Advanced 56000-005ADV User manual

4 1
ADVANCED FIRE SYSTEMS INC.
100 South Street • Hopkinton, MA 01748
Telephone: [phone]
www.afsi.us.com
56000-005ADV
Dual Action Addressable
Manual Polycarbonate Pull Station
Installation Instructions
The Dual Action Polycarbonate Addressable Manual Pull Station may be ush
mounted on a single gang electrical box, or it may be surface mounted using the
Pull Station Polycarbonate Back Box (56000-006, sold separately). Be sure to follow
local codes and regulations. To comply with ADA standards, the Pull Station must be
connected less than 48 inches above oor level for front wheelchair access, and less
than 54 inches for side wheel chair access.
Control Panel Compatibility
Compatibility Identier number: 56000-005ADV. The module has been approved
by Underwriters Laboratories Inc. The pull station is compatible with Advanced Fire
Systems Inc's AX Series re control panels. Contact Advanced Fire Systems Inc or refer
to the Fire Alarm Control Unit's installation manual for more details.
Set the address using the DIP switches in accordance with the address table overleaf.
Open the Pull Station using the included key, turning the key to the right and allowing
the Pull Station to open out.
With the Pull Station open, carefully undo the clear protective cover to the circuit
board area. The cover should open out, hinging from the bottom, closest to the
alarm switch. If the clear protective cover comes off completely, replace the cover
by making sure that the protruding pivot points are positioned down, toward the
alarm switch, and aligned with the corresponding slots.
Program the address of the station using the DIP switches under the clear protective
cover. When address programming is completed, apply equal pressure over the
upper tabs of the cover until it snaps into place and is secure.
See Fig 1 for wiring options.
If using the Pull Station Polycarbonate Back Box (56000-006), attach to the wall
using four #8 screws that are appropriate for the wall type or anchor. Verify that the
orientation of the box is as shown in Figure 1 on the following page, with the arrows
inside the box pointing UP. Connect the ½ NPT conduit to the top or bottom of the
box and run the wiring as required by the application. Make sure that the wires at the
back of the pull station are not pinched by the electrical box during installation.
Close and lock the station using the key provided. Test the station as required by the
local code and the particular installation.
Reset the station by opening and closing it.
APD0519 A130107
Analog Value
AV=4: Trouble
AV=16 Normal
AV=64: Alarm State
Unit generates priority interrupt.
Technical Data
Operating voltage 17-28V DC
UL listed to operate 20-28V DC
Current Consumption at 24V
Stand by current 200µA
LED Operated Alarm current 3.6mA + Quiescent
Output Bit Function Input Bit Function
2LED 1 = On
0 = Off
2LED Conrmed 1 = On
0 = Off
1TEST 1 = On
0 = Off
1 1 in normal state
0 in alarm state
0Not Used 0 0 in normal state
1 in alarm state

2 3
DIP switch DIP switch DIP switch DIP switch DIP switch
setting setting setting setting setting
addr 1234567 addr 1234567 addr 1234567 addr 1234567 addr 1234567
1 1000000 11 1101000 21 1010100 31 1111100 41 1001010
2 0100000 12 0011000 22 0110100 32 0000010 42 0101010
3 1100000 13 1011000 23 1110100 33 1000010 43 1101010
4 0010000 14 0111000 24 0001100 34 0100010 44 0011010
5 1010000 15 1111000 25 1001100 35 1100010 45 1011010
6 0110000 16 0000100 26 0101100 36 0010010 46 0111010
7 1110000 17 1000100 27 1101100 37 1010010 47 1111010
8 0001000 18 0100100 28 0011100 38 0110010 48 0000110
9 1001000 19 1100100 29 1011100 39 1110010 49 1000110
10 0101000 20 0010100 30 0111100 40 0001010 50 0100110
51 1100110 61 1011110 71 1110001 81 1000101 91 1101101
52 0010110 62 0111110 72 0001001 82 0100101 92 0011101
53 1010110 63 1111110 73 1001001 83 1100101 93 1011101
54 0110110 64 0000001 74 0101001 84 0010101 94 0111101
55 1110110 65 1000001 75 1101001 85 1010101 95 1111101
56 0001110 66 0100001 76 0011001 86 0110101 96 0000011
57 1001110 67 1100001 77 1011001 87 1110101 97 1000011
58 0101110 68 0010001 78 0111001 88 0001101 98 0100011
59 1101110 69 1010001 79 1111001 89 1001101 99 1100011
60 0011110 70 0110001 80 0000101 90 0101101 100 0010011
101 1010011 106 0101011 111 1111011 116 0010111 121 1001111
102 0110011 107 1101011 112 0000111 117 1010111 122 0101111
103 1110011 108 0011011 113 1000111 118 0110111 123 1101111
104 0001011 109 1011011 114 0100111 119 1110111 124 0011111
105 1001011 110 0111011 115 1100111 120 0001111 125 1011111
126 0 111111
Address Setting
The address of the Pull Station is set using the seven segments of the DIP switch. Each
segment of the switch must be set to “0” or “1”, using a small screwdriver or similar
tool. A complete list of address settings is shown below.
Fig 1 – Connections to the Terminals.
The Pull Station has one status LED:
Red Indicates alarm condition, ashing when polled is controlled by panel.
1234567
ON
0101110
Address 78 =
Example:
ON = 0
©Apollo Fire Detectors Limited 2011/EKC
Wiring options for the Pull Station
L1 - L2 +
Pull Station
Back Box,
56000-006
(sold separately)
Remove clear protective DIP Switch
cover to set pull station address
