Advantech UNO-1251G User manual

User Manual
UNO-1251G
Windows Embedded Compact7
Software Manual

UNO-1251G Software User Manual for WEC7 ii
Copyright
The documentation and the software included with this product are copyrighted 2016
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2003W25130 Edition 1
Printed in Taiwan August 2016

iii UNO-1251G Software User Manual for WEC7
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Technical Support and Assistance
1. Visit the Advantech web site at http://support.advantech.com where you can
find the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages

UNO-1251G Software User Manual for WEC7 iv

v UNO-1251G Software User Manual for WEC7
Contents
Chapter 1 Advanced Applications.......................1
1.1 Networking ............................................................................................... 2
Figure 1.1 Network and Dial-up Connections .............................. 2
Figure 1.2 Selected Connection .................................................. 2
Figure 1.3 Setting IP Address...................................................... 2
1.2 Remote Access Server Configuration ....................................................... 3
Figure 1.4 Network and Dial-up Connections .............................. 3
Figure 1.5 Selected Make New Connection ................................ 3
Figure 1.6 Make New Connection ............................................... 3
Figure 1.7 Selected a Modem...................................................... 4
Figure 1.8 Enter the Telephone Number ..................................... 4
Figure 1.9 Dial-up Connection ..................................................... 5
Figure 1.10Dialing Properties ....................................................... 5
Figure 1.11Dialing Patterns .......................................................... 6
Figure 1.12Status of My Connection ............................................ 6
Figure 1.13Selected Control Panel............................................... 7
Figure 1.14Selected RAS Server.................................................. 7
Figure 1.15 Advantech RAS Server Configuration (General) ....... 7
Figure 1.16Advantech RAS Devices ............................................ 8
Figure 1.17Advantech RAS Server Configuration (Logon Security)
8
Figure 1.18Advantech RAS Server Configuration (Users) ........... 9
Figure 1.19Save Registry Setting ................................................. 9
1.3 Auto-run Configuration ............................................................................ 10
Figure 1.20Selected Configuration Utility ................................... 10
Figure 1.21 Advantech Configurator (Misc) ................................ 10
Figure 1.22Select the Program................................................... 11
Figure 1.23Add Program Success.............................................. 11
1.4 Application Development Procedure....................................................... 12
1.4.1 Application Development Procedure........................................... 12
Figure 1.24New Project in Visual Studio .................................... 12
Figure 1.25Selected SDK for UNO-1251G ................................. 13
Figure 1.26Select Build Solution................................................. 13
1.4.2 Watchdog Timer.......................................................................... 14
1.5 Saving Your Settings............................................................................... 19
Figure 1.27 Select Registry Saver .............................................. 19
Figure 1.28Registry saved successfully ..................................... 19
1.6 Create SD Card for booting..................................................................... 20
1.7 Updating Image & Bootloader ................................................................. 23
Figure 1.29Update MLO/ EBOOTSD.nb0................................... 23
Figure 1.30Update NK.nbl .......................................................... 23
Figure 1.31My Device in UNO-1251G ........................................ 24
Figure 1.32Delete Documents and Settings in HardDisk ........... 25
1.8 UNO-1251G Network Administration User Guide ................................... 25
1.8.1 Network Administration ............................................................... 25
Figure 1.33 Windows CE Remote Management Tool ................ 26
Figure 1.34Password Properties in Windows CE ....................... 26
Figure 1.35 Gateway Resetting .................................................. 27
1.8.2 Network Setting........................................................................... 28
Figure 1.36Remote Admin.......................................................... 28
Figure 1.37System Properties in Windows CE........................... 28
Figure 1.38Windows CE Remote Management ......................... 29
1.8.3 Add/Del Network Adapter ........................................................... 29
Figure 1.39 The Add/Del Network Adapter................................. 29

UNO-1251G Software User Manual for WEC7 vi
1.8.4 SMB Server Statistics ................................................................. 29
Figure 1.40The SMB Server Statistics ....................................... 29
1.8.5 Configure FTP Server................................................................. 30
Figure 1.41The FTP Server........................................................ 30
Figure 1.42 The FTP Server Virtual Roots ................................. 31
Figure 1.43FTP Users ................................................................ 31
1.8.6 Telnet Server .............................................................................. 32
Figure 1.44Telnet Server............................................................ 32
1.8.7 Security....................................................................................... 33
Figure 1.45Add/Modify Users ..................................................... 33
Figure 1.46Add/Modify Shares ................................................... 33
1.8.8 Printer ......................................................................................... 33
Figure 1.47 Add/Modify Printer................................................... 33

