Advantech PCI-1710 User manual

PCI-1710/1710HG
Multifunction DAS Card for
PCI Bus
User's manual

Copyright
This documentation and the software included with this product are
copyrighted 1998 by Advantech Co., Ltd. All rights are reserved.
Advantech Co., Ltd. reserves the right to make improvements in the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of Advantech Co., Ltd. Information provided in this manual
is intended to be accurate and reliable. However,Advantech Co., Ltd.
assumes no responsibility for its use, nor for any infringements of the
rights of third parties which may result from its use.
Acknowledgments
PC-LabCard is a trademark of Advantech Co., Ltd. IBM and PC are
trademarks of International Business Machines Corporation. MS-DOS
and Windows are trademarks of Microsoft Corporation. Intel and
Pentium are trademarks of Intel Corporation.
CE notification
ThePCI-1710/1710HG,developedbyADVANTECHCO., LTD., has
passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded
cables. This kind of cable is available from Advantech. Please contact
your local supplier for ordering information.
On-line Technical Support
For technical support and service please visit our support website at
http:/support.advantech.com
Part No. 2003171010 2nd Edition
Printed in Taiwan Feburary 1999

Contents
Chapter 1: General Information ............................. 1
1.1 Introduction ............................................................... 2
1.2 Features .................................................................... 3
1.3 Specifications............................................................. 4
1.4 BlockDiagram........................................................... 8
Chapter 2: Installation.............................................. 9
2.1 InitialInspection ....................................................... 10
2.2 Unpacking ............................................................... 10
2.3 InstallationInstructions ............................................. 11
Chapter 3: Signal Connections.............................. 13
3.1 Overview................................................................. 15
3.2 I/OConnector ......................................................... 15
3.3 AnalogInputConnections ........................................ 19
3.4 AnalogOutputConnections ..................................... 23
3.5 TriggerSourceConnections ..................................... 25
3.6 FieldWiringConsiderations...................................... 25
Chapter 4: Register Structure and Format ......... 27
4.1 Overview................................................................. 28
4.2 I/O Port Address Map............................................. 28
4.3 Channel NumberandA/DData ............................... 33
4.4 SoftwareA/DTrigger............................................... 33
4.5 A/DChannelRangeSetting ...................................... 34
4.6 MUX Control .......................................................... 37

4.7 ControlRegister....................................................... 39
4.8 Status Register ......................................................... 40
4.9 ClearInterrupt andFIFO......................................... 41
4.10 D/AChannel0Output ............................................. 42
4.11 D/AChannel1Output ............................................. 42
4.12 D/AReferenceControl ............................................ 43
4.13 DigitalI/ORegisters ................................................. 44
4.14 ProgrammableTimer/CounterRegisters .................... 44
Chapter 5: Calibration............................................ 45
5.1 Introduction ............................................................. 46
5.2 VRAssignment ........................................................ 46
5.3 A/DCalibration ....................................................... 47
5.4 D/ACalibration ....................................................... 48
5.5 SelfA/DCalibration................................................. 49
Appendix A: 82C54 Counter Chip Functions ......51
A.1 TheIntel 82C54 ...................................................... 52
A.2 CounterRead/WriteandControlRegisters ............... 53
A.3 CounterOperatingModes ....................................... 56
A.4 CounterOperations ................................................. 58

Chapter 1 General Information 1
1
General Information
CHAPTER

2PCI-1710 /1710HG User's Manual
1.1 Introduction
The PCI-1710/1710HG is a multifunction DAS card for the PCI bus.
Advanced circuit design brings you higher quality and more func-
tions, including the five most desired measurement and control
functions: 12-bit A/D conversion, D/A conversion, digital input,
digital output, and counter/timer.
PCI-bus Plug and Play
The PCI-1710/1710HG uses a PCI controller to interface the card with
the PCI bus. The controller fully implements the PCI bus specifica-
tion Rev 2.1. All bus relative configurations, such as base address
and interrupt assignment, are automatically controlled by software.
No jumper or DIP switch setting is required for user configuration.
Flexible Inputs Types and Ranges Setting
The PCI-1710/1710HG features an automatic channel/gain scanning
circuit. The circuit, rather than your software, controls multiplexer
switching during sampling. The on-board SRAM stores different gain
values and configuration for each channel. This design lets you
perform multi-channel high-speed sampling (up to 100 kHz) with
different gains for each channel with free combination of single-ended
and differential inputs.
On-board FIFO (First In First Out) Memory
The PCI-1710/1710HG has an on-board FIFO buffer which can store
up to 4K A/D samples. The PCI-1710/1710HG generates an interrupt
when the FIFO is half full. This feature provides continuous high-
speed data transfer and more predictable performance on Windows
systems.

