handset ON or OFF the receiver.
The ON receiver indicates the call came in as a missed call. The OFF receiver indicates the
call came in and was answered.