Chapter 1
1Advanced
Applications
This Chapter will provide detailed
explanations of the UNO-1251G’s
Advanced Applications
Sections include:
Networking
ActiveSync Connection
Remote Access Configuration
Autorun Configuration
Application Development Proce-
dure
Saving Your Settings
Create SD Card for booting
Updating Image and Bootloader
Network Administration User
Guide

UNO-1251G Software User Manual for WEC7 2
1.1 Networking
This section shows how to re-configure the IP of the UNO-1251G to meet your net-
work configuration. The procedure is listed below step by step.
1. Press Start in the task bar of Windows and select Setting / Networking and
Dial-up Connections.
Figure 1.1 Network and Dial-up Connections
2. A window that shows all available connections will pop up. Double click the icon
that has the connection you want to configure. For example, double click
DM9CE1 icon to configure.
Figure 1.2 Selected Connection
3. Select the IP Address tab.
The default IP address for EMAC1 (LAN1) is: 10.0.0.1 / DM9CE1 (LAN2) is:
10.0.0.2 and the default Subnet mask is: 255.255.255.0. So you can set your
computer IP address to 10.0.0.3 and set the Subnet mask to 255.255.255.0.
Figure 1.3 Setting IP Address

3 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
1.2 Remote Access Server Configuration
UNO-1251G provides “Remote Access Services” which offer the possibilities for
remote networks and users to have TCP/IP access to local mail servers, access to a
database, web servers or other Intranet services.
The following description introduces how to set the dial-up and dial-in configuration.
Dial-up Configuration
1. Press Start in task bar and select Settings / Networking and Dial-up Connec-
tions.
Figure 1.4 Network and Dial-up Connections
2. Double click Make New Connection and then a dialog window will pop out.
Figure 1.5 Selected Make New Connection
3. Select Dial-Up Connection and press Next >.
Figure 1.6 Make New Connection

UNO-1251G Software User Manual for WEC7 4
4. Setup the device according to the specification of the modem and press Next >.
Figure 1.7 Selected a Modem
5. Enter the telephone number in the “Phone Number” window. Click the Finish
button to complete the dial-up configuration.
Figure 1.8 Enter the Telephone Number

5 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
6. Press Start in the task bar and select Settings / Networking and Dial-up Con-
nections. Double click the new connection that you made previously (it is My
Connection in this case), and it will pop up the Dial-Up Connection dialog box.
Enter your user name / password and then press Dial Properties.
Figure 1.9 Dial-up Connection
Figure 1.10 Dialing Properties

UNO-1251G Software User Manual for WEC7 6
7. Press Dialing Patterns button in the Dialing Properties window.
Edit the dialing pattern for each type of call to change how the phone is dialed.
Figure 1.11 Dialing Patterns
8. Double click My Connection Status and press Connection button to build a
PPP connection.
Figure 1.12 Status of My Connection
Note! Country/Region Code, please enter “E” or “e”
Area Code, please enter “F” or “f”
Number, please enter “G” or “g”

7 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
Dial-in Configuration
1. Press Start in the task bar and select Setting / Control Panel.
Figure 1.13 Selected Control Panel
2. Double click the RAS Server icon in Control Panel.
Figure 1.14 Selected RAS Server
3. Select the General tab in the Advantech RAS Server Configuration box.
Select Enable RAS, Use Static IP Address and enter a specified IP in Static IP
Address blank.
Figure 1.15 Advantech RAS Server Configuration (General)

UNO-1251G Software User Manual for WEC7 8
4. Select the Input Lines tab in the Advantech RAS Server Configuration box.
Click Add button to setup the input line according to the available RAS device.
Figure 1.16 Advantech RAS Devices
5. Select the Logon Security tab in the Advantech RAS Server Configuration
box. Select security protocol if necessary.
Figure 1.17 Advantech RAS Server Configuration (Logon Security)

9 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
6. Select the Users tab to add a new account for remote access services.
Figure 1.18 Advantech RAS Server Configuration (Users)
7. After all settings are completed, press OK button and then it will pop up the
RasConfig dialog window. Press Yes button to save the registry setting to the
storage card.
Figure 1.19 Save Registry Setting
RAS configuration procedure is complete and you can access UNO-1251G via a
remote device.