Chapter 1 General Information 3
On-board Programmable Counter
The PCI-1710/1710HG provides a programmable counter for generat-
ing a pacer trigger for the A/D conversion. The counter chip is an
82C54 or equivalent, which includes three 16-bit counters on a 10
MHz clock. One counter is used as an event counter for counting
events coming from the input channels. The other two are cascaded
together to make a 32-bit timer for a pacer trigger.
1.2 Features
• 16 single-ended or 8 differential analog inputs, or a combination
• 12-bit A/D converter, with up to 100 kHz sampling rate
• Programmable gain for each input channel
• Automatic channel/gain scanning
• On-board 4K samples FIFO buffer
• Two 12-bit analog output channels
• 16 digital inputs and 16 digital outputs
• Programmable pacer/counter

4PCI-1710 /1710HG User's Manual
1.3 Specifications
Analog Input:
•Channels: 16 single-ended or 8 differential (software programma-
ble)
•Resolution: 12-bit
•On-board FIFO: 4K samples
•Conversion time: 8 µs
•Inputrange:(V, software programmable)
•Maximum Input Overvoltage: ±30V
•CommonModeRejection Ratio (CMRR)
PCI-1710 PCI-1710HG
Bipolar ±10, ±5, ±2.5, ±1.25,
±0.625 ±10, ±5, ±1, ±0.5, ±0.1, ±0.05, ±0.01, ±0.005
Unipolar 0 ~ 10, 0 ~ 5, 0 ~ 2.5,
0 ~ 1.25 0 ~ 10, 0 ~ 1, 0 ~ 0.1, 0 ~ 0.01
PCI-1710 PCI-1710HG
Gain CMRR Gain CMRR
0.5, 1 75dB 0.5, 1 75dB
2 80dB 10 90dB
4 84dB 100 106dB
8 84dB 1000 106dB

Chapter 1 General Information 5
•Maximumdatathroughput:
PCI-1710: 100 kHz
PCI-1710HG: (variable, depending on PGIA settling time)
PCI-1710HG
Gain Speed
0.5, 1 100 kHz
5, 10 35 kHz
50, 100 7 kHz
500, 1000 770 Hz
PCI-1710 PCI-1710HG
Gain Accuracy Gain Accuracy Remark
0.5, 1 0.01% of
FSR ±1 LSB 0.5, 1 0.01% of FSR ±1 LSB S.E./D*
20.02% of
FSR ±1 LSB 5, 10 0.02% of FSR ±1 LSB S.E./D
40.02% of
FSR ±1 LSB 50, 100 0.04% of FSR ±1 LSB D
80.04% of
FSR ±1 LSB 500, 1000 0.08% of FSR ±1 LSB D
•Accuracy: (depending on gain)
*S.E. = Single-ended D = Differential
•Linearity error: ±1 LSB
•Inputimpedance:1 GΩ
•Trigger mode: Software, on-board programmable pacer or external

6PCI-1710 /1710HG User's Manual
Analog Output:
•Channels:2
•Resolution: 12-bit
•Relative accuracy: ±1/2 LSB
•Gain error: ±1 LSB
•Maximum update rate: 100 K samples/s
•Slew rate:10V/µs
•Outputrange: (softwareprogrammable)
With internal reference: 0 ~ +5V, 0 ~ +10V
With external reference: 0 ~ +xV @ -xV (-10 ≤ x ≤10)
Digital Input:
•Channels: 16
•Inputvoltage:
Low: 0.4V max.
High: 2.4V min.
•Inputload:
Low: -0.2 mA @ 0.4V
High: 20 µA @ 2.7V
Digital Output:
•Channels:16
•Outputvoltage:
Low: 0.4V max. @ 8.0 mA (sink)
High: 2.4V min. @ -0.4 mA (source)

Chapter 1 General Information 7
Programmable Timer/Counter
•Counter chip: 82C54 or equivalent
•Counters: 3 channels, 16 bits, 2 channels are permanently
configured as programmable pacers; 1 channel is free
for user application
•Input, gate: TTL/CMOS compatible
•Time base:
Channel 1:10 MHz
Channel 2:Takes input from output of channel 1
Channel 0:Internal 1 MHz or external clock (10 MHz max.)
selected by software.
General:
•I/O Connector: 68-pin SCSI-II female connector
•Power consumption: +5 V @ 850 mA (Typical),
+5 V @ 1.0 A (Max.)
•Dimensions: 175 mm x 107 mm (6.9” x 4.2”)
•Operating temperature: 0 ~ +60 °C (32 ~ 140 °F) ( refer to IEC 68-
2-1, 2 )
•Storage temperature: -20 ~ +70 °C (-4 ~ 158 °F)
•Operating humidity: 5 ~ 95%RH non-condensing ( refer to IEC 68-
2-3 )
•MTBF: over 64,770 hrs @ 25 °C, grounded, fixed environment

8PCI-1710 /1710HG User's Manual
1.4 Block Diagram
Figure1-1:PCI-1710/PCI-1710HGblockdiagram
PCI Controller
Address Decoder
16-bit Digital Output
16-bit Digital Input
12-bit D/A Output 0
12-bit D/A Output 1
Data Bus
PCIBus
A/D & D/A Status
Control Logic
4K Samples
FIFO
12-bit A/D
Convertor
IRQ Control
Logic
A/D Trigger
Logic
10 MHz
OSC
10 MHz/10=
1 MHz
PGIA
+
-
Gain Control RAM
Channel Scan Logic
Multiplexer
16 S/E
or
8 DIFF
COUNTER
2
COUNTER
1
COUNTER
0
AI15
AI0
AI1
EXT_TRG
CNT0_GATE
CNT0_OUT
CNT0_CLK
Address Bus
INT
PACER_OUT

Chapter 2 Installation 9
2
Installation
CHAPTER

10 PCI-1751/1710HG User's Manual
2.1 Initial Inspection
Before installing the PCI-1710/1710HG, check the card for visible
damage. We have carefully inspected the card both mechanically and
electrically before shipment. It should be free of marks and in perfect
order upon receipt.
As you unpack the PCI-1710/1710HG, check it for signs of shipping
damage (damaged box, scratches, dents, etc.). If it is damaged or fails
to meet specifications, notify our service department or your local
sales representative immediately. Also, call the carrier immediately and
retain the shipping carton and packing materials for inspection by the
carrier. We will then make arrangements to repair or replace the unit.
2.2 Unpacking
The PCI-1710/1710HG contains components that are sensitive and
vulnerable to static electricity. Discharge any static electricity on your
body to ground by touching the back of the system unit (grounded
metal) before you touch the board.
Removethe PCI-1710/1710HG card from its protective packagingby
grasping the card's rear panel. Handle the card only by its edges to
avoid static discharge which could damage its integrated circuits.
Keep the antistatic package. Whenever you remove the card from the
PC, protect the card by storing it in this package.
You should also avoid contact with materials that hold static electricity
such as plastic, vinyl and styrofoam.
Check the product contents inside the packing. There should be one
card, one CD-ROM, and this manual. Make sure nothing is missing.