UNO-1251G Software User Manual for WEC7 10
1.3 Auto-run Configuration
This document introduces how to execute applications automatically when you boot
UNO-1251G up.
Auto-run Configuration Procedure
1. Press Start on the task bar and select Programs / Advantech / Configuration
Utility.
Figure 1.20 Selected Configuration Utility
2. Go to the Misc tab in Advantech Configurator dialog box.
Figure 1.21 Advantech Configurator (Misc)

11 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
3. Click on the Add button to set the program for Auto-Run action. Click on the
Program Path button for selecting the program for Auto-Run setting.
Figure 1.22 Select the Program
Please choose the program then press OK.
4. The program and its path will show the below dialog window.
Figure 1.23 Add Program Success
The Configuration Utility will add the selected program in Auto-Run. Press OK to fin-
ish the configuration.

UNO-1251G Software User Manual for WEC7 12
1.4 Application Development Procedure
UNO-1251G provides Software Development Kit (SDK) and a built-in runtime library;
you can use your existing Windows-based programming skills to develop applica-
tions easily and rapidly through those tools. This document introduces how to
develop custom applications step by step.
1.4.1 Application Development Procedure
1. Install Microsoft Visual Studio 2008
The Microsoft Visual Studio 2008 tool is a desktop development environment for
creating applications and system components for Windows CE.NET-powered
devices. This version features new capabilities such as C++ exception handling,
Run Time Type Information (RTTI), and a plethora of new debugger functional-
ities. Before you begin to develop your application, you must install Microsoft
Visual Studio 2008 first.
2. Insert UNO-1251G SD card into the USB slot in the host PC.
3. Install UNO-1251G Software Development Kit for Visual Studio 2008 from the
below path:
C:\Program Files\Windows CE Tools\SDK
4. Execute Microsoft Visual Studio 2008
5. Select “File” / “New” to open a new project. Select your project type and enter
the new project name / location in the window. Please note that the CPU type
must be Win32 (WCE ARMV4I).
Figure 1.24 New Project in Visual Studio

13 UNO-1251G Software User Manual for WEC7
Chapter 1 Advanced Applications
6. Select “UNO-1251G” in the main window of Visual Studio.
Figure 1.25 Selected SDK for UNO-1251G
7. After you complete the above configuration procedure, you can start to develop
your application. Press Build/ Build Solution to compile your program to an
.exe file and download it to UNO-1251G.
Figure 1.26 Select Build Solution

UNO-1251G Software User Manual for WEC7 14
1.4.2 Watchdog Timer
There is a built-in watchdog timer in UNO-1251G. Users can utilize the WDT driver
with standard WIN32 API to implement the watchdog function in their applications. To
use the watchdog driver, firstly users must open “WDT1:”, then use the DeviceIO-
Control function to access the watchdog hardware. The introduction below includes
the definition of DeviceIOControl and its parameters as well as an example.
How to Use the Control Code
There are 9 control codes for the operation codes in the WDT driver.
1. IOCTL _WDT_ENABLE:
Enable the Watchdog timer on your application. By default, if the Watchdog timer is
enabled, the WDT driver will automatically reload the timeout counter after a speci-
fied period and your application does not need to trigger the strobe periodically for
masking the timeout, unless use IOCTL_WDT_REBOOT timeout to stop this auto-
matic strobe triggering.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
2. IOCTL _WDT_DISABLE:
Disable the Watchdog timer on your application.
lpInBuffer: unsed.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
3. IOCTL_WDT_STROBE:
Trigger strobe signal to reload watchdog timeout counter. If your application uses
IOCTL_WDT_ENABLE to enable the Watchdog first and then sends
IOCTL_WDT_REBOOT to the WDT driver, your application must trigger the Watch-
dog once during the Watchdog timer period. If your application has not triggered at
the specified period, the device will re-boot automatically.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: unused.
nOutBufferSize: unused.
4. IOCTL_WDT_GET_TIMEOUT:
Get the Watchdog timeout value.
lpInBuffer: unused.
nInBufferSize: unused.
lpOutBuffer: The DWORD pointer to your Watchdog timeout setting. The Watchdog
timeout setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means
10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds, 6
means 60 seconds, 7 means 120 seconds,8 means 300 seconds, 9 means 600 sec-