Chapter 2 Installation 11
2.3 Installation Instructions
The PCI-1710/1710HG can be installed in any PCI slot in the
computer. However, refer to the computer user's manual to avoid any
mistakes and danger before you follow the installation procedure
below:
1. Turn off your computer and any accessories connected to the
computer.
Warning! TURNOFF yourcomputerpowersupply whenever
you install or remove any card, or connect and
disconnect cables.
2. Disconnect the power cord and any other cables from the back of
the computer.
3. Remove the cover of the computer.
4. Select an empty 5 V PCI slot. Remove the screw that secures the
expansion slot cover to the system unit. Save the screw to secure
the interface card retaining bracket.
5. Carefully grasp the upper edge of the PCI-1710/1710HG. Align the
hole in the retaining bracket with the hole on the expansion slot and
align the gold striped edge connector with the expansion slot socket.
Press the card into the socket gently but firmly. Make sure the card
fits the slot tightly.
6. Secure the PCI-1710/1710HG by screwing the mounting bracket to
the back panel of the computer.
7. Attach any accessories (68-pin cable, wiring terminal, etc.) to the
card.
8. Replace the cover of your computer. Connect the cables you
removed in step 2.
9. Turn the computer power on.

12 PCI-1751/1710HG User's Manual

Chapter 3 Signal Connections 13
3
Signal Connections
CHAPTER

14 PCI-1710/1710HG User's Manual
3.1 Overview
Correct signal connections are one of the most important factors in
ensuring that your application system is sending and receiving data
correctly. A good signal connection can avoid much unnecessary and
costly damage to your valuable PC and other hardware devices. This
chapter will provide some useful information about how to connect
input and output signals to the PCI-1710/1710HG card via the I/O
connector.
3.2 I/O Connector
The I/O connector for the PCI-1710/1710HG card has 68 pins that you
can connect to 68-pin accessories with the PCL-10168 shielded cable.
Note! ThePCL-10168 shieldedcableis speciallydesigned
forthe PCI-1710/1710HGforreducing noisein the
analog signal lines. Its wires are all twisted pairs,
and the analog lines and digital lines are seperately
shielded,providing minimalcross talk between
signals and the best protection against EMI/EMC
problems.
Pin Assignment
Figure 3-1 shows the pin assignments for the 68-pin I/O connector on
thePCI-1710/1710HGcard.

Chapter 3 Signal Connections 15
Figure3-1:I/Oconnectorpinassignmentsforthe PCI-1710/1710 HG card
AI0
AI2
AI4
AI6
AI8
AI10
AI12
AI14
AIGND
DA0_REF
DA0_OUT
AOGND
DI0
DI2
DI4
DI6
DI8
DI10
DI12
DI14
DGND
DO0
DO2
DO4
DO6
DO8
DO10
DO12
DO14
DGND
CNT0_CLK
CNT0_OUT
CNT0_GATE
+12V
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
AI1
AI3
AI5
AI7
AI9
AI11
AI13
AI15
AIGND
DA1_REF
DA1_OUT
AOGND
DI1
DI3
DI5
DI7
DI9
DI11
DI13
DI15
DGND
DO1
DO3
DO5
DO7
DO9
DO11
DO13
DO15
DGND
PACER_OUT
TRG_GATE
EXT_TRG
+5V

16 PCI-1710/1710HG User's Manual
I/O Connector Signal Descriptions
Signal
Name Reference Direction Description
AI<0…15> AIGND Input
Analog Input Channels 0 through 15. Each
channel pair, AI<i, i+1> (i = 0, 2, 4...14), canbe
configured as either two single-ended inputs or
one differential input.
AIGND - -
Analog Input Ground. These pins are the
reference points for single-ended
measurements and the bias current return point
for differential measurement. The three ground
references (AIGND, AOGND, and DGND) are
connected together on the PCI-1710/1710HG
card.
DA0_ REF AOGND Input Analog Output Channel 0 External Reference. This is the external reference input
for the analog output channel 0 circuitry.
DA1_ REF AOGND Input Analog Output Channel 1 External
Reference. This is the external reference input
for the analog output channel 1circuitry.
DA0 _OUT AOGND Output Analog Output Channel 0. This pin supplies
the voltage output of analog output channel 0.
DA1 _OUT AOGND Output Analog Output Channel 1. This pin supplies
the voltage output of analog output channel 1.
AOGND - -
Analog Output Ground. The analog output
voltages are referenced to these nodes. The
three ground references (AIGND, AOGND, and
DGND) are connected together on the PCI-
1710/1710HG card.
